Toyota HILUX 2008 Owner's Manual
  1. Manuals
  2. Brands
  3. Toyota Manuals
  4. Automobile
  5. HILUX 2008
  6. Owner's manual

Toyota HILUX 2008 Owner's Manual

Hide thumbs Also See for HILUX 2008:
Table of Contents

Advertisement

Quick Links

For your safety and comfort,
read carefully and keep in the vehicle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HILUX 2008 and is the answer not in the manual?

Questions and answers

Related Manuals for Toyota HILUX 2008

Summary of Contents for Toyota HILUX 2008

  • Page 1 For your safety and comfort, read carefully and keep in the vehicle.
  • Page 2 For important information about this manual and your Toyota, read the following pages carefully. When it comes to service, remember that your Toyota dealer knows your vehicle very well and is interested in your complete satisfaction. Your Toyota dealer will provide quality maintenance and any other assistance you may require.
  • Page 3 Important information about this manual Safety and vehicle damage warnings Safety symbol Throughout this manual, you will see safety and vehicle damage warnings. You must follow these warnings carefully to avoid possible injury or damage. The types of warnings, what they look like, and how they are used in this manual are explained as follows: CAUTION This is a warning against anything which may cause...
  • Page 4 Occupant restraint systems Fuel and fuel filter (diesel engine) Toyota encourages you and your family to take the time to read Section 1−3 of this Owner’s Manual carefully. In The fuel filter for a diesel engine does not need to be terms of helping you understand how you can receive replaced periodically.
  • Page 5 SRS (Supplemental Toyota recommends you to read the provisions in Sec- Restraint System) airbags are, as their names imply, tion 1−3 carefully and refer to them as needed during designed to work with, and be supplemental to, seat your time of ownership of this vehicle.
  • Page 6 SRS airbag system and seat belt pretensioner system, ries which are not genuine Toyota products, nor for re- be sure to check with your Toyota dealer for precaution- placement or installation involving such parts.
  • Page 7 In addition, this ve- service shop or by your Toyota dealer before you scrap hicle has a higher ground clearance and center of gravi- your vehicle.
  • Page 8 Driving system Grade 15, 16: Two−wheel drive models S: SR 25, 26: Four−wheel drive models D: DLX The model code appears on the manufacturer’s plate with the heading “MODEL”. See “Your Toyota’s identification” on page 176 for the manufacturer’s plate location.
  • Page 9 viii...

  • Page 10: Table Of Contents

    ......... . Other equipment 2 INFORMATION BEFORE DRIVING YOUR TOYOTA ... . .

  • Page 12: Operation Of Instruments And Controls

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Overview of instruments and controls Instrument panel overview ........Instrument cluster overview .
  • Page 13 Instrument panel overview "View A 1. Side vent ..... . . 2. Personal lights* ....3.
  • Page 14 "View B 1. Front passenger’s seat belt reminder light ....2. Clock with multi−information display* ....148, 154 3.
  • Page 15 Instrument cluster overview "With tachometer (type A) 11H012 1. Tachometer ..... . 4. Engine coolant temperature 6. Trip meter reset knob .
  • Page 16 "With tachometer (type B) 11h001 1. Tachometer ..... . 4. Engine coolant temperature 6. Trip meter reset knob ... . gauge .
  • Page 17 "Without tachometer 11H009 1. Engine coolant temperature 3. Service reminder indicators 5. Trip meter reset knob ... . gauge ......and indicator lights .
  • Page 18 Indicator symbols on the instrument panel Anti−lock brake system warning light* Brake system warning light* (on some models) Open door warning light* Driver’s seat belt reminder light* SRS warning light* Front passenger’s seat belt reminder light* Timing belt replacement warning light* Charging system warning light* (diesel engine) Low engine oil pressure warning light*...
  • Page 19 Automatic transmission indicator light Tail light indicator light (on some models) (on some 5−speed models) Automatic transmission indicator light Headlight high beam indicator light (on some 4−speed models) : For details, see “Service reminder indicators and warning Turn signal indicator lights buzzers”...

  • Page 20: Keys And Doors

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Keys and Doors Keys ............Engine immobilizer system .

  • Page 21: Keys

    Keys Your vehicle is supplied with two kinds Your Toyota dealer will need one of mas- of keys. ter keys to make a new key with a built− in transponder chip. 1. Master keys—These keys work in ev- To protect items locked in the glove box ery lock.
  • Page 22 12h005 12h006 12h007 NOTICE z When starting the engine, do not z Do not bend the key grip. use the key with other transponder z Do not cover the key grip with any When using a key containing a trans- keys around (including keys of oth- material that cuts off electromagnet- ponder chip, observe the following...

  • Page 23: Engine Immobilizer System

    The engine will start only when occurs, contact your Toyota dealer. need additional keys, duplicates can be the electronic code in the chip corre- made by a Toyota dealer using the key The indicator light stays on. sponds to the registered ID code for number.

  • Page 24: Wireless Remote Control

    For your Toyota dealer to make a new key Do not leave the key in places where with a built−in transponder chip, your deal-...
  • Page 25 If you lose your wireless remote control Locking operation key, contact your Toyota dealer as soon If the lock switch is pushed while the key as possible to avoid the possibility of is in the ignition, locking will not be per- theft, or an accident.
  • Page 26 1. Open the cover using a flathead screw- z Replace only with the same or driver wrapped with plastic tape. equivalent type recommended by a Toyota dealer. z Dispose of used batteries according to the local laws. Replace the battery by following these...
  • Page 27 4. Remove the discharged battery and put After replacing the battery, check that the in a new battery with positive (+) side key operates properly. If the key still does not operate properly, contact your Toyota dealer.

  • Page 28: Side Doors

    Side doors 12h009 12h010 12h011b LOCKING AND UNLOCKING WITH KEY LOCKING UNLOCKING WITH LOCKING UNLOCKING WITH INSIDE LOCK KNOB POWER DOOR LOCK SWITCH Insert the key into the keyhole and turn (on some models) Move the lock knob. Push the switch. To lock: Turn the key forward.

  • Page 29: Power Windows

    Power windows (on some models) CAUTION Before driving, be sure that the doors are closed and locked, especially when small children are in the ve- 12h018 12h012 hicle. Along with the proper use of seat belts, locking the doors helps prevent the driver and passengers from being thrown out from the ve- hicle in an accident.
  • Page 30 Window lock switch 12h013 12h014 12h019 Automatic opening operation: Push the OPERATING PASSENGERS’ switch completely down and then release WINDOWS it. The window will fully open. To stop the Use the switch on each passenger’s window partway, lightly pull the switch up door or the switches on the driver’s and then release it.

  • Page 31: Quarter Windows

    Quarter windows (on extra−cab models) CAUTION Be sure to remove the ignition key when you leave your vehicle. To avoid death or serious injury, you Never leave anyone (particularly a must do the following. small child) alone in your vehicle, Before you close the power win- especially with the ignition key still 12H034...

  • Page 32: Tailgate

    Tailgate Type A: To open the tailgate, unlock the latches as shown. Type B: To open the tailgate, pull the handle up. The support cables will hold the tailgate 12h033b 12h021 horizontal. See “Luggage stowage precautions” on page 175 for precautions when loading luggage.

  • Page 33: Hood

    Hood 12h022 12h023a 12h024 To open the hood: 2. In front of the vehicle, pull up the 3. Hold the hood open by inserting the auxiliary catch lever and lift the support rod into the slot. 1. Pull the hood lock release lever. The hood.

  • Page 34: Fuel Tank Cap

    Fuel tank cap (type A) CAUTION After inserting the support rod into the slot, make sure the rod supports the hood securely preventing from 12i062 12h025 falling down on to your head or body. NOTICE Be sure to return the support rod to its clip before closing the hood.
  • Page 35 The fumes are flammable. the event of an accident. 12h026 When opening the cap, do not re- Use only a genuine Toyota fuel tank move the cap quickly. In hot weath- cap for replacement. It is designed er, fuel under pressure could cause to regulate fuel tank pressure.
  • Page 36 Fuel tank cap (type B) CAUTION Do not smoke, cause sparks or al- low open flames when refueling. The fumes are flammable. 12i062 12h053 When opening the cap, do not re- move the cap quickly. In hot weath- er, fuel under pressure could cause injury by spraying out of the filler neck if the cap is suddenly re- moved.
  • Page 37 Make sure the cap is tightened se- curely to prevent fuel spillage in the event of an accident. 12h054 Use only a genuine Toyota fuel tank cap for replacement. It is designed to regulate fuel tank pressure. 2. To remove the fuel tank cap, turn...

  • Page 38: Occupant Restraint Systems

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Occupant restraint systems Seats ............Front seats .

