Summary of Contents for Clevo N240PU
- Page 1 N240PU / N241PU...
- Page 3 Preface Notebook Computer N240PU / N241PU Service Manual...
- Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
- Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the N240PU / N241PU series notebook PC.
- Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
-
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 8: Power Safety
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals. -
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. - Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup °...
-
Page 11: Table Of Contents
Preface Contents Introduction ..........1-1 Bottom ................... A-4 LCD ....................A-5 Overview ..................1-1 HDD ....................A-6 Specifications ..................1-2 Schematic Diagrams......... B-1 External Locator - Top View with LCD Panel Open ......1-4 External Locator - Front & Right Side Views .........1-5 System Block Diagram ..............B-2 External Locator - Left Side &... - Page 12 Preface PWR VNN_SVID ................ B-28 PWR 1.05VS/1.24VA/1.8VA ............B-29 PWR Charger ................B-30 USB Board ................... B-31 CRT ....................B-32 LAN ....................B-33 Power SW Board ................B-34 Click Board .................. B-35 LED Board ................... B-36 HDD Board .................. B-37 Level Shifter 1 ................
-
Page 13: Introduction
Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the N240PU / N241PU series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g. -
Page 14: Specifications
Introduction Specifications Processor Options Storage Intel® Pentium® Processor One Changeable 2.5" 7mm (h) SATA HDD/SSD N4200 (1.10GHz) (Factory Option) One M.2 SATA Solid State Drive (SSD) 2MB Smart Cache, 14nm, DDR3L-1866MHz, TDP 6W (Factory Option) 32GB eMMC* Intel® Celeron® Processor Latest Specification Information *Note: Systems with 32GB eMMC modules only support N3450 (1.10GHz), N3350 (1.10GHz) - Page 15 Introduction Interface Power One USB 2.0 Port Full Range AC/DC Adapter One USB 3.0 (USB 3.1 Gen 1) Port AC Input: 100 - 240V, 50 - 60Hz One USB 3.0 (USB 3.1 Gen 1) Type C Port DC Output: 19V, 2.1A (40W) One HDMI-Out Port Removable 4 Cell Smart Lithium-Ion Battery Pack, 32WH One External Monitor Port...
-
Page 16: External Locator - Top View With Lcd Panel Open
Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated in red. 3. Built-In Microphone 4. LCD 5. -
Page 17: External Locator - Front & Right Side Views
Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicators FRONT VIEW Figure 3 Right Side View 1. USB 2.0 Port RIGHT SIDE VIEW 2. Multi-in-1 Card Reader 3. External Monitor Port 4. RJ-45 LAN Jack External Locator - Front &... -
Page 18: External Locator - Left Side & Rear View
Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Security Lock Slot 2. DC-In Jack 3. HDMI-Out Port LEFT SIDE VIEW 4. Vent 5. USB 3.0/3.1 Port 6. USB 3.0/3.1 Type C Port 7. Microphone-In Jack 8. -
Page 19: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Vent 3. Speakers Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7... -
Page 20: Mainboard Overview - Top (Key Parts)
Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1 - 8 Mainboard Overview - Top (Key Parts) -
Page 21: Mainboard Overview - Bottom (Key Parts)
Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. KBC-ITE IT8587 2. CPU 3. Memory Slots DDR4 SO-DIMM 4. CMOS Battery Mainboard Overview - Bottom (Key Parts) 1 - 9... -
Page 22: Mainboard Overview - Top (Connectors)
Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. DC-In Jack 2. HDMI-Out Port 3. USB Port 3.0/3.1 Port 4. USB Port 3.0/3.1 Type C Port 5. Microphone-In Jack 6. Headphone-Out Jack 7. SIM Card Reader 8. Keyboard Cable Connector 1 - 10 Mainboard Overview - Top (Connectors) -
Page 23: Mainboard Overview - Bottom (Connectors)
Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. 3G/4G Card Connector 2. WLAN Connector 3. HDD Connector 4. Touchpad Connector 5. Speaker Connector 6. Fan Connector 7. LCD Cable Connector 8. CCD Connector 9. Battery Connector Mainboard Overview - Bottom (Connectors) 1 - 11... - Page 24 Introduction 1 - 12...
