19. RESETTING FILTER (Filtered units only. For non filtered units proceed to step 20)
In order to access the programming button, the lower door must be open. The button is located at the bottom of the
upper panel
With your finger, depress the program button for approximately 2 seconds until the display changes then release.
The display will change and scroll through three messages:
"RST FLTR" – Reset Filter Status LED
"RST BCNT" – Reset Bottle Count
"RNG SET" – Range Set for IR Sensor
If the program button is not pushed again the display will scroll through the three messages above for three cycles
and then default
back to bottle count and be back in run mode.
When the display changes to "RST FLTR", depress the button again. The display will change to show "FLT=".
Depress the button again and the display will show "FLTR=0". The green LED shoud now be illuminated indicating
that the visual filter monitor has been reset.

20. RESETTING BOTTLE COUNTER

In order to access the programming button, the lower door must be open. The button is located at the bottom of the
upper panel
With your finger, depress the program button for approximately 2 seconds until the display changes then release.
The display will change and scroll through three messages:
"RST FLTR" – Reset Filter Status LED
"RST BCNT" – Reset Bottle Count
"RNG SET" – Range Set for IR Sensor
If the program button is not pushed again the display will scroll through the three messages above for three cycles
and then default
back to bottle count and be back in run mode.
When the display changes to "RST BCNT", depress the button again. The display will change to show current bottle
count value i.e. "BC0033183". Depress the button again and the display will change to "BTLCT=0" for approximately
2 seconds and then return to run mode displaying 000000. You can test the bottle counter by running water
approximately 5 seconds to see bottle counter advance 1.