  • Page 39: Seats

    Front seats— Seats —Front seat precautions While the vehicle is being driven, all ve- Driver seat Slightly recline the back of the hicle occupants should have the seatback seat. Although vehicle designs vary, upright, sit well back in the seat and prop- CAUTION many drivers can achieve the 250 erly wear the seat belts provided.
  • Page 40 —Seat adjustment precautions Front passenger seat CAUTION Do not put objects under the seats. Otherwise, the objects may interfere CAUTION Do not adjust the seat while the with the seat−lock mechanism or vehicle is moving as the seat may unexpectedly push up the seat posi- The SRS front passenger airbag also unexpectedly move and cause the tion adjusting lever and the seat...
  • Page 41 —Adjusting front seats (separate type) 1. SEAT POSITION ADJUSTING LEVER CAUTION Hold the center of the lever and pull it up. Then slide the seat to the desired Avoid reclining seatback position with slight body pressure and more than needed. The seat belts pro- release the lever.
  • Page 42 —Adjusting front seats —Moving front passenger’s (bench type) seat (on extra−cab models) 1. SEAT POSITION ADJUSTING LEVER Pull the lever up. Then slide the seat to the desired position with slight body pressure and release the lever. 2. SEATBACK ANGLE ADJUSTING 13H054 LEVER...

  • Page 43: Removing Rear Seat Cushions

    Removing rear seat cushions (on extra−cab models) CAUTION CAUTION After putting back the seat, try When removing or reinstalling the pushing the seat forward and rear- seat cushions, observe the following ward to make sure it is secured in precautions to prevent personal inju- 13h097 place.

  • Page 44: Tumbling Rear Seat Cushion

    Tumbling rear seat cushion (on double−cab models) To prevent death or serious injury in a collision or sudden stop: When reinstalling the seat cush- ions, be careful not to hit the seat cushions against you or inside of 13H175 13h004a the vehicle.

  • Page 45: Head Restraints

    Head restraints For your safety and comfort, adjust the CAUTION head restraint before driving. To raise: Pull it up. When returning the seats to their To lower: Push it down while pressing the original position, observe the follow- lock release button. ing precautions in order to prevent 13h051 Rear head restraints—When an occupant...

  • Page 46: Seat Belts

    Seat belts— —Seat belt precautions Toyota strongly urges that the driver and If a child must sit in the front seat, the CAUTION passengers in the vehicle be properly re- seat belts should be worn properly. If an strained at all times with the seat belts...
  • Page 47 Be careful not to damage the belt Australian owners: Observe the fol- It is essential to replace the entire webbing or hardware. Take care that lowing additional WARNINGS. assembly after it has been worn in a severe impact even if damage to they do not get caught or pinched WARNING: Seat belts are designed in the seat or doors.
  • Page 48 Position the lap belt as low as possible Toyota dealer. Do not use the seat tractor and insert the tab into the on your hips—not on your waist, then ad- until the seat belt is fixed, because buckle.
  • Page 49 CAUTION CAUTION Both high−positioned lap belts and Always make sure the shoulder belt loose−fitting belts could cause is positioned across the center of death or serious injuries due to your shoulder. The belt should be 13h024 sliding under the lap belt during a kept away from your neck, but not collision or other unintended event.
  • Page 50 If the seat belt does not function Buckle normally, immediately contact your Toyota dealer. Do not use the seat until the seat belt is fixed, because To release the belt, press the buckle Sit up straight and well back in the...
  • Page 51 —Seat belt pretensioners Too high 13H098 13h007 Adjust to a snug fit Keep as low on hips as possible Remove excess length of the belt and To release the belt, press the buckle The driver and front passenger seat adjust the belt position. release button.
  • Page 52 1. SRS warning light rounding area or wiring. Consult your Toyota dealer about any repair 2. Front airbag sensors and modification. 3. Airbag sensor assembly 4. Seat belt pretensioner assemblies The seat belt pretensioners are controlled by the airbag sensor assembly.
  • Page 53 If any of the following conditions occurs, NOTICE this indicates a malfunction of the airbags or seat belt pretensioners. Contact your Do not perform any of the following Toyota dealer as soon as possible. changes without consulting your Toyota dealer.

  • Page 54: Srs Driver And Front Passenger Airbags

    The SRS front airbags help reduce injuries mainly to the driver’s or front passenger’s In the following cases, contact your Toyota The SRS (Supplemental Restraint Sys- head or chest caused by hitting the ve-...
  • Page 55 The SRS front airbags will deploy if the The driver and front passenger can child restraint system. Toyota severity of the impact is above the de- be killed or seriously injured by the strongly recommends that all in- signed threshold level, comparable to an...
  • Page 56 Hitting curb, Falling into or edge of pavement Collision from the rear jumping over a 13h009 13h010 13h106 or hard surface deep hole Collision from the side Landing hard or vehicle falling Vehicle rollover The SRS front airbags are generally not The SRS front airbags may also deploy The SRS front airbag system consists designed to inflate if the vehicle is in-...
  • Page 57 These tors very quickly fills the airbags with Toyota strongly recommends that: non−toxic gas to help restrain the forward are usually in the nature of minor burns motion of the occupants.
  • Page 58 13h107 13h108 13h109 Do not sit on the edge of the seat Toyota strongly recommends that all Do not put anything or any part of infants and children be placed in or lean against the dashboard when your body on or in front of the...
  • Page 59 Modification of the front end struc- can result in death or serious injury. It goes off after about 6 seconds. This ture Consult your Toyota dealer about any means the SRS front airbags are oper- z Attachment of a grille guard (bull repair and modification.

  • Page 60: Child Restraint

    Child restraint— —Child restraint precautions If any of the following conditions occurs, Toyota strongly urges the use of ap- this indicates a malfunction of the airbags propriate child restraint systems for or seat belt pretensioners. Contact your children. Toyota dealer as soon as possible.
  • Page 61 A child restraint system for a small Double−cab models: A forward−facing child restraint sys- child or baby must itself be properly Toyota strongly urges use of a should allowed restrained on the seat with either the proper child restraint system which...
  • Page 62 If your child restraint system does not provide a locking clip, you can purchase the following item from your Toyota dealer. Locking clip for child restraint system (Part No. 73119−22010)
  • Page 63 —Installation with 3−point type seat belt (ALR/ELR belt) 13h011 13h115a (A) Baby (infant) seat (C) Junior (booster) seat (A) BABY (INFANT) SEAT INSTALLATION A baby (infant) seat must be used in rear−facing position only. (B) Child (convertible) seat...
  • Page 64 13H162a 13H118 13H140 To install the baby (infant) seat: Do not install a child restraint sys- CAUTION 1. Run the lap and shoulder belt through tem on the rear seat if it interferes or around the baby (infant) seat follow- Extra−cab models: with the lock mechanism of the ing the instructions provided by its...
  • Page 65 2. Fully extend the shoulder belt to put it 3. While pressing the baby (infant) seat Contact your Toyota dealer in the lock mode. When the belt is firmly against the seat cushion and immediately. Do not install the child...
  • Page 66 13H119a 13H120a 13H049 4. Attach the child restraint attaching clip 5. To remove the baby (infant) seat, press CAUTION to the child restraint anchor fitting. the buckle release button and allow the Make sure the clip is securely attached belt to retract completely. The belt will Push and pull the child restraint sys- and tighten the upper anchorage strap.
  • Page 67 13h116a 13h163a 13H121 CHILD (CONVERTIBLE) SEAT Do not install a child restraint sys- CAUTION INSTALLATION tem on the rear seat if it interferes A child (convertible) seat must be used Extra−cab models: with the lock mechanism of the in forward−facing or rear−facing posi- front seats.
  • Page 68 To install the forward−facing child (con- 2. Fully extend the shoulder belt to put it Contact your Toyota dealer vertible) seat: in the lock mode. When the belt is immediately. Do not install the child then retracted even slightly, it cannot 1.
  • Page 69 13H161 13H123a 13H122a 3. While pressing the child (convertible) 4. Attach the child restraint attaching clip CAUTION seat firmly against the seat cushion to the child restraint anchor fitting. and seatback, let the shoulder belt re- Make sure the clip is securely attached Push and pull the child restraint sys- tract as far as it will go to hold the and tighten the upper anchorage strap.
  • Page 70 13h011 13h164a 5. To remove the child (convertible) seat, (C) JUNIOR (BOOSTER) SEAT INSTAL- CAUTION press the buckle release button and LATION allow the belt to retract completely. The A junior (booster) seat must be used in Extra−cab models: belt will move freely again and be forward−facing position only.
  • Page 71 Both high−positioned lap belts and child from death or serious injury. loose−fitting belts could cause Contact your Toyota dealer immedi- death or serious injuries due to ately. install child To install the junior (booster) seat: sliding under the lap belt during a restraint system on the seat until collision or other unintended event.
  • Page 72 You can purchase a child restraint anchor chorages under the rear seat cushion. allow the belt to retract. fitting package from your Toyota dealer. When installing a child restraint, follow The anchor fitting package consists of: both the instructions here and those pro- Bolt—5/16”...
  • Page 73 Bolt Attaching clip Anchor fitting Lock washer Spacers Upper anchorage strap Front of vehicle Anchor fitting Front of vehicle CHILD RESTRAINT ANCHORAGE 2. Install a 5/16” 18 UNC × 30 mm (1.2 ATTACHMENT OF THE ATTACHING CLIP in.) bolt through the lock washer and 1.
  • Page 74 If your child restraint system does not provide a locking clip, you can purchase one at your Toyota dealer. (See “—Child restraint system” on page 50.)
  • Page 75 Contact your Toyota dealer side, please contact your Toyota immediately. Do not install the child dealer for the installation of the restraint system on the seat until child restraint system in the front the seat belt is fixed.
  • Page 76 —Installation with 2−point type seat belt 13H155 13h153 13h157 (A) BABY (INFANT) SEAT CHILD (CONVERTIBLE) SEAT INSTALLATION CAUTION A child (convertible) seat must be used in forward−facing position only. Do not install a baby (infant) seat in either the front center or rear center positions.
  • Page 77 It may child from death or serious injury. also hamper your driving. Contact your Toyota dealer immedi- To install the child (convertible) seat: ately. install child Double−cab models:...
  • Page 78 13H037a 13H038 13H033 2. While pressing the child (convertible) 3. To remove the child (convertible) seat, CAUTION seat firmly against the seat cushion press the buckle release button. and seatback, tighten the lap belt by Push and pull the child restraint sys- pulling its free end to hold the child tem in different directions to be sure (convertible) seat securely.

