Summary of Contents for Celsius CONDOR
- Page 2 - 1 -...
-
Page 3: Important Safety Notice
IMPORTANT SAFETY NOTICE NOTE THE FOLLOWING PRECAUTION BEFORE ASSEMBLING OR OPERATING THE MACHINE. 1. Assemble the machine exactly as the descriptions in the instruction manual. 2. Check all the screws, nuts and other connections before using the machine for the first time and ensure that the trainer is in the safe condition. -
Page 4: Exploded Diagram
EXPLODED DIAGRAM - 3 -... -
Page 5: Parts List
PARTS LIST DESCRIPTION DESCRIPTION Main frame Allen bolt M8XL72 Round end cap Pedal (L/R) Handlebar foam grip Crank(L/R) Computer Leveler end cap Handlebar Rear stabilizer Front handlebar cover Allen Bolt M8XL90 Allen Bolt Arc washer M8X15 D8X2 XΦ25 XR39 Pulse sensor wire Pop-pin knob M16X1.5X32 Rear handlebar cover... -
Page 6: Assembly Instruction
ASSEMBLY INSTRUCTION STEP 1 Attach the front Stabilizer (18) to the Main frame (1) with the Allen bolts (20) and Arc washers (19), and then fix the rear Stabilizer (24) to the Main frame (1) with the Allen bolts (25) and Arc washers (26) as shown. - Page 7 STEP 3 Attach the Pedals (21) to the Cranks (22) respectively, viewed from the rider’s exercising position. Always make sure the Pedals are securely tightened before any exercise. Note: Both pedals are engraved with L for left and R for right. To tighten turn the Left pedal COUNTERCLOCKWISE and the Right pedal CLOCKWISE.
- Page 8 STEP 5 A: Feed the Pulse sensor wires (8) out of the Handlebar post (11) through the computer bracket on the top. Attach the Handlebar (5) to the Handlebar post (11), secured with the Allen bolts (7) and Spring washers (36) as shown.
-
Page 9: Maintenance And Treatment
Maintenance and Treatment Verify that all the bolts and nuts are locked properly and the turning parts should be turned freely without damaged parts. Clean the equipment with soap and slightly damp cloth only. Please do not use any solvent to clean the equipment. -
Page 10: Warm-Up And Cool-Down
WARM-UP and COOL-DOWN A successful exercise program consists of a warm-up, aerobic exercise, and a cool-down. Do the entire program at least two and preferably three times a week, resting for a day between workouts. After several months, you can increase your workouts to four or five times per week. WARM-UP The purpose of warming up is to prepare your body for exercise and to minimize injuries. -
Page 11: Warranty Information
Warranty Information This product is guaranteed to be free from quality and manufacturing defects for a period of one (1) year. If your product becomes defective during this period, Rebel Sport Limited will offer you either a replacement, credit or refund where a product is faulty; wrongly described; different from the sample shown to you or does not do what it is supposed to do.
