SPECIFICATIONS

Radio setion
Receive range:
FM
AM
Intermediate frequency:
FM
AM
Quieting sensitivity:
FM
AM
Auto tuning stop sensitivity:
FM
AM
CD section
System:
Compact disc audio system
Usable Discs:
Compact disc
Signal to Noise Ratio: More then 60dB
Separation:
More then 55dB
General
Load impedance:
4
Output power:
More then 30W
Power supply voltage: DC13.2V(10.8 to 15.6V)
Negative ground
Dimensions(mm):
187.5(W)
Weight:
1.65kg
NOTE
Specification and design are subject to change without
notice for further improvement.
We cannot supply PWB with component parts in prin-
ciple. When a circuit on PWB has failure, please repair
it by component parts base. Parts which are not men-
tioned in service manual are not supplied.
Clarion Co., Ltd.
5-35-2, Hakusan, Bunkyouku, Tokyo, 112-8608 Japan
Service Dept.- 50 kamitoda,Toda-shi,Saitama,335-8511 Japan Tel: 048-443-1111 FAX:048-433-6996
87.75 & 87.9 to 107.9MHz
(200kHz step)
530 to 1,710Hz(10kHz step)
10.7
±
0.2MHz
450
±
3kHz
Less than 12dB
μ
(at 30dB S/N)
Less than 35dB
μ
(at 20dB S/N)
24
±
6dB
μ
35
±
6dB
μ
Ω
×
2
×
60(H)
×
160(D)
Service Manual
HONDA Automobile Genuine
AM/FM Radio CD Stereo
PH-2416I
Model
(Genuine No.39100-S6M-A000)
(ID No.4XJ0)
Prevent damage caused by static electricity when re-
pairing the pick-up.
The pattern of the pick-up is short-circuiting for preven-
tion.
Remove the soldering with a solder iron whose insula-
tion resistance is larger than 10M
plete connection to the main PWB
For repair table shall use copper or conductive sheet
(with impedance is lower to 100M
a sheet.
Be sure to put on a wrist-strap for prevent electric
static's.(with impedance is to 100M
strap works to drain away the static electricity build-up
on the human body.
And as static electricity build-up on clothes is not drained
away, be careful and not your clothes to touch the pick-
up.
Position of short soldering for pick-up protection posi-
tion is different by model.
Some units have two short soldering points.
Always short LD circuit to open the short circuit and re-
moves by soldering iron.
COMPONENTS
PH-2416I-A
Main unit
CATS CARD
Label
To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow
the instructions so that customers and Engineers
in charge of repair or inspection can avoid suf-
fering any risk or injury.
- 1 -
2005.05.25
Published by Service Dept.
298-5935-00 Oct.2001 P
Printed in Japan
Ω
(DC500V) after com-
Ω
from 1M
Ω
)such as
Ω
from 1M
Ω
) The
−−−−−
1
287-1681-03
1
290-7868-02
1
PH-2416I