  • Page 80: Steering Wheel And Mirrors

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Steering wheel and Mirrors Tilt steering wheel ......... . . Outside rear view mirrors .
  • Page 81 Tilt steering wheel Outside rear view mirrors— CAUTION Do not adjust the steering wheel while the vehicle is moving. Doing so may cause the driver to mishan- 13h013 13h001 dle the vehicle and an accident may occur resulting in death or serious injuries.
  • Page 82 —Power rear view mirror control (on SR grade models*) —Folding rear view mirrors NOTICE If ice should jam the mirror, do not operate the control or scrape the mir- ror face. Use a spray de−icer to free the mirror. 13h014 13h002 *: If you are not sure of which model your vehicle is, see “Model code”...
  • Page 83 Anti−glare inside rear view Vanity mirror mirror CAUTION Do not adjust the mirror while the vehicle is moving. Doing so may cause the driver to mishandle the ve- 13h015 13h026 hicle and an accident may occur re- sulting in death or serious injuries. Adjust the mirror so that you can just To use the vanity mirror, swing down see the rear of your vehicle in the mir-...

  • Page 84: Lights, Wipers And Defogger

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Lights, Wipers and Defogger Headlights and turn signals ........Emergency flashers .

  • Page 85: Headlights And Turn Signals

    Headlights and turn signals Light reminder buzzer A buzzer will remind you to turn the lights off when the driver’s door is opened if you remove the key with the headlight switch left on. 14H002 NOTICE To prevent the battery from being dis- charged, do not leave the switch on longer than necessary when the en- gine is not running.

  • Page 86: Emergency Flashers

    Emergency flashers NOTICE To prevent the battery from being dis- charged, do not leave the switch on longer than necessary when the en- gine is not running. 14H003 14h009 TURN SIGNALS To turn on the emergency flashers, push the switch. To signal a turn, push the headlight/ turn signal lever up or down to position All the turn signal lights will flash.

  • Page 87: Instrument Cluster Light Control

    Instrument cluster light control Front driving lights (on SR grade models*) Interior light (on some models) 15i012 14H004 14h011 To adjust the brightness of the instru- To turn on the front driving lights, twist To turn on the interior light, slide the ment cluster light, turn the knob.

  • Page 88: Personal Lights

    Personal lights Engine (ignition) switch light Windshield wipers and (on some models) (on some models) washer 14h008 14h010 14h005 Type A To turn on the personal light, push the Type A— switch on side 1. To turn the light off, For easy access to the engine switch, push the switch on side 2.
  • Page 89 Twist the interval adjuster upward to blocked. If a nozzle becomes blocked, The key must be in the “ON” position. increase the wiping time interval be- contact your Toyota dealer to have the tween sweeps, and downward to de- Lever position Speed setting vehicle serviced.

  • Page 90: Rear Window Defogger

    Rear window defogger (on some models) NOTICE z When cleaning the inside of the rear window, be careful not to scratch or damage the heater wires or connectors. 14h007 z To prevent the battery from being discharged, turn switch when the engine is not running. To defog or defrost the rear window, push the switch.

  • Page 92: Gauges, Meters And Service Reminder Indicators

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Gauges, Meters and Service reminder indicators Fuel gauge ..........Engine coolant temperature gauge .

  • Page 93: Fuel Gauge

    The indicator lamp goes off after driving 16H016 16I010 several times. If the indicator lamp does not go off, contact your Toyota dealer as soon as possible. Low fuel level warning light Without tachometer Without tachometer...

  • Page 94: Tachometer

    Tachometer (on some models) The gauge indicates the engine coolant NOTICE temperature when the engine switch is on. The engine operating temperature z Do not remove the thermostat in will vary with changes in weather and the engine cooling system as this engine load.

  • Page 95: Odometer And Two Trip Meters

    Odometer and two trip meters 3. Trip meter reset knob—Resets the two trip meters to zero, and also change the meter display. To change the meter display, quickly push and release the knob. The meter display changes in the order from the 16h009 odometer to trip meter A to trip meter B, then back to the odometer each...

  • Page 96: Service Reminder Indicators And Warning Buzzers

    Service reminder indicators and warning buzzers If the indicator or buzzer comes on... Do this. If parking brake is off, stop immediately and contact Toyota dealer. Fasten driver’s seat belt. (indicator and buzzer) Fasten front passenger’s seat belt. Stop immediately and contact Toyota dealer.
  • Page 97 If the indicator or buzzer comes on... Do this. Take vehicle to Toyota dealer. Fill up tank. Take vehicle to Toyota dealer. Close all doors. Take vehicle to Toyota dealer immediately. Take vehicle to Toyota dealer.
  • Page 98 If the indicator or buzzer comes on... Do this. Take vehicle to Toyota dealer. If flashing, drain water.* Shift four−wheel drive control out of “N”. Stop and check. Remove key. Key reminder buzzer Light reminder buzzer Turn off the lights.
  • Page 99 When the brake fluid level is low... seat belt is not fastened. place and contact your Toyota dealer. In this case, the brakes may not work The reminder light continues flashing until CAUTION properly and your stopping distance the driver fastens the seat belt.
  • Page 100 Do not drive the vehicle with the If it comes on while you are driving in warning light on—even for one block. case a, have your vehicle checked/re- It may ruin the engine. paired by your Toyota dealer as soon as possible.
  • Page 101 Never drive at high speed or race the vehicle at low speeds. Have your Toyota engine even after the light goes out. checked by your Toyota dealer as soon as The light comes on when the ignition key possible. is turned to the “ON” position. If the anti−...
  • Page 102 Contact your It goes off after about 6 seconds. This the trip amount gets 150000 km in kilome- Toyota dealer as soon as possible to means the SRS airbags and seat belt ter reading or 90000 miles in mile reading service the vehicle.
  • Page 103 “N”, In this case, have your vehicle checked Toyota dealer or qualified repair shop for or the vehicle can move. and the warning light reset by your Toyota assistance. dealer as soon as possible. NOTICE...
  • Page 104 This buzzer will sound if the headlight above, have it checked by your Toyota switch is left on and the driver’s door is 3. Close the door. dealer as soon as possible.

  • Page 106: Engine (Ignition) Switch, Transmission And Parking Brake

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Engine (ignition) switch, Transmission and Parking brake Engine (ignition) switch ........Automatic transmission .

  • Page 107: Engine (Ignition) Switch

    Engine (ignition) switch “ACC”—Accessories such as the radio CAUTION operate, but the engine is off. If you leave the key in the “ACC” or For manual transmission: “LOCK” position and open the driver’s Never remove the key when the ve- door, a buzzer will remind you to remove hicle is moving, as this will lock the the key.

  • Page 108: Automatic Transmission

    Automatic transmission "5−speed models Your automatic transmission has a shift lock system to minimize the possibility of incorrect operation. This means you can only move out of “P” position when the Selector lever brake pedal is depressed (with the engine switch in “ON”...
  • Page 109 "4−speed models Your automatic transmission has a shift lock system to minimize the possibility of incorrect operation. This means you can only move out of “P” position when the Selector lever brake pedal is depressed (with the engine switch in “ON” position). (a) Selector lever On some models—...
  • Page 110 (b) Normal driving Always use the “D” position for better fuel (c) Using engine braking economy and quieter driving. If the engine 1. Start the engine as instructed in “How To use engine braking, you can downshift coolant temperature is low or when the to start the engine”...
  • Page 111 Shift into the “2” position. The trans- Vehicles with cruise control—When the 4−speed models: mission will downshift to second gear cruise control is being used, even if you Shift into the “3” position. The trans- when the vehicle speed drops down to downshift from “D”...
  • Page 112 Vehicles with cruise control—When the (d) Using “3”, “2” and “L” positions Four−wheel drive models cruise control is being used, even if you (5−speed models) downshift from “D” to “3”, engine braking Transfer The “3”, “2” and “L” positions are used for will not be enabled because the cruise “H2”...
  • Page 113 (e) Using the “2” and “L” positions (f) Backing up NOTICE (4−speed models) 1. Bring the vehicle to a complete stop. z Be careful not to over−rev the en- The “2” and “L” positions are used for 2. With the brake pedal held down with gine.

