- Page 1 Owner’s manual VX406AU DVD MULTIMEDIA STATION WITH 6.0’’ TOUCH PANEL CONTROL...
-
Page 2: Table Of Contents
Audio Simple Control Mode Screen ............29 iPod Video Menu Operations ................29 iPod Video ID3 Mode Screen ................29 iPod Video List Mode Screen ................30 iPod Video Simple Control Mode Screen ............30 iPod Video Play Mode Screen ................30 iPod Audio Bluetooth Mode ................31 VX406AU... - Page 3 16. HDMI MODE ....................41 Wire Connection of HDMI Mode .................41 Select HDMI Source ..................42 Select DISP Source ...................42 Operate Waze from VX406AU (Android phone only) ..........42 17. AUX .........................43 18. CAMERA INPUT OPERATIONS ..............43 19. REAR SOURCE OPERATIONS ...............44 DVD Video in Rear ....................44 DVD Video Rear Source Control Info Mode.
-
Page 4: Features
Expanding Audio Features Expanding Visual Features External Power Rear Monitor Rear Vision Camera Amplifier iPod ® Memory iPhone ® iPhone/Smartphone via HDMI Bluetooth Telephone NOTE: The items listed outside of the frames are the commercial products generally sold. • VX406AU... -
Page 5: Precautions
Clarion service center. Using it in that condition may cause an accident, fire, or electric shock. • Use a fuse with the same specification only when replacing the fuse. Using a fuse with a different specification may causes a fire. • For the installation of this unit or a change in the installation, ask your authorized dealer or a nearest Clarion service center for safety. Professional skills and experiences are required to do • Do not use the navigation system to locate emergency services. The database does not contain a complete listing of emergency services such as police stations, fire halls, hospitals and walk-in clinics. Please show discretion and ask for directions in such instances. • As the driver, you alone are responsible for your driving safety. - Page 6 3、内容印刷黑色:PANTONE Black C。 4、要求内容印刷正确、清晰，贴纸表面干净、整洁，不得有脏污、斑点、折痕； 切边务必整齐,不得歪斜。 3.This unit uses a precision mechanism. Even 邱 腾 萱 VX406AU 2 0 1 5 0 8 2 5 in the event that trouble arises, never open the case, disassemble the unit, or lubricate the rotating parts.
-
Page 7: Cautions On Handling
When affected by static electricity or When the memorized data is lost or electric noise. Connect/disconnect the USB damaged by any chance, Clarion shall not memory stick when it is not accessed. be liable for any damage. • Connecting with the computer is not When using an USB memory stick, we supported. -
Page 8: Handling Discs
Use of such discs may cause misoperation or damage. • To remove a disc from its storage case, press down on the center of the case and lift the disc out, holding it carefully by the edges. • Do not use commercially available disc protection sheets or discs equipped with stabilizers, etc. These may damage the disc or cause breakdown of the internal mechanism. VX406AU... - Page 9 Other trademarks and trade names are those of their respective owners. • Pandora, the Pandora logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc. used with permission. Pandora is only available in certain countries. Please visit http://www.pandora.com/legal for more information. VX406AU...
-
Page 10: Operation Panel
Press any place of the screen to turn on the monitor again. [RESET] Button • Press this button to hardware reset the unit. Note: When the [RESET] button is pressed, frequencies of radio stations, titles, etc. stored in memory are cleared. VX406AU... -
Page 11: Remote Control
• Batteries (battery pack or batteries installed) the same direction that you removed it. must not be exposed to excessive heat such as Please ensure the tray is inserted in the sunshine, fire or the like. correct direction. VX406AU... -
Page 12: Remote Control Functions
• If the battery leaks, wipe the remote control completely clean and install a new battery. Remote Control Functions You can use the remote control to operate the VX406AU. Note: • The wireless remote control operation may not be optimal in direct sunlight. - Page 13 • Press to eject disc from the unit. • Press to manually select the next lower or higher station in Tuner modes. • Press to perform fast-backward or fast-forward searching. Press again to change the speed to 2x, 4x, 8x or 16x. VX406AU...
