Treatment Programs

You can choose 6 different treatment programs.
When treatment program changes, the output intensity and treatment time resets to
zero, but changing the treatment program will not alter the choice of the 2-Pads or
4-Pads Treatment.
Program Type
1 Constant
2 Sweep
3 Sweep
4 Sweep
5 Abrupt
6 Abrupt

Placement of Electrodes

The placement of the electrodes is very important to the success of the treatment,
therefore please place electrodes according to the instructions of your treating
physician.
When operating in 4-Pads treatment mode, the
electrodes should be placed on the body as
described in the diagram below. The arrangement
of these 4 electrodes will allow the intersection
of the 2 sinusoidal outputs, which will result in
the required beat frequency. In 2-Pads treatment
mode, 2 separate pairs of electrodes can
simultaneously treat two different body regions.
8
I/F frequency
adjustable
2-160Hz Adjustable
2 to 20Hz adjustable in steps of 2Hz.
Yes
20 to 80Hz adjustable in steps of 5Hz.
80 to 160Hz adjustable in steps of 10Hz.
The beat frequency sweeps from 2Hz – 10Hz in 6
No seconds, and then back in 6 seconds, total cycle time
is 12 seconds.
The beat frequency sweeps from 2 Hz to 100Hz in 10
No seconds, and then back in 10 seconds, total cycle
time is 20 seconds.
The beat frequency changes gradually from the set
value to +200% of it in 6 seconds, and then back
Yes in 6 seconds, total cycle time is 12 seconds. The
selectable beat frequency ranges between 5 ~ 80Hz
with steps of 5Hz.
The beat frequency changes abruptly between set
value and +200% of it every 1 second. The total cycle
Yes
repeats in 2 seconds. The selectable beat frequency
ranges between 5-80Hz with steps of 5Hz.
The beat frequency changes abruptly between set
value and +200% of it every 6 seconds. The total
Yes
cycle repeats in 12 seconds. The selectable frequency
ranges between 5~80Hz with step of 5Hz.
Description
