When transporting this unit, be sure to use the unit's packing materials and box so as to protect
it against any damage, in particular, dents in the front grille during transportation.
本機を輸送する場合、輸送時の破損 (特に、フロントグリルのへこみ) 等を防ぐために必ず専用の梱
包箱を使用してください。
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already
known and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and
service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable
and specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please
contact the distributor's Service Division.
WARNING:
IMPORTANT:
I CONTENTS
TO SERVICE PERSONNEL .......................................... 2
FRONT PANEL .............................................................. 3
REAR PANELS .............................................................. 3
BOTTOM PANEL ........................................................... 4
REMOTE CONTROL PANELS ...................................... 4
SPECIFICATIONS / 参考仕様 ........................................ 5
INTERNAL VIEW ........................................................... 5
SET MENU TABLE ........................................................ 6
ファームウェアの書き込み ..................................... 13~23
1 0 0 9 6 6
DIGITAL SOUND PROJECTOR
YSP-800
IMPORTANT NOTICE
Failure to follow appropriate service and safety procedures when servicing this product may result in personal
injury, destruction of expensive components, and failure of the product to perform as specified. For these reasons,
we advise all YAMAHA product owners that any service required should be performed by an authorized
YAMAHA Retailer or the appointed service representative.
The presentation or sale of this manual to any individual or firm does not constitute authorization, certification or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
2005
This manual is copyrighted by YAMAHA and may not be copied or
redistributed either in print or electronically without permission.
SERVICE MANUAL
自己診断機能(ダイアグ) ..................................... 24~40
DISPLAY DATA ........................................................... 41
IC DATA ................................................................. 42~43
BLOCK DIAGRAM ....................................................... 44
PRINTED CIRCUIT BOARD .................................. 45~53
PIN CONNECTION DIAGRAM .................................... 54
SCHEMATIC DIAGRAM ........................................ 55~60
PARTS LIST ........................................................... 61~77
REMOTE CONTROL .............................................. 78~79
All rights reserved.
P.O.Box 1, Hamamatsu, Japan
'05.09

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha YSP-800

  • Page 1: Table Of Contents

    This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already known and understood by the users, and have therefore not been restated.
  • Page 2: To Service Personnel

    YSP-800 I TO SERVICE PERSONNEL AC LEAKAGE WALL EQUIPMENT TESTER OR 1. Critical Components Information OUTLET UNDER TEST EQUIVALENT Components having special characteristics are marked s and must be replaced with parts having specifications equal to those originally installed. 2. Leakage Current Measurement (For 120V Models Only)
  • Page 3: Front Panel

    YSP-800 I FRONT PANEL J model I REAR PANELS U, C models CAUTION: Detach the two metals from the rear panel. When you transport this unit, attach these metals again and use the original package. ATTENTION: Détachez les deux pièces en métal de la face arrière.
  • Page 4: Bottom Panel

    YSP-800 I BOTTOM PANEL U, C, J models I REMOTE CONTROL PANELS RRC4001-2603EM RRC4001-2601EM RRC4001-2602EM (J model) (U model) (C, T, K, A, B, G, L, V models) WF75640 WF72990 WF72980 電 源 電 源 電 源 STANDBY/ON POWER POWER...
  • Page 5: Specifications / 参考仕様

    YSP-800 I SPECIFICATIONS / 参考仕様 I Amplifier Section / アンプ部 • DIMENSIONS / 寸法図 Weight / 質量 Maximum Power / 実用最大出力 (EIAJ) [10% THD, 4 ohms] ..............9.0 kg (19 lbs. 13 oz.) Woofer [100 Hz] ..............20 W/ch Tweeter [1 kHz] ..............2 W/ch Finish / 仕上げ...
  • Page 6: Set Menu Table

