RECEIVER CONNECTION

Bind Cable
Antenna
FailSafe
Binding is the process of programming the receiver to recognize
the GUID (Globally Unique Identifier) code of a single specific
transmitter. When a receiver is bound to a transmitter, the receiver
will only respond to that specific transmitter. If you need to rebind for
any reason, please follow these steps:
1. With the transmitter switched OFF
2. Insert the bind cable to bind channel slot.
3. Power on the receiver, then turn on the transmitter with pressing
on the bind button within 5 seconds after receiver is power on.
4. Loose the bind button and wait for about 5 seconds.
5. After the receiver stop blinking, it means the binding is finished
6. Unplug the bind cable and then you are ready to run.
CAUTION: DO NOT leave the bind cable in the bind channel
plug after binding finished, otherwise the binding program will
work automatically each time when you power on the receiver.

FAILSAFE Setting

The EX2 comes with the receiver failsafe set to NONE. In the event
of loss of signal the motor will stop and the vehicle willdrift. If the
signal is regained normal function willreturn. If you wish to program
the failsafe to a custom setting just follow these simple steps:
1. With both the transmitter and receiver powered ON, press the bind
button on the receiver for about 3 seconds.
2. The receiver will enter the failsafe setting menu and the receiver
LED will flash.
3. You have about 3 seconds to move the controls to the position that
you wish to program into failsafe.
4. After the 3 seconds the receiver will save the settings and return to
normal mode.
5. If you wish to reset to a different setting, simply repeat the above
steps.
6
BINDING
BIND BUTTON
EXMITTER EX2 Digital Radio System