  • Page 114: Manual Transmission

    Manual transmission (h) Good driving practice NOTICE If the transmission repeatedly shifts up Always use the brake pedal or the and down between fourth (5−speed parking brake to hold the vehicle on models) or third (4−speed models) gear an upgrade. Do not attempt to hold and overdrive when climbing a gentle the vehicle using the accelerator ped- slope, shift the selector lever to the “4”...
  • Page 115 Maximum allowable speeds 1KD−FTV engine 1KD−FTV engine With 205R16C tires With 195R14C tires To get on a highway or to pass slower gear km/h (mph) traffic, maximum acceleration may be nec- gear km/h (mph) “H2” and “H4” “L4” essary. Make sure you observe the follow- 36 (22) (24) ing maximum allowable speed in each...

  • Page 116: Four−Wheel Drive System

    Four−wheel drive system— (a) Front drive control Good driving practice “N” (neutral position): Lever at “N” No power is delivered to the wheels. The If it is difficult to shift into reverse, put vehicle must be stopped. the transmission in neutral, release the clutch pedal momentarily, and then try “L4”...
  • Page 117 (c) Shifting procedure (c) Shifting procedure (b) A.D.D. (on some models) (with automatic transmission) (with manual transmission) The A.D.D. (automatic disconnecting dif- SHIFTING BETWEEN “H2” AND “H4” SHIFTING BETWEEN “H2” AND “H4” ferential) can be engaged or disengaged To shift from “H2” to “H4”, reduce your To shift from “H2”...

  • Page 118: Parking Brake

    Parking brake SHIFTING BETWEEN “H4” AND “L4” CAUTION To shift from “H4” to “L4”, stop the vehicle or reduce your speed to less than Before driving, be sure the parking 8 km/h (5 mph). With your foot off the brake is fully released and the park- accelerator pedal, depress the clutch ped- ing brake reminder light is off.

  • Page 119: Cruise Control

    Cruise control (on some models) The cruise control is designed to main- CAUTION tain a set cruising speed without requir- ing the driver to operate the accelera- To avoid accidentally engaging the tor. Cruising speed can be set to any cruise control, turn the system off speed above 40 km/h (25 mph).
  • Page 120 The cruise control may be temporarily out other than for the above cases, have canceled by the driver or by the system your vehicle checked by your Toyota deal- itself under certain circumstances. Tempo- er at the earliest opportunity. rary cancellation allows the set cruising RESUMING THE CRUISE CONTROL speed to remain in memory.
  • Page 121 If this is the case, contact your Toyota To decrease the vehicle speed, reset to a dealer and have your vehicle inspected. lower speed with the cruise control lever or depress the brake pedal.

  • Page 122: Audio System

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Audio system Reference ..........Using your audio system .
  • Page 123 Using your audio system— Reference —Some basics This section describes some of the basic features on Toyota audio systems. Some information may not pertain to your sys- tem. Your audio system works when the ignition key is in the “ACC” or “ON” position.
  • Page 124 SWITCHING BETWEEN FUNCTIONS YOUR RADIO ANTENNA YOUR CASSETTE PLAYER (type 2) Push “AM”, “FM”, “FM1”, “FM2”, “TAPE” or To lower a manual antenna, carefully push When you insert a cassette, the exposed “DISC” if the system is already on but you it down.
  • Page 125 YOUR COMPACT DISC PLAYER (type 1) YOUR MP3 PLAYER When you insert a disc, gently push it in MP3 files specifications or media formats with the label side up. The compact disc registering their specifications which your player will play from track 1 to the end MP3 player can operate are limited.
  • Page 126 "Type 1 Details of specific buttons, controls, and features are described in the alphabetical list that follows. 18H018...
  • Page 127 1 2 3 4 5 6 (Preset buttons) Sound balance adjustment function— These buttons are used to preset and Push “AM” to turn on the radio and select This knob is also used to adjust the tune in radio stations. the AM band.
  • Page 128 When the audio system is set into com- FM1 FM2 When playing a disc featuring both audio pact disc operation, the display shows the data (CD−DA) and MP3 files, audio data Push “FM1” or “FM2” to turn on the radio track currently being played.
  • Page 129 MP3 Player MP3 Player SCAN There are two random features—You can There are two repeat features—You can Radio either listen to all the files on the compact either replay a file or a whole folder. You can either scan all the frequencies on disc in random order, or only listen to the Repeating a file: a band or scan only the preset stations...
  • Page 130 Compact Disc Player SEEK (Seeking) TEXT Push “SCAN” to scan the tracks on a Radio Compact Disc Player disc. “SCAN” will appear on the display In the seek mode, the radio finds and This button is used to change the display and the player will scan all the tracks on plays the next station up or down the for the compact disc that contains text...
  • Page 131 MP3 Player TRACK (Track up/down) TUNE·FILE (Tuning and File up/down) This button is used to change the display Compact Disc Player Radio for the MP3 file that contains text data. To skip up or down to a different track: Turn the knob clockwise to step up the To change the display, quickly push and Push either side of the “TRACK”...
  • Page 132 "Type 2 Details of specific buttons, controls, and features are described in the alphabetical list that follows. 18I017...
  • Page 133 1 2 3 4 5 6 (Preset buttons) Compact disc (Program) These buttons are used to preset and To eject one compact disc only: Push and Push “ ” to select the other side of a tune in radio stations. release the compact disc eject button.
  • Page 134 Sound balance adjustment function— When the audio system is set into com- pact disc operation, the display shows the Push “AM” to turn on the radio and select This knob is also used to adjust the track or, track and disc number currently the AM band.
  • Page 135 DISC  If the audio system is off, you can turn LOAD on the radio by pushing “FM”. Also, push By using this button, you can select a This button is used to load the compact “FM” to switch from cassette or compact disc you wish to listen to.
  • Page 136 Loading multiple compact discs— RAND (Random) MP3 Player To load multiple compact discs, push and Compact Disc Player There are two random features—You can hold (until you hear a beep when the au- either listen to all the files on the compact There are two random features—You can dio system is on).
  • Page 137 RPT (Repeat) Repeating a track: MP3 Player Quickly push and release “RPT” while the Cassette Player There are two repeat features—You can track is playing. “RPT” will appear on the either replay a file or a whole folder. Push “RPT” while the track is playing. display.
  • Page 138 SCAN Compact Disc Player MP3 Player Radio There are two scan features—You can ei- There are two scan features—You can ei- ther scan the tracks on a specific disc or ther scan the files in a folder on a specif- You can either scan all the frequencies on scan the first tracks of all the discs in the ic disc or scan the first file of all the...
  • Page 139 SEEK (Seeking) When counting the number of tracks you ST (Stereo reception) display want to rewind, remember to count the Radio Your radio automatically changes to stereo current track as well. For example, if you reception when a stereo broadcast is re- In the seek mode, the radio finds and want to rewind to a song that is two be- ceived.
  • Page 140 If this button is pushed while a compact TRACK (Track up/down) TUNE·FILE (Tuning and File up/down) disc that does not contain text data is Compact Disc Player Radio playing, “NO TITLE” will appear on the To skip up or down to a different track: Turn the knob clockwise to step up the display.
  • Page 141 Audio system operating hints CARING FOR YOUR CASSETTE PLAYER Use high−quality cassettes. NOTICE AND TAPES Low−quality cassette tapes can cause To ensure correct audio system op- For the best performance for your cas- many problems, including poor sound, erations: sette player and tapes: inconsistent playing speed,...
  • Page 142 CARING FOR YOUR COMPACT DISC PLAYER AND DISCS Your compact disc player is intended for use with 12 cm (4.7 in.) discs only. Extremely high temperatures can keep your compact disc player from working. On hot days, use the air conditioning to cool the vehicle interior before you listen to a disc.
  • Page 143 NOTICE z Do not use special shaped, trans- parent/translucent, low quality or la- beled discs such as those shown in the illustrations. The use of such z17039 discs may damage the player or changer, or it may be impossible to eject the disc.
  • Page 144 MP3 FILES When playing discs with MP3 files and audio data (CD−DA) such as CD−EX- MP3 is short for MPEG Audio Layer 3 TRA and MIXED−MODE CD, both types and refers to an audio compression can be played only by switching be- technology standard.
  • Page 145 The MP3 player does not play back The turn of play of the compact disc MP3 files from discs recorder using having the structure shown on the left packet write data transfer (UDF for- is as follows: mat). Discs should be recorded using Folder 1 001.mp3 002.mp3 .
  • Page 146 CD−R and CD−RW discs Titles and other text information re- TERMS corded on a CD−R/CD−RW disc may CD−R/CD−RW discs that have not been Packet write— not be displayed by the MP3 player (in subject to the “finalizing process” (a This is a general term for a method of the case of audio data (CD−DA)).
  • Page 147 CD−DA— ISO 9660 format— m3u— CD−DA is an abbreviation of Compact This is the international standard for the Playlists created using the “WINAMP” soft- Disc Digital Audio. It refers to the uncom- format logic of CD−ROM folders and files. ware have a playlist file extension (.m3u). For the ISO 9660 format, there are regula- pressed format of regular CDs.

