NC-link NC-AP212 User Manual page 18

VAP Interface is Enable, then CPE will open the Wi-Fi

SSID means Service Set Identifier (Your Wi-Fi name).

Broadcast SSID: Enable, SSID is visible; Disable: SSID is hidden, the

user can't scan the SSID if hide, have to input it by manual.
Encryption: Support None, WPA, WPA2, WPAPSK/WPA2, recommend

TKIP/AES mode
There is no need to set Channel in Bridge Mode here, because
the CPE's channel will keep it same with WLAN and AP's
Channel in Bridge Mode
Instruction
f) Advanced Settings
Click "Advanced
Advanced"
Country Region: set it of your country or region

RF Output Power: 100%, 75%, 50%, 25%, 12.5%

MAX user: limit the number of connect client

Sensitivity threshold: limit the weak signal client to connect

Other advanced Setting: Professional installation or maintenance

person can set it accordingly. General, keep it default. Click Apply after
setting
Settings" → "5.8GHz
P16 Advanced Settings
17
Repeater" → "5.8GHz
www.nc-link.cn