-
Page 25: Disassembly
Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the N240PU / N241PU series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. -
Page 26: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 27: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 28: Disassembly Steps
Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the CCD Module: 1. Remove the battery page 2 - 5 1. -
Page 29: Removing The Battery
Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn off the computer, turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold it 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1b in place. -
Page 30: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7.0mm Removal (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk. - Page 31 Disassembly 5. Remove screw and slightly lift to pull the hard disk assembly in the direction of arrow (Figure 3d Figure 3 6. Lift the hard disk assembly out of the bay (Figure 3e HDD Assembly 7. Remove the screws and the adhesive cover from the hard disk (Figure 3f...
-
Page 32: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) Figure 4 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L Up to 1867MHz. The main memory can be expanded up to 8GB. The total memory size is automatically de- tected by the POST routine once you turn on your computer. - Page 33 Disassembly 5. Pull the latches to release the second module if necessary. 6. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. 7. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot as it will go.
-
Page 34: Removing The Keyboard
Disassembly Removing the Keyboard Figure 5 1. Turn off the computer, turn it over to remove the battery (page 2 - Keyboard Removal 2. Remove screws from the bottom case (Figure 5a). 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module while releas- ing the keyboard in the direction of the arrow as shown... -
Page 35: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 6 Wireless LAN 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 6a). -
Page 36: Wireless Lan, And Combo Module Cables
Disassembly Wireless LAN, and Combo Module Cables Note that the cables for connecting to the antennae on WLAN, and WLAN & Bluetooth Combo modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for identification as outlined in the table below. -
Page 37: Removing The 3G Module
Disassembly Removing the 3G Module Figure 7 3G Module Removal Procedure 3G Module Removal 1. Turn off the computer, remove the battery (page 2 - 5) and bottom cover (page 2 - a. Locate the module. 2. Locate the module, it is visible at point Figure 7a b. -
Page 38: Removing And Installing The M.2 Ssd Module
Disassembly Removing and Installing the M.2 SSD Module Figure 8 M.2 SSD Module m.2 SSD Removal Procedure Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - 2. - Page 39 Disassembly M.2 SSD Installation Procedure Figure 9 1. Place the thermal pad on the bottom case as shown (Figure 9a). M.2 SSD Module 2. Insert the module in the computer Figure 9b Installation 3. Tighten the screw to secure it in place (Figure 9c).
-
Page 40: Removing The Ccd
Disassembly Removing the CCD Figure 10 CCD Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and then separate the LCD Panel from the bottom case. a. Remove the rubber cov- 2. Remove the rubber covers and screws (Figure 10a). - Page 41 Disassembly 6. Remove the LCD front cover (Figure 11e). Figure 11 7. Disconnect the cable (Figure 11f). CCD Removal 8. Remove the CCD module (Figure 11g). (cont’d.) 9. Reverse the process to install a new CCD module. e. Remove the LCD front cover.
- Page 42 Disassembly 2 - 18...