    YSP-800...
  • Page 7: Service Precautions / サービス時の注意事項

    YSP-800 I SERVICE PRECAUTIONS / サービス時の注意事項 安全対策 Safety measures ・ この製品の内部には高電圧部分があり危険です。修理の • Some internal parts in this product contain high voltages and are dangerous. Be sure to take safety measures 際は、絶縁性の手袋を使用するなどの安全対策を行って ください。 during servicing, such as wearing insulating gloves. ・ C523には電源をOFFにした後も電荷が残り、高電圧が...
  • Page 8 YSP-800 Rear Panel リアパネル Fig. 1 Top Cover トップカバー Frame Top フレームトップ Grill Net Ass'y グリルネットASSY Grill Bottom Ass'y グリルボトムASSY Front Grill フロントグリル Fig. 2 7. Removal of Bufful Unit 7. バッフルユニットの外し方 a. 9 のネジ17本を外します。 (Fig. 3) a. Remove 17 screws (9). (Fig. 3) b.
  • Page 9 YSP-800 AMP P.C.B DSP P.C.B Bufful Unit CB704 CB708 CB707 CB10 バッフルユニット Driver (Woofer) Bufful Unit Driver (Woofer) スピーカーユニット(ウーファー) バッフルユニット スピーカーユニット(ウーファー) Fig. 3 9. Removal of Frame Bottom C 9. フレームボトムCの外し方 a. A のネジ14本、 B のネジ8本を外します。 (Fig. 4) a. Remove 14 screws (A) and 8 screws (B). (Fig. 4) b.
  • Page 10 YSP-800 11.INPUT ( 2) INPUT P.C.B.の外し方 11. Removal of INPUT(2) INPUT P.C.B. a. Remove connector CB5. (Fig. 4) a. コネクターCB5を外します。 (Fig. 4) b. D のネジ6本, E のネジ2本を外します。 (Fig. 4) b. Remove 6 screws (D) and 2 screws (E). (Fig. 4) c.
  • Page 11 YSP-800 Bufful Unit バッフルユニット AMP P.C.B DSP P.C.B CB715 CB11 CB714 CB709 CB711 CB713 CB710 CB712 Fig. 6 17. スピーカーユニット (ツイーター) の外し方 17. Removal of Driver (Tweeter) a. K のネジ2本/個を外します。 (Fig. 7) a. Remove 2 screws/piece (K). (Fig. 7) b. Remove the Driver (Tweeter). (Fig. 7) b.
  • Page 12 YSP-800 P.C.B.チェックをする場合には When checking the P.C.B. : • The Rear Unit removed from the unit does not work ・ 取り外したリアユニットはアースが浮いて動作しませ because its grounding is loose. Be sure to connect the んので、リード線等でシャーシ、またはGNDに接続し てください。 (Fig. A) ground of the Rear Unit to the chassis or GND with a lead wire or the like.
  • Page 13: ファームウェアの書き込み

