- Page 1 USERS MANUAL Turbo WOOD LATHE Model: T-40...
-
Page 3: Table Of Contents
Table of Contents GENERAL SAFETY RULES ................1 Wood Lathe Introductions ................2 Features ......................2 Product Components ..................3 Wood Lathe Specifications ................4 Accessories ...................... 5 Power Supply ....................6 Assembling and Adjustment ................6 Base ......................6 Unpacking .................... -
Page 5: General Safety Rules
When turning a large wood piece, the turner should not stand close to the lathe to avoid being struck by a wood piece ejected by an imbalance. Hold the tool handle firmly to avoid the rebound Turbo T-40 Wood Lathe... -
Page 6: Wood Lathe Introductions
After developing the Harvey Turbo T-50/60 heavy duty woodworking lathes, the Harvey team then spent over two years working to develop a smaller lathe ideally sized to suit the demands of serious hobbyists and home workshops. Now we are glad to announce that our efforts have been achieved: the Turbo T-40 Lathe is the result. -
Page 7: Product Components
Tool Rest Lock Handle Spindle Tool Slide Lock Handle 3″Face Plate Tool Rest Spur Center Head Stock Lock Handle Live Center Pulley Cover Tail Stock Quill Motor Mount Handle Tail Stock Quill Lock Handle Motor Lock Handle Turbo T-40 Wood Lathe... -
Page 8: Wood Lathe Specifications
MT2# Through hole diameter 3/8” Tail Stock Travel 4-1/4” Accessories Tool Rest Width 12” Face Plate Dia. 3″ Spur Center Taper MT2# Dead Center Taper MT2# Motor Data Motor Servo Motor Power Power Supply 200-230VAC、Single Phase、50/60Hz Turbo T-40 Wood Lathe... -
Page 9: Accessories
Spindle Position Bar 1piece 50# Spanner 1piece Live Center 1piece 3mm Hex Key 1piece Knockout Rod 1piece Live Center Position Bar 1piece 19# One Head Spanner 1piece Optional Accessories Please visit Harvey official website for more information www.harveymachinery.com Turbo T-40 Wood Lathe... -
Page 10: Power Supply
If you have found any damage, please contact your local dealer immediately. Please verify that all parts listed underneath are included. Please contact your local dealer if any item is missing. Please read the user manual carefully before operating. Turbo T-40 Wood Lathe... -
Page 11: Packing List
Main Body (Including: Bed, Head Stock, Tail Stock, Tool Slide and Tool Rest) User Manual Knockout Rod 50# Spanner Spindle Pin Live Center Pin Live Center Spur Center 3mm Long Hex Key with Ball Head 19# Spanner 3″Face Plate Turbo T-40 Wood Lathe... -
Page 12: Operating
Stop: turn the switch C to position 0 or press red button A (if the lathe has been stopped by pressing button please follow procedure1 to restart). 4. Speed Adjustment Knob: Change the spindle speed by turning this knob. Figure 3 Turbo T-40 Wood Lathe... -
Page 13: Speed Range Adjustment
Wood Piece Dia. Rough Turning Normal Turning Sanding ＜ 2” 1600rpm 3500rpm 4300rpm 2-4” 800rpm 1600rpm 2500rpm 4-6” 500rpm 1100rpm 1700rpm 6-8” 400rpm 800rpm 1250rpm 8-10” 300rpm 700rpm 1000rpm 10-12” 250rpm 550rpm 900rpm 12-14” 200rpm 450rpm 680rpm Turbo T-40 Wood Lathe... -
Page 14: Tool Slide
Notice: the electrical supply must be disconnected before swiveling the Head Stock! When repositioning the Head Stock back to 0°, use the bed as reference, turn the Head Stock anticlockwise firmly, and then tighten the Head Stock Lock Handle! Figure 5 Turbo T-40 Wood Lathe... -
Page 15: Tail Stock
2. Dismounting the Live Center: Loosen the Tail Stock Quill Lock Handle, rotate the Tail Stock Hand Wheel anticlockwise until the Live Center is ejected from the Tail Stock Quill, pull out the Live Center by hand. Turbo T-40 Wood Lathe... -
Page 16: General Maintenance
Clean and apply a coat of wax on the Spindle, Tail Stock Quill and bed Monthly: Check the belt tension Change for wear on the belt Clean the dust from the belt Check the stability of the lathe base Turbo T-40 Wood Lathe... -
Page 17: Parts List And Exploded View
GB/T 2089 d0.8-D7-n6-H HWT40-01-01 Stop Rod HWT40-01-09 Bronze Sleeve Bearing 37-305 Tension Washer HW616-04-07 Hex Lock Nut GB/T 889.1 M12 Manual T-40 English Hammer HWT40-01-45 50 Spanner HWT40-01-52 Spindle Pin HWT50-01-55 Live Center Pin HWT50-01-42 Live Center HWT50-01-41 Spur Center... - Page 18 HWT40-01-38 Speed Range Warning Label HWT40-06-03 Warning Label HWT40-06-02 Tooth Washer Chain Cap Screw GB/T 70.2 M6×12 Rivet 6×6 Belt 80×26 Tail Stock Quill HWT40-02-02 14″Tail Stock HWT40-02-01 Tail Stock Quill Sleeve HWT40-02-08 Adjustable Handle M8×40 Turbo T-40 Wood Lathe...
- Page 19 Flat Key GBT/T 1096 6×25 Adjustable Handle M8×20 Cap Screw GB/T 70.1 M8×25 Large Washer GB/T 5287 8 Motor Mount Plate HWT40-04-10 Motor Mount Grip 25x5x80 δ1.5 5M Motor Pulley HWT40-01-18 Mounting Plate HWT40-04-11 Connection Switch HWT40-04-04 Turbo T-40 Wood Lathe...
- Page 20 Power for Speed Meter 220V/DC5V Power Cable Two Connection 、 Eight Pair- Terminals Cap Screw GB/T 70.2 M4×12 Connection Nut PG 11 Connection Nut PG 9 Electricity Side Cover HWT40-04-21 Input Power Cable with Plug Optional Turbo T-40 Wood Lathe...
- Page 21 Description Part Number Cable Protector 0813 Reset Label HWT40-06-08 Connection Cable I 1C×1.5mm L0.25m ASD-BCNDS0044_0.6M Servo Drive Control Cable 8C×25AWG Switch Control Cable 9C×24AWG L0.7m Connection Cable II 1C×1.5mm L0.10m Hex Lock Nut GB/T 889.1 M8 Turbo T-40 Wood Lathe...
-
Page 22: Exploded View
Exploded View Turbo T-40 Wood Lathe... - Page 23 Turbo T-40 Wood Lathe...
- Page 24 Turbo T-40 Wood Lathe...
- Page 25 Turbo T-40 Wood Lathe...
- Page 26 Turbo T-40 Wood Lathe...
- Page 28 Harvey Industries Co., Ltd. 68-10 Suyuan Avenue, Jiangning District, Nanjing 211100, China www.harveymachinery.com Harvey Industries Co.,Ltd. all right reserved.