  • Page 148: Air Conditioning System

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Air conditioning system Controls ........... Air flow selector settings .
  • Page 149 Controls 1. “A/C” button (on some models) 2. Air intake selector 3. Temperature selector 4. Fan speed selector 5. Air flow selector 19h014b...
  • Page 150 Fan speed selector 3. Floor—Air flows mainly from the floor vents. Turn the knob to adjust the fan speed—to the right to increase, to the left to de- Use with the air intake selector posi- tioned in Fresh. crease. Temperature selector 4.
  • Page 151 “A/C” button (on some models) To turn on the air conditioning, press the “A/C” button. The “A/C” button indicator will come on. To turn the air conditioning off, press the button again. h17032 Air intake selector Move the selector lever to select the air source.
  • Page 152 Air flow selector settings Operating tips To cool off your Toyota after it has been parked in the hot sun, drive with the windows open for a few minutes. This vents the hot air, allowing the air conditioning to cool the interior more quickly.
  • Page 153 If following another vehicle on a dusty Heating Air conditioning road, or driving in windy and dusty For best results, set controls to: For best results, set controls to: conditions, it is recommended that the air intake be temporarily set to RECIR- Fan speed—Any setting except “OFF”...
  • Page 154 Ventilation Defogging Defrosting For best results, set controls to: The inside of the windshield The outside of the windshield For best results, set controls to: For best results, set controls to: Fan speed—Any setting except “OFF” Temperature—Towards COLD Fan speed—Any setting except “OFF” Fan speed—Any setting except “OFF”...
  • Page 155 Power heater switch Air conditioning filter— Instrument panel vents (on some models) Open/ adjust 19h016 Close Center vents To turn on the power heater, push the The air conditioning filter information switch. To turn off the power heater, label is placed in the glove box as push the switch once again.
  • Page 156 —Checking and replacing the air conditioning filter The air conditioning filter may clog af- ter long use. The filter may need to be replaced if the air flow of the air condi- tioning and heater experiences extreme reductions in operating efficiency, or if the windows begin to fog up easily in 19H027 19H028...
  • Page 157 19H029 19H030 19H031 2. Remove the filter cover as shown in 3. Pull the filter out of the filter outlet. When inserting the filter in the filter the illustration. Inspect the filter on the surface. outlet, keep the arrow pointing up. If it is dirty, it should be replaced.

  • Page 158: Other Equipment

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Other equipment Multi−information display ........Clock .

  • Page 159: Multi−Information Display

    Multi−information display (on some models) The following information is displayed on the multi−information display when you push the “INFO.” button (on the multi−information display) with the en- gine switch turned on. Each time you push the “INFO.” button, the display changes to the next display setting.
  • Page 160 “––_C” will appear on the display. If fore the engine switch is off will appear. “––_C” appears, contact your Toyota deal- Note that an accurate figure may not be If the electrical power source has been shown in the following cases.
  • Page 161 AVERAGE VEHICLE SPEED DRIVING RANGE (“AVG. km/h”) (“RANGE km”) Average vehicle speed is calculated and The distance the vehicle can travel with displayed based on total driving dis- the remaining fuel is calculated and tance and total driving time with the displayed based on the quantity of re- engine running.
  • Page 162 COMPASS The vehicle is on an inclined surface. Calibrating the compass (deviation calibration) The vehicle is in a place where the The compass indicates the direction in earth’s magnetic field is subject to in- which the vehicle is heading. The direction display on the compass terference by artificial magnetic fields deviates from the true direction deter- Displays...
  • Page 163 After calibration, leave the system for 6 seconds or push the “INFO.” button. The calibration is finished. CAUTION Operate the switches with due care while you are driving to avoid acci- dents. 10i003a Zone number...
  • Page 164 If calibration cannot be performed because of the magnetized vehicle, etc., take your vehicle to Toyota dealer. Perform circling calibration just after you have purchased your Toyota. Then perform circling calibration whenever the battery has been removed, replaced Calibrating the compass If no button is pushed for 6 seconds, the or disconnected.

  • Page 165: Clock

    Clock To set the hour: Push the “H” button. CAUTION To set the minutes: Push the “M” button. The time can also be set by pushing the When performing circling calibra- “H” or “M” button continuously. tion, be sure to secure a wide The key must be in the “ACC”...

  • Page 166: Cigarette Lighter And Ashtrays

    Do not hold the cigarette lighter pressed vent other cigarette butts from catching fire. After using the ashtray, close the lid completely. Use a Toyota genuine cigarette lighter or equivalent for replacement. To remove the ashtray, pull it out of a bottle holder.

  • Page 167: Power Outlet

    Power outlet (on SR grade models*) NOTICE CAUTION z To prevent the fuse from being To reduce the chance of injury in blown, do not use the electricity case of an accident or sudden stop over the total vehicle capacity of while driving, always close the ash- 12V/120W.

  • Page 168: Rear Console Box

    Rear console box Glove box (on some models) CAUTION To reduce the chance of injury in case of an accident or a sudden stop, always keep the glove box door 10i014 19h001a closed while driving. NOTICE Take care when placing sharp−edged objects in the glove box, as they may scratch or damage the inner surface of the compartment.

  • Page 169: Auxiliary Box

    Auxiliary box Cup holders (on some models) The cup holder is designed for holding NOTICE cups or drink−cans securely. Your ve- hicle is equipped with several types of z In hot weather, the interior of the cup holders. To use them, observe the vehicle becomes very hot.
  • Page 170 19h002 19h003 10i018 Type A (Instrument panel) Type C (Console box) Type E (Rear console box) 19h012 19h011 Type B (Console box) Type D (Console box)

  • Page 171: Bottle Holders

    Bottle holders Floor mat NOTICE When using the bottle holder, put a cap with the bottle. Otherwise, the liquid will spill over when opening or closing the door. 19h005 19h006 The bottle holders are designed to hold Use a floor mat of the correct size. bottles securely.
  • Page 172 19h007 CAUTION Observe the following precautions. Failure to do so may result in the floor mat slipping and interfering with the movement of the pedals during driving, resulting in an accident. Make sure the floor mat is properly placed on the vehicle carpet and the correct side faces upward.

  • Page 174: Information Before Driving Your Toyota

    ........Your Toyota’s identification .

  • Page 175: Off−Road Vehicle Precautions

    Off−road vehicle precautions (on four−wheel drive models) This vehicle has higher ground clear- CAUTION ance and narrower tread in relation to the height of its center of gravity to Always observe the following precau- make it capable of performing in a wide tions to minimize the risk of death, variety of off−road applications.

  • Page 176: Break−In Period

    Engine damage caused by use of improp- higher center of gravity, your ve- for the first 1000 km (600 miles) can add er fuels is not covered under Toyota’s new hicle is more sensitive to side to the future economy and long life of vehicle warranty.

  • Page 177: Fuel Pump Shut Off System

    “ACC” or “LOCK” once and start Toyota dealer. performance, the use of premium un- leaded gasoline with a Research Oc- However, occasionally, you may notice tane Number of 95 or higher is rec-...

  • Page 178: Operation In Foreign Countries

    Operation in foreign Three−way catalytic converters countries (gasoline engine) If you plan to drive your Toyota in The three−way catalytic converters are another country... emission control devices installed in the exhaust system. First, comply with the vehicle registration laws. The purpose is to reduce pollutants in the exhaust gas.

  • Page 179: Catalytic Converter

    Use only unleaded gasoline. vehicle in for a check−up as soon z Do not drive with an extremely low as possible. Remember, your Toyota fuel level; running out of fuel could dealer knows your vehicle and its cause the engine to misfire, creat- three−way catalytic converter sys-...

  • Page 180: Engine Exhaust Cautions

    NOTICE inspected and repaired by your z If the engine becomes difficult to Toyota dealer. Failure to do so may start or stalls frequently, take your A large amount of unburned gases allow exhaust gases to enter the vehicle in for a check−up as soon...
  • Page 181 Do not remain for a long time in a Do not leave the engine running in Toyota does not recommend occu- parked vehicle with the engine run- an area with snow build−up, or pying the rear cargo area when it ning.

  • Page 182: Facts About Engine Oil Consumption

    It is normal that an engine should con- regularly. Toyota recommends that the oil A new engine consumes more oil, since sume some engine oil during normal level be checked every time you refuel its pistons, piston rings and cylinder walls engine operation.

