Page 3 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each component adjustment before driving, etc.
Page 4: Table Of Contents
TABLE OF CONTENTS For your information .......8 Instrument cluster Reading this manual.....12 How to search ......13 Pictorial index .......14 Instrument cluster Warning lights For safety and security and indicators....76 Gauges and meters..... 82 Multi-information display 1-1. For safe use (Type A) ......
Page 5 Operation of Driving each component 3-1. Key information 4-1. Before driving Keys........102 Driving the vehicle..... 142 Cargo and luggage.... 153 3-2. Opening, closing and locking the doors Trailer towing (for Australia) ....154 Side doors......107 Access panels (smart-cab 4-2. Driving procedures models only) ....112 Engine (ignition) switch Tailgate ......113...
Page 6 TABLE OF CONTENTS 4-5. Using the driving support 5-4. Using the audio system systems Selecting the audio Cruise control.....201 source ......264 Rear view monitor List screen operation..266 system ......205 Optimal use of the audio Four-wheel drive system..215 system......269 Rear differential lock Audio screen system ......219...
Page 7 ® 5-9. Bluetooth Audio Interior features ® Listening to Bluetooth audio........308 ® 5-10. Bluetooth Phone 6-1. Using the air conditioning ® system and defogger Using a Bluetooth Phone ......310 Manual air conditioning Making a call......312 system......348 Receiving a call....317 Automatic air conditioning system......
Page 8 TABLE OF CONTENTS 8-2. Steps to take in an Maintenance and care emergency If your vehicle needs to be towed ..... 439 7-1. Maintenance and care If you think something is Cleaning and protecting wrong ......445 the vehicle exterior ..376 Fuel pump shut off Cleaning and protecting system (gasoline engine...
Page 9 Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.)...494 Fuel information ....512 9-2. Customization Customizable features ..514 Index What to do if... (Troubleshooting) .....520 Alphabetical index ......524 For vehicles with navigation system or multimedia system, refer to the “Navigation and Multimedia System Owner’s Manual” for information regarding the equipment listed below.
Page 10: For Your Information
SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of an RF-transmitter system. Further information regarding frequency bands, power levels, antenna posi- tions and installation provisions for the installation of RF-transmitters, is avail-...
Page 11 ● Data usage Toyota may use the data recorded in these computers to diagnose malfunc- tions, conduct research and development, and improve quality. Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 12 EDR. ● Disclosure of the EDR data will not disclose the data recorded in an EDR to a third party except Toyota when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained •...
Page 13 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 14: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. 1 2 3 Indicates operating or working procedures.
Page 15: How To Search
How to search ■ Searching by name • Alphabetical index ..P. 524 ■ Searching installation position • Pictorial index....P. 14 ■ Searching by symptom or sound • What to do if... (Troubleshooting) ..P. 520 ■ Searching by title •...
Page 16: Pictorial Index
Pictorial index Pictorial index ■ Exterior The shape of the headlights may differ depending on the grade etc. (→P. 419) Side doors ........P. 107 Access panels (smart-cab models only) .
Page 17 Pictorial index Windshield wipers ....... . . P. 194 Precautions against winter season ..... P. 238 Fuel filler door .
Page 18 Pictorial index ■ Instrument panel Engine switch ....... . P. 164, 167 Starting the engine/changing the positions or modes .
Page 19 Pictorial index Meters ..........P. 82 Reading the meters .
Page 20 Pictorial index ■ Switches Power window switches ......P. 136 Window lock switch ....... P. 137 Door lock switch .
Page 21 Pictorial index Audio remote control switches ....P. 252 Talk switch Meter control switches ......P. 91 “DISP”...
Page 22 Pictorial index Emergency flasher switch ......P. 436 Front-wheel drive control switch ....P. 215 Power outlets .
Page 23 Pictorial index ■ Interior SRS airbags ........P. 35 Floor mats .
Page 24 Pictorial index Cup holders ........P. 364 Auxiliary boxes .
Page 25 Pictorial index Inside rear view mirror ......P. 132 Sun visors ........P. 370 Vanity mirror .
Page 26 Pictorial index...
Page 27: For Safety And Security
For safety and security 1-1. For safe use Before driving.......26 For safety drive ....28 Seat belts......30 SRS airbags......35 Exhaust gas precautions ..45 1-2. Child safety Riding with children....46 Child restraint systems ..47 1-3. Theft deterrent system Engine immobilizer system .......71 Alarm ........73...
Page 28: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 29 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 30: For Safety Drive
1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 31 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (→P. 132, 133) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 32: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 33 1-1. For safe use Adjusting the seat belt shoulder anchor height (if equipped for front seats) Push the seat belt shoulder anchor down while pulling the lock release knob. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 34 If the vehicle is involved in multiple collisions, the pretensioner will activate for the first collision, but will not activate for the second or subsequent collisions. ■ Seat belt regulations If seat belt regulations exist in the country where you reside, please contact your Toyota dealer for seat belt replacement or installation.
Page 35 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 36 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 37: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 38 1-1. For safe use SRS airbag system components Front impact sensors Side airbags Driver airbag Curtain shield airbags SRS warning light Side impact sensors (rear) Side impact sensors (front Front passenger airbag door) Airbag sensor assembly Seat belt pretensioners and Driver’s knee airbag force limiters The main SRS airbag system components are shown above.
Page 39 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats (if equipped) of the vehicle and properly restrained. The rear seats (if equipped) are safer for infants and children than the front passen- ger seat.
Page 40 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 41 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board, steering wheel pad and lower portion of the instrument panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.
Page 42 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 43 1-1. For safe use ■ If the SRS airbags deploy (inflate) ● Bruising and slight abrasions may result from contact with a deploying (inflating) SRS airbag. ● A loud noise and white powder will be emitted. ● Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the front seats, parts of the front and rear pillars, and roof side rails, may be hot for several minutes.
Page 44 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags, SRS side and curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 45 Vehicle rollover ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
Page 46 1-1. For safe use ● A portion of a door or its surrounding area is damaged or deformed, or the vehicle was involved in an accident that was not severe enough to cause the SRS side and curtain shield airbags to inflate.
Page 47: Exhaust Gas Precautions
Exhaust pipe The exhaust system needs to be checked periodically. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer.
Page 48: 1-2. Child Safety
1-2. Child safety Riding with children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. ● It is recommended that children sit in the rear seats (if equipped) to avoid accidental contact with the shift lever, wiper switch etc.
Page 49: Child Restraint Systems
1-2. Child safety Child restraint systems Before installing a child restraint system in the vehicle, there are precautions that need to be observed, different types of child restraint systems, as well as installation methods, etc., written in this manual. Use a child restraint system when riding with a small child that can not properly use a seat belt.
Page 50 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 51: Child Restraint System
1-2. Child safety Child restraint system Install the available child restraint system in vehicle upon confirming the following items. ■ Standards for child restraint systems Use a child restraint system that conforms to ECE R44 1, 2 ECE R129 The following approval mark is displayed on child restraint systems which are conformed.
Page 52 1-2. Child safety ■ Mass group (ECE R44 only) This Mass group table is required when confirming the child restraint system compatibility. Confirm in accordance with the child restraint system compatibility table. (→P. 55, 64) The child restraint system which conforms to the standard of ECE R44 is categorized into 5 groups according to the weight of the child.
Page 53 1-2. Child safety ■ Types of child restraint system installation methods Confirm with the operation manual enclosed with the child restraint system about the instruction of the child restraint system. Installation method Page Seat belt P. 55 attachment ISOFIX rigid anchor P.
Page 54: When Using A Child Restraint System
1-2. Child safety When using a child restraint system ■ When installing a child restraint system to a passenger seat For the safety of a child, install child restraint systems to a rear seats. When installing child restraint system to a front passenger seat is unavoidable, adjust the passenger seat as follows and install the child restraint system.
Page 55 1-2. Child safety WARNING ■ When using a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● Extreme Hazard! Do not use a rearward facing child restraint on a seat protected by an airbag in front of it! This is because the force of the rapid inflation of the front passenger airbag can cause...
Page 56 1-2. Child safety WARNING ■ When using a child restraint system ● Only put a forward-facing child restraint system on the front seat when unavoid- able. When installing a forward-facing child restraint on the front passenger seat, move the seat as far back as pos- sible.
Page 57: Fixed With A Seat Belt
1-2. Child safety Child restraint system fixed with a seat belt The child restraint system suitability table (→P. 55), with symbols, dis- plays the types of usable child restraint systems and possible seating position installation for the child restraint system owned by the cus- tomer.
Page 58 1-2. Child safety Single-cab models Seating position Mass groups Front passenger seat Up to 10 kg (22 lb.) Up to 13 kg (28 lb.) Rearward-facing — 9 to 18 kg Forward-facing — (20 to 39 lb.) 1, 2 II, III 1, 2 15 to 36 kg (34 to 79 lb.)
Page 59 1-2. Child safety Smart-cab models Seating position Mass groups Front passenger seat Rear seat Up to 10 kg (22 lb.) Up to 13 kg (28 lb.) Rearward-facing — 9 to 18 kg Forward-facing — (20 to 39 lb.) 1, 2 II, III 1, 2 15 to 36 kg...
Page 60 1-2. Child safety Double-cab models Seating position Mass groups Rear seat Front passenger seat Outboard Center Up to 10 kg (22 lb.) Up to 13 kg (28 lb.) Rearward-facing — 9 to 18 kg Forward-facing — (20 to 39 lb.) 1, 2 II, III 1, 2...
Page 61 1-2. Child safety Double-cab models: When securing some types of child restraint sys- tems in rear seat, it may not be possible to properly use the seat belts in positions next to the child restraint without interfering with it or affecting seat belt effectiveness.
Page 62 You may need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the following item from your Toyota dealer: Locking clip for child restraint system (Part No. 73119-22010) ■...
Page 63 1-2. Child safety WARNING ■ When installing a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious inju- ries that could result in death.
Page 64: Fixed With An Isofix Rigid Anchor
1-2. Child safety Child restraint system fixed with an ISOFIX rigid anchor ■ ISOFIX rigid anchors (ISOFIX child restraint system) Lower anchors are provided for the outboard rear seats. (Tags displaying the location of the anchors are attached to the seats.) ■...
Page 65 1-2. Child safety ■ Confirming the Mass group and Size class for ECE R44 ISOFIX corresponding child restraint systems Confirm the corresponding [Mass group] from the weight of the child (→P. 50) (Ex. 1) When the weight is 12 kg, [Mass group 0+] (Ex.
Page 66 1-2. Child safety ■ Child restraint systems fastened with ISOFIX (ECE R44) - Com- patibility table ISOFIX child restraint systems are divided in different “size class”. According to this “size class”, you will be allowed to use it in the vehicle seating position mentioned in the table below.
Page 67 1-2. Child safety Double-cab models Seating position Front seat Rear seat Mass groups Size class Passenger Outboard Center seat Carrycot Up to 10 kg (22 lb.) Up to 13 kg (28 lb.) 9 to 18 kg (20 to 39 lb.) Key of letters inserted in the above table: Not suitable seat position for ISOFIX child restraint systems in this mass group and/or size class.
Page 68 1-2. Child safety When securing some types of child restraint systems in rear seat, it may not be possible to properly use the seat belts in positions next to the child restraint without interfering with it or affecting seat belt effec- tiveness.
Page 69 1-2. Child safety When securing some types of child restraint systems in rear seat, it may not be possible to properly use the seat belts in positions next to the child restraint without interfering with it or affecting seat belt effec- tiveness.
Page 70: Using A Child Restraint Anchor Fitting
1-2. Child safety ■ When removing the head restraint to install a child restraint system After removing the child restraint system, make sure to reinstall the head restraint. WARNING ■ When installing a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury.
Page 71 1-2. Child safety ■ Fixing the strap to the anchor fitting Install the child restraint system in accordance to the operation manual enclosed with the child restraint system. Remove the head restraint. Pull up the anchor strap router. Route the upper anchorage strap through the anchor Anchor strap router strap router as shown in the...
Page 72 1-2. Child safety Latch the attaching clip onto the anchor fitting and tighten the upper anchorage strap. Anchor fitting Make sure the upper anchorage strap is securely latched. (→P. 61) ■ When removing the head restraint to install a child restraint system After removing the child restraint system, make sure to reinstall the head restraint.
Page 73: Engine Immobilizer System
1-3. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 74 1-3. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type engine immobilizer system. ■ Conditions that may cause the system to malfunction ● If the grip portion of the key is in contact with a metallic object ●...
Page 75: Alarm
1-3. Theft deterrent system ∗ Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door is opened in any way other than using the entry func- tion, wireless remote control or mechanical key.
Page 76 1-3. Theft deterrent system Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarms: ● Unlock the doors. ● Start the engine. (The alarm will be deactivated or stopped after a few seconds.) ■ System maintenance The vehicle has a maintenance-free type alarm system.
Page 77: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ....76 Gauges and meters .....82 Multi-information display (Type A)......87 Multi-information display (Type B)......90 Fuel consumption information......98...
Page 78: Instrument Cluster Warning Lights
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustrations dis- play all warning lights and indicators illuminated.
Page 79 2. Instrument cluster Vehicles with multi-information display type B Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Brake system warning ABS warning light light (→P. 447) (→P. 448) Charging system Slip indicator light warning light (→P.
Page 80 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. : The light turns on or flashes to indicate a malfunction.
Page 81 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator VSC OFF indicator (→P. 187) (→P. 223) Headlight high beam “TRC OFF” indicator indicator (→P. 190) (→P. 223) (if equipped) Tail light indicator Four-wheel drive (→P.
Page 82 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. : The light turns to green. : The light flashes to indicate that the system is operating.
Page 83 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.
Page 84: Gauges And Meters
2. Instrument cluster Gauges and meters Vehicles without multi-information display Vehicles with multi-information display type A...
Page 85 2. Instrument cluster Vehicles with multi-information display type B Tachometer Displays the engine speed in revolutions per minute. Outside temperature Displays the outside temperature. The temperature range that can be dis- played is from -40°C (-40°F) to 50°C (122°F). The low outside temperature indicator comes on when the ambient temperature is approximately 3°C (37°F) or lower, and goes off when approximately 5°C (41°F) or higher.
Page 86 2. Instrument cluster Engine coolant temperature gauge Displays the engine coolant temperature. Changing the display Vehicles without multi-information display Pressing this button switches between odometer and trip meter dis- plays. Odometer Trip meter A Trip meter B : Pressing and holding the button will reset the trip meter.
Page 87 When the outside temperature has changed suddenly (at the entrance/exit of a garage, tunnel, etc.) ■ When “--” is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. WARNING ■ The information display at low temperatures (vehicles with multi-infor-...
Page 88 2. Instrument cluster NOTICE ■ To prevent damage to the engine and its components ● Do not let the indicator needle of the tachometer enter the red zone, which indicates the maximum engine speed. ● The engine may be overheating if the engine coolant temperature gauge is in the red zone (H).
Page 89: Multi-Information Display (Type A)
2. Instrument cluster ∗ Multi-information display (Type A) Display contents The multi-information display presents the driver with a variety of driv- ing-related data. ● Trip information (→P. 88) Displays driving range, fuel con- sumption other cruising- related information. ● Setting (→P. 515) The settings of the following items can be changed.
Page 90 2. Instrument cluster Switching the display “DISP” button Items displayed can be switched by pressing the “DISP” button. Trip information ■ Current fuel consumption Displays the current rate of fuel consumption. ■ Average fuel consumption Displays the average fuel consumption since the engine switch is turned to the “ON”...