    YSP-800 I UPDATING FIRMWARE / ファームウェアーの書き込み When the following parts have been replaced with servicing 下記の部品をサービス部品に交換した場合、最新のファー ムウェアの書き込みを行ってください。 parts, be sure to write the updated data of the firmware. P.C.B. DSPのIC11:X6962B00 IC11 of P.C.B. ASS’Y DSP : X6962B00 ... Writing of DSP ...
  • Page 14 CPUの書き込み 1. Install DSP_FLASHER(YSP).exe into the PC. 1. PCにDSP_FLASHER(YSP).exeをインストールします。 2. YSP-800とPCの電源を入れる前にそれぞれをRS232C 2. Before turning on the power to YSP-800 and PC, connect each of them using RS232C conversion jig and 変換治具を使い、RS232Cケーブル (クロスケーブル) で 接続します。 (Fig. 1) RS232C cable (cross cable). (Fig. 1) Slit / 溝...
  • Page 15 YSP-800 5. 送信データ、ポートを選択します。 5. Select the data to be transmitted and port. · MOT FILE ・ MOT FILE Select “SA2_xxxxxxx.mot”. “SA2_xxxxxxx.mot”を選択します。 ・ RS232C · RS232C Select the port of RS-232C. 接続しているRS-232Cポートを選択します。 Press this button to open the window このボタンを押すとウィンドウが開きます Select the firmware ファームウェアを選択します...
  • Page 16 ます。 The press the [OK] button to end the procedure. [OK] ボタンを押して完了します。 8. YSP-800の電源コードをACコンセントから抜きます。 8. Disconnect the power cable of YSP-800 from the AC outlet. Writing of DSP DSPの書き込み 1. Install DSP_FLASHER(YSP).exe into the PC.
  • Page 17 YSP-800 4.“YSP DSP” タグを選択します。 4. Select “YSP DSP” Tag. 5. Select the data to be transmitted and port. 5. 送信データ、ポートを選択します。 ・ DSP HEX FILE · DSP HEX FILE Select “YSPx00_verxxxx.hex”. “YSPx00_verxxxx.hex”を選択します。 ・ RS232C · RS232C 接続しているRS-232Cポートを選択します。 Select the port of RS-232C.
  • Page 18 YSP-800 7. YSP-800の電源コードをACコンセントに接続し、YSP- 7. Connect the power cable of YSP-800 to the AC outlet. While pressing the “VOL+” key and “VOL-” key of the 800の “VOL+” キーと “VOL-” キーを押しながら、リモコ YSP-800, press the “STANDBY/ON” key of the remote ンの “STANDBY/ON” キーを押し、ダイアグを起動しま...
  • Page 19 ば完了です。 The procedure is completed when the value is obtained for “SUM from FILE” and “SUM from SET”. Confirm the value of SUM SUM値を確認します 10.YSP-800の “STANDBY/ON” キーを押し、電源をOFFに 10.Press the “STANDBY/ON” key of the YSP-800 to turn off the power. します。...
  • Page 20 RS232C cable (cross cable). (Fig. 1) 接続します。 (Fig. 1) 3. YSP-800の電源コードをACコンセントに接続し、YSP- 3. Connect the power cable of YSP-800 to the AC outlet. While pressing the “VOL+” key and “VOL-” key of the 1の “VOL+” キーと “VOL-” キーを押しながら、リモコン YSP-1, press the “STANDBY/ON” key of the remote の...
  • Page 21 YSP-800 5. 送信データ、ポートを選択します。 5. Select the data to be transmitted and port. · COM Port ・COM Port Select the port of RS-232C. 接続しているRS-232Cポートを選択します。 ・D/load Protocol · D/load Protocol Select “SPCM Protocol” SPCMプロトコルを選択します。 Select the port of RS-232C 接続しているRS-232Cポートを選択します Select SPCM Protocol SPCMプロトコルを選択します...
  • Page 22 4 Press the [Done] button. 4 [Done] ボタンを押します。 5 For restarting, use the “STANDBY/ON” key of the 5 YSP-800またはリモコンの “STANDBY/ON” キーで YSP-800 or the remote control. 再起動します。 6 The display returns to screen ( 1 ). 6 1の画面に戻ります。 Select SPID and perform steps 1 to 4 for writing.
  • Page 23 YSP-800 7. YSP-800の “STANDBY/ON” キーを押し、電源をOFFし 7. Press the “STANDBY/ON” key of the YSP-800 to turn off the power. ます。 8. YSP-800の “VOL+” キーと “VOL-” キーを押しながら、リ 8. While pressing the “VOL+” key and “VOL-” key of the YSP-800, press the “STANDBY/ON” key of the remote モコンの...
  • Page 24: Self Diagnosis Function (Diag) / 自己診断機能(ダイアグ

