PNI B5000 User Manual

Audio baby monitor wireless two-way communication
Hide thumbs Also See for B5000:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
USER MANUAL
AUDIO BABY MONITOR PNI B5000
WIRELESS TWO-WAY COMMUNICATION

Advertisement

loading
Need help?

Need help?

Do you have a question about the B5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PNI B5000

Summary of Contents for PNI B5000

  • Page 1 USER MANUAL AUDIO BABY MONITOR PNI B5000 WIRELESS TWO-WAY COMMUNICATION...
  • Page 2 Introduction This Baby monitor has been designed to help you look after your baby and is not Intended as a tool for substituting the adults' supervision & care in any circumstances. The Baby Monitor is a portable monitoring system with the following features: - 2.4GHz Digital wireless transmission.
  • Page 3 Package content: - Baby unit (1 pc.) - Parent unit (1 pc.) - Power adaptors (2 pcs.) - User manual (6 pcs alkaline battery not included) Features of the units: Parent unit: 1. Antenna 7. Talk key 2. Power LED 8.
  • Page 4 Operation: Connect both the parent unit and the baby unit to the provided power adaptors or Alkaline battery size AAA (6 pcs required, but not included). Switch power keys upward. The power LEDs will be on in green color。 - Put the baby unit in the baby room and keep it from the baby at 2m distance.
  • Page 5 2. Press the Pair keys on both units simultaneously. Release the Pair keys after one second. When seeing the Power LEDs flashing on both units, this means the pairing is successful. Normal operation resumes. . Reset keys Some points to remember: Battery Power: For both units, receiver and transmitter: 1.

  • Page 6: Troubleshooting

    If the receiver is too far from transmitter, the system cannot work properly. You will hear “ beep beep” sound which is Out of range alert. At the same time all volume LEDs flash simultaneously . In this case, you have to put the two units nearer to each other. If the receiver is too close to the transmitter, an acoustic feedback might be heard.

  • Page 7: Specifications

    Specifications: Item Value Transmitter Transmission Frequency 2400MHz-2480MHz Transmission Power 20dBm Unobstructed Effective 400 m Range Operating Temperature 0 -50 C Storage Temperature 25 C Operating Humidity 20%-80％RH Modulation Mode FHSS Consumption Current min:25mA max:125mA Power Supply DC5V 1000mA Receiver Transmission Frequency 2400MHz-2480MHz Transmission Power 20dBm...