-
Page 43: Part Lists
Appendix A:Part Lists This appendix breaks down the N240PU / N241PU series notebook’s construction into a series of illustrations. The com- ponent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation. -
Page 44: Part List Illustration Location
Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 page A - 6 A - 2... -
Page 45: Top
Figure A - 1 Top A - 3... -
Page 46: Bottom
Bottom Figure A - 2 Bottom A - 4 Bottom... -
Page 47: Lcd
Figure A - 3 LCD A - 5... -
Page 48: Hdd
Figure A - 4 A - 6 HDD... -
Page 49: Schematic Diagrams
Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the N240PU / N241PU notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1... -
Page 50: System Block Diagram
Schematic Diagrams System Block Diagram 7 IN 1 5V,5VS,3.3V,3.3VS 6-7P-N24P7-002 N240PU/N250PU Apollo Lake System Block Diagram 3.3VA,1.8VA MAIN BOARD SHEET 1~29 37~40 6-71-N24P0-D02 SHEET 22 USB BOARD 6-71-N24P3-D02 SHEET 30 VDD3,VDD5 SHEET 23 MULTI BOARD CRT CONN 1066/ 1333 MHz VDD1.8,1.15VA... -
Page 51: Processor 1/8
Schematic Diagrams Processor 1/8 U25A APL_SOC U25B APL_SOC M_A_A[15:0] M_B_A[15:0] M_A_A15 BG57 DDR0 M_B_A15 BG16 DDR1 M_A_DQ[63:0] M_B_DQ[63:0] M_A_A14 DDR3_M0_MA_15 M_A_DQ63 M_B_A14 DDR3_M1_MA_15 M_B_DQ63 BG56 BJ34 BG15 DDR3_M0_MA_14 DDR3_M0_DQ_63 DDR3_M1_MA_14 DDR3_M1_DQ_63 M_A_A13 M_A_DQ62 M_B_A13 M_B_DQ62 BG46 BG37 DDR3_M0_MA_13 DDR3_M0_DQ_62 DDR3_M1_MA_13 DDR3_M1_DQ_62 M_A_A12 BG54... -
Page 52: Processor 2/8
Schematic Diagrams Processor 2/8 Note: There is no need to have a RCOMP for DDI0. U25C APL_SOC Please ensure that the eDP_RCOMP pin is populated with the correct value. The SoC will use the eDP_RCOMP value for DDI Port0 as well. MCSI_DP_0 MCSI_DN_0 MCSI_DP_1... -
Page 53: Processor 3/8
Schematic Diagrams Processor 3/8 APL_SOC U25D PCIE_TXP0_C C307 0.1u_10V_X7R_04 SATATXP0 PCIE_TXP0_LAN PCIE_TXP0 SATA_TXP0 PCIE_TXN0_C 1.8VS LAN/CARD READER C308 0.1u_10V_X7R_04 PCIE_TXN0_LAN PCIE_TXN0 SATA_TXN0 SATATXN0 SATA HDD PCIE_RXP0_LAN PCIE_RXP0 SATA_RXP0 SATARXP0 PCIE_RXN0_LAN SATARXN0 PCIE_RXN0 SATA_RXN0 SATA_TXP1 SATA_TXP1/USB3_TXP5 R449 SATA_TXN1 PCIE_TXP1 SATA_TXN1/USB3_TXN5 (3G+mSATA)(B KEY) SATA_RXP1 PCIE_TXN1 SATA_RXP1/USB3_RXP5... -
Page 54: Processor 4/8