-
Page 14: Main Menu
20 - Rear---Touch the button to display the Rear mode. Scrolling the menu Flicking to right or left it will switch to next or previous page of main menu. Moving the menu position 1. Touch any quadrate icon on main menu more than 2 seconds, the icon will float on main menu. 2. Scrolling the floating icon to any position you want. VX406AU... -
Page 15: Dvd Video Player Operations
The CD player is not supported even if it is a hybrid disc. About MP3/WMA/AAC playback This unit can play back CD-R/CD-RW, DVD-R/ RW and DVD+R/RW discs on which MP3/WMA/ AAC music data have been recorded. For a detailed information, see the section entitled “Listening to compressed audio”. VX406AU... -
Page 16: Change Dvd System Settings
When a disc with view restrictions is inserted, you will Note: be prompted to input this password. The disc will not be viewable until the correct password is entered. If you force a disc into before auto reloading, it may damage a disc. VX406AU... -
Page 17: Showing Dvd Player Mode Screen
8 - Total time 2. Input the number of the title/chapter that you want 9 - Menu List button to play with the [0] to [9] key. 10 - System time 3. Touch the [ ] button. 11 - Bluetooth status indicator VX406AU... -
Page 18: Showing Video Files Player Mode Screen
The display will return to 4. Touch [ ] button to fix on the selected item. the playback screen, if you do not touch the screen 5. Touch [ ] button. for 10 seconds. VX406AU... -
Page 19: Operate The Video Files Player Menu
• Picture size: 720 x 480 Skip using seek bar • Audio format: MP3 Touch the ball on seek bar and drag it to any position • Audio sampling frequency: 32/44.1/48 KHz where you want to start playback. VX406AU... - Page 20 • format: MPEG4 Visual Simple @L1 • Picture size: 720 x 405 • Audio format: AAC • Audio sampling frequency: 32/44.1/48 KHz *.mpg files • format: MPEG2 • Picture size: 720 x 480 • Audio format: MP3 • Audio sampling frequency: 32/44.1/48 KHz VX406AU...
-
Page 21: Cd Player Operations
9 - Shortcut button 3. Touch the desired track title button. The 10 - Play/Pause button corresponding track is started playback. 11 - Next Track/Fast Forward button 12 - Shuffle button 13 - Direct Searching button 14 - Scan Start/Stop button VX406AU... -
Page 22: Listening To Compressed Audio
PC). 1.1 and 1.0. • Some noise may occur depending on the type of In displaying, this unit gives priority to the Version 2.3 encoder software used while recording. and 2.4 TAGs. VX406AU... -
Page 23: Playback Mp3/Wma/Aac Menu
1. Touch [ ] button to stop playback. 2. Touch [ ] button again to resume playback. Playback resumes from start of the folder which playing track is in. •Other operations about playing MP3/WMA/AAC are almost same as CD Player mode. VX406AU... -
Page 24: Usb/Sd Audio Operations
WMA AAC/FLAC file). • The maximum allowable number of files in a folder is 65535. • You can store the MP3/WMA/AAC/FLAC files together in a folder. • The system may become slow if the files or folders exceed the limitation above. VX406AU... -
Page 25: Playing Audio Files In Usb/Sd Memory
2. Touch this button again to turn off the feature. Alphabet Search Touch [ ] button to search with alphabet in current list. Album Art work If MP3 audio file contains album art image in ID3, the picture will be displayed in this area. VX406AU... -
Page 26: Usb/Sd Video Operations
4 - Elapsed playing time indicator/Seek bar do not touch the screen for 10 seconds. 5 - Menu List 6 - Repeat button 7 - System time 8 - Bluetooth status indicator 9 - Playback information 10 - Shortcut button VX406AU... - Page 27 This operation is same as this in USB/SD Audio mode. 5 - Repeat button Searching with the Track Number 6 - Shuffle button This operation is same as this in USB/SD Audio mode. 7 - Video files in list 8 - System time VX406AU...
