This manual is for use with engines with the combustion bowl top pistons.
If your engine has fl a t top pistons or shallow, double recessed top pistons please contact us
for the applicable information
Worldwide Parts Source LLC, email: Parts@WwPartsSource.com
Worldwide Parts Source LLC
Phone: 269 673 2313
Email: Parts@WwPartsSource.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K3G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mitsubishi K3G

Summary of Contents for Mitsubishi K3G

  • Page 1 This manual is for use with engines with the combustion bowl top pistons. If your engine has fl a t top pistons or shallow, double recessed top pistons please contact us for the applicable information Worldwide Parts Source LLC, email: Parts@WwPartsSource.com Worldwide Parts Source LLC Phone: 269 673 2313 Email: Parts@WwPartsSource.com...
  • Page 2 Mitsubishi K3G Cylinder Head Gasket Installation Information with Head Bolt Torque Values and Sequence, With Valve Lash Settings . Mitsubishi K3G Cylinder Head Gasket Installation Information with Head Bolt Torque Values and Sequence, With Valve Lash Settings . Courtesy of Worldwide Parts Source LLC Source for hard to find engine gasket sets, pistons and rings sets, and engine overhaul kits.
  • Page 3 Worldwide Parts Source LLC - Source for hard to find gasket sets , engine overhaul kits and engine repair parts. Email: Parts@WwPartsSource.com Alternate email: wwparts@gmail.com Phone: 269 673 2313 Fax: 269 673 7226...
  • Page 4 Worldwide Parts Source LLC - Source for hard to find gasket sets , engine overhaul kits and engine repair parts. Email: Parts@WwPartsSource.com Alternate email: wwparts@gmail.com Phone: 269 673 2313 Fax: 269 673 7226...
  • Page 5 0·02 0·02 SECTIONAL VIEWS OF ENGINE ®--t==+-*---= ® Longitudinal Sectional View of K3 Engine Water outlet fitting Fan belt Rocker shaft ® Thermostat Crankshaft pulley Cylinder head Thermostat fitting Crankshaft Cylinder block Inlet valve Gear case Push rod ® Cl}) Oil pan Tappet Cooling fan...
  • Page 8 0·04 SPECIFICATIONS 0·04 � ..4-cyc le, water - cooled, Type vertical diesel engine 1 - 3 - 2 Firing order General Compression ratio Combustion chamber Direct injection Engine weight Number of cylinders 82 X 78 Cylinder Bore x Stroke (mm) Total displacement 1.236 Liters...