Schematic Diagrams Processor 4/8 C464 *18p_50V_NPO_04 R646 0_04 GCLK_19.2M_SOC U25E APL_SOC XTAL_SOC_IN R647 OSCIN GPIO_83/AVS_DMIC_DATA_2 XTAL_SOC_OUT OSCOUT GPIO_81/AVS_DMIC_DATA_1 *FSX3M_19.2MHZ *200K_04 GPIO_80/AVS_DMIC_CLK_B1 OSC_CLK_OUT0 SOC_GPIO82 AG62 OSC_CLK_OUT0 GPIO_82/AVS_DMIC_CLK_AB2 OSC_CLK_OUT1 AF61 OSC_CLK_OUT1 GPIO_79/AVS_DMIC_CLK_A1 AG63 PLTFM CLK's OSC_CLK_OUT2 AE60 OSC_CLK_OUT3 GPIO_76/AVS_I2S1_WS_SYNC SOC_GPIO78 C465 *18p_50V_NPO_04 AF62 OSC_CLK_OUT4 GPIO_78/AVS_I2S1_SDO... -
Page 55: Processor 5/8
Schematic Diagrams Processor 5/8 When the platform does not use the USB2_OTG_ID and USB2_VBUS_SNS pins, U25F APL_SOC USB2_OTG_ID pin should be unconnected on the platform (terminated with internal USB2.0 pull ups] and USB2_VBUS_SNS should be USB_OTG_ID USB3.0 AC15 connected to ground. USB_OTG_ID M/B USB port0(2.0+3.0) USB3_TX0_P... -
Page 56: Processor 6/8
Schematic Diagrams Processor 6/8 GCLK_32K_RTC R684 0_04 C303 *18p_50V_NPO_04 R411 0429 DEL test pad U25G APL_SOC 0511 ADD * *CM315D_32.768KHZ *10M_04 XDP_H_TCK RTC_X1 AC59 XDP_H_TDI RTC_X1 AC58 RTC_X2 C302 *18p_50V_NPO_04 0428 modify CHG XDP_H_TDO RTC_X2 AG51 BVCCRTC_EXTPAD 0.1u_10V_X7R_04 XDP_H_TMS RTC_EXTPAD XDP_H_TRST_N RTC_RST# JTAG... -
Page 57: Processor 7/8
Schematic Diagrams Processor 7/8 U25H APL_SOC AA36 AJ37 VCGI VCC_VCGI_1 VNN_SVID_1 VNN_SVID AA37 AJ39 VCC_VCGI_2 VNN_SVID_2 AA39 AJ41 3.3A VCC_VCGI_3 VNN_SVID_3 AC36 AJ42 VCC_VCGI_4 VNN_SVID_4 AC37 AJ46 VCC_VCGI_5 VNN_SVID_5 C475 C474 C476 C477 C478 AE36 AK37 C479 C480 C481 C482 C483 C484 VCC_VCGI_6... -
Page 58: Processor 8/8
Schematic Diagrams Processor 8/8 U25J APL_SOC U25K APL_SOC U25L APL_SOC U25M APL_SOC AG42 POWER-VSS AK36 POWER-VSS BB19 AN54 POWER-VSS POWER-VSS VSS_70 VSS_1 VSS_1 VSS_69 VSS_1 VSS_71 AG44 AR19 BB25 AN56 AC20 VSS_71 VSS_2 VSS_2 VSS_70 VSS_2 VSS_72 RSVD_1 NCTF_3 AG46 AR32 AN57 AM32... -
Page 59: Emmc
Schematic Diagrams eMMC eMMC 3.3VA +V3P3A_EMMC +V1P8A 1.8VA R796 0_04 R797 0_04 eMMC eMMC C543 C544 C545 C546 C547 C548 C549 C550 0630 CHG 0630 CHG 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 1u_6.3V_X5R_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 1u_6.3V_X5R_04 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 eMMC eMMC eMMC eMMC eMMC eMMC eMMC eMMC eMMC... -
Page 60: Ddr3L So-Dimm_0
Schematic Diagrams DDR3L SO-DIMM_0 SO-DIMM A JDIMM1B 1.35V VDD1 VSS16 VDD2 VSS17 JDIMM1A VDD3 VSS18 M_A_A[15:0] M_A_DQ[63:0] M_A_A0 M_A_DQ1 VDD4 VSS19 M_A_A1 M_A_DQ4 VDD5 VSS20 M_A_A2 M_A_DQ2 VDD6 VSS21 M_A_A3 M_A_DQ3 VDD7 VSS22 M_A_A4 M_A_DQ0 VDD8 VSS23 M_A_A5 M_A_DQ5 3.3VS VDD9 VSS24 M_A_A6... -
Page 61: Ddr3L So-Dimm_1
