RS150 GNSS Receiver
INSTALLATION
INSTRUCTIONS
English (EN)
Date:
05-2016
Document number:
87271-1
© 2015 Raymarine UK Limited

Advertisement

Table of Contents
loading

Summary of Contents for Raymarine RS150

  • Page 1 RS150 GNSS Receiver INSTALLATION INSTRUCTIONS English (EN) Date: 05-2016 Document number: 87271-1 © 2015 Raymarine UK Limited...
  • Page 3 Software updates Important: Check the Raymarine website for the latest software releases for your product. www.raymarine.com/software Product handbooks The latest versions of all English and translated handbooks are available to download in PDF format from the website www.raymarine.com.
  • Page 5: Table Of Contents

    7.1 Service and maintenance ........32 7.2 Routine equipment checks........32 7.3 Product cleaning ..........33 Chapter 8 Technical support ......35 8.1 Raymarine product support and servicing ....36 8.2 Learning resources ..........37 Chapter 9 Technical specification...... 39 9.1 Technical specification.......... 40 Chapter 10 Spares and accessories ....
  • Page 6 RS150 Installation instructions...
  • Page 7: Chapter 1 Important Information

    Disclaimer Warning: Positive ground systems Do not connect this unit to a system which Raymarine does not warrant that this product is has positive grounding. error-free or that it is compatible with products manufactured by any person or entity other than Raymarine.
  • Page 8: Connections To Other Equipment

    Connections to other equipment Requirement for ferrites on non-Raymarine cables If your Raymarine equipment is to be connected to other equipment using a cable not supplied by Raymarine, a suppression ferrite MUST always be attached to the cable near the Raymarine unit.
  • Page 9: Chapter 2 Document And Product Information

    Chapter 2: Document and product information Chapter contents • 2.1 Document information on page 10 • 2.2 RS150 product overview on page 10 Document and product information...
  • Page 10: Document Information

    87271 RS150 Installation instructions SeaTalk utilizes a single backbone to which Installation of a RS150 and connection to a compatible instruments connect using a spur. Data wider system of marine electronics. and power are carried within the backbone. Devices that have a low draw can be powered from the...
  • Page 11: Chapter 3 Planning The Installation

    Chapter 3: Planning the installation Chapter contents • 3.1 Installation checklist on page 12 • 3.2 Parts supplied on page 12 • 3.3 Software updates on page 13 • 3.4 Tools required for installation on page 13 • 3.5 Warnings and cautions on page 14 •...
  • Page 12: Installation Checklist

    6. Finger nuts x 3 (used for surface mounting) Unpack you product carefully to prevent damage or loss of parts, check the box contents against the list above. Retain the packaging and documentation for future reference. RS150 Installation instructions...
  • Page 13: Software Updates

    3.3 Software updates 3.4 Tools required for installation The software running on the product can be updated. • Raymarine periodically releases software updates to improve product performance and add new features. • You can update the software for your product using a connected and compatible multifunction display.
  • Page 14: Warnings And Cautions

    EMC installation guidelines Raymarine equipment and accessories conform to the appropriate Electromagnetic Compatibility (EMC) regulations, to minimize electromagnetic interference RS150 Installation instructions...
  • Page 15: Product Dimensions

    For optimum EMC performance we recommend that wherever possible: • Raymarine equipment and cables connected to it are: – At least 1 m (3 ft) from any equipment transmitting or cables carrying radio signals e.g.
  • Page 16 RS150 Installation instructions...
  • Page 17: Chapter 4 Cables And Connections

    Chapter 4: Cables and connections Chapter contents • 4.1 General cabling guidance on page 18 • 4.2 Connections overview on page 18 • 4.3 SeaTalk ng® power supply on page 19 • 4.4 NMEA 2000 network connection on page 21 •...
  • Page 18: General Cabling Guidance

    • Unless otherwise stated use only standard cables of the correct type, supplied by Raymarine. NMEA 2000 SeaTalk backbone DeviceNet • Ensure that any non-Raymarine cables are of the adaptor correct quality and gauge. For example, longer cable power cable runs may require larger wire gauges (A06045) to minimize voltage drop along the run.
  • Page 19: Seatalk Ng® Power Supply

    In the example above the system has an overall LEN please consult an authorized Raymarine dealer or of 10, so the optimum connection point would be to a suitably qualified professional marine electrician.
  • Page 20 (12 V dc) is available at the SeaTalk ng® backbone’s power connection. More information Raymarine recommends that best practice is observed in all vessel electrical installations, as detailed in the following standards: • BMEA Code of Practice for Electrical and Electronic Installations in Boats •...
  • Page 21: Nmea 2000 Network Connection

    DeviceNet adaptor cable 1. SeaTalk ng® (A06045) 2. SeaTalk ng® VHF Radio 3. DeviceNet T-piece 3. RS150 GNSS Receiver 4. NMEA 2000 backbone 4. Evolution EV sensor 5. SeaTalk Pilot controller 6. ACU (Actuator Control Unit) 7. SeaTalk to SeaTalk ng® converter...
  • Page 22 RS150 Installation instructions...
  • Page 23: Chapter 5 Installation

    Chapter 5: Installation Chapter contents • 5.1 Surface mounting on page 24 • 5.2 Pole mounting on page 24 Installation...
  • Page 24: Surface Mounting