Page 91 2. Instrument cluster ■ Average vehicle speed Displays the average vehicle speed since the engine switch is turned to the “ON” position (vehicles without smart entry & start sys- tem) or IGNITION ON mode (vehicles with smart entry & start sys- tem).
Page 92: Multi-Information Display (Type B)
2. Instrument cluster ∗ Multi-information display (Type B) Display contents The multi-information display presents the driver with a variety of vehi- cle data. The following information will be displayed when a menu icon is selected. (→P. 91) Some of the information may be displayed automatically depend- ing on the situation.
Page 93 2. Instrument cluster Warning message display Select to display warning messages and measures to be taken if a malfunction is detected. (→P. 454) Settings display Select to change the meter display settings. (→P. 515) Operating the meter control switches The multi-information display is operated using the meter control switches.
Page 94 2. Instrument cluster Drive information Items displayed can be switched by pressing “<” or “>” of the meter control switches to select and pressing “∧” or “∨”. ● Current fuel economy (bar type/value type) 1, 2 Displays the current rate of fuel consumption. 1, 2 ●...
Page 95 2. Instrument cluster ● Eco Driving Indicator Zone Display (if equipped) Displays Zone of Eco driving with current Eco driving ratio based on acceleration. (→P. 80) ● Eco Score (if equipped) Displays the eco-driving total count to help improve the customer’s eco driving techniques.
Page 96 2. Instrument cluster Settings display The settings of the following items can be changed, refer to P. 514 ● Units Select to change the unit for measure of the fuel consumption. ● Eco Driving Indicator Light (if equipped) Select to activate/deactivate the Eco Driving Indicator Light. ( →...
Page 97 2. Instrument cluster ■ Pop-up display In some situations, such as when a switch operation is performed, a pop-up display will be temporarily displayed on the multi-information display. The pop-up display function can be set on/off. (→P. 515) ■ Eco Score (if equipped) Driving conditions are displayed in 5 stages and divided into 3 categories: start, cruise and stop.
Page 98 2. Instrument cluster ■ Eco Saving (if equipped) Displays the fuel consumption comparison, the average fuel consumption after reset, and the cost of the consumed fuel. Fuel consumption comparison Displays the set fuel consumption that is compared with the actual fuel con- sumption.
Page 99 2. Instrument cluster WARNING ■ Eco Score Use the Eco Score as a reference. Always drive safely in accordance with road and traffic conditions.
Page 100: Fuel Consumption Information
2. Instrument cluster ∗ Fuel consumption information The fuel consumption information can be displayed on the navi- gation system or multimedia system screen. Display the trip information or past record screen Audio system with “CAR” button Press the “CAR” button. Audio system with “APPS”...
Page 101 2. Instrument cluster ■ Past record If the past record screen does not appear, select “Past record”. Reset the past record data Best recorded fuel consump- tion Average fuel consumption (if equipped) Previous fuel consumption record Current fuel consumption Update the past record data “Trip information”...
Page 102 2. Instrument cluster...
Page 103: Operation Of Each Component
Operation of each component 3-1. Key information Keys........102 3-2. Opening, closing and locking the doors Side doors......107 Access panels (smart-cab models only) ....112 Tailgate ......113 Smart entry & start system ......115 3-3. Adjusting the seats Front seats......122 Rear seats ......124 Head restraints ....127 3-4.
Page 104: 3-1. Key Information
3-1. Key information Keys The keys The following keys are provided with the vehicle. Vehicles without smart entry & start system Master keys Operating the wireless remote con- trol function (→P. 103) Valet key Key number plate Vehicles with smart entry & start system Electronic keys •...
Page 105 3-1. Key information Wireless remote control Vehicles without smart entry & start system Locks all the doors (→P. 107) Check that the door is securely locked. Unlocks all the doors (→P. 107) Vehicles with smart entry & start system Locks all the doors (→P. 107) Check that the door is securely locked.
Page 106 3-1. Key information Using the master key (vehicles without smart entry & start sys- tem) Releasing To release the key, press the but- ton. Folding To stow the key back in its case, push the key back to the stowed position while pressing the button.
Page 107 ■ If you lose your keys New genuine keys can be made by your Toyota dealer using a master key (vehicles without smart entry & start system) or the other key (vehicles with smart entry & start system) and the key number stamped on your key number plate.
Page 108 When an electronic key is lost (vehicles with smart entry & start sys- tem) If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that were provided with your vehicle.
Page 109: Side Doors
3-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry func- tion, wireless remote control, key or door lock switch. Locking and unlocking the doors from outside ◆ Smart entry & start system (if equipped) While carrying the electronic key, press the button to lock and unlock.
Page 110 3-2. Opening, closing and locking the doors ◆ Vehicles without smart entry & start system Locks all the doors Unlocks all the doors Vehicles with smart entry & start system The doors can also be locked and unlocked with the mechanical key.
Page 111 3-2. Opening, closing and locking the doors ■ Setting the alarm (if equipped) Locking the doors will set the alarm system. (→P. 73) ■ If a symbol indicating one or more doors are open is shown on the multi- information display (if equipped) One or more of the doors is not fully closed.
Page 112 3-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. Close the door while pulling the door handle. Vehicles without smart entry & start system: The driver’s door cannot be locked if either of the door is open and the key is in the engine switch.
Page 113 3-2. Opening, closing and locking the doors ■ Conditions affecting operation Vehicles without smart entry & start system The wireless remote control function may not operate normally in the follow- ing situations: ● Near a TV tower, radio station, electric power plant, airport or other facility that generates strong radio waves ●...
Page 114: Access Panels (Smart-Cab Models Only)
3-2. Opening, closing and locking the doors Access panels (smart-cab models only) The access panels (rear door) can be opened using the inside handle. Open the front door widely. Pull (from the outside) or push (from the inside) the inside han- dle of the access panels.
Page 115: Tailgate
3-2. Opening, closing and locking the doors ∗ Tailgate The tailgate can be opened by the following procedures. Opening the tailgate Type A Unlock the latches and open the tailgate slowly. The support stays will hold the tail- gate horizontal. After closing the tailgate, try pulling it toward you to make sure it is securely locked.
Page 116 3-2. Opening, closing and locking the doors Lowering the tailgate Release the brackets on the sup- port stays from the lugs on both sides as shown in the illustration. Rear step bumper The rear step bumper is for rear end protection and easier step-up loading.
Page 117: Smart Entry & Start System
3-2. Opening, closing and locking the doors ∗ Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ●...
Page 118 3-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) of either of the lock/unlock button on the outside door handle.
Page 119 3-2. Opening, closing and locking the doors ■ Alarms and warning indicators A combination of exterior and interior alarms as well as warning messages shown on the multi-information display are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate mea- sures in response to any warning message on the multi-information display.
Page 120 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart entry & start system uses weak radio waves. In the following situa- tions, the communication between the electronic key and the vehicle may be affected, preventing the smart entry & start system, wireless remote control and engine immobilizer system from operating properly.
Page 121 (6 ft.) of the vehicle. ● The smart entry & start system can be deactivated in advance. Ask your Toyota dealer for details. ■ To operate the system properly Make sure to carry the electronic key when operating the system. Do not get the electronic key too close to the vehicle when operating the system from the outside of the vehicle.
Page 122 Retrieve the electronic key from the vehicle and lock the doors again. ■ Customization that can be configured at your Toyota dealer Settings (e.g. smart entry & start system) can be changed. (Customizable features: →P. 514) ■...
Page 123 (→P. 115) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitting radio waves.
Page 124: 3-3. Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Manual seat Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (if equipped for driver’s seat only) Power seat (driver’s seat only) Seat position adjustment switch Seatback angle adjustment switch Seat cushion...
Page 125 3-3. Adjusting the seats WARNING ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat. ● Do not put your hands under the seat or near the moving parts to avoid injury.
Page 126: Rear Seats
3-3. Adjusting the seats ∗ Rear seats Removing the rear seat cushions (smart-cab models) Unhook the lock release lever. Pull the seat cushions up and then pull toward the front of vehicle. The seat cushions can be removed separately. Raising the bottom cushion (double-cab models) Type A Pull the head restraint up.
Page 127 3-3. Adjusting the seats Anchor the strap to the head restraint. Type B Pull the head restraints up. Pull the straps and raise the bottom cushions. The latch under the bottom cush- ions will release allowing the bot- tom cushions to be raised.
Page 128 3-3. Adjusting the seats Anchor the straps to the head restraints. WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When removing the rear seat cushions ● Do not remove the rear seat cushions while driving. ●...
Page 129: Head Restraints
3-3. Adjusting the seats Head restraints Front seats Adjustable type Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Integrated type Head restraints cannot be adjusted and removed. Rear seats (if equipped) Adjustable type Pull the head restraints up.
Page 130 3-3. Adjusting the seats ■ Removing the head restraints Pull the head restraint up while pressing the lock release button. Lock release button ■ Installing the head restraints Align the head restraint with the installa- tion holes and push it down to the lock position.
Page 131 3-3. Adjusting the seats WARNING ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ● Adjust the head restraints to the correct position at all times. ●...
Page 132: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Hold the steering wheel and push the lever down. Type A Adjust to the ideal position by moving the steering wheel verti- cally. After adjustment, pull the lever up to secure the steering wheel.
Page 133 3-4. Adjusting the steering wheel and mirrors Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. WARNING ■...
Page 134: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 135: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, turn the switch. Left Right To adjust the mirror, move the switch. Right Down Left...
Page 136 3-4. Adjusting the steering wheel and mirrors Folding the mirrors Manual folding type Push the mirror back in the direc- tion of the vehicle’s rear. Power folding type Press the switch. Folding Extending ■ Mirror angle can be adjusted when Vehicles without smart entry &...
Page 137 3-4. Adjusting the steering wheel and mirrors WARNING ■ Important points while driving Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ●...
Page 138: Power Windows
3-5. Opening and closing the windows Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Type A Closing Opening One-touch opening (driver’s window only) One-touch closing (driver’s window only) : To stop the window partway, oper-...
Page 139 3-5. Opening and closing the windows Window lock switch Press the switch down to lock the passenger window switches. Use this switch to prevent children from accidentally opening or clos- ing a passenger window. ■ The power windows can be operated when Vehicles without smart entry &...
Page 140 1 second or more. If you release the switch while the window is moving, start again from the beginning. If the window movement reverses and can not be closed or completely open, have the vehicle inspected by your Toyota dealer.
Page 141 3-5. Opening and closing the windows WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers. In order to prevent accidental operation, especially by a child, do not let a child operate the power windows.
Page 142: Quarter Windows (Smart-Cab Models)
3-5. Opening and closing the windows Quarter windows (smart-cab models) Opening and closing procedures The quarter windows can be opened and closed using the latch han- dle. To open the quarter windows, pull the latch handle toward you and swing it fully out. To close the quarter windows, reverse the opening procedure.
Page 143: Driving
Driving 4-1. Before driving 4-5. Using the driving support systems Driving the vehicle .....142 Cruise control.....201 Cargo and luggage ....153 Rear view monitor Trailer towing system ......205 (for Australia) ....154 Four-wheel drive system..215 4-2. Driving procedures Rear differential lock Engine (ignition) switch system ......219 (vehicles without smart Driving assist systems ..222...
Page 144: Driving The Vehicle
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine →P. 164, 167 Driving Automatic transmission With the brake pedal depressed, shift the shift lever to D. (→P. 175) Release the parking brake. (→P. 188) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 145 4-1. Before driving Parking the vehicle Automatic transmission With the shift lever in D, depress the brake pedal. Shift the shift lever to P. (→P. 175) Set the parking brake. (→P. 188) Vehicles without smart entry & start system: Turn the engine switch to the “LOCK” position to stop the engine. Vehicles with smart entry &...
Page 146 4-1. Before driving Starting off on a steep uphill Automatic transmission Make sure that the parking brake is set and shift the shift lever to D. Gently depress the accelerator pedal. Release the parking brake. Manual transmission With the parking brake firmly set and the clutch pedal fully depressed, shift the shift lever to 1.
Page 147 4-1. Before driving ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ● For the first 300 km (200 miles): Avoid sudden stops. ● For the first 800 km (500 miles) (for Australia): Do not tow a trailer.
Page 148 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle On vehicles with automatic transmission, always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehi- cle from creeping.
Page 149 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● Do not adjust the positions of the steering wheel, the seat, or the inside or outside rear view mirrors while driving.
Page 150 ■ If you hear a squealing or scraping noise (brake pad wear indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 151 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is stopped ● Do not race the engine. If the vehicle is in any gear other than P (vehicles with automatic transmis- sion only) or N, the vehicle may accelerate suddenly and unexpectedly, causing an accident.
Page 152 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Always apply the parking brake, shift the shift lever to P (vehicles with automatic transmission only), stop the engine and lock the vehicle. Do not leave the vehicle unattended while the engine is running.
Page 153 On vehicles with manual transmission, if you cannot accelerate the vehicle even when the clutch is engaged and the accelerator pedal is depressed, this may mean that the clutch is slipping, and the vehicle may be rendered undriveable. Have your Toyota dealer inspect the vehicle as soon as pos- sible.
Page 154 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 155: Cargo And Luggage
4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. WARNING ■ Things that must not be carried in the rear deck The following things may cause a fire if loaded in the rear deck: ●...
Page 156: Trailer Towing (For Australia)
Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. For towing purposes, Toyota recommends the use of the following parts: ● When towing a caravan trailer etc., use a distributing hitch.
Page 157 4-1. Before driving ◆ Gross vehicle weight The gross vehicle weight must not exceed the following: 2WD models Single-cab models: 2700 kg (5952 lb.) [gasoline engine] 2810 kg (6195 lb.) [diesel engine] Smart-cab models: 2810 kg (6195 lb.) Double-cab models: 2780 kg (6129 lb.) [2TR-FE engine] 2810 kg (6195 lb.) [1GR-FE engine] 2860 kg (6305 lb.) [diesel engine] 4WD models...
Page 158 Total trailer weight Tongue load Towing a trailer Contact your Toyota dealer for further information about additional requirements such as a towing kits etc. Hitch Trailer hitch assemblies have different weight capacities established by the hitch manufacturer. Even though the vehicle may be rated for towing a higher weight, the operator must never exceed the maximum weight rating specified for the trailer hitch.
Page 159 4-1. Before driving Selecting a trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer cou- pler. Most couplers are stamped with the required trailer ball size.
Page 160 ■ Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bear- ings, etc.) to tow a trailer for the first 800 km (500 miles) of driving.
Page 161 4-1. Before driving WARNING ■ To avoid accident or injury ● The total trailer weight (trailer weight plus the weight of cargo) must not exceed the following: 2WD models 2500 kg (5512 lb.) 4WD models 1GR-FE engine: 3000 kg (6614 lb.) 1GD-FTV engine: 3200 kg (7055 lb.) [automatic transmission] 3500 kg (7716 lb.) [manual transmission]...
Page 162 ■ When installing a trailer hitch ● Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ● Do not use axle-mounted hitches, as they can cause damage to the axle housing, wheel bearings, wheels or tires.
Page 163 4-1. Before driving Trailer towing tips Your vehicle will handle differently when towing a trailer. In order to avoid accident, death or serious injury, keep the following in mind when towing: ● Before starting out, check the trailer lights and the vehicle-trailer connections.
Page 164 4-1. Before driving ● Crosswinds and rough roads will adversely affect handling of your vehicle and trailer, causing sway. Periodically check the rear to pre- pare for being passed by large trucks or buses, which may cause your vehicle and trailer to sway. If swaying occurs, firmly grip the steering wheel, reduce speed immediately but gradually, and steer straight ahead.