Schematic Diagrams DDR3L SO-DIMM_1 SO-DIMM B JDIMM2A JDIMM2B M_B_A[15:0] M_B_DQ[63:0] M_B_A0 M_B_DQ0 M_B_A1 M_B_DQ4 M_B_A2 M_B_DQ6 1.35V M_B_A3 M_B_DQ3 M_B_A4 M_B_DQ1 M_B_A5 M_B_DQ5 VDD1 VSS16 VDD2 VSS17 M_B_A6 M_B_DQ7 VDD3 VSS18 M_B_A7 M_B_DQ2 M_B_A8 M_B_DQ12 VDD4 VSS19 Layout Note: VDD5 VSS20 M_B_A9 M_B_DQ8... -
Page 62: Hdmi
Schematic Diagrams HDMI HDMI CONNECTOR ( W/O LEVELSHIFT) HDMI_5VS J_HDMI1 VOUT C191 C190 19,22,25 SUSB HDMI_HPD-C R305 100K_04 HOT PLUG DETECT 0621 PDA bug CHG SY6288D20AAC OLD=uP7549UMA5-20 DDC/CEC GND HDMI_SDA-C HDMI_SCL-C PLATFROM PLATFROM RESERVED HDMI_CEC R289 470_04 TMDS_CLOCK#-R TMDS_CLOCK# TMDS_CLOCK#J TMDS CLOCK- CLK SHIELD TMDS_CLOCK-R... -
Page 63: Ps8625
Schematic Diagrams PS8625 Single link (Odd) LVDS Default eDP VDDIO VDDIO VDDIO VDDIO LVDS-L0N LVDS-L0P LVDS-L1N R552 R553 C434 C435 LVDS LVDS-L1P VDDIO HCB1005KF-121T20 10K_04 10K_04 0.1u_10V_X7R_04 0.1u_10V_X7R_04 3.3VS 6-19-31001-247 VDDIO LVDS LVDS LVDS LVDS LVDS-L2N 0513 CHG LVDS-L2P PS8625_PD# RST# D01 to D02 LVDS-LCLKN... -
Page 64: Panel
Schematic Diagrams Panel PANEL CONNECTOR (For coaxial cable) PANEL POWER PLVDD PLVDD 0510 modify J_LCD1 OPEN PLVDD 3.3VS 3.3VS C185 VOUT CLOSE 1u_6.3V_X5R_04 For eDP & LVDS NEAR PIN4,5 C184 C192 R270 C203 LVDS-U0N 1u_6.3V_X5R_04 1u_6.3V_X5R_04 10u_6.3V_X5R_06 100K_04 LVDS-U0P uP7553 FOR EDP LVDS-U1N PANEL_VCC_EN... -
Page 65: Audio Codec
Schematic Diagrams Audio Codec AUDIO CODEC ALC269-CV2 For 1.8V HDA Link. 1.5V OR 3.3V BY PLATFORM R213 0_04 PVDD1_2 1.8VS HCB1005KF-121T20 D E S I G N , Layout note: D01 to D02 GND and AUDG space is DVDD_IO 0511 del C372 C380 60mils ~ 100mils... -
Page 66: Sata,Led,Hub
Schematic Diagrams SATA, LED, HUB C463 0.1u_10V_X7R_04 J_LED1 3.3VS LED_BAT_CHG_R LED_BAT_FULL_R LED_ACIN_R LED_PWR_R USB HUB SATA_LED# AIRPLAN_LED# FP225H-008S11M 0516 CHG value FP *DT1140-04LP-7 LED_BAT_CHG_R LED_BAT_CHG LED_BAT_FULL_R LED_BAT_FULL LED_ACIN_R LED_ACIN LED_PWR_R LED_PWR Sheet 17 of 39 SATA, LED, HUB 0513 ESD J_MINI1 SATA HDD H6_5D3_7... -
Page 67: Usb, Tpm
Schematic Diagrams USB, TPM USB PORT Charge USB 3.0 port (CHARGER) C339 22u_6.3V_X5R_08 Smart CDP C117 22u_6.3V_X5R_08 80 MIL pin8 pin4 Function C350 *220u_6.3V_6.3*6.3*4.2 USBVCC_CH 0511 CHG value 6-11-22711-AB7 DCP autodetect with mouse/keyboard wake up CLOSE TO CONNECTOR J_USB3_1 DT1140-04LP-7 S0 Charging with SDP USB3_TX1P USB3_TX1PJ... -
Page 68: Conn,Ccd,Fan,Click,Tv
