NordicTrack NTEL99416.0 User Manual

Spacesaver se7i
Hide thumbs

Advertisement

Table of Contents

www.nordictrack.com
Model No. NTEL99416.0
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today, go
to www.nordictrackservice.com/
registration.
CUSTOMER CARE
For service at any time, go to
www.nordictrackservice.com.
Or call 1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTEL99416.0 and is the answer not in the manual?

Questions and answers

Related Manuals for NordicTrack NTEL99416.0

Summary of Contents for NordicTrack NTEL99416.0

  • Page 1 Model No. NTEL99416.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.nordictrackservice.com/ registration. CUSTOMER CARE For service at any time, go to www.nordictrackservice.com.

  • Page 2: Table Of Contents

    NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks of Google Inc. The BLUETOOTH word mark and logos are registered trademarks of Bluetooth SIG, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 18. The heart rate monitor is not a medical 20. Keep your back straight while using the device. Various factors may affect the accu- elliptical; do not arch your back. racy of heart rate readings. The heart rate monitor is intended only as an exercise aid 21.
  • Page 5 STANDARD SERVICE PLANS...

  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK SPACESAVER SE 7I elliptical. The manual. To help us assist you, note the product model ® SPACESAVER SE 7I elliptical provides an impressive number and serial number before contacting us.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • In addition to the included tool(s), assembly requires the following tool(s): • Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you finish all assembly steps.
  • Page 8 3. With the help of another person, place some packing inserts from the packing material under the Frame (1) so that the Frame is lifted off the floor. Have another person hold the elliptical to prevent it from moving from side to side until this step is completed.
  • Page 9 5. Rotate the Right Upper Body Arm (9) to the posi- tion shown. Attach the Right Upper Body Arm (9) to the Right Upper Body Leg (6) with an M10 x 50mm Screw (95). Next, tighten the indicated M10 x 45mm Hex Screw (78).

  • Page 10: How To Use The Elliptical

    HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER CORD A temporary adapter may 2-pole Receptacle This product must be grounded. If it should mal- be used to function or break down, grounding provides a path of connect the Adapter least resistance for electric current to reduce the risk power cord...
  • Page 11 HOW TO MOVE THE ELLIPTICAL HOW TO LEVEL THE ELLIPTICAL Due to the size and weight of the elliptical, moving If the elliptical it requires two persons. rocks slightly on your floor dur- First, loosen the ing use, turn upright knob. one or both of Next, pull the the leveling feet...
  • Page 12 HOW TO EXERCISE ON THE ELLIPTICAL See HOW TO MOVE THE ELLIPTICAL on page 11 and lower the upright to the folded position. To mount the elliptical, hold the handlebars or the upper body arms and step onto the pedal that is in the Next, hold the handle (not shown) on the front stabi- lower position.
  • Page 13 CONSOLE DIAGRAM FEATURES OF THE CONSOLE The advanced console offers an array of features designed to make your workouts more effective and enjoyable. When you use the manual mode of the console, you can change the resistance of the pedals and the incline of the frame with the touch of a button.
  • Page 14 HOW TO TURN ON THE POWER Note: After you press a button, it will take a moment for the pedals to reach the selected IMPORTANT: If the elliptical has been exposed to resistance level. cold temperatures, allow it to warm to room tem- perature before you turn on the power.
  • Page 15 Pulse Average (BPM AVG)—This display will Press the Home button to exit the workout and show your average heart rate in beats per minute return to the main menu. If necessary, press the (bpm) when you use the handgrip heart rate moni- Home button again.
  • Page 16 6. Turn on the fan if desired. HOW TO USE AN ONBOARD WORKOUT The fan has several speed 1. Begin pedaling or press any button on the console to turn on the console. settings, including an auto mode. While the auto mode is selected, the speed of the See HOW TO TURN ON THE POWER on fan will automatically increase or decrease as your...
  • Page 17 HOW TO CONNECT YOUR TABLET TO THE As you exercise, keep your pedaling speed near the target speed for the current segment. CONSOLE IMPORTANT: The target speed is intended only The console supports BLUETOOTH connections to to provide motivation. Your actual pedaling tablets via the iFit Bluetooth Tablet app and to compat- speed may be slower than the target speed.
  • Page 18 4. Record and track your workout information. HOW TO USE THE SOUND SYSTEM Follow the instructions in the iFit Bluetooth Tablet To play music or audio books through the console app to record and track your workout information. sound system while you exercise, plug a 3.5 mm male to 3.5 mm male audio cable (not included) into the 5.

  • Page 19: Fcc Information

    HOW TO CHANGE CONSOLE SETTINGS Incline System Calibration— If the incline sys- tem is not functioning properly, it may need to be 1. Select the settings mode. calibrated. To calibrate the incline system, press the Incline increase or decrease button. The frame To select the settings mode, press the Settings will move upward and downward as it calibrates.

  • Page 20: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE Then, look into the access opening and locate the Reed Switch (58). Rotate the Pulley (66) until a Regular maintenance is important for optimal Magnet (41) is aligned with the Reed Switch. performance and to reduce wear. Inspect and properly tighten all parts each time the elliptical is used.
  • Page 21 HOW TO ADJUST THE DRIVE BELT shown) from the Large Storage Foot (27), and remove the Large Storage Foot. Remove the two M4 x 16mm If the pedals slip while you are pedaling, even while the Screws (not shown) from the Top Shield (37), and resistance is adjusted to the highest setting, the drive then use a standard screwdriver to pry the Top Shield belt may need to be adjusted.

  • Page 22: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 23: Part List

    PART LIST Model No. NTEL99416.0 R1116A Key No. Qty. Description Key No. Qty. Description Frame Small Storage Foot Upright Idler Rear Upright Cover Small Spacer Console Resistance Motor Accessory Tray Axle Cover Right Upper Body Leg M4 x 12mm Washer Head Screw...
  • Page 24 Key No. Qty. Description Key No. Qty. Description Left Upper Body Leg M6 x 16mm Screw Upright Axle Right Pedal Pad M8 x 20mm Hex Bolt Left Pedal Pad Lift Frame Right Pedal Handle Lift Motor Left Pedal Handle Control Board Right Pedal Plate Control Board Bracket Left Pedal Plate...

  • Page 28: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, see the front cover of this manual. To help us assist you, please be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
