Machine Disassembly and Replacement
IMPORTANT:The outside housing and color may vary from the mass produced model.
This chapter contains step-by-step procedures on how to disassemble the notebook computer for
maintenance and troubleshooting.
Disassembly Requirements
To disassemble the computer, you need the following tools:
•
•
•
•
•
NOTE: The screws for the different components vary in size. During the disassembly process, group the
Chapter 3
Downloaded from
www.Manualslib.com
Wrist grounding strap and conductive mat for preventing electrostatic discharge
Flat screwdriver
Philips screwdriver
Plastic flat screwdriver
Plastic tweezers
screws with the corresponding components to avoid mismatch when putting back the components.
manuals search engine
Chapter 3
41