Schematic Diagrams Conn, CCD, Fan, Click, TV T/P OR CLICK PAD AX995B(SOT23-6) & APE8872 Co-Layout CPU FAN CONN R480 *0_04 FON# TP_VCC FAN_5VS VOUT R521 *0_04 CPU_FAN VSET C335 R522 0_04 C420 C421 C425 1u_6.3V_X5R_04 NCT3940S-A 3.3VS R525 R526 *10u_10V_Y5V_08 0.1u_10V_X7R_04 FAN_5VS 10K_04... -
Page 69: Wlan/Bt, 3G/Msata
Schematic Diagrams WLAN/BT, 3G/mSATA CURRENT2A ,DON'T DROP BELOW R366 0_06_2A W/O 3G/LTE 3G,LTE CARD / mSATA 3.3VS 3.135V 3G POWER R360 0_06_2A W/O 3G/LTE 3G_3.3V 80 mils J_3G1 C242 220u_6.3V_6.3*6.3*4.2 R375 *0_06_2A 3G/LTE 3G_3.3V 3G/LTE R368 *0_06_2A 3G/LTE CHECK EC, 1.8V LEVEL C232 0.1u_16V_Y5V_04 CONFIG_2... -
Page 70: Kbc Ite It8987E
VOLTAGE VDD3 KBC_AVDD 0420 modify PIN 106 J_80DEBUG1 8887H HSPI leve V, PIN1 3 . 3 V N240PU HCB1005KF-121T20 3.3V 8887H HSPI leve V, PIN1 1 . 8 V 3IN1 VDD3 VDD3 EC ROM(EC ROM for BIOS+ME+EC) power... -
Page 71: System Power
Schematic Diagrams System Power VIN1 P2808 VIN1 VDD3 VDD3 DD_ON R517 10K_04 R530 100K_04 VDD3 VIN1 DD_ON_P R506 1_06 DD_ON_LATCH R400 R398 PWR_SW#_R R509 10K_04 R529 10K_04 19,22 M_BTN# M_BTN# PWR_SW# VDD3 47K_04 R528 1K_04 47K_04 U74AHC1G08G-AL5-R R508 1K_04 PWR_SW# 21,23 USB_CHARGE_EN INSTANT-ON... -
Page 72: Vdd3, Vdd5
Schematic Diagrams VDD3, VDD5 VDD3/VDD5 VDD5 PC338 PC339 PC340 PC341 PC342 PR306 PC337 220K_1%_04 1000p_50V_X7R_04 PR307 0_04 PU38 G5330AQN1U LDO5 +V5_LDO LDO5 VDD5_EN PC343 PR308 PR309 PC344 VDD5_TON 0_04 0.1u_10V_X7R_04 VDD5_BST 10u_6.3V_X5R_06 0_04 PL18 SYS5V PJ18 VDD5 VDD5_VCC BCIHP0730-2R2M *OPEN-5mm VDD5_LX VDD5_FB PC345... -
Page 73: Usb
Schematic Diagrams 3.3V 3.3V 3.3V 5V_MUX 3.3V_MUX 3.3V_MUX 3.3V R742 *4.7K_04 R743 *0_04 R744 *4.7K_04 R745 *0_04 C569 C570 C571 R746 R747 R748 *0_04 0.01u_16V_X7R_04 0.1u_10V_X7R_04 1u_6.3V_X5R_04 C574 C575 HCB1608KF-121T30 R749 2K_1%_04 C572 C573 C576 *4.7K_04 *4.7K_04 1u_6.3V_X5R_04 10u_6.3V_X5R_06 5V_MUX 0.1u_10V_X7R_04 0.1u_10V_X7R_04 1u_6.3V_X5R_04... -
Page 74: Power 1.35V/0.675V
Schematic Diagrams Power 1.35V/0.675V PC302 PC298 PC299 PC300 PD24 PC301 *RB0540S2 0.1u_10V_X7R_04 PU35 G5616BRZ1U 0.675VS VDDQ PC303 10u_6.3V_X5R_06 VDDQ_VBST PQ32 VLDOIN VBST 1.35V PJ17 PR285 QM3004M3 *OPEN-2mm 0_04 VDDQ_DRVH VDDQ_DRVH_R VTT_MEM DRVH VDDQ 1.35V PL16 PJ16 CLOSE PC304 PC305 BCIHP0730-1R0M *OPEN-10mm VDDQ_L VTTGND... -
Page 75: Pwr Vcgi