Page 165 4-1. Before driving ● Always place wheel blocks under both the vehicle and the trailer wheels when parking. Apply the parking brake firmly, and put the transmission in P (automatic transmission) or in the 1st or R (man- ual transmission). Avoid parking on a slope, but if unavoidable, do so only after performing the following: Apply the brakes and keep them applied.
Page 166: Engine (Ignition) Switch (Vehicles Without
4-2. Driving procedures Engine (ignition) switch (vehicles without smart entry & start system) Starting the engine Automatic transmission (gasoline engine) Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal. Turn the engine switch to the “START”...
Page 167 Shift the shift lever to P (automatic transmission) or N (manual transmis- sion). (→P. 175, 181) Push in the key and turn it to the “LOCK” position. ■ If the engine does not start The engine immobilizer system may not have been deactivated. (→P. 71) Contact your Toyota dealer.
Page 168 Do not crank the engine for more than 30 seconds at a time. This may overheat the starter and wiring system. ● Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately.
Page 169: Engine (Ignition) Switch (Vehicles With Smart Entry & Start System)
4-2. Driving procedures Engine (ignition) switch (vehicles with smart entry & start system) Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Automatic transmission Check that the parking brake is set. Check that the shift lever is set in P.
Page 170 4-2. Driving procedures Manual transmission Check that the parking brake is set. Check that the shift lever is set in N. Firmly depress the clutch pedal. A message will be displayed on the multi-information display. If it is not displayed, the engine cannot be started.
Page 171 4-2. Driving procedures Stopping the engine Automatic transmission Stop the vehicle. Shift the shift lever to P. Set the parking brake. (→P. 188) Press the engine switch. Release the brake pedal and check that the display on the instru- ment cluster is off. Manual transmission Stop the vehicle.
Page 172 4-2. Driving procedures Changing engine switch modes Modes can be changed by pressing the engine switch with brake pedal (vehicles with automatic transmission) or clutch pedal (vehicles with manual transmission) released. (The mode changes each time the switch is pressed.) The emergency flashers can be used.
Page 173 Electronic key battery depletion →P. 120 ■ Conditions affecting operation →P. 118 ■ Note for the entry function →P. 119 ■ If the engine does not start The engine immobilizer system may not have been deactivated. (→P. 71) Contact your Toyota dealer.
Page 174 MANUAL”/“Smart Entry & Start System malfunction See owner’s man- ual” is shown on the multi-information display (if equipped) The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If the electronic key battery is depleted →P.
Page 175 4-2. Driving procedures WARNING ■ When starting the engine Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 176 Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 177: Automatic Transmission
4-2. Driving procedures ∗ Automatic transmission Select a shift position appropriate for the driving conditions. Shifting the shift lever Vehicles without smart entry & start system While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 178 4-2. Driving procedures Shift position purpose Shift position Function Parking the vehicle/starting the engine Reversing Neutral (Condition in which the power is not transmitted) Normal driving S mode driving (→P. 178) : To improve fuel efficiency and reduce noises, set the shift lever in the D position for normal driving.
Page 179 4-2. Driving procedures Selecting the driving mode The following modes can be selected to suit driving conditions. ■ Eco drive mode Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. Press the “ECO MODE” switch to select Eco drive mode.
Page 180 4-2. Driving procedures Selecting shift ranges in the S position To enter S mode, shift the shift lever to S. Shift ranges can be selected by operating the shift lever, allowing you to drive in the shift range of your choosing. The shift range can be selected by the shift lever. Upshifting Downshifting The selected shift range, from 1 to...
Page 181 If the “S” indicator does not come on or the “D” indicator is displayed even after shifting the shift lever to S This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. ■ Transmission protection function...
Page 182 When the warning message goes out, the vehicle can be driven again. If the warning message does not go out after waiting a while, have your vehi- cle inspected by your Toyota dealer. ■ AI-SHIFT The AI-SHIFT automatically selects the suitable gear according to driver per- formance and driving conditions.
Page 183: Manual Transmission
4-2. Driving procedures ∗ Manual transmission Shifting the shift lever 5-speed transmission Fully depress the clutch pedal before operating the shift lever, and then release it slowly. If it is difficult to shift in reverse, shift the shift lever to N, release the clutch pedal momentarily, and then try again.
Page 184 4-2. Driving procedures Selecting the driving mode (if equipped) The following modes can be selected to suit driving conditions. ■ Eco drive mode Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. Press the “ECO MODE” switch to select Eco drive mode.
Page 185 4-2. Driving procedures iMT (Intelligent Manual Transmission) (if equipped) iMT detects clutch pedal and shift lever operations performed by the driver. When the shift position is changed, iMT judges the optimal engine speed and performs the appropriate control to help the driver to change the shift position smoothly.
Page 186 4-2. Driving procedures 6-speed transmission 4WD models (front-wheel drive control switch in H2 or H4): km/h (mph) Maximum speed Shift position 225/70R17C 35 (21) 69 (42) 116 (72) 167 (103) 175 (108) tires 1GD-FTV 265/60R18 36 (22) 70 (43) 118 (73) 171 (106) 180 (111) engine tires 265/65R17...
Page 187 The clutch pedal is not completely released and depressed again ● The clutch pedal is not fully depressed ■ If the warning message for iMT is shown on the multi-information dis- play iMT may be malfunctioning and the function is disabled. Have the vehicle inspected at your Toyota dealer.
Page 188 4-2. Driving procedures WARNING ■ Limitations of the iMT iMT is not a system that prevents shift lever operation error or engine over- revving. Depending on the situation, iMT may not operate normally and the shift position may not be changed smoothly. Overly relying on iMT may cause an unexpected accident.
Page 189: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions Left turn Right turn Lane change to the left (push and hold the lever partway) The left hand signals will flash until you release the lever. Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever.
Page 190: Parking Brake
4-2. Driving procedures Parking brake Sets the parking brake Fully pull the parking brake while depressing the brake pedal. At this time, the parking brake indi- cator light will come on. Releases the parking brake Slightly raise the lever and lower it completely while pressing the but- ton.
Page 191: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: The headlights, front position, tail, license plate, instrument panel and daytime running lights (→P.
Page 192 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
Page 193 4-3. Operating the lights and wipers Follow me home system This system allows the headlights and front position lights to be turned on for 30 seconds when the engine switch is turned to the “LOCK” position (vehicles without smart entry & start system) or off (vehicles with smart entry &...
Page 194 4-3. Operating the lights and wipers ■ Automatic light off system The lights turn off after the engine switch is turned to the “LOCK” position (vehicles without smart entry & start system) or off (vehicles with smart entry & start system) and the driver’s door is opened. To turn the lights on again, turn the engine switch to the “ON”...
Page 195: Fog Light Switch
4-3. Operating the lights and wipers ∗ Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Turns the fog lights off Turns the fog lights on ■ Fog lights can be used when The headlights or front position lights are turned on.
Page 196: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever The wiper operation is selected by moving the lever as follows. Intermittent operation Low speed operation High speed operation Temporary operation If equipped, wiper intervals can be adjusted when intermittent opera- tion is selected.
Page 197 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 198: Cap
■ Use of ethanol blended gasoline in a gasoline engine Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10%. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
Page 199 4-4. Refueling WARNING ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel cap, touch an unpainted metal surface to discharge any static electricity.
Page 200: Refueling
4-4. Refueling NOTICE ■ Refueling ● Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally or damaging fuel system components or the vehicle’s painted surface. ● Vehicles with DPF system: Use the specified fuel.
Page 201 4-4. Refueling ■ Type B To unlock the fuel tank cap, insert the key and turn it counterclockwise. Turn the fuel tank cap slowly to open. Make sure not to hold and turn the key.
Page 202 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 203: Using The Driving Support
4-5. Using the driving support systems ∗ Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control.
Page 204 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 205 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer.
Page 206 4-5. Using the driving support systems WARNING ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 207: Rear View Monitor System
4-5. Using the driving support systems ∗ Rear view monitor system The rear view monitor system assists the driver by displaying an image of the view behind the vehicle with fixed guide lines while backing up, for example while parking. The screen illustrations used in this text are intended as examples, and may differ from the image that is actually displayed on the screen.
Page 208 4-5. Using the driving support systems Using the rear view monitor system ■ Screen description Vehicles without smart entry & start system The rear view monitor system screen will be displayed if the shift lever is shifted to R while the engine switch is in the “ON” position. Vehicles with smart entry &...
Page 209 4-5. Using the driving support systems Rear view monitor system precautions ■ Area displayed on screen The rear view monitor system displays an image of the view from the bumper of the rear area of the vehicle. The image on the rear view monitor system screen can be adjusted: →P.
Page 210 4-5. Using the driving support systems ■ Rear view monitor system camera The camera for the rear view monitor system is located on the tail- gate. Type A Type B ● Using the camera If dirt or foreign matter (such as water droplets, snow, mud etc.) is adhering to the camera, it cannot transmit a clear image.
Page 211 4-5. Using the driving support systems ● When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than the actual dis- tance. Because this, objects will appear to be fur- ther away than they actually are.
Page 212 4-5. Using the driving support systems ● When any part of the vehicle sags When any part of the vehicle sags due to the number of passengers or the distribu- tion of the load, there is a margin of error between the fixed guide lines on the screen and the actual dis- A margin of error...
Page 213 4-5. Using the driving support systems ● Distance guide lines Visually check the surround- ings and the area behind the vehicle. On the screen, it appears that a truck is park- ing at point . However, in reality if you back up to point , you will hit the truck.
Page 214 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Likely cause Solution The image is difficult to see •...
Page 215 The camera or surrounding area has Have the vehicle inspected by your received a strong impact. Toyota dealer. The fixed guide lines are very far out of alignment The camera position is out of align- Have the vehicle inspected by your ment.
Page 216 ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible.
Page 217: Four-Wheel Drive System
4-5. Using the driving support systems ∗ Four-wheel drive system Use the front-wheel drive control switch to select the following transfer modes. H2 (high speed position, two- wheel drive) Use this for normal driving on dry - surfaced roads. This position hard gives greater economy, quietest ride and least wear.
Page 218 4-5. Using the driving support systems Shifting between H2 and H4 ■ Shifting from H2 to H4 Reduce your speed to less than 100 km/h (62 mph). Turn the front-wheel drive control switch to H4. The four-wheel drive indicator light will come on. ■...
Page 219 4-5. Using the driving support systems Shifting between H4 and L4 (manual transmission) ■ Shifting from H4 to L4 Stop the vehicle or reduce your speed to less than 3 km/h (2 mph). With your foot off the accelerator pedal, depress the clutch pedal. Push and turn the front-wheel drive control switch to L4.
Page 220 4-5. Using the driving support systems WARNING ■ While driving ● Never turn the front-wheel drive control switch from H2 to H4 if the wheels are slipping. Stop the slipping or spinning before shifting. ● For normal driving on dry and hard surface roads, use H2 position. Driving on dry and hard surface roads in H4 or L4 position may cause drive com- ponent oil leakage, seizure, or other problems resulting in an accident.
Page 221: Rear Differential Lock System
4-5. Using the driving support systems ∗ Rear differential lock system The rear differential lock system is provided for use only when wheel spinning occurs in a ditch or on a slippery or ragged sur- face. This differential lock system is effective in case one of the rear wheels is spinning.
Page 222 4-5. Using the driving support systems Using the rear differential lock system Automatic transmission 4WD models only: Before using the rear differential lock system, try turning the front-wheel drive control switch to L4. If this is not suffi- cient, use the rear differential lock system as well. Be sure to stop the wheels.
Page 223 4-5. Using the driving support systems ■ Locking the rear differential The following systems do not operate when the rear differential is locked. It is normal operation for the ABS warning light (if equipped), VSC OFF indi- cator (if equipped) and “TRC OFF” indicator (if equipped) or for “TRC TURNED OFF”/“TRC turned off”...
Page 224: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 225 4-5. Using the driving support systems ◆ Trailer Sway Control Helps the driver to control trailer sway by selectively applying brake pres- sure for individual wheels and reducing engine torque when trailer sway is detected. Trailer Sway Control is part of the VSC system and will not operate if VSC turned off or experiences a malfunction.
Page 226 4-5. Using the driving support systems Vehicles with multi-information display To turn the TRC/A-TRC sys- tems off, quickly press and release The “TRC TURNED OFF”/“TRC turned off” will be shown on the multi-information display. Press again to turn the sys- tem back on.
Page 227 TRC, A-TRC and downhill assist control cannot be operated. Contact your Toyota dealer. ■ Sounds and vibrations caused by the ABS, brake assist, VSC, Trailer Sway Control, TRC, A-TRC and the hill-start assist control systems ●...
Page 228 The system judges from the vehicle deceleration that is not a sudden brak- ing operation. ■ If the slip indicator light comes on It may indicate a malfunction in the VSC, Trailer Sway Control, TRC and A-TRC. Consult your Toyota dealer. WARNING ■ The ABS does not operate effectively when ●...
Page 229 4-5. Using the driving support systems WARNING ■ Stopping distance when the ABS is operating may exceed that of nor- mal conditions The ABS is not designed to shorten the vehicle’s stopping distance. Always maintain a safe distance from the vehicle in front of you, especially in the following situations: ●...
Page 230 The ABS, TRC, A-TRC, VSC, Trailer Sway Control, hill-start assist control and downhill assist control systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■...
Page 231: Downhill Assist Control System
4-5. Using the driving support systems ∗ Downhill assist control system The downhill assist control system helps to prevent excessive speed on steep downhill slopes. The system will operate when the vehicle is traveling under 30 km/h (18 mph), the front-wheel drive control switch is in the L4 or H4 position and the rear differential is not locked.
Page 232 4-5. Using the driving support systems ■ Operating tips The system will operate when the shift lever is in a position other than P, how- ever to make effective use of the system it is recommended that the shift lever be shifted to 2 or 1 range of S mode. ■...
Page 233 The downhill assist control system indicator does not come on when the “DAC” switch is pressed. ● The slip indicator comes on. In the above cases, have your vehicle checked by your Toyota dealer. WARNING ■ When using downhill assist control system Do not rely overmuch on the downhill assist control system.
Page 234: Dpf (Diesel Particulate Filter) System
DPF system warning message “DPF FULL VISIT YOUR DEALER”/“DPF full Visit your dealer” appears on the display (vehicles with multi-information display), the malfunction indicator lamp comes on, have the vehicle inspected by your Toyota dealer immediately. ∗ : If equipped...
Page 235 4-5. Using the driving support systems Vehicles with DPF system switch ● If the DPF system warning light turns on (vehicles without multi- information display) or the DPF system warning message “DPF FULL MANUAL REGENERATION REQUIRED SEE OWNER’S MANUAL”/“DPF full Manual regeneration required See owner’s manual”...
Page 236 DPF system warning message “DPF FULL VISIT YOUR DEALER”/“DPF full Visit your dealer” appears on the display (vehicles with multi-information display), the malfunction indicator lamp comes on, have the vehicle inspected by your Toyota dealer immediately.
Page 237 4-5. Using the driving support systems ■ Regeneration with the DPF system switch (if equipped) ● After pressing the DPF system switch, depressing the accelerator pedal or clutch pedal (manual transmission) will stop regeneration. If regeneration has been stopped, restart regeneration as soon as possible. ●...
