VESTA LOG FIRE
VLF45NG, VLF45NG, VLF45P, VLF45P
Manual & Remote Operated Models
THIS IS NOT
A 'DO-IT-YOURSELF' PRODUCT
THIS APPLIANCE MUST BE INSTALLED
BY A CORGI REGISTERED PERSON
INSTALLATION, USERS AND
SERVICING INSTRUCTIONS
Article I.
PLEASE LEAVE THESE INSTRUCTIONS
WITH THE USER
0120
THESE PRODUCTS ARE APPROVED TO THE EUROPEAN GAS DIRECTIVE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Verine VLF45NG
Summary of Contents for Verine VLF45NG
- Page 1 VESTA LOG FIRE VLF45NG, VLF45NG, VLF45P, VLF45P Manual & Remote Operated Models THIS IS NOT A ‘DO-IT-YOURSELF’ PRODUCT THIS APPLIANCE MUST BE INSTALLED BY A CORGI REGISTERED PERSON INSTALLATION, USERS AND SERVICING INSTRUCTIONS Article I. PLEASE LEAVE THESE INSTRUCTIONS WITH THE USER...
-
Page 2: Table Of Contents
Contents Page No. List of components Appliance Data ENERAL NSTALLATION EQUIREMENTS Fitting the Appliance Fitting the appliance into the optional Radiant Firebox Additional notes for handset remote control model Assembling the fire & the placing of the logs OMMISSIONING Check for spillage Briefing the User SERS UIDE... -
Page 3: List Of Components
(e) For Handset Remote Models only 1 Handset Control unit c/w 9V alkaline battery 1 Signal receiver (with mount) 1 Battery Charger c/w lead & jack plug 1 Rechargeable Battery pack & wiring harness PPLIANCE DATA VLF45NG VLF45NG VLF45P VLF45P (Manual) (Remote) -
Page 4: Fitting The Appliance
FIREPLACE See figure 1 FIGURE 1 The radiant fireboxes can be fitted to fireplaces which meet the dimensional requirements shown in figure 1. Basket installations require a fireplace large enough to accommodate the basket chosen. Decorative frets should have minimum of 50cm (8 sq. -
Page 5: Fitting The Appliance Into The Optional Radiant Firebox
If it is being drawn into the chimney proceed with the installation. If not, preheat the chimney over the period of a few minutes and recheck. If there is any doubt about the soundness of the chimney a smoke pellet should be used after preheating the flue and if smoke still fails to clear, further investigation of the chimney is required and the appliance MUST NOT be fitted. -
Page 6: Additional Notes For Handset Remote Control Model
Cut and form a section of 8mm pipe, only rigid or semi-rigid tube is acceptable, and run this into the fireplace opening. If a concealed fitting is required, care must be taken to sleeve the supply pipe when passing it through masonry. Exposed pipe within the fire opening should be wrapped, painted with bituminous paint, or be factory sheathed. - Page 7 Charging the battery pack The charger supplied with the battery pack is a true charger and will not overcharge the batteries. The charger has a built in switch so that it will switch off when the batteries in the pack are fully charged. The red LED on the front face of the charger will light when there is current passing to the batteries.
-
Page 8: Assembling The Fire & The Placing Of The Logs
IR Signal Receiver The signal receiver should be placed on the hearth just behind the ash pan cover such that it is visible to the user operating the remote control handset. If the receiver is covered in any way the fire will not operate. The receiver is secured to a bracket with a screw which can be removed when the burner is taken out for service. - Page 9 CAUTION All the ceramic components are fragile and should be handled with care. The burner tray and base ceramics are illustrated in figure 6. Position the burner ceramic making sure that the holes are aligned with the burner ports. Take the front ceramic and place it on the burner tray in front of the burner ports.
-
Page 10: Commissioning
OMMISSIONING When commissioning your appliance, remove the cap from the isolator fitting and unscrew the plug all the way out. Replace the cap making sure that the tab engages with the slot in the top of the plug. Tighten cap securely. Light the appliance in accordance with the instructions relevant to the appropriate control. -
Page 11: Users Guide
SERS UIDE USEFUL TIPS AND RECOMMENDATIONS Once your fire has been fitted, the following recommendations are made to ensure you enjoy the best results from your purchase; The installation of this appliance must be carried out by a qualified installer and in accordance with the requirements of the Gas Safety (Installation &... -
Page 12: Manual Appliances
When the fire is first lit, the flames tend to be rather blue in colour. Once the core of the fire becomes hot, the flames will become yellow and more lifelike. During this initial warm-up period it is recommended that the control remains in the ‘MAX’ or ‘HIGH’... -
Page 13: Remote Appliances
Remote Appliances Using the handset When using the handset make sure that it is pointed at the infra red signal receiver located under the front of the fire (the small black pad). Unlike a TV control the fire does not react to a quick press on the button on the handset control. -
Page 14: Cleaning Your Fire
Replacing the batteries As stated above, the batteries are of the nickel – metal - hydride type which have a long life and are able to be re-charged many times. Eventually, due to age and use, a point will come when they need recharging at inconveniently short intervals and they will have to be replaced. -
Page 15: Servicing & Maintenance
SERVICE AND MAINTENANCE WARNING This product uses fuel effect pieces containing Refractory Ceramic Fibre (RCF), which is man-made vitreous silicate fibres along with fibrous glass and mineral wool. Excessive exposure to these materials may cause temporary irritation to eyes, skin and respiratory tract;... -
Page 16: Spares Parts List
SPARE PARTS LIST In the event of a part requiring replacement the parts list is as follows VERINE PART DESCRIPTION NUMBER OXYGEN DEPLETION PILOT ASSEMBLY (NATURAL GAS ONLY). OXYGEN DEPLETION PILOT ASSEMBLY (L.P.G. PROPANE ONLY). GAS CONTROL BM VALVE (NATURAL GAS MANUAL) INC. PIEZO & HT LEAD SPECIAL ORDER GAS CONTROL BM VALVE (L.P.G. -
Page 17: Guarantee
GUARANTEE. The appliance is guaranteed for one year from the date of purchase. This guarantee is given subject to the following provisions:- a) The installation is carried out by a CORGI registered person. b) That the fireplace conforms to the requirements given in the Installation Instructions for this appliance. -
Page 18: Installation & Service Record
Installation & Service Record Please ensure that installer completes the installation record below INSTALLATION RECORD Appliance Supplied by: …………………………..Installation Date: ……………Serial No.: ….……... Installed By: …………..…...CORGI No.: …..…… Signed by Installer: ……………………………..… RECORD OF 1 SERVICE RECORD OF 2 SERVICE Serviced by: …………... - Page 20 Verine Limited 52 Broton Drive Trading Estate Halstead, Essex CO9 1HB Tel: (01787) 472551 Fax: (01787) 476589 Email: sales@verine.co.uk Website: www.verine.co.uk LOG/1006/II&UI THIS BOOKLET CONTAINS 20 PAGES...