Schematic Diagrams PWR VCGI 0517 CHG Value PR211 VCGI_VREF VBOOT SET to 0V PC253 PR210 84.5_1%_04 PR212 0.1u_10V_X7R_04 2.2_04 VCGI 1.05VS 51K_1%_04 VCGI_VREF H_PROCHOT# PR213 VCGI_VCLK PR215 PJ73 100K_1%_04 30K_1%_04 PR214 95.3_1%_04 H_CPU_SVIDCLK 7,27 8.25K_1%_04 *OPEN-1mm EW TF02-104F4F-N VCGI_VDIO PR216 20_1%_04 H_CPU_SVIDDAT 7,27... -
Page 76: Pwr Vnn_Svid
Schematic Diagrams PWR VNN_SVID PR248 VNN_SVID 75_1%_04 PC278 PR252 VNN_VREF PR249 PR250 0.1u_10V_X7R_04 2.2_04 PR251 7.5K_1%_04 150K_1%_04 169_1%_04 0517 CHG Value VNN_VREF 1.05VS PR254 VNN_VCLK 100K_1%_04 46.4K_1%_04 PR253 95.3_1%_04 H_CPU_SVIDCLK 7,26 EW TF02-104F4F-N VNN_VDIO PR255 20_1%_04 H_CPU_SVIDDAT 7,26 VNN_ALERT# PR257 PR256 0_04 H_CPU_SVIDALRT#... -
Page 77: Pwr 1.05Vs/1.24Va/1.8Va
Schematic Diagrams PWR 1.05VS/1.24VA/1.8VA 0511 CHG Value PR294 PU36 180K_1%_04 G5383A VIN_PAD 0511 CHG value PC316 PC317 PC318 1.24VA 1u_25V_X5R_06 4.7u_25V_X5R_08 4.7u_25V_X5R_08 PR295 1.5_04 1.24_V5V PC319 PL17 1.24VA PJ83 0.1u_10V_X5R_04 BCIHP0730-1R0M PC320 4.7u_6.3V_X5R_04 PC322 PC323 PC324 PC325 PC326 PJ84 *OPEN-5mm PR296 0_04 1.8VA_PG... -
Page 78: Pwr Charger
Schematic Diagrams PWR Charger PR76 *20mil short-p SMART CHARGER V_BAT PR43 20K_04 EMB20P03V PC75 PC74 0505 FP modify VJACK HCB2012KF-800T80 EMB20P03V PR40 0428 modify 4.7 to 10 0428 modify PR60 0420 power modify PC60 0.02_1%_32 BCIHP-0730 8R2M 0420 power modify 0.01_1%_32 EMC1 GND1... -
Page 79: Usb Board
Schematic Diagrams USB Board U_USBVCC_1 100 MIL UJ_USB1 U_5V VOUT U_5V 10u_10V_Y5V_08 0.1u_16V_Y5V_04 22u_6.3V_X5R_08 22u_6.3V_X5R_08 *220u_6.3V_6.3*6.3*4.2 SY6288D20AAC U_GND U_GNDU_GND U_GND UDD_ON# UUSBH1_USB_DP2 0511 CHG Value UUSBH1_USB_DN2 U_USBVCC_1 60 mil UUSBH1_USB_DP4 UUSBH1_USB_DN4 UDD_ON# 0.1u_16V_Y5V_04 UJ_USB2_1 FP225H-016S10M UUSBH1_USB_DN2 UUSB_PN2R UUSB_PN2_RJ Sheet 30 of 39 U_GND DATA_L UUSB_PP2_RJ... -
Page 80: Crt
Schematic Diagrams 0621 PDA bug CHG OLD=FCM1005MF-600T01 0511 CHG Value M_5VS_CRT M_5VS MJ_CRT1 DR7N115B-41-55-005 RB751S-40C2 MDAC_RED ML12 GZ1005D600TF MFRED MDAC_GREEN ML13 GZ1005D600TF MFGRN POWER MR50 MR53 MDAC_BLUE ML14 GZ1005D600TF MFBLUE 2.2K_04 2.2K_04 M_3.3VS 0511 CHG Value MC51 MC52 MC53 MC61 MC62 MC63 MVGA_SDA... -
Page 81: Lan
Schematic Diagrams LAN (RTL8411B) Crystal HSX32 1 S(3. 2X 2. 5X 0. 6 5) INTE L PLAYFOR M SUPP ER R TC WA KE O N Switching Regulator close to PIN48 meet realtek Freq tolerance 50ppm L A N ( S 5 ) D e d e o A D 6 MSD_CMD/MS_D2 MSD_CMD/MS_D2_R... -
Page 82: Power Sw Board
