Summary of Contents for BenQ GSI
- Page 1 Digital Portable LED Projector Quick Start Guide...
-
Page 2: Hdmi Cable
GS1 Projector GS1 Battery Remote Control Adapter HDMI Cable Protective Case Carry Bag Batteries (AAA) x 2 Quick Start Guide Warranty Card • Lamp life results will vary depending on environmental conditions and usage. Actual product's features and specifications are subject to change without notice. •... - Page 3 Control panel Vent Front IR sensor Focus ring Projection lens Angle adjust dial HDMI USB 3.0 Type-A Micro SD USB 2.0 Type-A Audio Out DC-IN power jack LED indicator lights Speaker grill kensington lock Speaker grill Rear IR sensor With the projector off, long press to turn off all the LED indicator lights, double click to retain the indicate function.
- Page 4 Focus ring Source Power Arrow keys Back Menu Home...
- Page 5 Vents Vents Battery connector Projector connector Charge indicator light USB Type-A Micro USB Type-B...
- Page 6 Power on by adapter Power on by battery...
- Page 10 A/V Device Notebook or Desktop Computer Bluetooth Speakers Wireless AP Smartphone or Tablet PC Speakers...
- Page 11 Mouse and keyboard can be easier to achieve complex operations.
- Page 14 The screens are for reference only and may vary by the product supplied for your region.
- Page 18 Connect to an external power source (optional)
- Page 20 Supply power to projector...
- Page 21 Supply power to mobile device USB cable Mobile device (smartphone, tablet, etc.)
- Page 22 Charge by USB Charge by adapter...
-
Page 23: Instructions And Requirements For Handling The Battery
Instructions and requirements for handling the battery • Recommending usage Please read the battery instructions and the label on its surface before use. Use the battery indoors under normal condition, temperature: (25±3)°C, absolute humidity: 65±20% When in use, the battery shall be kept out of heat, high voltage and avoided children's touching. Do not drop the battery. - Page 24 • To avoid use the battery near the heat Do not use the battery near the fire and stove, or over 60°C, and over heating will cause the battery internal short-circuit and make it heat, smoke, distort or burning. • Forbid bathing the battery Do not dampen the battery, or even immerse it in the water, which will cause internal protection circuit and its function lost or abnormal chemical reactions, which will lead to heating, smoking, distortion or burning.
- Page 25 • Warning • Do not mix with other battery This battery cannot mix with deposal or twice-recycled batteries in use. Otherwise, for its abnormal charge and discharge, it will cause over-heated, distort, smoke or burning. Keep the battery out of children's area and prevent them biting or swallowing the battery. Do not insert the battery onto the charger for a long time.
- Page 26 • Children use When Children use the battery, they should be under their parents' instructions and superintend in use. • Avoid children's touch Battery should keep out of the area where children in reach. Prevent children taking the battery out of the charger or the equipment to play. To avoid the leak-out liquid be exposed to the skin or clothes.
- Page 27 • The projector should only be placed in the protective case after it has already been installed onto the GSI battery. • Ensure that there are no connections to the ports on the projector or battery before installing the protective case.
-
Page 28: Product Specifications
Product specifications Projection System Native Resolution 720p (1280 x 720), 0. 3''TRP Brightness 300AL Contrast Ratio (FOFO) 100000:1 Lens F=1.5, f=5.53mm Throw Ratio 0.81:1 (60"@1m) Interface HDMI USB 3.0 (Type A) x 1 (USB reader) USB 2.0 (Type A) x 1 (USB reader) Audio out (Mini Jack) x 1 (3.5mm) Micro SD card... -
Page 29: Battery Specifications
Battery specifications Type Lithium-ion Polymer Electrical Rating 7.4V 8000mAh 59.2Wh Dimensions 135.5 x 118.5 x 18.5 mm Weight 400g Battery Cycle Life 300 cycles charging Charging Time 3.5 hrs under empty condition Battery Life 3 hrs battery life @ 150AL (The battery life differs depending on the personal habit of use.) LED Indicator Battery + Adaptor... -
Page 30: Supported File Formats
Supported File Formats Mstar628 ARM A7 Qual-core CPU 1GB DDR3 Flash 8G EMMC Andoird OS 4.4 WLAN 802.11b/g/n, 2.4G, Single band, 2T2R Video AVI (XVID, MJPEG), DIVX (MJPEG, XVID), DAT (MPEG1), MPG (MPEG1), MPEG (MPEG1) Music MP3, MP2, MP1, OGG, AAC, WAV Photo JPG (.jpg , .jpeg) , BMP (.bmp) Subtitle... - Page 31 Scan the QR code with an appropriate mobile app to access the latest QSG in various languages. Scannez le code QR avec une appli mobile appropriée pour accéder au dernier Guide de démarrage rapide en plusieurs langues. Scannen Sie den QR-Code mit einer entsprechenden Mobil-App, um auf die aktuelle Kurzanleitung in verschiedenen Sprachen zuzugreifen.
- Page 32 The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by BenQ Corporation is under license. BenQ.com © 2017 BenQ Corporation. All rights reserved. Rights of modification reserved. P/N: 4J.JFL01.003...