    YSP-800 I SELF DIAGNOSIS FUNCTION (DIAG) / 自己診断機能(ダイアグ) ダイアグメニューは1 4 個あり、そのそれぞれにサブメ There are 14 DIAG menu items, each of which has sub- ニューがあります。下表はメニュー一覧です。 menu items. Listed in the table below are menu items and sub-menu items. DIAG MENU SUB MENU DSP THROUGH 1.
  • Page 25 YSP-800 DIAG MENU SUB MENU 11. BS 2 12. BS 3 13. BS 4 14. BS 5 15. BS 6 16. BS 7 17. DS 1 18. DS 2 19. T 11 20. T 12 21. T 13 22. T 21 23.
  • Page 26 YSP-800 • Starting DIAG ● ダイアグの起動 To activate the DIAG function, press the “STANDBY/ON” 本体の下図に示すキーを同時に押しながらリモコンの key of the remote control while pressing the keys of the “STANDBY/ON” キーを押すと、ダイアグが起動します。 main unit as shown below at the same time. Keys of main unit / 本体キー...
  • Page 27 YSP-800 DIAGNOSTIC MENU 1.DSP THR 8.PRESET 2.RAM THR 9.AD CHECK 3.PRO LOGIC 10.IF STATUS 4.MIC CHECK 11.MODEL 5.VFD CHECK 12.VER/SUM 6.MAN’ LTEST 13.DATE 7.RS232C 14.DSP CHECK 本体のFLディスプレイにプロテクション履歴情報とバージョ The FL display of the main unit displays the protection function history data and the version (1 alphabet) and the ン...
  • Page 28 YSP-800 • History of protection function ● プロテクションの履歴 When the protection function has worked, its history is プロテクションが働いた場合、履歴をバックアップして stored in memory with a backup. Even if no abnormality 記憶しています。サービスのときに異常が認められなく is noted while servicing the unit, an abnormality which ても、バックアップが残っていれば、お客様のところで has occurred previously can be defined as long as the 起きた異常を区別できます。...
  • Page 29 YSP-800 • Details of DIAG menu ● ダイアグメニュー詳細 1. DSP THROUGH 1. DSP THROUGH The signal is not changed into beam and output from ビーム化は行わず、サブメニューの指定CHから出力し the channel specified by the sub-menu. ます。 When 2CH signals are inputted, they are distributed as 2CH信号入力時はDSP♯1にて以下のように信号を振り...
  • Page 30 YSP-800 [ DD/dts/AAC multi ] OPT1 TI-DSP Ti-DSP OPT2 SL/SR SL/SR COAX C/LFE C/LFC LFE&BASS Analog1 YSS-930 YSS-930 YSS-930 Analog2 SWFR WFL/WFR TXn(beam) TXn(beam) TXn(beam) [ PCM ] OPT1 TI-DSP Ti-DSP OPT2 COAX L/LFC L&BASS Analog1 YSS-930 YSS-930 YSS-930 Analog2...
  • Page 31 YSP-800 2. RAM THROUGH 2. RAM THROUGH ビーム化は行わず、サブメニューの指定CHから出力し The signal is not changed into beam and output from ます。 the channel specified by the sub-menu. When 2CH signals are inputted, they are distributed as 2CH信号入力時はDSP♯1にて以下のように信号を振り follows at DSP#1. 分けます。 L CH ..FRONT L, SURROUND L, CENTER, LFE L CH ..
  • Page 32 YSP-800 [ DD/dts/AAC multi ] OPT1 TI-DSP Ti-DSP OPT2 SL/SR SL/SR COAX C/LFE C/LFC LFE&BASS Analog1 YSS-930 YSS-930 YSS-930 Analog2 SWFR WFL/WFR TXn(beam) TXn(beam) TXn(beam) [ PCM ] OPT1 TI-DSP Ti-DSP OPT2 COAX L/LFC L&BASS Analog1 YSS-930 YSS-930 YSS-930 Analog2...
  • Page 33 YSP-800 OPT1 TI-DSP Ti-DSP OPT2 SL/SR SL/SR COAX C/LFC BASS Analog1 YSS-930 YSS-930 YSS-930 Analog2 SWFR WFL/WFR TXn(beam) TXn(beam) TXn(beam) 4. MIC CHECK 4. MIC CHECK The Signals input through the microphone are output マイク入力された信号をAD-DA経由で出力します。 via A/D-D/A. 5. EFFECT OFF / DISPLAY CHECK 5.
  • Page 34 YSP-800 全セグメント消灯・全セグメント点灯によりFLドライ Segment conditions of the FL driver and the FL tube are checked by turning ON and OFF all segments. Next, バー、FL管のセグメントの不良を確認します。 the operation of the FL driver is checked by using the 次に、ディマーコントロールによってFLドライバーの 動作チェックを行います。 dimmer control. Then a short between segments next to each other is checked by turning ON and OFF all さらに全セグメントを交互...
  • Page 35 YSP-800 8. FACTORY PRESET 8. FACTORY PRESET This menu is used to reserve and inhibit initialization of バックアップ用RAM (音場プログラムのパラメーターや the back-up RAM. The signals are processed using セットメニュー内容等) の初期化を予約/禁止します。 信号処理はEFFECT OFFと同じです (ANALOG MAIN EFFECT OFF. (The L/R signal is output using ANALOG MAIN BYPASS.)
  • Page 36 YSP-800 K0/K1 (本体パネルキー) K0/K1 (Panel key of main unit) [Remote control code: –] A/D of the key fails to function properly when the standard キーのA/Dは基準値から±4%を外れると、正常な動きをし value is deviated by ±4%. In this case, check the constant ません。下表2をご覧になり、各キーの分圧抵抗の定数、 ハンダ不良等の確認をしてください。 of partial pressure resistor, solder condition, etc. Refer to table 2.
  • Page 37 YSP-800 T21-3: T21-3: Operation information of the DSP IC (T2). DSP IC (T2) の動作情報を表示します。 Y11-2、21-2、31-2: Y11-2, 21-2, 31-2: Not applied to this model. このモデルには適用されません。 MTT: MTT: Mute Trigger Mute Trigger Byte No. Function Mute condition / ミュート状態 The last Mute Trigger / 最後のミュートトリガー...
  • Page 38 YSP-800 13. DATE 13. DATE There are 6 SUB menu items. サブメニューは6つあります。 The updated date of the program, clearance of the プログラムの更新日付、プロテクション履歴のクリア、 リモコン受信コードを表示します。 protection history and the remote control reception code are displayed. Remo Codeのメニューにすると、リモコンの全キーの 値を検出するためキー操作はできなくなりますが、本体 When Remo Code menu is selected, keys become non- のINPUTキーを押すことにより、次のサブメニューに進...
  • Page 39 YSP-800 ・ T01ーT21 TWEETER • T01–T21 TWEETER ・ W01ーW02 WOOFER • W01–W02 WOOFER • ALL Sound is output from all drivers ・ ALL すべてのスピーカーユニットから出力されます ・ ーーー • – – – Tx Test Tx Test Select the sound to be produced in ONE SP TEST.
  • Page 40 YSP-800 Cert Mode Cert Mode Select the special mode for testing. 試験用の特殊モードを選択します。 * Be sure to set to “OFF” ※ 必ず “OFF” にしてください The version of T1(DSP) is displayed. T1 (DSP) のバージョンを表示します。 The updated date of the T1(DSP) Firmware is displayed.
  • Page 41: Display Data