  • Page 183: Brake System

    Brake system This brake system is a hydraulic system BRAKE BOOSTER ANTI−LOCK BRAKE SYSTEM with two separate sub−systems. If either (on some models) The brake booster uses engine vacuum to sub−system should fail, the other will still power−assist the brakes. If the engine The anti−lock brake system is designed work.
  • Page 184 Depressing the brake pedal on slippery CAUTION Anti−lock brake system is not de- road surfaces such as on a manhole cov- signed to shorten the stopping dis- er, a steel plate at a construction site, Do not overestimate the anti−lock tance: Always drive at a moderate joints in a bridge, etc.

  • Page 185: Brake Pad Wear Indicators

    If either of the following conditions oc- curs, this indicates a malfunction some- where in the components monitored by the warning light system. Contact your Toyota dealer as soon as possible to service the vehicle. 20h002 The light does not come on when the ignition key is turned to the “ON”...

  • Page 186: Luggage Stowage Precautions

    Rear step bumper Luggage stowage precautions (on some models) When stowing cargo and luggage in the CAUTION vehicle, observe the following: Put cargo and luggage in the rear deck Double−cab models: To prevent car- when at all possible. Be sure all items go and luggage from sliding for- are secured in place.

  • Page 187: Limited−Slip Differential

    This is the primary identification number Use only a spare tire of the same for your Toyota. It is used in registering size, construction and load capacity the ownership of your vehicle. as the original tires on your Toyota because damage to the limited−slip...

  • Page 188: Suspension And Chassis

    —Engine number Suspension and chassis CAUTION Do not modify the suspension/chassis with lift kits, spacers, springs, etc. It can cause dangerous handling charac- 20H017 20h005 teristics, resulting in loss of control. 1GR−FE engine 1KD−FTV engine The engine number is stamped on the engine block as shown.

  • Page 190: Starting And Driving

    SECTION STARTING AND DRIVING Before starting the engine ........How to start the engine .

  • Page 191: Before Starting The Engine

    How to start the engine— (b) Starting the engine Before starting the engine (a) Before cranking (gasoline engine) 1. Check the area around the vehicle be- 1. Apply the parking brake firmly. Before starting the engine, be sure to fore entering it. follow the instructions in “(a) Before 2.
  • Page 192 (b) Starting the engine (diesel engine) If the weather is below freezing, let the NOTICE engine warm up for a few minutes before driving. z Do not crank for more than 30 sec- onds at a time. This may overheat If the engine is warm...

  • Page 193: Precautions For Turning Off An Engine With Turbocharger

    Driving condition and required idling eye! Or, if you would like, your Toyota time dealer will be pleased to make this check Wheel nuts. Make sure no nuts are miss- for you at a nominal cost.

  • Page 194: Tips For Driving In Various Conditions

    To dry them, drive the vehicle cautiously while lightly pressing the brake pedal with the park- ing brake applied. If they still do not work safely, pull to the side of the road and call a Toyota dealer for assistance.

  • Page 195: Driving In The Rain

    Driving in the rain Four−wheel drive models—Toyota rec- Driving on a slippery road surface To drive down a long or steep hill, ommends not using four−wheel drive on Drive carefully when it is raining, because reduce your speed and downshift.

  • Page 196: Off−Road Driving Precautions

    After driving through a puddle, injure your hands. Keep both hands flooded, be sure to have your Toyota lightly depress the brake pedal to and especially your thumbs on the dealer check brake function, changes make sure that the brakes are func- outside of the rim.

  • Page 197: Winter Driving Tips

    Water can wash the grease from selection. causing death or serious injury. You wheel bearings, causing rusting and “Toyota Super Long Life Coolant” is a mix- are also risking expensive damage premature failure, and may also en- ture of 50% coolant and 50% deionized to your vehicle’s suspension and...

  • Page 198: Trailer Towing

    If you are not sure Keep ice and snow from accumulating a distributing hitch. about which oil to use, call your Toyota under the fenders. When the total trailer weight is greater dealer–they will be pleased to help.
  • Page 199 WEIGHT LIMITS The combination of the gross trailer The load on either the front or rear Before towing, make sure the total trail- weight added to the total weight of axle resulting from distribution of er weight, gross vehicle weight, gross the vehicle, occupants and vehicle the gross vehicle weight on both axle weight and trailer tongue load are...
  • Page 200 BRAKES AND SAFETY CHAINS Total trailer weight Tongue load Use only a hitch which is recom- Toyota recommends trailers with brakes mended by the hitch manufacturer and that conform to any applicable state conforms to the total trailer weight re- law.
  • Page 201 Make sure the trailer cargo is securely BREAK−IN SCHEDULE loaded so that it cannot shift. Toyota recommends that you do not Check that your rear view mirrors con- tow a trailer with a new vehicle or a form to any applicable state law. If not,...
  • Page 202 TRAILER TOWING TIPS Because stopping distance may be in- Crosswinds and rough roads will ad- versely affect handling of your vehicle creased, vehicle−to−vehicle distance When towing a trailer, your vehicle will and trailer, causing sway. Pay attention should be increased when towing a handle differently than when not tow- to the rear from time to time to pre- trailer.

  • Page 203: How To Save Fuel And Make Your Vehicle Last Longer, Too

    How to save fuel and make your vehicle last longer, too Because of the added load of the When restarting out after parking on a Improving fuel economy is easy—just take trailer, your vehicle’s engine slope: it easy. It will help make your vehicle last overheat on hot days (at temperatures longer, too.
  • Page 204 Accelerate slowly smoothly. Avoid heavy traffic or traffic jams Keep your vehicle tuned−up and in Avoid jackrabbit starts. Get into high whenever possible. top shape. A dirty air cleaner, carbure- gear as quickly as possible. tor out of adjustment, improper valve Do not rest your foot on the clutch clearance, dirty plugs, dirty oil and Avoid long engine idling.

  • Page 206: In Case Of An Emergency

    SECTION IN CASE OF AN EMERGENCY If your vehicle will not start ........If your engine stalls while driving .

  • Page 207: If Your Vehicle Will Not Start

    It may damage gine still will not start, it needs adjust- the vehicle or cause a collision when ment or repair. Call a Toyota dealer or the engine starts. On vehicles with qualified repair shop for assistance.
  • Page 208 CAUTION If the engine still will not start, it needs If you run out of fuel and the engine adjustment or repair. Call a Toyota dealer dies, the engine may not restart after Batteries contain...
  • Page 209 JUMP STARTING PROCEDURE Discharged If you should accidentally get acid 1. If the booster battery is installed in battery on yourself or in your eyes, remove another vehicle, make sure the vehicles any contaminated clothing and flush are not touching. Turn off all unneces- the affected area with water imme- sary lights and accessories.
  • Page 210 Jumper cable 40h040 40h058 Discharged battery Negative Booster terminal battery (“−” mark) Connecting point for 1GR−FE engine Connecting point for 1KD−FTV engine c. Connect the clamp of the negative (black) jumper cable to the negative (–) Do not connect the cable to or near terminal on the booster battery.

  • Page 211: If Your Engine Stalls While Driving

    9. If removed, replace all the battery vent plugs. If the cause of your battery discharging is not apparent (for example, lights left on), you should have it checked at your Toyota dealer.

  • Page 212: If You Cannot Increase Engine Speed

    Have your Toyota (automatic) or neutral (manual) and ap- When the engine is running, keep checked by your Toyota dealer as soon as ply the parking brake. Turn off the air hands and clothing away from the possible.