Schematic Diagrams Power SW Board S_VDD3 POWER SW & LED POWER SWITCH 100K_04 SJ_SW1 S_VDD3 YB8251 Hall-effect sensor SMGND 20mil S_3.3VS FOR 15" SMGND SMGND 0511 CHG Value SM_BTN# 15" SMGND SLID_SW# SMGND FP225H-008S11M Sheet 33 of 39 YB8251 Hall-effect sensor SLID_SW# 0511 CHG Value Power SW Board... -
Page 83: Click Board
Schematic Diagrams Click Board CLICK BOARD FOR 14"(old) CTP_VCC CJ_TP2 FOR 14"(old) *0.1u_16V_Y5V_04 CTP_VCC CGND CTP_CLK CTP_DATA *0.1u_16V_Y5V_04 *0_06 CTPBUTTON_L CGND CTP_CLK *0_04 CTPBUTTON_R CTP_DATA *0_04 CGND CGND CJ_TP1 *85201-06051 CTPBUTTON_L 20mil 0_04 CTPBUTTON_R 5mil 0_04 20mil 0_06 15" 20mil 15"... -
Page 84: Led Board
Schematic Diagrams LED Board LED BOARD L_LED_BAT_FULL L_LED_ACIN L_LED_BAT_CHG L_LED_PWR LRN1 220_8P4R_04 RY-SP155HYYG4-1 RY-SP155HYYG4-1 Sheet 35 of 39 LED Board LGND LGND LGND LGND POWER ON LED/ AC IN FULL LED/ BAT CHARGE L3.3VS D01 to D02 L3.3VS LJ_LED1 LGND 220_04 220_04 L_LED_BAT_CHG... -
Page 85: Hdd Board
Schematic Diagrams HDD Board H_3.3VS FOR 15" HR23 *4.7K_04 HR24 *4.7K_04 HGND HR22 *4.7K_04 HR21 0_04 W/RDVR D02 to D02a W/RDVR W/RDVR W/RDVR W/RDVR 0.01u_16V_X7R_04 0.1u_16V_Y5V_04 1u_6.3V_X5R_04 4.7K_04 PIN6 PIN10 PIN16 HJ_HDD1 HJ_HDD2 HGND HGND HGND HSATA_TXP0_L HSATA_TXP0_R HSATA_TXP0 0.01u_16V_X7R_04 RX1P TX1P HSATA_TXN0_L... -
Page 86: Level Shifter1
Schematic Diagrams Level Shifter 1 SMB_CLK SCI# SMB_DATA SWI# SMI# 0419 Modify DEL 1.8VA R610 3.3VA 3.3VS *0402_short 0421 Modify FP 0801 Modify R543 R544 R172 R171 SMI#_N SMI# 1K_04 1K_04 2.2K_04 2.2K_04 2SK3018S3 SMB_CLK_N SMB_CLK SMB_CLK_N SMB_CLK 11,12,19 Q63A Sheet 37 of 39 SCI#_N SCI#... -
Page 87: Level Shifter2
Schematic Diagrams Level Shifter 2 3.3VS NB_ENAVDD PCIE_WAKE# LAN_CLKREQ# 3.3VS 1.8VA 3.3VA 1.8VA R106 10K_04 10K_04 R444 R438 10K_04 10K_04 R736 R737 R738 R739 NB_ENAVDD 10K_04 10K_04 10K_04 10K_04 LAN_CLKREQ#_R Q65A MTDK3S6R MTDK5S6R PCIE_WAKE0# PCIE_WAKE0#_R 2SK3018S3 *0.1u_16V_Y5V_04 Q57B R450 1K_04 Q65B SOC_ENAVDD MTDK5S6R... -
Page 88: Power Sequence
Schematic Diagrams Power Sequence G0/S0/C0=> FULL ON G0/S0/CX=> Cx State G1/S4 =>Suspend-To-Disk VDD3 G2/S5=> SOFT OFF G3 =>Mechanical OFF VA_ON VA_ON 1.195ms 3.3VA VA_ON 6.896ms VA_ON 11.3ms 1.8VA VA_ON 12.88ms 1.24VA VA_ON 20.4ms DD_ON Sheet 39 of 39 DD_ON 794.3us VDD5 DD_ON 835.2us... -
Page 89: Updating The Flash Rom Bios
Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files... -
Page 90: Use The Flash Tools To Update The Bios
BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.