    YSP-800 I DISPLAY DATA G V901 : 15-BT-99GNKF (WE204600) PATTERN AREA G PIN CONNECTION Pin No. Connection 24 23 22 21 20 19 Pin No. Connection P32 P33 P34 P35 NX NX Note : 1) F1, F2 ..Filament 2) NP ..No pin 3) NX ..
  • Page 42: Ic Data

    YSP-800 I IC DATA IC24 : M30626FJPFP (DSP P.C.B) Single-Chip 16bit CMOS MICROCOMPUTER (Main CPU) Port P0 Port P1 Port P2 Port P3 Port P4 Port P5 Port P6 <VCC2 ports> <VCC1 ports> Internal peripheral functions A/D converter System clock...
  • Page 43 YSP-800 IC24 : M30626FJPFP (DSP P.C.B) IC24 : M30626FJPFP (DSP P.C.B) Single-Chip 16bit CMOS MICROCOMPUTER (Main CPU) Single-Chip 16bit CMOS MICROCOMPUTER (Main CPU) Pin No. Port Definition Function Pin No. Name Definition Function PO96 Data output to FL driver Clock signal to EEPROM...
  • Page 44: Block Diagram

    YSP-800 I BLOCK DIAGRAM • See page 55~57 → SCHEMATIC DIAGRAM IC22 IC711 D+12 DRIVER YDA138 29,36 WOOFER L RMCK IC716 D+12 XTAL Woofer 24.576MHz DRIVER YDA138 29,36 28,29 WOOFER R (U, C, T, K, A, B, G, L, V models)
  • Page 45 YSP-800 I PRINTED CIRCUIT BOARD (Foil side) DSP P.C.B. (Side A) Lead Free Solder Used INPUT(2) INPUT(3) (CB3) MAIN U-COM (CB902) WRITER INPUT(1) (CB507) R189 R179 R198 R178 R197 R195 (CB702) R175 R194 R174 R193 R173 R192 80 81 DGND...
  • Page 46 YSP-800 I PRINTED CIRCUIT BOARD (Foil side) DSP P.C.B. (Side B) Lead Free Solder Used Ref No. Location IC10 IC12 IC18 IC19 IC20 IC21 IC22...
  • Page 47 YSP-800 I PRINTED CIRCUIT BOARD (Foil side) AMP P.C.B. (Side A) Lead Free Solder Used DRIVER x 3 DRIVER x 3 DRIVER x 3 DRIVER x 3 DRIVER x 3 (TWEETER) (TWEETER) (TWEETER) (TWEETER) (TWEETER) DRIVER – – – –...
  • Page 48 YSP-800 I PRINTED CIRCUIT BOARD (Foil side) AMP P.C.B. (Side B) Lead Free Solder Used Ref No. Location D709 D712 Q701 Q702...
  • Page 49: Printed Circuit Board