Page 238 DPF system warning light is flashing (vehicles without multi-information dis- play) or the DPF system warning message appears on the display (vehicles with multi-information display). In this event, damage may be caused to the vehicle or an accident may occur. Have the vehicle inspected by your Toyota dealer immediately.
Page 239 4-5. Using the driving support systems NOTICE ■ To prevent the DPF system from failing ● Do not drive for long periods of time while the DPF system warning light is flashing (vehicles without multi-information display) or the DPF system warning message “DPF FULL VISIT YOUR DEALER”/“DPF full Visit your dealer”...
Page 240: 4-6. Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 241 4-6. Driving tips When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road con- ditions. When parking the vehicle (in the winter time or in the cold lati- tudes) Park the vehicle and move the shift lever to P (automatic transmis- sion) or 1 or R (manual transmission) without setting the parking...
Page 242 4-6. Driving tips WARNING ■ Driving with snow tires Observe the following precautions to reduce the risk of accidents. Failing to do so may result in a loss of vehicle control and cause death or serious injury. ● Use tires of the specified size. ●...
Page 243 4-6. Driving tips...
Page 244 5-1. Using the multimedia system Audio system types....244 Multimedia system .....246 5-2. Basic Operations Multimedia system Operations .......248 Steering wheel audio switches......252 AUX port/USB port.....253 Basic Audio Operations ..255 5-3. Setup “Setup” menu .....257 General settings....258 Audio settings ....260 Display settings....262 5-4.
Page 245: Audio System
Audio system ® 5-5. Using the radio 5-9. Bluetooth Audio ® Radio operation ....273 Listening to Bluetooth audio........308 5-6. Playing an audio CD and ® MP3/WMA/AAC discs 5-10. Bluetooth Phone ® CD player operation...275 Using a Bluetooth Phone ......310 5-7. Using an external device Making a call......312 iPod player operation..281 Receiving a call....317...
Page 246: Audio System Types
5-1. Using the multimedia system Audio system types Vehicles with navigation system Refer to the “Navigation and Multimedia System Owner’s Manual”. Vehicles with multimedia system ● Type A: Refer to the “Navigation and Multimedia System Owner’s Manual”. ● Type B: →P. 246...
Page 247 5-1. Using the multimedia system ■ Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. NOTICE ■ To prevent battery discharge Do not leave the audio system on longer than necessary when the engine stopped.
Page 248: Multimedia System
5-1. Using the multimedia system ∗ Multimedia system Multimedia system functions The following functions can be used on multimedia system. Audio system (→P. 273, 275, 281, 286, 290, 308) ® Radio, CD, iPod, USB, AUX, A/V and Bluetooth audio can be played to.
Page 249 5-1. Using the multimedia system ■ Operating conditions Vehicles without smart entry & start system The engine switch is in the “ACC” or “ON” position. Vehicles with smart entry & start system The engine switch is in ACCESSORY or IGNITION ON mode. ■...
Page 250: 5-2. Basic Operations
5-2. Basic Operations Multimedia system Operations Operations such as listening to audio, using the hands-free phone, confirming vehicle information and changing multimedia system settings are started by using the following buttons. Multimedia system operation buttons “AUDIO” button Display the “Select audio source” screen or audio top screen. (→P.
Page 251: Basic Operations
5-2. Basic Operations Touch screen gestures Operations are performed by touching the screen directly with your finger. Operation method Outline Main use Touch Changing and selecting Quickly touch various settings. release once. Drag Touch screen Scrolling the lists, using with your finger, and scroll bar in lists, etc.
Page 252 5-2. Basic Operations Entering letters and numbers When entering data, letters and numbers can be entered via the screen. Text field. Entered character(s) will be displayed. Select to erase one character. Select and hold to continue erasing characters. Select to display other symbols. Select to display the alphabet keys.
Page 253 5-2. Basic Operations ■ When using the touch screen ● Dimmed screen buttons cannot be operated. ● If the screen is cold, the display may be dark, or the system may seem to be operating slightly slower than normal. ● The screen may seem dark and hard to see when viewed through sun- glasses.
Page 254: Steering Wheel Audio Switches
5-2. Basic Operations Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of multimedia sys- tem or navigation system. For details, refer to the manual pro- vided with the multimedia system or navigation system.
Page 255: Aux Port/Usb Port
5-2. Basic Operations AUX port/USB port Connect an iPod, USB memory device or portable audio player to the USB/AUX port as indicated below. Select “iPod”, “USB”, “AUX” or “A/V” on the audio source selection screen and the device can be operated via multimedia system. Connecting using the USB/AUX port ■...
Page 256 5-2. Basic Operations Connected device (portable audio device, etc.) Left audio Right audio Ground Video When using an iPod video, a cable that has a 4-pole AUX plug and a USB connector is necessary. Con- nect the plug and connector to the AUX and USB ports.
Page 257: Basic Audio Operations
5-2. Basic Operations Basic Audio Operations Basic audio operations are explained in this section. Operating the multimedia system Press this button to eject a disc Press to turn the audio system on and off Press the “+” or “-” button to adjust the volume. : Select to pause music.
Page 258 5-2. Basic Operations Random playback Each time “RAND” is selected, the mode changes in the following order: Icon Action Target audio source Random play of the disc/ folder/album Random play of all folders MP3/WMA/AAC disc, USB ® Random play of all tracks Bluetooth , USB Repeat play...
Page 259: Setup
5-3. Setup “Setup” menu You can adjust the multimedia system to your desired settings. Control screen Press the “SETUP” button to display the “Setup” screen. Select to change the operation sound, change screen color, etc. (→P. 258) Select to adjust the contrast, brightness, tone and color of the screens.
Page 260: General Settings
Select to delete personal data (→P. 259) Select to update software versions. For details, contact your Toyota dealer. Select to display the software information. Notices related to third party software used in this product are enlisted. (This includes instructions for obtaining such software, where applicable.)
Page 261 5-3. Setup Delete personal data Display the “General settings” screen. (→P. 258) Select “Delete personal data”. Select “Delete”. Check carefully beforehand, as data cannot be retrieved once deleted. Select “Yes” when the confirmation screen appears. Registered or changed personal settings will be deleted or returned to their default conditions.
Page 262: Audio Settings
5-3. Setup Audio settings Detailed audio settings can be programmed. Screen for audio settings Press the “SETUP” button. Select “Audio” on the “Setup” screen. Select the item to be set. FM Radio settings ( → P. 260) iPod settings ( → P. 261) External video settings ( →...
Page 263 5-3. Setup iPod settings Display the audio setting screen. (→P. 260) Select “iPod Settings”. Select a screen button for the desired setting. External video settings Display the audio setting screen. (→P. 260) Select “External video settings”. Select a screen button for the desired setting.
Page 264: Display Settings
5-3. Setup Display settings The brightness, contrast, tone and colour of the screen can be adjusted, and/or changed to either day or night mode. Screen for display settings Press the “SETUP” button. Select “Display”. Select the item to be set. Select to adjust the screen display.
Page 265 5-3. Setup Brightness, contrast, tone and color adjustment The brightness, contrast, tone and colour of the screen can be adjusted. Select “General”, “Camera” or “Video”. Select the desired item. “-” “+” “Brightness” Darker Brighter “Contrast” Weaker Stronger “Tone” Weaker Stronger “R”...
Page 266: 5-4. Using The Audio System
5-4. Using the audio system Selecting the audio source Switching between audio sources such as radio and CD are explained in this section. Changing audio source Press the “AUDIO” button. Select “Source”. Select desired audio source.
Page 267 5-4. Using the audio system Reordering the audio source Select “Source”. Select “Reorder”. Select the desired audio source then to reorder. Using the steering wheel switches to change audio source Press the “MODE/HOLD” switch when the audio system is turned on. The audio source changes each time the switch is pressed.
Page 268: List Screen Operation
5-4. Using the audio system List screen operation When a list style screen is displayed, use the appropriate but- tons to scroll through the list. How to scroll : Select to skip to the next or previous page. Select and hold to scroll through the dis- played list.
Page 269 5-4. Using the audio system Selecting, fast-forwarding and reversing tracks/files/songs ■ Selecting a track/file/song Press the “>” or “<” button on “TUNE•TRACK” to select the desired track/file/song number. To fast-forward or reverse, press and hold the “>” or “<” button on “TUNE•TRACK”.
Page 270 5-4. Using the audio system Character jump buttons in lists Some lists contain character screen buttons, “ABC”, “DEF” etc., which allow a direct jump to list entries that begin with the same letter as the character screen button. Select the desired character jump buttons.
Page 271: Optimal Use Of The Audio System
5-4. Using the audio system Optimal use of the audio system On the “Sound settings” screen, sound quality, volume balance and ASL settings can be adjusted. How to adjust the sound settings and sound quality Select “Sound” to adjust the sound settings.
Page 272 5-4. Using the audio system “DSP” tab ● Automatic sound leveliser (ASL) Select the ASL level among “High”, “Mid”, “Low” and “Off”. ■ The sound quality level is adjusted individually The treble, mid and bass levels can be adjusted for each audio mode sepa- rately.
Page 273: Audio Screen Adjustment
5-4. Using the audio system Audio screen adjustment Settings are available for selecting the screen size and adjusting display. Screen size settings iPod video/VTR The screen size can be selected for each type of media. Select “Options” on the control screen. Select “Screen format”...
Page 274 5-4. Using the audio system Adjusting the audio screen The brightness, contrast, color and tone of the screen can be adjusted. Select “Options” on the control screen. Select “Display” on the option screen. Select the desired item to be adjusted. “-”...
Page 275: Using The Radio
5-5. Using the radio Radio operation Select “AM” or “FM” on the audio source selection screen to begin listening to the radio. Control screen Pressing the “AUDIO” button displays the audio control screen from any screens of the selected source. Audio source selection screen appears Preset stations...
Page 276 5-5. Using the radio Setting station presets Up to 6 preset stations can be registered in AM mode and up to 12 preset stations can be registered for FM radio mode. Tune in the desired station. Select one of the screen buttons (1-12) and hold it until a beep is heard.
Page 277: Cd Player Operation
5-6. Playing an audio CD and MP3/WMA/AAC discs CD player operation Insert a disc or select “DISC” on the audio source selection screen with a disc inserted to begin listening to a CD. Control screen Pressing the “AUDIO” button displays the audio control screen from any screens of the selected source.
Page 278 Error messages If the following error messages appear on the screen, refer to the table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures It indicates that the disc is dirty, damaged, or it was inserted upside down.
Page 279 5-6. Playing an audio CD and MP3/WMA/AAC discs ■ Lens cleaners Do not use lens cleaners. Doing so may damage the CD player. ■ MP3, WMA and AAC files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression.
Page 280 5-6. Playing an audio CD and MP3/WMA/AAC discs ● AAC file compatibility • Compatible standards MPEG4/AAC-LC • Compatible sampling frequencies 11.025/12/16/22.05/24/32/44.1/48 (kHz) • Compatible bit rates 16-320 (kbps) ● Compatible media Media that can be used for MP3, WMA and AAC playback are CD-Rs and CD-RWs.
Page 281 5-6. Playing an audio CD and MP3/WMA/AAC discs ● ID3, WMA and AAC tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
Page 282 5-6. Playing an audio CD and MP3/WMA/AAC discs NOTICE ■ Discs and adapters that cannot be used Do not use the following types of CDs. Also, do not use 8 cm (3 in.) CD adapters, DualDiscs or printable discs. Doing so may damage the CD player and/or the CD insert/eject function. ●...
Page 283: Using An External Device
5-7. Using an external device iPod player operation Select “iPod (DEVICE NAME)” on the audio source selection screen. Connecting an iPod →P. 253 Control screen Pressing the “AUDIO” button displays the audio control screen from any screens of the selected source. iPod audio iPod video Audio source selection screen...
Page 284 5-7. Using an external device Selecting a play mode Select “Browse” on the screen. Select the desired play mode by selecting the “Playlists”, “Artists”, “Albums”, “Songs”, “Podcasts”, “Audiobooks”, “Genres”, “Composers” or “Videos” tab. Then select a song to begin using the selected play mode.
Page 285 5-7. Using an external device ■ About iPod ● “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to an iPod, or iPhone, respec- tively, and has been certified by the developer to meet Apple performance standards.
Page 286 Error messages If the following error messages appear on the screen, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures This indicates a problem in the iPod or its con- “iPod error”...
Page 287 5-7. Using an external device ■ Compatible models ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system. ● Made for • iPod touch (5th generation) •...
Page 288: Usb Memory Device Player Operation
5-7. Using an external device USB memory device player operation Touch “USB” on the audio source selection screen. Connecting a USB memory device →P. 253 Control screen Pressing the “AUDIO” button displays the audio control screen from any screens of the selected source. Audio source selection screen appears Displaying the file/track list...
Page 289 Error messages for USB memory If the following error messages appear on the screen, refer to the table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures This indicates a problem with the USB mem- “USB error.”...
Page 290 5-7. Using an external device ● MP3 file compatibility • Compatible standards MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III, MPEG2.5) • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz) •...
Page 291 5-7. Using an external device ● MP3, WMA and AAC playback • When a device containing MP3, WMA and AAC files is connected, all files in the USB memory device are checked. Once the file check is fin- ished, the first MP3, WMA and AAC file is played. To make the file check finish more quickly, we recommend that you do not include any files other than MP3, WMA and AAC files or create any unnecessary folders.
Page 292: Using The Aux Port
5-7. Using an external device Using the AUX port This port can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Connecting a portable audio device →P. 253 Control screen Press the “AUDIO” button to display the audio control screen. Select “Source”...
Page 293: Vtr
5-7. Using an external device Control screen Connect a device to the AUX port. (→P. 253) Press the “AUDIO” button to display the audio control screen. Select “Source” and select “A/V”. Audio source selection screen appears Setting the sound (→P. 269) Displaying full screen VTR Options screen appears VTR options...
Page 294: 5-8. Connecting Bluetooth
® 5-8. Connecting Bluetooth Preparations to use wireless communication ® The following can be performed using Bluetooth wireless com- munication: ■ A portable audio player can be operated and listened to via multimedia system ■ Hands-free phone calls can be made via a cellular phone In order to use wireless communication, register and connect a ®...
Page 295: Connecting Bluetooth
® 5-8. Connecting Bluetooth Device registration/connection flow ® 1. Register the Bluetooth device to be used with multimedia system (→P. 295, 296, 298) ® 2. Select the Bluetooth device to be used (→P. 300) To be used for audio To be used for hands-free phone ®...
Page 296 ® 5-8. Connecting Bluetooth Registering and connecting from the “Bluetooth setup” screen To display the screen shown below. Press the “SETUP” button and select “Bluetooth ” on the “Setup” screen. ® ● Registering Bluetooth device (→P. 298) ® ● Deleting a Bluetooth device (→P.
Page 297: Registering A Bluetooth ® Audio Player For The First Time
® 5-8. Connecting Bluetooth ® Registering a Bluetooth audio player for the first time ® To use the Bluetooth Audio, it is necessary to register an audio player with the system. Once the player has been registered, it is possible to use the ®...
Page 298: Registering A Bluetooth ® Phone For The First Time
® 5-8. Connecting Bluetooth ® Registering a Bluetooth phone for the first time To use the hands-free system, it is necessary to register a ® Bluetooth phone with the system. Once the telephone has been registered, it is possible to use the hands-free system.
Page 299 ® 5-8. Connecting Bluetooth ® ® Register your Bluetooth device on the Bluetooth system. A PIN-code is not required for SSP (Secure Simple Pairing) compatible ® ® Bluetooth devices. Depending on the type of Bluetooth device being connected, a message confirming registration may be displayed on the ®...
Page 300: Registering A Bluetooth ® Device
® 5-8. Connecting Bluetooth ® Registering a Bluetooth device ® Up to 5 Bluetooth devices can be registered. ® Bluetooth compatible phones (HFP) and audio players (AVP) can be registered simultaneously. This operation cannot be performed while driving. ® How to register a Bluetooth device Display the “Bluetooth setup”...
Page 301 ® 5-8. Connecting Bluetooth ® Removing a Bluetooth device Display the “Bluetooth setup” screen. (→P. 294) Select “Remove”. Select the desired device. Select “Yes” when the confirmation screen appears. Check that a confirmation screen is displayed when the operation is complete.
Page 302: Connecting A Bluetooth ® Device
® 5-8. Connecting Bluetooth ® Connecting a Bluetooth device ® Up to 5 Bluetooth devices (Telephones (HFP) and audio players (AVP)) can be registered. ® If more than 1 Bluetooth device has been registered, select which device to connect to. ®...
Page 303 ® 5-8. Connecting Bluetooth Check that a confirmation screen is displayed when the operation is complete. If an error message is displayed, follow the guidance on the screen to try again. ® Depending on the type of Bluetooth device being connected, it may be necessary to perform additional steps on the device.