  • Page 213: If You Have A Flat Tire

    Block the wheel diagonally opposite system. You should have it checked as to the one being changed if neces- soon as possible at your Toyota dealer. sary. Make sure to set the jack properly in the jack point. Raising the ve-...
  • Page 214 —Required tools and spare tire Never get under the vehicle when the vehicle is supported by the jack alone. Use the jack only for lifting your vehicle during wheel changing. 40h023 40h025 40h025a Do not raise the vehicle with some- one in the vehicle.
  • Page 215 Turn the jack joint by hand. To remove the spare tire: When connecting a jack handle extension with jack handle end, use a Phillips−head To remove: Turn the joint in direction 1 1. Put a wheel nut wrench, jack handle screwdriver or your hand to tighten the until the jack is free.
  • Page 216 40h003 40h036 40h035a 2. Insert the jack handle end with the 3. After the tire is lowered completely to When storing the spare tire, put it in place extensions into the lowering screw the ground, remove the holding bracket with the outer side of the wheel facing up through the access hole and turn it as shown in the illustration.
  • Page 217 —Removing wheel ornament (except two−wheel drive —Blocking the wheel models with aluminum wheels) 3. Remove the wheel ornament. Pry off the wheel ornament, using the beveled end of the wheel nut wrench as shown. 40h021 40h009 CAUTION Do not try to pull off the ornament by hand.
  • Page 218 —Loosening wheel nuts —Positioning the jack CAUTION Front of two−wheel drive models Never use oil or grease on the bolts or nuts. The nuts may loosen and the wheels may fall off, which could cau- 40h026 se serious accident. Front of four−wheel drive models 40h039 4.
  • Page 219 —Raising your vehicle 5. Position the jack at the correct jack To raise the vehicle, insert the jack handle points as shown. end into the jack (it is a loose fit) and turn it clockwise with the wheel nut Two−wheel drive models wrench, making sure the wheel nut wrench Front—Under the side rail remains firmly fitted onto the jack handle...
  • Page 220 —Removing wheel ornament (on two−wheel drive models —Changing wheels with aluminum wheels) 40h022 40h001 40h011 7. Remove the wheel nuts and change Before putting on wheels, remove any cor- 8. Remove the wheel ornament. tires. rosion on the mounting surfaces with a Before stowing the flat tire, remove the wire brush or such.
  • Page 221 —Reinstalling wheel nuts —Lowering your vehicle 9. Reinstall all the wheel nuts finger tight. Reinstall the wheel nuts (tapered end in- ward) and tighten them as much as you can by hand. Press back on the tire and see if you can tighten them more. 40h030 40h018 CAUTION...
  • Page 222 —Reinstalling wheel ornament 10. Lower the vehicle completely and Two−wheel drive models: Have the tighten the wheel nuts. wheel nuts tightened by torque Turn the jack handle end with the exten- wrench to 121 N·m (12.3 kgf·m, 89 sions counterclockwise to lower the ve- ft·lbf) for aluminum wheel and 152 hicle, making sure the handle remains N·m (15.5 kgf·m, 112 ft·lbf) for steel...
  • Page 223 —After changing wheels 12. Check the air pressure of the re- CAUTION placed tire. Adjust the air pressure to the specification Take due care in handling the orna- designated on page 271. If the pressure ment to avoid unexpected personal is lower, drive slowly to the nearest ser- injury.

  • Page 224: If Your Vehicle Becomes Stuck

    If your vehicle becomes stuck If your vehicle becomes stuck in snow, NOTICE CAUTION mud, sand, etc., then you may attempt to rock the vehicle free by moving it If you rock your vehicle, observe the Before driving, make sure all the forward and backward.

  • Page 225: If Your Vehicle Needs To Be Towed

    If towing is necessary, we recommend (a) Towing with wheel lift type truck— (a) Towing with wheel lift type truck— you to have it done by your Toyota dealer or a commercial tow truck ser- —From front —From front vice.
  • Page 226 TOWING PRECAUTIONS: From rear— Four−wheel drive models— Place the ignition key in the “ACC” posi- Use a safety chain system for all towing, (a) Towing with wheel lift type truck and abide by the state/provincial and local tion. From front— laws.
  • Page 227 If towing is necessary, we recommend with front wheels you to have it done by your Toyota ground, as this may cause serious (c) Towing with sling type truck dealer or a commercial tow truck ser- damage to the differential.
  • Page 228 —Emergency towing eyelet precautions A driver must be in the vehicle to steer Before towing, release the parking brake, Before emergency towing, check that it and operate the brakes. put the transmission in neutral (manual) or the eyelet is not broken or damage and “N”...

  • Page 229: If You Cannot Shift Automatic Transmission Selector Lever

    “P” position only while pushing the button. 3. Shift into the “N” position. 4. Start the engine. For your safety, keep the brake pedal depressed. Be sure to have the system checked by your Toyota dealer as soon as possible.

  • Page 230: If You Lose Your Keys

    Toyota dealer if you can give them the key number and master key. Even if you lose only one key, contact your Toyota dealer to make a new key. If you lose all your master keys, you cannot make new keys; the whole engine immobi- lizer system must be replaced.

  • Page 232: Corrosion Prevention And Appearance Care

    SECTION CORROSION PREVENTION AND APPEARANCE CARE Protecting your Toyota from corrosion ..... . . Washing and waxing your Toyota ......
  • Page 233 Now, it is up to Road salt or dust control chemicals will clean by regular washing, but to prevent you. Proper care of your Toyota can help accelerate corrosion, as will the pres- corrosion, the following points should be ensure long−term corrosion prevention.
  • Page 234 Wash your vehicle as soon as pos- shields are installed be treated to resist body shop make the repair. sible. corrosion. Your Toyota dealer will be Check the interior of your vehicle. Wa- happy to assist in supplying and installing When driving in a coastal area...
  • Page 235 Hand−washing your Toyota Plastic wheel ornaments: plastic Plastic bumpers: Wash carefully. Do not wheel ornaments are damaged easily by scrub with abrasive cleaners. The bumper Work in the shade and wait until the organic substances. If any organic sub- faces are soft.
  • Page 236 Toyota dealer to chip. have the vehicle serviced. NOTICE If a nozzle becomes blocked, do not try to clear it with a pin or other...
  • Page 237 Cleaning the interior NOTICE NOTICE CAUTION Do not use solvent, thinner, gasoline z Do not use dye or bleach on the Do not wash the vehicle floor with or window cleaner on the interior. belts—it may weaken them. water, or allow water to get onto the z Do not use the belts until they be- floor when cleaning the vehicle interi- Carpets...
  • Page 238 If you have any questions about the ing the leather as these could cleaning of your Toyota, your local cause discoloring. Toyota dealer will be pleased to answer them. z Use of a nylon brush or synthetic fiber cloth, etc. may scratch the...

  • Page 240: Maintenance Requirements

    SECTION MAINTENANCE REQUIREMENTS Maintenance facts ......... Does your vehicle need repairing? .
  • Page 241 Service Booklet”. rather than while they are working on it. Doesn’t that seem like the best way? Your Toyota dealer has invested a lot of money in special Toyota tools and service equipment. It helps do the job better and Regular maintenance is essential.
  • Page 242 Toyota dealer who will Note that rubber hoses will deteriorate leak. Drive with the windows open and keep a record of maintenance on your with age, resulting in swelling, chafing or have the exhaust system checked im- Toyota.
  • Page 243 If you notice any of these clues, take your vehicle to your Toyota dealer as soon as possible. It probably needs adjustment or repair. CAUTION Do not continue driving with the ve- hicle unchecked. It could result in se- rious vehicle damage and possibly...

  • Page 244: Do−It−Yourself Maintenance Introduction

    SECTION − DO−IT−YOURSELF MAINTENANCE Introduction Engine compartment overview ......Fuse locations .
  • Page 245 Engine compartment overview "1GR−FE engine 1. Engine oil level dipstick 2. Engine coolant reservoir 3. Engine oil filler cap 4. Fuse block 5. Battery 6. Windshield washer fluid tank 7. Condenser 8. Radiator 71h013...
  • Page 246 "2TR−FE engine 1. Engine oil level dipstick 2. Engine oil filler cap 3. Fuse block 4. Battery 5. Windshield washer fluid tank 6. Condenser 7. Radiator 8. Engine coolant reservoir 71h002...
  • Page 247 "1KD−FTV engine 1. Engine oil filler cap 2. Intercooler 3. Engine oil level dipstick 4. Fuel filter 5. Fuse block 6. Battery 7. Windshield washer fluid tank 8. Condenser 9. Radiator 10. Engine coolant reservoir 71h003a...
  • Page 248 Fuse locations Spare fuses 71i005a 71i007 71h001 71i006...
  • Page 249 Do−it−yourself service precautions If you perform maintenance by yourself, CAUTION Be extremely cautious when work- be sure to follow the correct procedure ing on the battery. It contains poi- given in this section. When the engine is running, keep sonous and corrosive sulfuric acid. You should be aware that improper or in- hands, clothing, and tools away Do not get under your vehicle with...
  • Page 250 If you spill brake and clutch fluid, ter in household trash, in sewers or z Add only “Toyota Super Long Life be sure to wash it off with water to onto the ground. Call your dealer or Coolant”...

  • Page 252: Engine And Chassis

    SECTION − DO−IT−YOURSELF MAINTENANCE Engine and Chassis Checking the engine oil level ....... . Checking the engine coolant level .

  • Page 253: Checking The Engine Oil Level

    Checking the engine oil level With the engine at operating tempera- If the oil level is below or only slightly ture and turned off, check the oil level above the low level, add engine oil of Low level Full level on the dipstick.
  • Page 254 ENGINE OIL SELECTION Recommended viscosity (SAE): Gasoline engine— “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent satisfy following grade viscosity. Oil grade: 20W−50 and 15W−40— API grade SL or SM multigrade...
  • Page 255 Diesel engine— good starting in cold weather. ACEA (Association des Construc- “Toyota Genuine Motor Oil” is used in If you use SAE 10W−30 or a higher teurs Européens d’Automobiles) your Toyota vehicle. Use Toyota approved viscosity engine oil in extremely low “Toyota Genuine Motor Oil”...

  • Page 256: Checking The Engine Coolant Level

    “Toyota Genuine cock and water pump. Motor Oil” is available, which has been NOTICE If you can find no leak, have your Toyota specifically tested and approved for all dealer test the cap pressure and check Toyota engines.

