Summary of Contents for Simaudio MOON 888
- Page 1 MOON Mono Power Amplifier Owner’s Manual...
- Page 3 Simaudio Ltd., 1345 Newton Road Boucherville, Québec J4B 5H2 CANADA Date Code: 05052017...
- Page 4 Important Safety Instructions 1. Read these instructions. 11. Only use attachments and accessories specified by the manufacturer. 2. Keep these instructions. 12. Use only with the cart, stand, tripod, bracket, or table 3. Heed all warnings. specified by the manufacturer or sold with the 4.
- Page 5 COMPLETELY BEFORE OPERATING YOUR MOON 888 POWER AMPLIFIER 1. ALWAYS disconnect your entire system from the AC mains 6. NEVER wet the inside of the MOON 888 with any liquid. If a before connecting or disconnecting any cables, or when liquid substance does enter your MOON 888, immediately cleaning any component.
-
Page 6: Table Of Contents
Table of Contents Introduction Unpacking Installation & Placement Rear Panel Connections Connecting the 888 Balanced Operation Operating the 888 Troubleshooting Remote Operation with the 12V Trigger Specifications / Fuse Replacement... -
Page 7: Introduction
Before setting up your new MOON 888, we encourage you to please read this manual thoroughly to properly acquaint yourself with its features. We hope you enjoy listening to the MOON 888 as much as the pride we have taken in creating this extraordinary audio product. -
Page 8: Unpacking
You should never place another component on top of this amplifier. As well, the amplifier should be placed on a solid level surface. No need for adjustments as the feet of the MOON 888 are self-levelling. -
Page 9: Rear Panel Connections
Rear Panel Connections Figure 1: Rear panel of the MOON 888... -
Page 10: Connecting The 888
Operation” on for further information. these two inverted signals on a balanced line are input into a differential power amplifier such as the MOON 888, any 2. Select the proper type of input with the switch labeled noise picked up by the interconnect will be eliminated since... -
Page 11: Troubleshooting
The blue LED located on the front panel also indicates the operational status of the MOON 888. In the unlikely event the LED starts blinking on and off during normal use, it means it has detected a problem. It is a “smart” power... -
Page 12: Remote Operation With The 12V Trigger
Remote Operation with the 12V Trigger If you wish you to connect your 888 amplifiers in such a way that they turn on or off following the state of your preamplier, see figure below on how to connect the system using the MOON 850P as example. Both connection schemes works the same, just use the configuration most convenient for you. -
Page 13: Specifications / Fuse Replacement
Specifications Configuration Fully balanced Differential, mono Power Supply Transformers 2 x 1.5kVA Power Supply Capacitance 350,000µF Class Of Operation A/AB Input Impedance 24kΩ Input Sensitivity 2.4V Output Device Type MOON Bipolars – 32 Output Power at 8Ω 888 Watts per channel Output Power at 4Ω...