-
Page 28: Ipod Operations
• This system will not operate or may operate improperly with unsupported versions. • For detailed information on the playable iPod/iPhone models, see our home page: www.clarion.com The playback starts after a while, from where the iPod/ iPhone has been paused. -
Page 29: Ipod Audio Playlist Mode Screen
• Touch the button[ ] to go back to the parent folder. If the list is in root, touch it to close the list. • Touch the button[ ] to search with alphabet in current list VX406AU... -
Page 30: Ipod Audio Simple Control Mode Screen
] button to starts playback from the beginning of the next track. • Touch the [ ] button to starts playback from the beginning of the current track. When this button is touched again within about 5 seconds, playback starts from the beginning of the VX406AU... -
Page 31: Ipod Video List Mode Screen
] button to pause during playback. 2. Touch [ ] button again to resume playback. Switch to Previous/Next Track This operation is same as this in iPod Audio mode. • Touch [ ] or [ ] button during playback to play previous/next track. VX406AU... -
Page 32: Ipod Audio Bluetooth Mode
Audio mode. Please refer to the iPod Audio Mode operation. Note: Video playback is not available on all iPod/iPhone devices. Please contact your Clarion dealer for details. An optional connection cable or accessory may be required for this feature. Note: •... -
Page 33: Operations
13 - Current album name • Skipping a track (Pandora mode) Touch [ ] button during playback, tracks are skipped and starts playback from the beginning of the next track. Note: • Some track are not able to be skipped. VX406AU... -
Page 34: Pandora Bluetooth Mode
Pandora doesn’t playback correctly. Please don’t operate the audio player or internet radio other than Pandora when the Pandora mode. 5. During Pandora playback in the Pandora mode with the Bluetooth connection, the volume level is controlled also the mobile phone side. (Both iOS device and Android) VX406AU... -
Page 35: Bluetooth Audio Player Operations
2. Touch the Device button [ ] to display the Device • For detailed information on the playable Bluetooth Select screen. audio players, see our home page: www.clarion.com Selecting the Bluetooth Audio Mode 1. Touch the [BT Audio] button to select the Bluetooth Audio mode. -
Page 36: Selecting The Bluetooth Audio Player
3. Touch the desired Device button you wish to use. Touch [ ] button to select it as your active device. The corresponding cellular phone is set as current telephone. 4. Touch the [ ] button to return to the previous screen. VX406AU... -
Page 37: Bluetooth Telephone Operations
Note: • The input level of the microphone can be affected by its surroundings. Adjust the level if the person on the other end of the telephone has a reception problem. VX406AU... -
Page 38: Registering Your Cellular Phone (Pairing)
5. If entering the Pass Key code is prompted on your cellular phone, enter the Pass Key code set in this unit. • You can change the Pass key setting of this unit from the Bluetooth Info screen under the Telephone Settings screen. VX406AU... - Page 39 2. When the call is finished, touch the [ ] button Note: to hang up. • Depending on some special cellular phone, the Telephone Interrupt screen may be closed and the connection with this system may be disconnected when entering the Private mode. VX406AU...