Page 304 ® 5-8. Connecting Bluetooth Manual connection When auto connection has failed or “Bluetooth power” is turned off, ® you must connect the Bluetooth device manually. Press the “SETUP” button. Select “Bluetooth ”. ® Follow the steps in “How to select a Bluetooth device”...
Page 305: Displaying A Bluetooth ® Device Details
® 5-8. Connecting Bluetooth ® Displaying a Bluetooth device details You can confirm and change the registered device details. ® Bluetooth device registration status Display the “Bluetooth setup” screen. (→P. 294) ® : The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
Page 306 ® 5-8. Connecting Bluetooth Changing a device name Select “Device name”. Enter the name and select “OK”. Even if the device name is changed, the name registered in your ® Bluetooth device does not change. Setting audio player connection method Select “Connect audio player from”.
Page 307: Detailed Bluetooth ® Settings
® 5-8. Connecting Bluetooth ® Detailed Bluetooth settings ® You can confirm and change the detailed Bluetooth settings. ® How to check and change detailed Bluetooth settings Display the “Bluetooth setup” screen. (→P. 294) Select “System settings”. Select the desired item to be set.
Page 308 ® 5-8. Connecting Bluetooth Changing “Bluetooth power” Select “Bluetooth power”. Vehicles without smart entry & start system ® When “Bluetooth power” is on: The Bluetooth device is automati- cally connected when the engine switch is turned to the “ACC” or “ON”...
Page 309 ® 5-8. Connecting Bluetooth ■ While driving You cannot change the state of “Bluetooth power” from on to off while driv- ing, but it can be changed from off to on. ® : The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
Page 310: Bluetooth Audio
® 5-9. Bluetooth Audio ® Listening to Bluetooth audio ® The Bluetooth audio system enables the user to enjoy music played on a portable player from the vehicle speakers via wire- less communication. ® When a Bluetooth device cannot be connected, check the connec- ®...
Page 311 ® 5-9. Bluetooth Audio Status display You can check indicators of connection status and battery charge on the screen. Battery charge The battery charge indicator may not be displayed depending on the connected device. Connection status Indicators Conditions Good Not connected Connection status Full Empty...
Page 312: Bluetooth ® Phone Using A Bluetooth ® Phone
® 5-10. Bluetooth Phone ® Using a Bluetooth Phone The hands-free system is a function that allows you to use your cellular phone without touching it. ® ® This system supports Bluetooth . Bluetooth is a wireless data system that allows the cellular phone to wirelessly connect to the hands-free system and make/receive calls.
Page 313 ® 5-10. Bluetooth Phone ■ Microphone The vehicle’s built in micro- phone is used when talking on the telephone. The person you are speaking to can be heard from the front speakers. To use the hands-free system, must register your ®...
Page 314: Making A Call
® 5-10. Bluetooth Phone Making a call ® Once a Bluetooth phone is registered, you can make a call using the following procedure: Dialing Display the telephone top screen. (→P. 310) Select the “Dial pad” tab and enter a telephone number. To delete the input telephone num- ber, select For the first digit, you can enter “+”...
Page 315 ® 5-10. Bluetooth Phone Select the desired number and then check that the “Call” screen is displayed. When the contact is empty If your cellular phone is neither PBAP (Phone Book Access Profile) nor OPP (Object Push Profile) compatible, the contacts cannot be transferred.
Page 316 ® 5-10. Bluetooth Phone ® ■ For a PBAP incompatible but OPP compatible Bluetooth phone Display the telephone top screen. (→P. 310) Select the desired item. Transfer the contacts from connected cellular phone. Select to add a new con- tact manually. Cancel transferring.
Page 317 ® 5-10. Bluetooth Phone Dialing from favourites You can make a call using numbers registered in the favourites. (→P. 333) Display the telephone top screen. (→P. 310) Select “Favourites” tab on the telephone top screen and select the desired contact. Select the desired number and then check that the “Call”...
Page 318 ® 5-10. Bluetooth Phone ■ Call history list ● If you make a call to or receive a call from a number registered in the con- tact, the name is displayed in the call history. ● If you make multiple calls to the same number, only the last call made is dis- played in the call history.
Page 319: Receiving A Call
® 5-10. Bluetooth Phone Receiving a call When a call is received, the following screen is displayed together with a sound. To answer the telephone • Press the switch on the steering wheel. • Select The incoming call display mode can be set.
Page 320: Speaking On The Telephone
® 5-10. Bluetooth Phone Speaking on the telephone The following screen is displayed when speaking on the tele- phone. Displaying the dial pad to send tones (→P. 318) Muting your voice to the other party Changing handset modes between hands-free and cellu- lar phone Hanging up the telephone Select “+”...
Page 321 ® 5-10. Bluetooth Phone ■ By selecting “Release tones” “Release tones” appear when a continuous tone signal(s) contain- ing a (w) is registered in the contact list. This operation can be per- formed while driving. Select “Release tones”. Transmit volume setting Select “Transmit volume”.
Page 322 ® 5-10. Bluetooth Phone ■ While driving The function “By dial pad” is unavailable. ■ Release tones ● A continuous tone signal is a character string that consists of numbers and the characters “p” or “w”. (e.g.056133w0123p#1∗) ● When the “p” pause tone is used, the tone data up until the next pause tone will be automatically sent after 2 seconds have elapsed.
Page 323: Bluetooth ® Phone Message Function
® 5-10. Bluetooth Phone ® Bluetooth phone message function Received messages can be forwarded from the connected ® Bluetooth phone, enabling checking and replying using the multimedia system. ® Depending on the type of Bluetooth phone connected, received messages may not be transferred to the message inbox. If the telephone does not support the message function, this function cannot be used.
Page 324 ® 5-10. Bluetooth Phone ■ Receiving a message ● Depending on the cellular phone used for receiving messages, or its registration status with the multimedia system, some informa- tion may not be displayed. ● The pop up screen is separately available for incoming e-mail and SMS/MMS messages under the following conditions: E-mail: •...
Page 325 ® 5-10. Bluetooth Phone ■ While driving The text of the message is not displayed. ■ Check the messages ● ® Messages are displayed in the appropriate connected Bluetooth phone’s registered mail address folder. Select the tab of the desired folder to be displayed. ®...
Page 326 ® 5-10. Bluetooth Phone Calling the message sender Calls can be made to an e-mail/SMS/MMS message sender’s tele- phone number. ■ Calling from e-mail/SMS/MMS message display Display the “Message inbox” screen. (→P. 321) Select the desired message. Select If there are 2 or more telephone numbers, select the desired number. Check that the “Call”...
Page 327: Using The Steering Wheel Switches
® 5-10. Bluetooth Phone Using the steering wheel switches The steering wheel switches can be used to operate a connected cellular phone. Operating a telephone using the steering wheel switches Volume switch • Increase/Decrease the vol- • Press and hold: Continuously increase/ decrease the volume...
Page 328: Bluetooth ® Phone Settings
® 5-10. Bluetooth Phone ® Bluetooth phone settings You can adjust the hands-free system to your desired settings. “Telephone/message settings” screen To display the screen shown below, press the “SETUP” button, and select “Telephone” on the “Setup” screen. Registering/connecting a tele- phone (→P.
Page 329 ® 5-10. Bluetooth Phone Sound setting Display the “Telephone/message settings” screen. (→P. 326) Select “Sound settings”. Select the desired item to be set. Setting the desired ringtone. Select “-” or “+” to adjust the ringtone volume. Select “-” or “+” to adjust the message readout volume.
Page 330: 5-11. Contact
5-11. Contact Contact/call history settings ® The contact can be transferred from a Bluetooth phone to the system. The contact also can be added, edited and deleted. The call history can be deleted and contact and favourites can be changed. Depending on the type of telephone, certain functions may not be available.
Page 331: Contact
5-11. Contact Clearing contacts from the call history. Adding new contacts to the contact list. (→P. 331) Editing contacts in the contact list. (→P. 331) Deleting contacts from the contact list. (→P. 332) Resetting all setup items. Depending on the type of telephone, certain functions may not be available.
Page 332 5-11. Contact ® ■ For PBAP incompatible but OPP compatible Bluetooth Phones Display “Contact/call history settings” screen. (→P. 328) Select “Update contacts from telephone”. ® Transfer the contact data to the system using a Bluetooth phone. This operation may be unnecessary depending on the type of cellular phone.
Page 333 5-11. Contact Registering a new contact to the contact list New contact data can be registered. Up to 4 numbers per person can ® be registered. For PBAP compatible Bluetooth phones, this function is available when “Automatic contact/history transfer” is set to off. (→P.
Page 334 5-11. Contact ■ Editing the contacts in a different way (from the “Contact details” screen) Display the telephone top screen. (→P. 310) Select the “Contacts”, “Call history” tab or the “Favourites” tab and select the desired contact. Select “Edit contact”. “E-mail addresses”: Select to display all registered e-mail addresses for the contact.
Page 335 5-11. Contact Registering the contacts in the favourites list Up to 15 contacts (maximum of 4 numbers per contact) can be regis- tered in the favourites list. Display “Contact/call history settings” screen. (→P. 328) Select “Add favorite”. Select the desired contact to add to the favourites list. Dimmed contacts are already stored as a favourite.
Page 336 5-11. Contact ■ Registering contacts in the favourites list in a different way (from the “Contacts” screen) Display the telephone top screen. (→P. 310) Select the “Contacts” tab. Select at the beginning of the desired contact list name to be registered in the favourites list.
Page 337 5-11. Contact Deleting the contacts in the favourites list Display “Contact/call history settings” screen. (→P. 328) Select “Remove favourite”. Select the desired contacts and select “Remove”. Select “Yes” when the confirmation screen appears. Check that a confirmation screen is displayed when the operation is complete.
Page 338 5-11. Contact Message settings Display the “Telephone/message settings” screen. (→P. 326) Select “Messaging settings”. Select the desired item to be set. Select to set automatic mes- sage transfer on/off. Select to set automatic mes- sage readout on/off. Select to set the SMS/MMS notification popup on/off.
Page 339 5-11. Contact ■ Displaying the “Messaging settings” screen in a different way Display the telephone top screen. (→P. 310) Select Select “Settings” on the “Message inbox”. Telephone display settings Display the “Telephone/message settings” screen. (→P. 326) Select “Telephone display settings”. Select the desired item to be set.
Page 340: 5-12. Bluetooth
® 5-12. Bluetooth What to do if... (Troubleshooting) ® If there is a problem with the hands-free system or a Bluetooth device, first check the table below. ® When using the hands-free system with a Bluetooth device ® The hands-free system or Bluetooth device does not work.
Page 341 ® 5-12. Bluetooth When registering/connecting a cellular phone A cellular phone cannot be registered. An incorrect passcode was entered on the cellular phone. → Enter the correct passcode on the cellular phone. The registration operation has not been completed on the cellular phone side.
Page 342 ® 5-12. Bluetooth When making/receiving a call A call cannot be made/received. Your vehicle is in a “No service” area. → Move to where “No service” no longer appears on the display. When using the phonebook Phonebook data cannot be transferred manually/automatically. Automatic contact transfer function on this system is set to off.
Page 343 ® 5-12. Bluetooth ® When using the Bluetooth message function Messages cannot be viewed. Message transfer is not enabled on the cellular phone. → Enable message transfer on the cellular phone (approve message transfer on the telephone). Automatic transfer function on this system is set to off. →...
Page 344: Bluetooth
If the following error messages appear on the screen, refer to the table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures “Music tracks not supported. Please This indicates a problem in the ®...
Page 345 ® 5-12. Bluetooth ■ Conditions under which the system will not operate ● ® If using a cellular phone that does not support Bluetooth ● If the cellular phone is turned off ● If you are outside of cellular phone service coverage ●...
Page 346 ® 5-12. Bluetooth ■ About the Contact in this system The following data is stored for every registered cellular phone. When another telephone is connecting, you cannot read the registered data. ● Contact data ● Call history ● Favourites ● Image data ●...
Page 347 ® 5-12. Bluetooth ● Profiles: • HFP (Hands Free Profile) Ver. 1.0 or higher (Recommended: Ver. 1.6 or higher) This is a profile to allow hands-free phone calls using a cellular phone or head set. It has outgoing and incoming call functions. •...
Page 348 ® 5-12. Bluetooth WARNING ■ While driving Do not use the portable audio player, cellular phone or connect a device to ® the Bluetooth system. ■ Caution regarding interference with electronic devices ● ® Your audio unit is fitted with Bluetooth antennas.
Page 349: Interior Features
Interior features 6-1. Using the air conditioning system and defogger Manual air conditioning system ......348 Automatic air conditioning system ......353 6-2. Using the interior lights Interior lights list....359 • Personal/interior light main switch....360 • Personal/interior lights ......360 • Interior light....360 6-3.
Page 350: Using The Air Conditioning System And Defogger Manual Air Conditioning System
6-1. Using the air conditioning system and defogger ∗ Manual air conditioning system Air conditioning controls ■ Adjusting the fan speed setting Turn clockwise (increase) or counterclockwise (decrease). Turning the dial to “OFF” turns off the fan. ■ Adjusting the temperature setting Turn clockwise (warm) or counterclockwise (cool).
Page 351 6-1. Using the air conditioning system and defogger Other functions ■ Switching between outside air and recirculated air modes Move the outside/recirculated air mode lever. The mode switches between (introduces air from outside the vehi- cle) and (recycles air inside the vehicle) each time the lever is moved.
Page 352 6-1. Using the air conditioning system and defogger ■ Heater idle up (if equipped) This feature is used to heat the engine coolant, speed up warming of the cab in cold weather, and keep the cab warm when the vehicle is not moving.
Page 353 6-1. Using the air conditioning system and defogger Side outlets Direct air flow to the left or right, up or down. Close the vents. ■ Fogging up of the windows ● The windows will easily fog up when the humidity in the vehicle is high. Turning on will dehumidify the air from the outlets and defog the wind- shield effectively.
Page 354 6-1. Using the air conditioning system and defogger ■ Ventilation and air conditioning odors ● To let fresh air in, set the air conditioning system to the outside air mode. ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 355: Automatic Air Conditioning System
6-1. Using the air conditioning system and defogger ∗ Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls ■ Adjusting the fan speed setting Turn clockwise (increase) or counterclockwise (decrease). Press to turn the fan off.
Page 356 6-1. Using the air conditioning system and defogger ■ Changing the air flow mode Press to change the air outlets. outlets used switched each time the button is pressed. Air flows to the upper body. Air flows to the upper body and feet.
Page 357 6-1. Using the air conditioning system and defogger Other functions ■ Switching between outside air and recirculated air modes Press to switch to recirculated air mode and press switch to outside air mode. ■ Defogging the windshield Press The dehumidification function operates and fan speed increases. Press if the recirculated air mode is used.
Page 358 6-1. Using the air conditioning system and defogger Air outlets ■ Location of air outlets The air outlets and air volume changes according selected air flow mode. ■ Adjusting the position of and opening and closing the air out- lets Center outlets Direct air flow to the left or right, up or down.
Page 359 6-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after is pressed.
Page 360 6-1. Using the air conditioning system and defogger ■ Ventilation and air conditioning odors ● To let fresh air in, set the air conditioning system to the outside air mode. ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 361: Using The Interior Lights
6-2. Using the interior lights Interior lights list Interior light (if equipped) (→P. 360) Personal/interior lights (→P. 360) Engine switch light...
Page 362: Personal/Interior Light Main Switch
6-2. Using the interior lights Personal/interior light main switch Door position The personal/interior lights come on when a door is opened. They turn off when the doors are closed. The personal/interior lights can be individually turned on or off. Personal/interior lights On/off Interior light (if equipped) Door position...
Page 363 6-2. Using the interior lights ● Illuminated entry system (if equipped): Vehicles without smart entry & start system The lights automatically turn on/off according to the engine switch position, whether the doors are locked/unlocked, and whether the doors are open/ closed.
Page 364: 6-3. Using The Storage Features
6-3. Using the storage features List of storage features Bottle holders (if equipped) Auxiliary boxes (if equipped) (→P. 365) (→P. 366) Cup holders (if equipped) Glove box (→P. 363) (→P. 364) Console box (if equipped) (→P. 363)
Page 365: Glove Box
6-3. Using the storage features WARNING ● Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: • Glasses may be deformed by heat or cracked if they come into contact with other stored items.
Page 366: Cup Holders
6-3. Using the storage features Cup holders Type A Type B (if equipped) Press in and pull the cup holder. Type C (if equipped) Type D (if equipped) Type E (if equipped) Pull the armrest down.
Page 367: Bottle Holders
6-3. Using the storage features WARNING Do not place anything other than cups or beverage cans in the cup holders. Other items may be thrown out of the holders in the event of sudden brak- ing, sudden swerving or an accident, cause injury. If possible, cover hot drinks to prevent burns.