    YSP-800 I PRINTED CIRCUIT BOARD (Foil side) INPUT (1) P.C.B. (Side A) INPUT(3) (CB901) Ref No. Location AC IN D501 D503 D510 D515 D516 D517 D518 D522 D523 D524 D528 D537 IC501 INPUT(2) IC502 (CB4) IC503 IC504 AGND +12V AGND...
  • Page 50 YSP-800 I PRINTED CIRCUIT BOARD (Foil side) INPUT (1) P .C.B. (Side B) Lead Free Solder Used Ref No. Location D502 D504 D507 D508 D509 D512 D513 D514 D519 D520 D521 D526 D527 D529 D530 D533 D536 IC505 Q504...
  • Page 51 YSP-800 I PRINTED CIRCUIT BOARD (Foil side) INPUT ( 2 ) P.C.B. (Side A) RS-232C AUDIO INPUT DIGITAL INPUT U, C, J models VCR L/R TV/STB L/R SUBWOOFER VIDEO OPTICAL COAXIAL SYSTEM CONNECTOR TV/STB INPUT(1) (CB505) AGND +12V AGND D+12...
  • Page 52 YSP-800 I PRINTED CIRCUIT BOARD (Foil side) INPUT ( 2 ) P.C.B. (Side B) Lead Free Solder Used U, C, J models Ref No. Location T, K, A, B, G, L models...
  • Page 53 YSP-800 I PRINTED CIRCUIT BOARD (Foil side) INPUT (4) P.C.B. (Side A) INPUT ( 4 ) P.C.B. (Side B) INPUT (3) P.C.B. (Side A) (CB9) Lead Free Solder Used INPUT(1) (CB506) KEY0 STBY_SW KEY1 S3.3 S3.3 KEY1 STBY_SW KEY0 INPUT...
  • Page 54: Pin Connection Diagram

    YSP-800 I PIN CONNECTION DIAGRAM • ICs • Diodes AN77L04 NJM78M05FA NJM2068MD S-29630AFJA PQ1CZ41H2Z M62782GP 1N4002S 1SS355 MA8036 SB01-05Q µPC4570G2 1Z180 1SS380 MA8051-M NJM78M12FA 1Z330 RB501V-40 MA8062-M AK09V0 Anode UDZ5.1B MA8068-M D1NL20U MA8091-M Anode ERA22 MA8100-H MTZJ27D MA8100-M MA8110-M Cathode...
  • Page 55: Schematic Diagram

    YSP-800 SCHEMATIC DIAGRAM (DSP 1/3) IC1~3: PQ1CZ41H2Z IC9: W9816G6CH Chopper Regulators 512K x 2 Banks x 16 Bits SDRAM CLK 35 CLOCK BUFFER CKE 34 Voltage ON/OFF regulator circuit COLUMN DECODER PWM COMP. ON/OFF CONTROL SIGNAL control GENERATOR COMMAND DECODER...
  • Page 56 YSP-800 SCHEMATIC DIAGRAM (DSP 2/3) IC12: D60YA003BPYP225 Decoder Digital Signal Processors EMIF32 L2 Cache/ L1P Cache Memory 4 Banks Direct Mapped McASP1 64K Bytes 4K Bytes Total Total McASP0 (4-Way) C67x McBSP1 Instruction Fetch Control Registers McBSP0 Instruction Dispatch Control...
  • Page 57 YSP-800 SCHEMATIC DIAGRAM (DSP 3/3) IC18, 19: YSS930-SZ MICROPROCESSOR INTERFACE PROGRAM COEFFICIENT ADDRESS CONTROL REGISTER 50 bit *1024 word 16 bit *1024 word 17 bit *256 word CONTROL SIGNALS SDBCK SDWCK SDI0 SDO0 SDI1 SDO1 SDI2 SDO2 SDI3 SDO3 32 bit DSP Core...
  • Page 58 YSP-800 SCHEMATIC DIAGRAM (AMP) Page 57 to DSP_CB11 Page 60 to INPUT(1)_CB504 IC703, 704: SN74AHCT541PWR IC711, 716: YDA138 IC701, 702, 705, 706, 709, 710, 712~715, 717: YDA139 OCTAL BUFFERS/DRIVERS Digital audio power amplifier Digital audio power amplifier To Seven Other Channels # All voltages are measured with a 10MΩ/V DC electronic volt meter.
  • Page 59 YSP-800 SCHEMATIC DIAGRAM (INPUT 1/2) INPUT SELECTOR AUDIO INPUT TV/STB 11.7 11.7 11.1 SUBWOOFER VIDEO M62782GP COAXIAL Page 60 to INPUT(1)_CB505 DIGITAL INPUT RF45710 RF45710 POINT A-1 pin 6 of IC8 TV/STB OPTICAL RF45710 RF45710 RF45710 IC901: M66003-0101FP FL Display Driver...
  • Page 60 YSP-800 SCHEMATIC DIAGRAM (INPUT 2/2) WG41030 WG41030 WG41030 Safety measures • Some internal parts in this product contain high voltages and are dangerous. Be sure to take safety measures during servicing, such as wearing insulating gloves. • Note that C523 is dangerous even after the power is turned off because an electric charge remains and a high voltage continues to exist there.
  • Page 61: Parts List

