Throttle TRIM
The throttle trim dial is used to
adjust the throttle trim when
the throttle stick is released
(neutral position). This is typically
used to adjust the brakes.
Rotating the dial causes the
throttle trim (the throttle position
at rest) to be changed.
STEERING TRIM
The steering trim dial is used to
adjust the steering trim when
the wheel is centered.
Rotating the dial changes the
steering trim (the steering at rest
position). Normally, the steering
trim is adjusted until the vehicle
tracks straight.
INSTALL YOUR RECEIVER
RECEIVER
BATTERY
ELECTRICAL
Install the Receiver in your vehicle using double-sided Velcro. Velcro
will hold the receiver in place and help isolate it from vibrations.
Mount the antenna up and away from the vehicle in an antenna tube.
The higher up the antenna is, the better signal it will receive.
CAUTION: Do not cut the antenna.
5
ELECTRONIC
SPEED CONTROL
EXMITTER EX2 Digital Radio System
Throttle Trim
Steering Trim
BEC
RECEIVER
GAS INSTALLATION
STEERING
THROTTLE
Advertisement
Table of Contents
Need help?
Do you have a question about the EX2 and is the answer not in the manual?
Questions and answers
My receiver does not respond to the bind plug. This joins the two outside connectors. The LED flashes about once a second. It's the same rate with bind plug fitted then powered on. The transmitter is turned on with bind button pressed and on releasing I hear several beeps. But nothing changes on receiver. I've tried 2 bind plugs. EX2 system with hand held controller. Help!
If your EXMITTER EX2 receiver does not respond to the bind plug and the LED flashes once a second, you should rebind the transmitter and receiver by following these steps:
1. Turn off the transmitter.
2. Insert the bind cable into the bind channel slot on the receiver.
3. Power on the receiver.
4. Within 5 seconds of powering on the receiver, turn on the transmitter while pressing the bind button.
5. Release the bind button and wait about 5 seconds.
6. Once the receiver stops blinking, binding is complete.
7. Remove the bind cable from the receiver.
Do not leave the bind cable inserted after binding is complete.
