Direct TENS
™

4. TREATMENT...

Figure 4-1 Switching the stimulator on
Figure 4-2 Initial screen
Additionally, icons may appear on the screen
The keys are locked (automatic function): To prevent inadvertent activation, the keys are
automatically locked 10 seconds after the current intensity has been set. The keys can be unlocked
with
The electric circuit is interrupted (see chapter 6 "What to do, if...)
Batteries need to be replaced. When you see this icon, replace the batteries as soon as possible.
• You can interrupt therapy at any time with the ON/OFF switch.
• If the stimulator is not used, it switches off automatically after approx. 5 minutes.
• When the therapy timer is activated, the device switches automatically off at the end of the
programmed interval. The remaining therapy time is always indicated on the display.
• The program can only be changed when the intensity in both channels is 0.

4.1. Starting Therapy

• Switch the stimulator on.
Once switched on, the display will briefly show the
software version. A functional test where all display
indicators appear for a short time is performed. The initial
screen appears next (Figure 4-2).
When the initial screen is displayed, the device has
successfully passed the functional test.
If the letter "E" is displayed instead of the initial screen, the
stimulator is defective and must be replaced. Do not use
this stimulator any more.
On the initial screen you will see:
Duration of the Stimulation
• Select the program either via the quick select keys or via
Selected program
• Increase the stimulation intensity for a channel
Stimulation Intensty
or by switching the device off.
Operation Information
- The remaining stimulation duration
- The intensity of the stimulation (indication of the
selected intensity level, adjustable in steps
of 0.5 from 0 to 60)
- The selected program
the program selection keys.
(1 or 2) by pressing the corresponding
Increase the intensity with great care and in
small increments. Select a level which causes a
pleasant sensation that is felt clearly.
19
key.
