- Page 1 EXMITTER -- Professional Remote Control Products Expert...
-
Page 2: Safety Precautions
• If at any time during the operation of your model you observe any erratic or abnormal operation, immediately stop operation of your model until the cause of the problem has been ascertained and corrected. EXMITTER EX6 Digital Radio System... -
Page 3: Transmitter Details
Channel 6 Channel 7 Knob Elevator Throttle Aileron Rudder Throttle Trim Elevator Trim Aileron Trim Rudder Trim Menu/Enter Back Down MODE 2 Elevator Throttle Rudder Aileron Elevator Trim Throttle Trim Aileron Trim Rudder Trim MODE 1 EXMITTER EX6 Digital Radio System... -
Page 4: Install Batteries
When the battery voltage drops below The EX6 comes with a retreatable 4.3 volts, an alarm will sound and the antenna. When transporting, you can voltage LEDs will flash. rotate it down at rear place to save space. EXMITTER EX6 Digital Radio System... -
Page 5: Install Your Receiver
5. After the receiver LED stop flashing, it means the binding is done. Failsafe Setting The EX7 comes with the receiver failsafe set to NONE. In the event of loss of signal the motor will stop and the vehicle will willdrift. If the signal is regained normal function will return. -
Page 6: Menu Functions
Menu Functions The EX7 comes with a digital LCD screen displaying a 3-level menu. Press Menu button to turn on/off background light of the screen. Following below instructions you are able to operate settings to EX7. D/R Setting D/R function allows you to adjust the travel volume of channels, its volume is based on Endpoint function. - Page 7 Sub-Trim Trim Buttons Sub-trim function allows to adjust channel servo travel center point from -30% to +30%. Sub-trim can be accumulated with trimming by adjusting trim buttons on transmitter. EXMITTER EX6 Digital Radio System...
-
Page 8: Digital Trims
Digital Trims The EX7 comes with digital trims. Each time a trimmer is moved the servo output will change one step. If the trimmer is held, the output will scroll in that direction until the trimmer is released or the output reaches its end. -
Page 9: Model Select
Setting adjustments apply to the current selected model only, including reset operation. Multi-button Function Settings EX7 allows you to adjust more setting for further usage, which requires multi-button operations. Follow below instructions to achieve the function settings. EXMITTER EX6 Digital Radio System... - Page 10 14dbm. 3. Logo on/off Holding BACK & UP while powering on -- Display / hide EXMITTER logo. 4. Mode1 / Mode 2 Switch Holding OK & DOWN & K6 while powering on -- Saved as Mode 2(left throttle).
- Page 11 FHSS is an advanced radio control system with better performance of anti-interference. EX6 comes with FHSS system, its faster frequence prevents interference signal from catching up. Therefore using this system allows the radio to work in a more stable environment. Perform Range Check EXMITTER EX6 Digital Radio System...
- Page 12 As a precaution, an operational ground range check should be performed before the first flight each time out. Performing a range check is a good way to detect problems that could cause loss of control such as low batteries , defective or damaged radio components or radio interference.