-
Page 40: Using Siri Eyes Free Function
The indicator change as follows. 3. Talk to Siri the same way as using it on the iPhone. 4. To finish Siri Eyes Free function, touch the [ button. Notes: Siri Eyes Free is available on iOS 6.1 or higher. Please use external mic when you use the Siri Eyes Free function. VX406AU... -
Page 41: Tuner Operations
Recalling a preset station order to separate closely spaced stations. This feature 1. Touch the [FM1/2/3/AM] button to select the desire is useful in areas that have many radio stations in band (FM or AM) on the tuner. close proximity. VX406AU... -
Page 42: Hdmi Mode
4 and iPhone 4s HDMI cable sold in the market 30pin cable 30pin-Digital AV adapter VX406AU (2) Connection with the iPhone 5, iPhone 5s, iPhone 5c, iPhone 6 and iPhone 6 Plus iPhone 5, iPhone 5s, iPhone 5c, HDMI cable sold in the market iPhone 6 and iPhone 6 Plus... -
Page 43: Select Hdmi Source
Touch the HDMI menu button, then appear the screen of the connected device. This HDMI mode is only indicative or an image the screen of the iPhone, Android. You cannot operate by the touch screen of VX406AU. 6. Touch Waze icon. Note: Depending on the application and model of the mobile phone, there is the case that black frame appears around the screen. -
Page 44: Aux
If the reverse cable is connected correctly to the car, the unit goes to camera mode automatically when the car is in reverses. As an additional safety feature, the audio from camera with built-in microphones can be heard through the VX406AU. VX406AU... -
Page 45: Rear Source Operations
DVD Video Rear Source Control Direct 3. Touch the Front button to access the main menu but Mode. not close the Rear Source. DVD Video in Rear NOTE: More detail please refer to DVD Video Front source. VX406AU... -
Page 46: Ipod Video Rear Source Control Play Mode
6 - Repeat button: Same as iPod function of front source 7 - Front/Rear button If the screen displays Rear Source, touch to switch to Front Source. If the screen displays Front Source, touch to switch to Rear Source. VX406AU... -
Page 47: Setting Operations
Shortcut menu and drag it to lower side area. Mute. Version: Display the software version information. Video Setup Menu DVD Wide Screen Mode: Set the DVD wide screen mode On or Off. Dimmer: Set Dimmer value from 0 to 20. VX406AU... -
Page 48: Audio Setup Menu
The numerical keypad is displayed, enter the right code to unlock. Note: If the anti-theft code is lost or forgotten, a charge will be incurred at the owner’s expense by a Clarion service station to unlock the VX406AU. VX406AU... -
Page 49: Troubleshooting
Check that the parking brake is displayed. engaged. engaged. Disc cannot play with Feature exceeds set parental Release the view limitation or the display “PARENTAL level. change the parental level. VIOLATION” shown. See the subsection “Setting up the parental level” VX406AU... -
Page 50: Usb Device
The audio quality is poor after The Bluetooth reception is Move the device closer to the connection with a Bluetooth poor. car audio system or remove enabled device. any obstacle between the device and the system. VX406AU... -
Page 51: Tft Screen
(The liquid crystal panel is produced according to technology with very high precision. Note that, though there are effective pixels of 99.99% or more, pixel missing or normally lit pixels account for 0.01%). VX406AU... -
Page 52: Error Display
Eject the disc then reload it inside the DVD deck and does properly. not play. PARENTAL VIOLATION Parental level error. Set the correct Parental level. Region code error Region code error. Eject the disc, and replace correct region code disc. VX406AU... -
Page 53: Specifications
Screen Size: 6.0” wide type Pixels: 1,152,000 Resolution: 800 x 480 x 3 (RGB) Bluetooth Specification: Bluetooth Ver 4.0 Profile: HFP1.5(Hands Free Profile) HSP1.0 (Headset Profile) A2DP (Advanced Audio Distribution Profile) AVRCP1.2,1.3,1.4 (AV Remote Control Profile) PBAP (Phone Book Access Profile) VX406AU... - Page 54 VX406AU dimensions: VX406AU weight: 2.3 kg VX406AU...
-
Page 55: Wire Connection Guide
• Before installing, be sure to disconnect the negative cable of the car battery. • In the optional devices, the RCA cables and the Connector cables are separately-sold items. • When connect the HDMI and USB cable, be sure to fix with the clamp. Refer to next page CCA-748 (sold separately) VX406AU... - Page 56 Note: *1: Connecting the PHONE INTERRUPT terminal The phone interrupt will mute the audio if the lead receives a negative or ground signal. VX406AU...
- Page 57 Clarion Co., Ltd. 2015/9 All Rights Reserved. Copyright © 2015: Clarion Co., Ltd.
