Sony DCR-DVD110E Service Manual page 185

2-5-2. Adjusting Method
Order Adjustment item
1
Servo Param
2
Initialize
3 -RW Ref
4 -RW Self
5 -R Self
6 +RDL Self
7 Data Dump
8
Note: Before exiting the AUDIT, click the
DCR-DVD110E/DVD115E/DVD310E/DVD410E/DVD610/
DVD610E/DVD710/DVD710E/DVD810/DVD810E_ADJ
Message Disc
No Disc
DVD-RW
Reference + DOW
Disc
DVD-R Disc
for Self Jitter
DVD+RDL
Self Disc
No Disc
[SET]
button of "After completing the TEST" to cancel the TEST mode.
6-53
Operation
[START]
Click the button of "SERVO
Adjustment".
Set the DVD-RW Reference + DOW Disc, and
with the disc cover left open, click the
button in the message window.
(If the adjustment result of previous item is
OK, this item is executed successively.)
(If the adjustment result of previous item is
OK, this item is executed successively.)
Remove the DVD-RW Reference + DOW
Disc, and set the DVD-R Disc for Self Jitter,
and then close the disc cover and click the
[OK]
button in the message window.
Remove the DVD-R Disc for Self Jitter, and
set the DVD+RDL Self Disc, and then close
[OK]
the disc cover and click the
message window.
(If the adjustment result of previous item is
OK, this item is executed successively.)
Remove the DVD+RDL Self Disc.
(On the AUDIT screen, if the status lamps of
respective adjustment buttons are all lit in
green, the adjustment is over.)
[OK]
button in the
