NC-link NC-AP212 User Manual page 2

1 s t ： P o r t C o n n e c t i o n a n d p o w e r s u p p l y
I n s t r u c t i o n o f d i f f e r e n t p o r t ：
1) Please use a power supply of 12V DC adapter or 24V POE adapter, WAN / LAN port is the PoE Port.
Pls make sure the CPE's power supply is normal in reset process, or the CPE will be
damaged and can't reboot
Pay Attention
2) Reset:
There are two ways to reset the CPE:
a).CPE Manage page: Click "Management", then "Save/Reload Settings", then click"Reset Settings"to finish the CPE
Reset
b) Press the Reset Button on CPE more than 15 seconds,
settings
3) The connection way of CPE, PoE Adapter and PC:
P1 CPE Port Connection
then release, the device will reboot and restore to factory
