WARNING: OWNER'S INSTRUCTION NOTICE NOT TO BE REMOVED
NOTES: 1. Zone 1 may be selected for EOLR supervised
or normally closed (no EOLR) operation via
cut jumper. (Cut red jumper for normally closed
operation. Do not cut for Fire Usage). Zones 2-8
Blue
may be selected for either operation via program
Jumper
field *41.
(note 5)
2. Zone 1 supports 2-wire smoke detectors.
See Installation and Setup Guide for recommended
type and maximum number of detectors supported.
BATTERY
3. Zone 7 may be used for remote keyswitch
TABS
arming/disarming. See Installation and Setup Guide
for wiring instructions.
Connect to
12VDC, 4AH
or 12VDC, 7AH
1 2 3
GEL CELL
BATTERY
CHARGING
VOLTAGE
13.7VDC
Connect to
See
24hr. 120VAC,
Installation
60 Hz Outlet
and Setup Guide
for required
capacity
Replace
TRANSFORMER
every
16.5VAC, 40VA
3 years
ADEMCO No.1361
(IN CANADA
USE No. 1361CN)
or 4300 IF
X-10 DEVICES
BELL
WILL BE USED
+
-
NOTE:
WHEN POWERING UP
THE PANEL, PLUG THE
TRANSFORMER IN BEFORE
CONNECTING THE BATTERY.
SIREN
ALARM SOUNDER OUTPUT 10VDC - 13.8VDC
ASSEMBLED
IN MEXICO
4. Zone 8 supports 2-wire latching type glass break detectors.
See Installation and Setup Guide for recommended type
and maximum number of detectors supported.
5. Cut blue jumper to disable supervision of alarm sounder output.
Leave jumper intact to supervise output. (See Installation and
Setup Guide for Programming and Wiring Instructions).
6. Zone 9 may be used for RS232 input.
Red Jumper
(note 1)
4 5 6 7 8 9 10 11
ZONE 1
+
-
Red Blk Grn Yel
REMOTE KEYPAD
Use FA260 or FA560
(Addressable keypads)
only
2k EOLR
See Installation Instructions
for max # of keypads
and for max wire run length.
+ -
+
-
SMOKE
AUXILARY POWER OUTPUT
9.6VDC - 13.8VDC,
750mA maximum
Note: Include current drawn
N.C.
by keypads and polling loop
devices when making
auxiliary power calculations.
N.O.
Notes For UL Household
Fire Installations
2k EOLR
1. Use 12VDC, 14AH battery
(note 1,2)
2. Maximum auxiliary current,
including polling loop 300mA
3. Combined alarm and auxilary power output
and polling loop current must be limited to 750mA
for UL985 Household Fire Installations.
ALL CIRCUITS ARE
POWER LIMITED.

SUMMARY OF CONNECTIONS

WEEKLY TESTING IS REQUIRED TO ENSURE PROPER OPERATION OF THIS SYSTEM.
J7 Header
1. Not Used
2. Ground-
3. Out 1 (Ground Start)
4. Ground-
5. Out 2 (fire)
6. Ground-
7. Out 3 (burg/aud. panic)
8. Ground
9. Out 4 (silent panic/
duress)
(Refer to Installation and Setup Guide for information concerning Direct Wire
Downloading and printer connections.)
ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 ZONE 7
12 13 14 15 16 17 18 19
+ - + + -
N.C. N.C. N.C.
N.O. N.O. N.O.
2k EOLR 2k EOLR 2k EOLR
(note 1) (note 1) (note 1) (note 1,3)
+ +
-
Fire
Usage
N.C. N.C.
N.O. N.O.
Burg.
Usage
2k EOLR 2k EOLR
(note 1) (note 1)
Zone resistance (Excluding EOLR):
ZONE 1,8: 100 OHMS MAXIMUM
ALL OTHER ZONES: 300 OHMS MAXIMUM
Zone response time:
ZONES 1: 350mSec-500mSec
FA1660C
J8 Header
1. I n 2 (Printer DTR) Optional programming:
Out 1: Smoke Detector Reset
2. Ground
Out 2: Armed LED
3. In 3 (4300 sync)
Out 4: Ready LED
4. In 4 (4300 sync)
Ratings for Out 1:
5. Ground
Active: 10VDC-13.8VDC through 4k OHMS
6. Out 5 (4300 data)
Not Active: 100 OHMS to ground
7. Out 6 (Printer RXD)
Ratings for out 2-4:
8. Ground
Active: 10VDC-13.8VDC through 5k OHMS
9. Ground
Not Active: 1k OHMS to ground
ZONE 8 ZONE 9
20 21 22 23 24 25 26 27
+
-
+
Handset
N.C.
Telephone connections
using Ademco No. 620
RJ31X direct connect
N.O.
cord.
+ - +
4208U
RPM
GLASS
BREAK
4192SD
N.C.
SMOKE
N.C.
4191SN
N.C.
N.O.
PIR
(note 6)
2k EOLR
(note 1,4)
USE UL LISTED ENERGY CABLE FOR ALL CONNECTIONS
Polling loop rating: 128mA max.
See Installation and Setup Guide for
maximum number of devices supported
and maximum wire run length
CONNECTION OF THE FIRE ALARM SIGNAL
TO A FIRE ALARM HEADQUARTERS OR A
THIS DEVICE COMPLIES WITH PART 15 OF
CENTRAL STATION SHALL BE PERMITED
FCC RULES. OPERATION IS SUBJECT TO THE
ONLY WITH THE APPROVAL OF THE LOCAL FOLLOWING TWO CONDITIONS: (1) THIS DEVICE
AUTHORITY HAVING JURISDICTION. THE
BURGLAR ALARM SIGNAL SHALL NOT BE
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE
CONNECTED TO A POLICE EMERGENCY
RECEIVED, INCLUDING INTERFERENCE
NUMBER.
THAT MAY CAUSE UNDESIRED OPERATION.
MAKE CONNECTIONS USING
No. 4142TR CABLE
J8
1 2 3 4 5 6 7 8 9
J7
1 2 3 4 5 6 7 8 9
EARTH GROUND
Connect to good earth
28 29 30
ground to maintain im-
munity to transients.
See Instructions for
proper grounding.
DOC LOAD NO.: 5
Incoming
Phone Line
WARNING: TO PREVENT
RISK OF ELECTRICAL
SHOCK, DISCONNECT
TELCO JACK BEFORE
SERVICING THIS PANEL.
THIS EQUIPMENT SHOULD BE INSTALLED
IN ACCORDANCE WITH THE NATIONAL
FIRE PROTECTION ASSOCIATION'S
STANDARD 72 (NATIONAL FIRE
PROTECTION ASSOC., BATTERYMARCH
PARK. QUINCY, MA. 02269). PRINTED
INFORMATION DESCRIBING PROPER
INSTALLATION, OPERATION, TESTING,
MAINTENANCE, EVACUATION PLANNING
AND REPAIR SERVICE IS TO BE
PROVIDED WITH THIS EQUIPMENT.
COMPLIES WITH FCC RULES, PART 68
FCC REGISTRATION NO. AC398U-68192-AL-E
RINGER EQUIVALENCE: 0.7B
MAY NOT CAUSE HARMFUL INTERFERENCE, AND
FA1660C-SOC-V0