  • Page 257: Checking The Radiator, Condenser And Intercooler

    (diesel engine) If any of the above parts are extremely dirty or you are not sure of their condi- tion, take your vehicle to a Toyota dealer. CAUTION 17h001 To prevent burning yourself, be care- ful not to touch the radiator, con- denser or intercooler when the engine is hot.

  • Page 258: Checking Tire Inflation Pressure

    If a tire frequently needs refilling, have it overheated tire sures that are even just a few pounds checked by your Toyota dealer. off can degrade ride and handling. Poor sealing of the tire bead Do not bleed or reduce tire inflation Wheel deformation and/or tire sepa- pressure after driving.

  • Page 259: Checking And Replacing Tires

    The tires on your Toyota have built−in This applies also to the spare tire and this may cause dangerous handling treadwear indicators to help you know tires stored for future use.

  • Page 260: Rotating Tires

    Toyota recommends all four tires, or at With a spare tire of the same wheel type balance wheels, or severe braking. least both front or rear tires be re- as the installed tires placed at a time as a set.

  • Page 261: Installing Snow Tires And Chains

    Installing snow tires and chains WHEN SNOW TIRES SNOW TIRE INSTALLATION CAUTION CHAINS Snow tires should be installed on all Snow tires or chains are recommended wheels. Observe the following instructions. when driving on snow or ice. Installing snow tires on the rear wheels Otherwise, an accident may occur re- On wet or dry roads, conventional tires only can lead to an excessive difference...

  • Page 262: Replacing Wheels

    When installing chains on your tires, care- Correct replacement wheels are available When driving with chains installed, fully follow the instructions of the chain at your Toyota dealer. be sure to drive carefully. Slow manufacturer. down before entering the curves to A wheel of a different size or type may avoid losing control of the vehicle.

  • Page 263: Aluminum Wheel Precautions

    Otherwise, an accident may occur re- sulting in death or serious injuries. When balancing your wheels, use only Toyota balance weights or equivalent Do not use wheels other than the and a plastic or rubber hammer. manufacturer’s recommended size,...

  • Page 264: Electrical Components

    SECTION − DO−IT−YOURSELF MAINTENANCE Electrical components Checking battery condition ........Battery recharging precautions .

  • Page 265: Checking Battery Condition

    Checking battery condition— —Checking battery exterior —Precautions CAUTION EMERGENCY MEASURES Ground Terminals cable If electrolyte gets in your eyes, BATTERY PRECAUTIONS flush your eyes with clean water The battery produces flammable and immediately immediate explosive hydrogen gas. medical attention. If possible, con- 73h002 tinue to apply water with a sponge Do not cause a spark from the bat-...
  • Page 266 —Checking battery fluid NOTICE O.K. z Be sure the engine and all accesso- Upper line ries are off before preforming main- tenance. 73h001 z When checking the battery, remove the ground cable from the negative terminal (“−” mark) first and rein- stall it last.

  • Page 267: Battery Recharging Precautions

    Battery recharging Checking and replacing fuses precautions During recharging, the battery is pro- ducing hydrogen gas. Therefore, before recharging: 1. Remove the vent plugs. 2. If recharging with the battery installed 73i022 73i023 on the vehicle, be sure to disconnect the ground cable.
  • Page 268 Turn the engine switch and inoperative Blown Good component off. Pull the suspected fuse straight out and check it. Determine which fuse may be causing the problem. The lid of the fuse box shows the name of the circuit for each fuse. See 73i025a 73i002a page 272 for the functions controlled by...

  • Page 269: Adding Washer Fluid

    LEDs. If any of the LEDs burn return the substitute to its original clip. product is available at your Toyota dealer out, take your vehicle to your Toyota deal- It is a good idea to purchase a set of and most auto parts stores. Follow the er to have the light replaced.
  • Page 270 Stop/tail lights 21/5 Toyota dealer. Back−up lights License plate lights 1. Open the hood. Interior light For easy access to the right−hand headlight (except for the 1GR−FE en-...
  • Page 271 Make sure the rubber cover fits securely bulb with the cutouts of the mounting on the connector and the headlight body. hole. Aiming is not necessary after replacing the bulb. When aiming adjustment is nec- essary, contact your Toyota dealer.
  • Page 272 If the connector is tight, wiggle it. Aiming is not necessary after replacing the bulb. When aiming adjustment is nec- essary, contact your Toyota dealer.
  • Page 273 —Front turn signal lights —Parking lights 73h024 73h006a 73h008 For easy access to the right−hand front turn signal light (except for the 1GR−FE engine): Release the clips of the air cleaner filter cover, and remove both the cover and filter. 73h007a 73h009...
  • Page 274 —Rear turn signal, stop/tail —Side turn signal lights and back−up lights 73h010 73h012 73h013 Front of vehicle Use a Phillips−head screwdriver. 73h011 73h014...
  • Page 275 —License plate lights 73h015 73h016 73h018 a: Stop/tail light b: Rear turn signal light c: Back−up light 73h017...

  • Page 276: Specifications

    SECTION SPECIFICATIONS Dimensions ..........Engine .

  • Page 277: Dimensions

    Dimensions Engine Fuel Overall length mm (in.) 5130 (202.0) Model: Fuel type: 1GR−FE, 2TR−FE and 1KD−FTV 5255 (206.9) 1GR−FE engine— Type: Overall width mm (in.) 1760 (69.3) Unleaded gasoline Research Octane 1GR−FE engine Number 91 or higher. For improved 1835 (72.2) 6 cylinder V type, 4 cycle, gasoline vehicle performance, the use of pre- Overall height...

  • Page 278: Service Specifications

    ACEA B1 1GR−FE engine Without filter 6.6 (7.0, 5.8) Recommended oil viscosity (SAE): DENSO K20HR−U11 “Toyota Genuine Motor Oil” is used in LFR6C11 Gasoline engine your Toyota vehicle. Use Toyota approved 2TR−FE engine “Toyota Genuine Motor Oil” or equivalent DENSO K20HR−U11...
  • Page 279 Diesel engine COOLING SYSTEM Coolant type: Total capacity, L (qt., Imp. qt.): “Toyota Super Long Life Coolant” is used in your Toyota vehicle at factory 1GR−FE engine fill. In order to avoid technical problems, With manual transmission only “Toyota Super...
  • Page 280 Two−wheel drive models ing automatic transmission fluid, use only ing automatic transmission fluid, use only 2.6 (2.7, 2.3) “Toyota Genuine ATF WS” to aid in assur- “Toyota Genuine ATF Type T−IV” to aid in Four−wheel drive models ing maximum transmission performance.
  • Page 281 DIFFERENTIAL CHASSIS LUBRICATION STEERING Oil capacity, L (qt., lmp. qt.): Propeller shafts: Wheel free play: Less than 30 mm (1.2 in.) Two−wheel drive models Spiders (four−wheel drive models) 3.2 (3.4, 2.8) Lithium base chassis grease, NLGI Power steering fluid type: No.2 Automatic transmission fluid DEXRONrII Four−wheel drive models...

  • Page 282: Tires

    Tires Tire size and cold tire inflation pressure: TWO−WHEEL DRIVE MODELS kPa (kgf/cm or bar, psi) Rear Model of vehicle Model of vehicle Tire size Tire size Front Front Unloaded Loaded 195R14C−8PR 106/104S 300 (3.0, 44) Single cab models Single−cab models 240 (2 4 35) 240 (2.4, 35) 450 (4 5 65)

  • Page 283: Fuses

    Fuses 80i001 80i002 80h001 Engine compartment Front passenger side kick panel Instrument panel 1. SPARE 25 A: Spare fuse 10. FR HTR 40 A: Air conditioning system, 16. AM2 30 A: Engine starter, “ST”, “IGN” “A/C” fuse and “INJ” fuses 2.
  • Page 284 23. ECU−B 7.5 A: Door courtesy switches, 36. INJ 15 A: Multiport fuel injection sys- 45. ACC 7.5 A: Audio system, power out- power door lock system, wireless re- tem/sequential multiport fuel injection let, clock, power rear view mirror con- mote control system, engine immobiliz- system trol system, shift lock control system...

  • Page 286: Index

    SECTION INDEX...
  • Page 287 Coolant level ..... . Protecting your Toyota Brightness control ....
  • Page 288 Engine Before starting the engine ..Defogger, Rear window ....Economical driving, Saving money Catalytic converter ....Differential, Limited slip .
  • Page 289 Fuel Bleeding the fuel system ... Facts about engine oil Identification Draining fuel filter water ... . consumption ..... . Engine .
  • Page 290 (seat belt pretensioners) ... . Protecting your Toyota from corrosion .....
  • Page 291 Seats ....... . Service and maintenance ... . Quarter windows .
  • Page 292 Unengaged “Park” warning light . . . 87, 92 Vanity mirror ......Vehicle identification number ..Warning buzzer .
  • Page 293 JQ−4 Quick index D If a service reminder indicator or warning buzzer comes on ..D If your vehicle will not start ........D If your engine stalls while driving .

Table of Contents

Save PDF