Page 368: Auxiliary Boxes
6-3. Using the storage features Auxiliary boxes Type A Type B Press the button. Press in and pull the cup holder, and push the cup tray. Type C Type D Press in the lid. The auxiliary box is useful for tem- porarily storing sunglasses and similar small items.
Page 369 6-3. Using the storage features Type G (if equipped) : The shape of the auxiliary box may differ depending on the grade, etc. ● Air conditioning-linked temperature regulation function (type A) (if equipped): By introducing air from the air conditioning system into the auxiliary box, canned drinks etc.
Page 370 6-3. Using the storage features WARNING ● Do not store items heavier than 0.2 kg (0.4 lb.). Doing so may cause the auxiliary box to open and the items inside may fall out, resulting in an accident. (type C) ● Keep the auxiliary boxes closed.
Page 371: Luggage Compartment Features
6-3. Using the storage features Luggage compartment features Deck hooks (if equipped) Deck hooks are provided for securing loose items.
Page 372: Other Interior Features
6-4. Using the other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. Vanity mirror (if equipped) Open the cover to use.
Page 373: Clock
6-4. Using the other interior features Clock The clock can be adjusted by pressing the buttons. Adjusts the hours Adjusts the minutes Rounds to the nearest hour : e.g. 1:00 to 1:29 → 1:00 1:30 to 1:59 → 2:00 ● The clock is displayed when: Vehicles without smart entry &...
Page 374: Power Outlets
6-4. Using the other interior features Power outlets (if equipped) The power outlet can be used for the following components: 12 V DC: Please use as a power supply for electronic goods that use less than 12 V DC / 10 A (power consumption of 120 W). When using electronic goods, make sure that the power consumption of all the connected power outlets is less than 120 W.
Page 375: Grocery Bag Hooks
6-4. Using the other interior features NOTICE ● To avoid damaging the power outlets, close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short circuit.
Page 376: Coat Hooks
6-4. Using the other interior features Coat hooks (if equipped) The coat hooks are provided above the back window. Armrest (if equipped) Fold down the armrest for use. NOTICE To prevent damage to the armrest, do not apply too much load on the arm- rest.
Page 377: Maintenance And Care
Maintenance and care 7-1. Maintenance and care Cleaning and protecting the vehicle exterior ..376 Cleaning and protecting the vehicle interior ...379 7-2. Maintenance Maintenance requirements....382 7-3. Do-it-yourself maintenance Do-it-yourself service precautions ......384 Hood ........386 Engine compartment..388 Tires........402 Tire inflation pressure ..405 Wheels.......407 Air conditioning filter ..409 Wireless remote control/...
Page 378: The Vehicle Exterior
7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 379 7-1. Maintenance and care ■ Aluminum wheels (if equipped) ● Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical clean- ers. Use the same mild detergent and wax as used on the paint. ●...
Page 380 7-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 381: Cleaning And Protecting The Vehicle Interior
7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 382 7-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 383 7-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 384: 7-2. Maintenance
These are best performed by qualified technicians. Even if you are an experienced do-it-yourself mechanic, we recommend that repairs and maintenance be conducted by your Toyota dealer who will keep a record of maintenance on your vehicle. This record could be helpful should you ever...
Page 385 ■ Where to go for maintenance service? It makes good sense to take your vehicle to your local Toyota dealer for main- tenance service as well as other inspections and repairs. Toyota technicians are well-trained specialists receiving the latest service information through technical bulletins, service tips, and in-dealership training programs.
Page 386: Precautions
Battery condition • Conventional wrench (for terminal clamp bolts) (→P. 396) • Distilled water • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- Engine coolant life hybrid organic acid technology level (→P.
Page 387 7-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.
Page 388: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. Hold the hood open by inserting the supporting rod into either of the slots.
Page 389 7-3. Do-it-yourself maintenance WARNING ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
Page 390: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment 1GR-FE engine Engine oil level dipstick Fuse box (→P. 414) (→P. 391) Battery (→P. 396) Engine coolant reservoir Washer fluid tank (→P. 400) (→P. 394) Condenser (→P. 396) Engine oil filler cap (→P. 392) Radiator (→P.
Page 391 7-3. Do-it-yourself maintenance 2TR-FE engine Engine coolant reservoir Fuse box (→P. 414) (→P. 394) Battery (→P. 396) Engine oil level dipstick Washer fluid tank (→P. 400) (→P. 391) Condenser (→P. 396) Engine oil filler cap (→P. 392) Radiator (→P. 396)
Page 392 7-3. Do-it-yourself maintenance 1GD-FTV and 2GD-FTV engines Engine coolant reservoir Fuse box (→P. 414) (→P. 394) Battery (→P. 396) Engine oil filler cap (→P. 392) Washer fluid tank (→P. 400) Engine oil level dipstick Intercooler (→P. 396) (→P. 391) Radiator (→P.
Page 393 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 394 7-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 395 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 396 7-3. Do-it-yourself maintenance Engine coolant The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir when the engine is cold. 1GR-FE engine 2TR-FE engine 1GD-FTV and 2GD-FTV engines Reservoir cap “L” line “F” line If the level is on or below the “L”...
Page 397 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system.
Page 398 Radiator, condenser and intercooler (if equipped) Check the radiator, condenser and intercooler and clear away any for- eign objects. If any of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■...
Page 399 7-3. Do-it-yourself maintenance ■ Checking battery fluid Check that the level is between the upper and lower lines. Upper line Lower line If the fluid level is at or below the lower line, add distilled water. ■ Adding distilled water Remove the vent plug.
Page 400 Make sure to turn off the engine before disconnect the battery. Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer. ■...
Page 401 7-3. Do-it-yourself maintenance WARNING ■ Chemicals in the battery Batteries contain poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: ●...
Page 402 7-3. Do-it-yourself maintenance NOTICE ■ When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. ■ When adding distilled water Avoid overfilling. Water spilled during battery recharging may cause corro- sion.
Page 403 Fuel filter (diesel engine only) You may drain the fuel filter yourself. However, as the operation is dif- ficult, we recommend having it drained by your Toyota dealer. Even if you decide to drain it yourself, contact your Toyota dealer.
Page 404: Tires
7-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires Check if the treadwear indicators are showing on the tires. Also check the tires for uneven wear, such as excessive wear on one side of the tread.
Page 405 Front Front To equalize tire wear and help extend tire life, Toyota recommends that tire rotation is carried out approximately every 10000 km (6000 miles). ■ When to replace your vehicle’s tires Tires should be replaced if: ●...
Page 406 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 407: Tire Inflation Pressure
Reduced tire life due to wear ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 408 7-3. Do-it-yourself maintenance WARNING ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. If the tires are not properly inflated, the following conditions may occur which could lead to an accident resulting in death or serious injury: ●...
Page 409: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions (if equipped) ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 410 7-3. Do-it-yourself maintenance WARNING ■ When replacing wheels ● Do not use wheels that are a different size from those recommended in the Owner’s Manual, as this may result in a loss of handling control. ● Never use an inner tube in a leaking wheel which is designed for a tube- less tire.
Page 411: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Vehicles without smart entry & start system: Turn the engine switch to the “LOCK” position. Vehicles with smart entry & start system: Turn the engine switch off. Open the glove box.
Page 412 7-3. Do-it-yourself maintenance Pull damper equipped) as shown in the illus- tration, and then remove the glove box. Remove the filter cover. Remove the air conditioning fil- ter and replace it with a new one. The “↑UP” marks shown on the fil- ter should be pointing up interval ■...
Page 413: Wireless Remote Control/Electronic Key Battery
7-3. Do-it-yourself maintenance ∗ Wireless remote control/electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery Vehicles without smart entry & start system: CR1620 Vehicles with smart entry &...
Page 414 7-3. Do-it-yourself maintenance Remove the depleted battery. Insert a new battery with the “+” terminal facing up. Vehicles with smart entry & start system Take out the mechanical key. Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a rag.
Page 415 Vehicles without smart entry & start system: CR1620 Vehicles with smart entry & start system: CR2032 ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer.
Page 416: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Vehicles without smart entry & start system: Turn the engine switch to the “LOCK” position. Vehicles with smart entry &...
Page 417 7-3. Do-it-yourself maintenance Remove the lid. Behind the instrument panel Remove the glove box (→P. 409), and remove the lid. Behind the cowl side panel Remove the front passenger’s door scuff plate.
Page 418 7-3. Do-it-yourself maintenance Remove the nut and the cowl side panel. Remove the fuse. Only type A fuse can be removed using the pullout tool.
Page 419 Type A, B, C and D: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type E: Contact your Toyota dealer. Type A Type B Type C...
Page 420 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (→P. 419) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 421: Light Bulbs
As there is a danger that components may be damaged, we recommend that replacement is carried out by your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (→P. 511) Bulb locations ■...
Page 422 7-3. Do-it-yourself maintenance Vehicles with LED headlights Headlight (high beam) Fog light Front turn signal light ■ Rear License plate light Back up light Stop/tail light Rear turn signal light...
Page 423 7-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight high/low beams (vehicles with halogen headlights) Unplug the connector and remove the rubber cover. Release the bulb retaining spring. Remove the bulb. To install a new bulb, align the tabs of the bulb with the cutouts of the mounting hole.
Page 424 7-3. Do-it-yourself maintenance ■ Headlight high beams (vehicles with LED headlights) Unplug the connector while depressing the lock release. Turn the bulb base counter- clockwise. Replace the light bulb, and install the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert.
Page 425 7-3. Do-it-yourself maintenance Install the connector Shake the bulb base gently to check that it is not loose, turn the headlight high beams on once and visually confirm that no light is leaking through the mounting. ■ Front position lights/daytime running lights (vehicles with halogen headlights) Turn the bulb base counter- clockwise.
Page 426 7-3. Do-it-yourself maintenance ■ Front turn signal lights Vehicles with halogen headlights Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 427 7-3. Do-it-yourself maintenance Vehicles with LED headlights To allow enough working space, turn steering wheel to the opposite side where bulb replaced is located. Remove the screws and clips. Removing the clip Installing the clip Type A Type B...
Page 428 7-3. Do-it-yourself maintenance Partly remove the fender liner and turn the bulb base counterclockwise. Fender liner Bumper Remove the light bulb. When installing, reverse the steps listed.
Page 429 7-3. Do-it-yourself maintenance ■ Fog lights (if equipped) To allow enough working space, turn steering wheel to the opposite side where bulb replaced is located. Remove the screws and clips. Removing the clip Installing the clip Type A Type B...
Page 430 7-3. Do-it-yourself maintenance Partly remove the fender liner and unplug the connec- tor while pressing the lock release. Fender liner Bumper Turn the bulb base counter- clockwise. Replace the light bulb, and install the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert.
Page 431 7-3. Do-it-yourself maintenance Turn the secure the bulb base. Install the connector. Shake the bulb base gently to check that it is not loose, turn the fog lights on once and visu- ally confirm that no light is leak- ing through the mounting. When installing the fender liner, screws and clips, reverse the removing procedure in steps...
Page 432 7-3. Do-it-yourself maintenance ■ Stop/tail lights, rear turn signal lights and back-up lights Remove the securing bolts and pull the unit sideways to remove. Turn the bulb base counter- clockwise. Stop/tail light Rear turn signal light Back-up light Remove the light bulb. Stop/tail light Rear turn signal light Back-up light...
Page 433 7-3. Do-it-yourself maintenance ■ License plate light Remove the unit. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 434 (vehicles with LED headlights), side turn signal lights (mirror mounted type) and high mounted stoplight (if equipped) consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 435 7-3. Do-it-yourself maintenance WARNING ■ Replacing light bulbs ● Turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. When it is unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid getting moisture and oils on the bulb.
Page 436 7-3. Do-it-yourself maintenance...
Page 437: When Trouble Arises
When trouble arises 8-1. Essential information Emergency flashers ...436 If your vehicle has to be stopped in an emergency.......437 8-2. Steps to take in an emergency If your vehicle needs to be towed ......439 If you think something is wrong.......445 Fuel pump shut off system (gasoline engine only).........446...
Page 438: 8-1. Essential Information
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 439: If Your Vehicle Has To Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 440 8-1. Essential information WARNING ■ If the engine has to be turned off while driving ● Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 441: Steps To Take In An Emergency If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 442 8-2. Steps to take in an emergency Towing with a wheel-lift type truck From the front From the rear Use a towing dolly under the rear Use a towing dolly under the wheels. front wheels.
Page 443 8-2. Steps to take in an emergency Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the illustrations. 2WD models 4WD models and Pre Runner When attaching the hooks to the rear of the vehicle, make sure to attach them to the inside of the vehicle.
Page 444 8-2. Steps to take in an emergency Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing hooks. This should only be attempted on hard surfaced roads for at most 80 km (50 miles) at under 30 km/h (18 mph).
Page 445 8-2. Steps to take in an emergency ■ While towing If the engine is not running, the power assist for the brakes and steering will not function, making steering and braking more difficult. WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■...
Page 446 8-2. Steps to take in an emergency NOTICE ■ To prevent damage to the vehicle when towing using a wheel-lift type truck ● Do not tow the vehicle from the rear when the engine switch is in the “LOCK” position or the key is removed (vehicles without smart entry & start system) or the engine switch is turned to off (vehicles with smart entry &...
Page 447: If You Think Something Is Wrong
8-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle.
Page 448: Fuel Pump Shut Off System (Gasoline Engine Only)
8-2. Steps to take in an emergency Fuel pump shut off system (gasoline engine only) To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 449: If A Warning Light Turns On Or A Warning Buzzer Sounds
• Low negative pressure in the vacuum tank (diesel engine) → Immediately stop the vehicle in a safe place and con- tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. Charging system warning light (if equipped) Indicates a malfunction in the vehicle’s charging system...
Page 450 • The boost pressure in the turbocharger is abnormally high. (diesel engine) • Malfunction in DPF system (if equipped) → Have the vehicle inspected by your Toyota dealer immediately. SRS warning light Indicates a malfunction in: • The SRS airbag system; or •...
Page 451 Indicates a malfunction in the four-wheel drive system when the light flashes rapidly and a buzzer does not sound. → Have the vehicle inspected by your Toyota dealer immediately. Low speed four-wheel drive indicator light (if equipped) Indicates a malfunction in the four-wheel drive system when the light flashes rapidly.
Page 452 Refer to P. 233. Indicates a malfunction in the DPF system if the light flashes rapidly. → Have the vehicle inspected by your Toyota dealer immediately. Brake Override System warning light (if equipped) Indicates that the accelerator and brake pedal are being depressed simultaneously if the warning light comes on (→P.
Page 453 8-2. Steps to take in an emergency Warning light Warning light/Details/Actions Low engine oil level warning light (if equipped) Indicates that engine oil level is low (This warning light may come on if the vehicle is stopped on a slope. Move the vehicle to a level surface and check to see if the light goes off.) →...
Page 454 If the fuel tank is empty, refuel the vehicle immediately. The malfunction indicator lamp will go off after several trips. If the malfunction indicator lamp does not go off, contact your Toyota dealer as soon as possible. ■...
Page 455 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 456: If A Warning Message Is Displayed
Multi-information display Handling method Follow the instructions of the message on the multi-information display. If any of the warning lights comes on again after the following actions have been performed, contact your Toyota dealer. ∗ : If equipped...
Page 457 Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Toyota dealer immediately. System...
