Troubleshooting Guide
Model No.: SMUS1518435
Product Name: 84" Air Hockey
2015
This guide provides helpful hints and solutions for troubleshooting
of the product above.
Table of Contents
1
Maintain airflow on playfield----------------------------------------------------------------------------------page 1
2
3
No light on one side of Scorer- Home or Visitor ---------------------------------------------------page 3
4
5
6
Replacement Parts# ----------------------------------------------------------------------------------------------- page 5
TM
Electronic Scorer
Advertisement
Table of Contents
Related Manuals for MD SPORTS SMUS1518435
Summary of Contents for MD SPORTS SMUS1518435
- Page 1 Troubleshooting Guide Model No.: SMUS1518435 Product Name: 84" Air Hockey Electronic Scorer 2015 This guide provides helpful hints and solutions for troubleshooting of the product above. Table of Contents Maintain airflow on playfield----------------------------------------------------------------------------------page 1 No light on of Scorer- Home or Visitor and score counter projection light ---------page 2 No light on one side of Scorer- Home or Visitor ---------------------------------------------------page 3 No light on both sides of Scorer- "Home &...
- Page 2 Maintain airflow on playfield Step 1: Keep the playfield clean and maintain the airflow smoothly. a. Please use pin to clean up the holes if any dust on the playfield. b. Please use "furniture polish spray" to clean up the playfield and maintain the airflow smoothly.
- Page 3 No light on of Scorer- Home or Visitor and score counter projection light Step 1: Please check the Adaptor Wire if it is installed properly. Step 2: Please check the Control Wire and Electronic Scorer wire if it is installed properly. If it is still not working: Please replace the Control Box with a new one.
- Page 4 No light on one side of Scorer- Home or Visitor Step 1: Please exchange the Sensor Wire on the Scorer. If it is working: Replace the Goal with Wire with a new one. If it is still not working: Please replace the Control Box with a new one. If it is still not working: Please replace the Scorer Bracket-A, Scorer Bracket-C, Scorer Bracket-or B with a new one.
- Page 5 Step 3: Please check the “Scoring Sensor Wire” if it is connected with the Electronic Scorer well. a. If it is working: Replace the Scoring Sensor Wire with a new one. b. If it is still not working: Please replace the Control Box with a new one. If it is still not working: Please replace the Scorer Bracket-A with a new one.
- Page 6 Replacement Parts# Adaptor ________________________________________________#20 Scorer Bracket-A _________________________________________#25 Scorer Bracket-B__________________________________________#26 Scorer Bracket-C__________________________________________#27 Scoring Sensor Wire_______________________________________#P2 Connect Box_____________________________________________ #p7 If you use the websie to order parts, please do not call our 800 number as well or CHARGES for duplicate shipments will be accessed. Please contact with us if you have any questions.