    YSP-800 PARTS LIST I ELECTRICAL PARTS I WARNING Components having special characteristics are marked s and must be replaced with parts having specifications equal to those originally installed. ● s印のある部分は、 安全確保部品を示 しています。 部品の交換が必要な場合、 パーツ リ ス トに記載されている部品を使用 して く ださい。...
  • Page 62 YSP-800 P.C.B. DSP Ref No. Part No. Description Remarks Markets 部 品 名 Rank WF721600 P.C.B. PCB DSP WC195900 CN.BS.PIN 9P TE FMNコネクター VT388300 CN.BS.PIN ベース付ポスト CB6-7 WC195900 CN.BS.PIN 9P TE FMNコネクター WC198700 CN.BS.PIN 37P TE FMNコネクター WC196200 CN.BS.PIN 12P TE FMNコネクター CB10 VT388600 CN.BS.PIN...
  • Page 63 YSP-800 P.C.B. DSP Ref No. Part No. Description Remarks Markets 部 品 名 Rank C126-146 US135100 C.CE.CHP 0.1uF チップセラコン C147 UF037100 C.EL.CHP 10uF チップケミコン C148 US126100 C.CE.CHP チップセラコン C149-178 US135100 C.CE.CHP 0.1uF チップセラコン C179 UF017470 C.EL.CHP 47uF 6.3V チップケミコン C180-181 US035100 C.CE.CHP 0.1uF...
  • Page 64 YSP-800 P.C.B. DSP & P.C.B. AMP Ref No. Part No. Description Remarks Markets 部 品 名 Rank D7-10 WB081800 DIODE SB01-05Q ショットキーダイオード D11-12 VV220700 DIODE.SHOT RB501V-40 ショットキーダイオード 01 IC1-3 X5172A00 IC PQ1CZ41H2Z 電源IC X5444A00 IC LC89057W-VF4D-E IC X6137B00 IC D60YA003BPYP225 IC X3833A00 IC SN74AHC1G08DCKR ロジックICSOP...
  • Page 65 YSP-800 P.C.B. AMP Ref No. Part No. Description Remarks Markets 部 品 名 Rank C727 UR818220 C.EL 220uF 6.3V ケミコン C728-729 UR837100 C.EL 10uF ケミコン C730 UR866100 C.EL ケミコン C731 US135100 C.CE.CHP 0.1uF チップセラコン C732 UR866100 C.EL ケミコン C733 US135100 C.CE.CHP 0.1uF チップセラコン...
  • Page 66 YSP-800 P.C.B. AMP & P.C.B. INPUT Ref No. Part No. Description Remarks Markets 部 品 名 Rank C805-808 US126100 C.CE.CHP チップセラコン C809-810 US135100 C.CE.CHP 0.1uF チップセラコン C811-814 UR838100 C.EL 100uF ケミコン C815 US135100 C.CE.CHP 0.1uF チップセラコン C816-817 US126100 C.CE.CHP チップセラコン C818 UR818220 C.EL 220uF 6.3V...
  • Page 67 YSP-800 P.C.B. INPUT Ref No. Part No. Description Remarks Markets 部 品 名 Rank CB507 VB390100 CN.BS.PIN ベースピン CB801 VB390200 CN.BS.PIN コネクタベースポスト CB901 VB390000 CN.BS.PIN ベースピン CB902 V6218000 CN.BS.PIN FMN 12P TE FFCコネクター CB903 VB390100 CN.BS.PIN ベースピン US061220 C.CE.CHP 22pF 50V B チップセラコン...
  • Page 68 YSP-800 P.C.B. INPUT Ref No. Part No. Description Remarks Markets 部 品 名 Rank US064100 C.CE.CHP 0.01uF 50V B チップセラコン C501 WE102900 C.PP 0.01uF 100V PPコン C502 UR739330 C.EL 3300uF ケミコン s C503 V6185300 C.CE.SAFTY 0.01uF 275V 規格認定コン * s C504 WE468500 C.CE.SAFTY 0.22uF...