    1 inch 14 TPI thread. only). 7. Position the unit so that the mounting studs pass through the holes in the mounting surface. 8. Secure the unit to the mounting surface using the thumb nuts provided. (these should be hand-tight only). RS150 Installation instructions...
  • Page 25: Chapter 6 System Checks And Troubleshooting

    Chapter 6: System checks and troubleshooting Chapter contents • 6.1 Initial test on page 26 • 6.2 Troubleshooting on page 28 System checks and troubleshooting...
  • Page 26: Initial Test

    GPS constellation. represent an error of approximately 15 m. Please • Square — A square identifies an (SBAS) remember that even a very low HDOP figure is differential satellite. NO guarantee that your receiver is providing an RS150 Installation instructions...
  • Page 27 accurate position. If in doubt, check the displayed vessel position in the Chart application against your actual proximity to a known charted object. • Estimated Horizontal Position Error (EHPE) — EHPE is a measure of the estimated error of a position fix in the horizontal plane. The value displayed indicates that your position is within a circle radius of the stated size 50% of the time.
  • Page 28: Troubleshooting

    All Raymarine products are, prior to packing and shipping, subjected to comprehensive test and quality assurance programs. However, if you experience problems with the operation of your...
  • Page 29 GNSS troubleshooting Problems with the GNSS and their possible causes and solutions are described here. Problem Possible causes Possible solutions “No Fix” GNSS status icon is Geographic location or prevailing Check periodically to see if a fix is obtained in better displayed.
  • Page 30 (Can take up to 5 minutes at first use or after factory reset or software update) Green • Compass linearizing • No GPS Signal • Bus not connected / fault 1.75s 1.75s • Bus connected but not receiving data 0.29s RS150 Installation instructions...
  • Page 31: Chapter 7 Maintenance

    Chapter 7: Maintenance Chapter contents • 7.1 Service and maintenance on page 32 • 7.2 Routine equipment checks on page 32 • 7.3 Product cleaning on page 33 Maintenance...
  • Page 32: Service And Maintenance

    7.1 Service and maintenance 7.2 Routine equipment checks This product contains no user serviceable Raymarine strongly recommends that you complete components. Please refer all maintenance a number of routine checks to ensure the correct and and repair to authorized Raymarine dealers.
  • Page 33: Product Cleaning

    7.3 Product cleaning Best cleaning practices. When cleaning products: • If your product includes a display screen, do NOT wipe the screen with a dry cloth, as this could scratch the screen coating. • Do NOT use abrasive, or acid or ammonia based products.
  • Page 34 RS150 Installation instructions...
  • Page 35: Chapter 8 Technical Support

    Chapter 8: Technical support Chapter contents • 8.1 Raymarine product support and servicing on page 36 • 8.2 Learning resources on page 37 Technical support...
  • Page 36: Raymarine Product Support And Servicing

    Servicing and warranty 3614 905 Raymarine offers dedicated service departments for Sweden support.se@raymarine.com warranty, service, and repairs. (0)317 (Raymarine subsidiary) Don’t forget to visit the Raymarine website to 633 670 register your product for extended warranty benefits: Finland +358 support.fi@raymarine.com http://www.raymarine.co.uk/display/?id=788. (0)207...
  • Page 37: Learning Resources

    Internet connection. • Some videos are only available in English. Training courses Raymarine regularly runs a range of in-depth training courses to help you make the most of your products. Visit the Training section of the Raymarine website for more information: •...
  • Page 38 RS150 Installation instructions...
  • Page 39: Chapter 9 Technical Specification

    Chapter 9: Technical specification Chapter contents • 9.1 Technical specification on page 40 Technical specification...
  • Page 40: Technical Specification

    < 5 m (95%) Speed accuracy (95%) < 0.3 kt Time to first fix from cold start < 2 minutes (< 45 seconds typical) Time to first fix from hot start < 8 seconds Geodetic Datum WGS84 RS150 Installation instructions...
  • Page 41: Chapter 10 Spares And Accessories

    Chapter 10: Spares and accessories Chapter contents • 10.1 Accessories on page 42 • 10.2 SeaTalk ng® cabling components on page 42 • 10.3 SeaTalk ng® cables and accessories on page 43 Spares and accessories...
  • Page 42: Accessories

    T-pieces. Used to branch, split, or SeaTalk 5–way connector make additional connections in SeaTalk or SeaTalk networks. Blanking plug Inserted into unused spur connector positions in a 5-way connector or T-piece. RS150 Installation instructions...
  • Page 43: Seatalk Ng® Cables And Accessories

    10.3 SeaTalk ng® cables and Description Part No Notes accessories SeaTalk to bare A06044 ends 3 m (9.8 ft) SeaTalk cables and accessories for use with spur compatible products. SeaTalk Power A06049 Description Part No Notes cable SeaTalk starter kit T70134 Includes: SeaTalk A06031...
  • Page 44 RS150 Installation instructions...
  • Page 45: Appendix A Nmea 2000 Pgn Support

    Appendix A NMEA 2000 PGN support The unit supports the following NMEA 2000 PGNs. Description Transmit (Tx) Receive (Rx) 59904 ● ISO Request 59932 ISO Acknowl- ● edgement 60928 ISO Address ● ● Claim ● Commanded 65240 address NMEA - ●...
  • Page 46 RS150 Installation instructions...