Page 458 Move to a level surface and check to see if the message goes off.) Immediately stop the vehicle in a safe place and contact your Toyota dealer. Continuing to drive the vehicle may be dangerous.
Page 459 Immediately have the vehicle inspected by your Toyota dealer. ● If “Low oil pressure Stop in a safe place” is shown, there may be a malfunc- tion. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Continuing to drive the vehicle may be dangerous.
Page 460 If “VISIT YOUR DEALER”/“Visit your dealer” is shown on the multi-infor- mation display The system or part shown on the multi-information display is malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Warning buzzer In some cases, the buzzer may not be heard due to being in a noisy location or audio sound.
Page 461: If You Have A Flat Tire
8-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: →P. 402 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
Page 462 8-2. Steps to take in an emergency Location of the jack and tools Single-cab models The jack and tools are stored behind the seat. Smart-cab models The jack and tools are stored under the lid. Double-cab models The jack and tools are stored under the bottom cushion.
Page 463 8-2. Steps to take in an emergency WARNING ■ Using the tire jack Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or install- ing and removing tire chains.
Page 464 8-2. Steps to take in an emergency Taking out the jack and tool bag Single-cab models Unhook the strap and take out the tool bag. Take out the jack. For loosening For tightening Smart-cab models Remove the rear seat cushions. (→P. 124) Pull the tag and open the lid.
Page 465 8-2. Steps to take in an emergency Take out the jack. For loosening For tightening Double-cab models Tumbling the bottom cushion (→P. 124) Open the lid. Take out the tool bag. Take out the jack. For loosening For tightening...
Page 466 8-2. Steps to take in an emergency Taking out the spare tire Assemble the jack handle end, jack handle extensions and wheel nut wrench. To assemble the jack handle extension and wheel nut wrench, push in the projection on the jack handle extension.
Page 467 8-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 468 8-2. Steps to take in an emergency Slightly loosen the wheel nuts (one turn). Assembling the jack handle. (→P. 464) Position the jack at the jack points as shown. Front 2WD models: Under the front side rail 4WD models and Pre Run- ner: Under the cross member Rear...
Page 469 8-2. Steps to take in an emergency Raise the vehicle until the tire is slightly raised off the ground. When positioning the jack under the rear axle housing, make sure the groove on the top of the jack fits with the rear axle housing. Remove all the wheel nuts and the tire.
Page 470 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered...
Page 471 8-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 472 8-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. 2WD models Tightening torque: Steel wheels 152 N•m (15.5 kgf•m, 112 ft•lbf) Aluminum wheels 121 N•m (12.3 kgf•m, 89 ft•lbf) 4WD models and Pre Runner Tightening torque:...
Page 473 8-2. Steps to take in an emergency Vehicles with spare tire of the same wheel type as the installed tires: Reinstall the wheel ornament. Type A Type B Type C Stowing the flat tire, jack and all tools Lay down the tire with the outer side facing up, and hook the holding bracket as shown in the illustration.
Page 474 8-2. Steps to take in an emergency Raise the tire. After the tire goes half way up, check that the suspended chain is able to enter the tire hole, for proper storage. Check the tire from the side to see that the tire is stored horizontally.
Page 475: If The Engine Will Not Start
8-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- → dures are being followed ( P. 164, 167), consider each of the following points: The engine will not start even though the starter motor operates normally.
Page 476 ● There may be a malfunction in the steering lock system. (vehicles with smart entry & start system) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with smart entry & start sys-...
Page 477: If The Shift Lever Cannot Be Shifted From P (Automatic Transmission)
(a sys- tem to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted: Set the parking brake.
Page 478: If The Electronic Key Does Not Operate Properly (Vehicles With Smart Entry & Start System)
8-2. Steps to take in an emergency If the electronic key does not operate properly (vehicles with smart entry & start system) If communication between the electronic key and vehicle is interrupted (→P. 118) or the electronic key cannot be used because the battery is depleted, the smart entry &...
Page 479 ACCESSORY mode. Firmly depress the brake pedal. A message indicating how to start the engine will be displayed on the multi-information display. Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer.
Page 480 ACCESSORY mode. Firmly depress the clutch pedal. A message indicating how to start the engine will be displayed on the multi-information display. Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer.
Page 481 8-2. Steps to take in an emergency ■ Stopping the engine Vehicles with automatic transmission Shift the shift lever to P and press the engine switch as you normally do when stopping the engine. Vehicles with manual transmission Shift the shift lever to N and press the engine switch as you normally do when stopping the engine.
Page 482: If The Vehicle Battery Is Discharged
The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 483 8-2. Steps to take in an emergency 2TR-FE engine 1GD-FTV and 2GD-FTV engines...
Page 484 ON mode (vehicles with smart entry & start system). Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible. ■...
Page 485 • If the 20 hour rate capacity is low, even if the time period where the vehi- cle is not used is a short time, the battery may discharge and the engine may not be able to start. ● For details, consult your Toyota dealer. WARNING ■ When removing the battery terminals Always remove the negative (-) terminal first.
Page 486 When the vent plug and indicator are close to the hold down bracket, the battery fluid (sulfuric acid) may leak. ● For information regarding battery replacement, contact your Toyota dealer. ■ To prevent damage to the vehicle (vehicles with manual transmission) Do not pull- or push-start the vehicle as the three-way catalytic converter or catalytic converter may overheat and become a fire hazard.
Page 487: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the engine has cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer.
Page 488 8-2. Steps to take in an emergency The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir. Reservoir “F” line “L” line Radiator cap (if equipped) 1GR-FE engine 2TR-FE engine 1GD-FTV and 2GD-FTV engines...
Page 489 Start the engine to check that the radiator cooling fan operates and to check for coolant leaks from the radiator or hoses. If the fan is not operating: Stop the engine immediately and contact your Toyota dealer. If the fan is operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 490 8-2. Steps to take in an emergency WARNING ■ When inspecting under the hood of your vehicle Observe the following precautions. Failure to do so may result in serious injury such as burns. ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided.
Page 491: If You Run Out Of Fuel And The Engine Stalls (Diesel Engine Only)
If the engine does not start after the above steps have been performed, wait for 10 seconds and try steps again. If the engine still does not start, contact your Toyota dealer. After starting the engine, depress the accelerator pedal lightly until the engine runs smoothly.
Page 492: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P (automatic transmission) or N (manual transmission).
Page 493 8-2. Steps to take in an emergency WARNING ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 494 8-2. Steps to take in an emergency...
Page 495: Vehicle Specifications
Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.)...494 Fuel information ....512 9-2. Customization Customizable features ..514...
Page 496: Maintenance Data (Fuel, Oil Level, Etc.)
9-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions 5265 mm (207.3 in.) Without rear bumper 5285 mm (208.1 in.) Overall length With rear bumper 5335 mm (210.0 in.) 1800 mm (70.9 in.) Without over fender 1815 mm (71.5 in.) Overall width With over fender 1855 mm (73.0 in.)
Page 497 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the rear right frame.
Page 498 9-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. 1GR-FE engine 2TR-FE engine 1GD-FTV and 2GD-FTV engines...
Page 499 9-1. Specifications Engine 1GR-FE engine Model 1GR-FE Type 6 cylinder V type, 4 cycle, gasoline × × Bore and stroke 94.0 95.0 mm (3.70 3.74 in.) Displacement 3956 cm (241.4 cu.in.) Intake: 0.15  0.25 mm (0.006  0.010 in.) Valve clearance Exhaust: 0.29 ...
Page 500 9-1. Specifications 2GD-FTV engine Model 2GD-FTV 4 cylinder in line, 4 cycle, diesel Type (with turbocharger) 92.0 × 90.0 mm (3.62 × 3.54 in.) Bore and stroke Displacement 2393 cm (146.0 cu.in.) Valve clearance Automatic adjustment (engine cold) Drive belt tension Automatic adjustment Fuel Gasoline engine...
Page 501 ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity. Oil grade: 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”...
Page 502 9-1. Specifications Oil viscosity (10W-30 is explained here as an example): • The 10W in 10W-30 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 503 ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”...
Page 504 9-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 505 ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”. Another motor oil of matching quality can also be used.
Page 506 2GD-FTV With automatic transmission engines 9.2 L (9.7 qt., 8.1 Imp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol- Coolant type based non-silicate, non-amine, non- nitrite, and non-borate coolant with long- life hybrid organic acid technology...
Page 507 9-1. Specifications Ignition system (gasoline engine) Spark plug Make 1GR-FE engine DENSO K20HR-U11 NGK LFR6C11 2TR-FE engine DENSO FK20HR-A8 1GR-FE engine 1.1 mm (0.043 in.) 2TR-FE engine 0.8 mm (0.031 in.) NOTICE ■ Iridium-tipped spark plugs (2TR-FE engine) Use only iridium-tipped spark plugs. Do not adjust the spark plug gap. Electrical system Battery 1.250 ...
Page 508 If replacement is necessary, contact your Toyota dealer. NOTICE ■ Automatic transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. Manual transmission 5-speed models 2.6 L (2.7 qt., 2.3 Imp.qt.)
Page 509 Recommended oil viscosity SAE 75W : Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent oil of matching quality that satisfies the above specifica- tions.
Page 510 9-1. Specifications Brakes 87 mm (3.4 in.) models Pedal clearance models and 90 mm (3.5 in.) Pre Runner 1.0  6.0 mm Pedal free play (0.04  0.24 in.) Parking brake lever 7  9 clicks travel Fluid type SAE J1703 or FMVSS No.116 DOT 3 : Minimum pedal clearance when depressed with a force of 490 N (50 kgf, 110 lbf) while the engine is running.
Page 511 9-1. Specifications Tires and wheels 16 inch tires Tire size 215/65R16C 106/104S Rear wheel Rear wheel Tire inflation pressure Front wheel (unladen) (full load) (Recommended cold tire kPa (kgf/cm kPa (kgf/cm kPa (kgf/cm inflation pressure) or bar, psi) or bar, psi) or bar, psi) Single-cab models 240 (2.4, 35)
Page 512 9-1. Specifications 17 inch tires (type B) Tire size 265/65R17 112S Rear wheel Rear wheel Front wheel (unladen) (full load) Tire inflation pressure kPa (kgf/cm kPa (kgf/cm kPa (kgf/cm (Recommended cold tire or bar, psi) or bar, psi) or bar, psi) inflation pressure) 200 (2.0, 29) 200 (2.0, 29)
Page 513 9-1. Specifications Light bulbs Light bulbs Type Headlights High/low beams (halogen headlights) 60/55 High beams (LED headlights) Fog lights Front position lights/daytime running lights 21/5 (halogen headlights) Front turn signal lights Exterior Halogen headlights LED headlights Rear turn signal lights Back-up lights License plate light Stop/tail lights...
Page 514: Fuel Information
■ If your engine knocks ● Consult your Toyota dealer. ● You may occasionally notice light knocking for a short time while accelerat- ing or driving uphill. This is normal and there is no need for concern.
Page 515 The use of fuel with more than 5% FAME content (B5) will damage the vehicle’s fuel system. You must ensure that refueling is carried out only from a source where fuel specification and quality can be guaranteed. In case of any doubt, ask your Toyota dealer.
Page 516: Customizable Features
The settings of these features can be changed using the multi-information display or at your Toyota dealer. Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Customizing vehicle features ■...
Page 517 9-2. Customization Customizable features Settings that can be changed using the multi-information display Settings that can be changed by your Toyota dealer Definition of symbols: O = Available, – = Not available ■ Gauges, meters and multi-information display (→P. 87, 90)
Page 518 9-2. Customization Customized Function Default setting setting Fuel consumption 10.0 – comparison Fuel price – Saving (No currency (Dollar) Currency – unit) : For details about each function: →P. 87, 90 : Some status screens cannot be registered (indicated on multi-information display).
Page 519 9-2. Customization WARNING ■ During customization As the engine needs to be running during customization, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Page 520 9-2. Customization...
Page 521: Index
Index What to do if... (Troubleshooting) .....520 Alphabetical index ......524 For vehicles with navigation system or multimedia system, refer to the “Navigation and Multimedia System Owner’s Manual” for information regarding the equipment listed below. • Navigation system • Audio/visual system...
Page 522 Toyota dealer. The doors cannot be locked, unlocked, opened or closed You lose your keys ● If you lose your keys, new genuine keys can be made by your Toyota dealer. (→P. 105) ● Vehicles with smart entry & start system: If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly.
Page 523 What to do if... (Troubleshooting) If you think something is wrong The engine does not start (vehicles without smart entry & start system) ● Vehicles with manual transmission: Do you turn the key with the clutch pedal depressed firmly? (→P. 164) ●...
Page 524 What to do if... (Troubleshooting) The steering wheel cannot be turned after the engine is stopped ● Vehicles without smart entry & start system: It is locked to prevent theft of the vehicle if the key is removed from the engine switch.
Page 525 What to do if... (Troubleshooting) A warning buzzer sounds when leaving the vehicle (vehicles with smart entry & start system) ● Is the message displayed on the multi-information display? Check the message on the multi-information display. A warning light turns on or a warning message is displayed ●...
Page 526: Alphabetical Index
Alphabetical index Alphabetical index Modification and disposal of airbags ....40 A/C........348, 353 Side airbag operating Air conditioning filter....409 conditions ......41 Automatic air conditioning Side airbag precautions ..39 system ........ 353 Side and curtain shield Manual air conditioning airbags operating system ........
Page 527 Alphabetical index Care Back-up lights Replacing light bulbs..... 430 Aluminum wheels....377 Wattage......... 511 Exterior ......... 376 Interior........379 Battery Seat belts......380 Battery checking ....396 If the vehicle battery is CD player ........ 275 discharged ......480 Chains........239 Preparing and checking Child restraint system....
Page 528 Alphabetical index Child-protectors....... 110 Doors Cleaning......376, 379 Door glasses......136 Aluminum wheels....377 Door lock....... 107 Exterior........376 Open door warning light..450 Interior........379 Outside rear view mirrors..133 Seat belts ......380 Rear door child-protectors ..110 Clock .........
Page 529 Alphabetical index Engine “ACC” position ...... 165 Eco Driving Indicator... 79, 80 Compartment ......388 EDR (Event data recorder) ..10 Engine switch....164, 167 Electronic key Hood ........386 If the electronic key does How to start the not operate properly ... 476 engine......
Page 530 Alphabetical index Engine switch light Fuel (ignition switch light) .... 359 Capacity........ 498 Event data recorder (EDR) ..10 Fuel filter ....... 401 Fuel gauge......83 Fuel pump shut off system..446 Gas station information..536 Flat tire........459 If you run out of fuel Floor mat ........
Page 531 Alphabetical index High mounted stoplight Replacing ......432 Jack Hill-start assist control.... 222 Vehicle-equipped jack... 460 Hood.......... 386 Jack handle ......464 Hooks Jam protection function Coat hooks......374 Power windows..... 137 Grocery bag hooks....373 Retaining hooks (floor mat)..26 Horn ..........
Page 532 Alphabetical index Light MP3 disc ......... 275 Engine switch light ....359 Multi-information display Fog light switch ..... 193 Drive information..... 92 Headlight switch....189 Language......515 Illuminated entry system ..361 Switching the display ....88 Interior lights ......360 Trip information....
Page 533 Alphabetical index Rear view mirror Inside rear view mirror ..132 Parking brake Outside rear view mirrors..133 Operation ......188 Rear view monitor system ..205 Parking brake engaged Rear window defogger ..349, 355 warning buzzer ....447 Refueling ........
Page 534 Alphabetical index Seats Snow tires ........ 238 Adjustment ......122 Spare tire Adjustment precautions ..123 Inflation pressure ....509 Child seats/child restraint Storage location....459 system installation ....47 Spark plug ........ 505 Cleaning........ 379 Specifications ......494 Removing the rear seat Speedometer......
Page 535 Alphabetical index Power door lock switch ..109 Transmission Power window switch.... 136 Automatic transmission..175 Rear window defogger If the shift lever cannot be switch........349 shifted from P ..... 475 “RESET” button.......88 Manual transmission..... 181 Telephone switches ....325 TRC (Traction Control)....
Page 536 Alphabetical index Washer Checking....... 400 Warning buzzers Preparing and checking Fuel filter ....... 449 before winter....... 238 Key reminder......166 Switch ........194 Seat belt reminder....450 Washing and waxing ....376 Warning lights Wheels ........407 ABS........448 Replacing wheels....459 Automatic transmission fluid Size........
Page 537 Alphabetical index : Refer to “Navigation and Multimedia System Owner’s Manual”.
Page 538: Gas Station Information
GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 386 P. 198 Hood lock release Fuel filler door Tire inflation pressure lever opener P. 386 P. 198 P. 509 Fuel tank capacity (Reference) 80 L (21.1 gal., 17.6 Imp.gal.) Unleaded gasoline with a Research 1GR-FE engine Octane Number of 95 or higher...