  • Page 69 YSP-800 P.C.B. INPUT Ref No. Part No. Description Remarks Markets 部 品 名 Rank C813 US064100 C.CE.CHP 0.01uF 50V B チップセラコン C815 US063100 C.CE.CHP 1000pF 50V B チップセラコン C817-818 UM397220 C.EL 22uF ケミコン C819 US064100 C.CE.CHP 0.01uF 50V B チップセラコン C901-903 US035100 C.CE.CHP 0.1uF...
  • Page 70 YSP-800 P.C.B. INPUT Ref No. Part No. Description Remarks Markets 部 品 名 Rank XD598A00 IC TC74HCU04AFEL INV ロジックIC X3505A00 IC NJM2068MD-TE2 アンプIC XG903A00 IC TC4052BF MPX IC XF291A00 IC uPC4570G2 IC X5359A00 IC MAX3232CDWR ロジックIC XZ012A00 IC TC74HCT08AF(EL) ロジックIC X6692A00 IC MB90050PF-110E1 OSDコントローラ...
  • Page 71 YSP-800 P.C.B. INPUT Ref No. Part No. Description Remarks Markets 部 品 名 Rank HV754150 R.CAR.FP 15Ω 1/4W 不燃化カーボン抵抗 HV754150 R.CAR.FP 15Ω 1/4W 不燃化カーボン抵抗 HV754180 R.CAR.FP 18Ω 1/4W 不燃化カーボン抵抗 R.CHP 39KΩ 1/16W J 0816 チップ抵抗 R.CHP 91KΩ 1/16W J 0816 TABGL チップ抵抗...
  • Page 72 YSP-800 Chip Resistors The chip resistor is not supplied as a replacement part. ● チッ プ抵抗はサービス部品と して供給 しません。 * When a chip resistor is necessary, use the following part. ※ チッ プ抵抗が必要な場合は、 下記の部品をご利用く ださい。 AAX60720: CHIP RESISTOR SAMPLE BOOK AAX60720: CHIP RESISTOR SAMPLE BOOK Ref No.
  • Page 73 YSP-800 Parts List for Carbon Resistors Value 1/4W Type Part No. 1/6W Type Part No. Value 1/4W Type Part No. 1/6W Type Part No. 1.0 Ω 3100 3100 10 kΩ 7100 7100 HJ35 HF85 HF45 HF45 1.8 Ω ❊ 3180 11 kΩ...
  • Page 74 YSP-800 I EXPLODED VIEW Black color, Titanium color models 5 (1) 5 (2) 5 (5) BAFFLE UNIT 5 (3) 37 6 places 5 (4) Silver color model...
  • Page 75 YSP-800 I MECHANICAL PARTS I ACCESSORIES Ref No. Part No. Description Remarks Markets 部 品 名 Rank WF721100 PCB ASS'Y INPUT PCB インプット WF721200 PCB ASS'Y INPUT PCB インプット WF721300 PCB ASS'Y INPUT TABGL PCB インプット WF721400 PCB ASS'Y INPUT PCB インプット WF721500 PCB ASS'Y INPUT PCB インプット...
  • Page 76 YSP-800 I BAFFLE UNIT Ref No. Part No. Description Remarks Markets 部 品 名 Rank WF721600 P.C.B. ASS'Y PCB DSP WF721700 P.C.B. ASS'Y PCB AMP 1-32 WF766200 FLEXIBLE FLAT CABLE 32P 80mm P=1.0 カード電線 1-12 WF453800 BASE TWEETER ベース ツイーター 1-16 CB040540 BINDING TIE S-72B 束線止め...
  • Page 77 YSP-800 I PACKING ASS’Y 16 * Rear 16 * 16 * 16 * * When attaching a tape directly to this unit, be sure to use the special polyester tape (VC38060). ※ 本機にテープを直接貼る場合は、必ず専用の ポリエステルテープ (VC380600) を使用して ください。 Front 1 pair Ref No.
  • Page 78: Remote Control

    YSP-800 I REMOTE CONTROL U model C, T, K, A, B, G, L, V models J model Key Layout I SCHEMATIC DIAGRAM...
  • Page 79 YSP-800 Code Function 78-4A VCR / ビデオ 78-49 STB / チューナー 78-DF TV / テレビ 78-DF AUXv 78-DE TV INPUT1 / 入力1 (TV / テレビ) – TV INPUT2 / 入力2 (TV / テレビ) – MACRO / マクロ (TV / テレビ) (–)