Toyota Hilux Owner's Manual

Table of Contents

25 1 for Safety and Security

Theft Deterrent System Engine Immobilizer

1-1. for Safe Use

1-2. Child Safety

Child Restraint Systems

75 2 Instrument Cluster

101 Operation of 3

Operation of each Component

3-1. Key Information

3-3. Adjusting the Seats

Opening and Closing

141 4 Driving

4-1. before Driving

Refueling

Using the Driving Support

4-6. Driving Tips

Table of Contents

Audio System

5-2. Basic Operations

Basic Operations

Setup

5-4. Using the Audio System

Using the Radio

Using an External Device

5-8. Connecting Bluetooth

Connecting Bluetooth

Bluetooth Audio

Bluetooth ® Phone Using a Bluetooth ® Phone

5-11. Contact

Contact

5-12. Bluetooth

347 6 Interior Features

Using the Air Conditioning System and Defogger Manual Air Conditioning System

Using the Interior Lights

6-3. Using the Storage Features

375 7 Maintenance and Care

7-1. Maintenance and Care

7-2. Maintenance

Maintenance Maintenance Requirements

Do-It-Yourself Maintenance

Do-It-Yourself Maintenance Do-It-Yourself Service Precautions

435 8 When Trouble Arises

8-1. Essential Information

Steps to Take in an Emergency if Your Vehicle Needs to be Towed

Vehicle Specifications

Specifications Maintenance Data

Quick Links

Chapters

Troubleshooting

Related Manuals for Toyota Hilux

Summary of Contents for Toyota Hilux
