  • Page 1 1074 Quad Noise Gate User Manual...

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION WARNING FOR YOUR PROTECTION READ THE FOLLOWING: KEEP THESE INSTRUCTIONS HEED ALL WARNINGS FOLLOW ALL INSTRUCTIONS THE APPARATUS SHALL NOT bE ExPOSED TO DRIPPING OR SPLASHING LIqUID AND NO ObjECT FILLED WITHI LIqUID, SUCH AS vASES, SHALL bE PLACED ON THE APPARATUS.

  • Page 3: Declaration Of Conformity

    Sandy, Utah 84070, USA Date: August 16, 2011 Bs1362. European Contact: Your local dbx Sales and Service Office or Harman Signal Processing 8760 South Sandy Parkway If you want to dispose this product, do not mix it with general household waste. There is a...

  • Page 4: Table Of Contents

    1074 Table of Contents Introduction 0.1 Defining the 1074 ............. 2 0.2 Service Contact Info ..........3 0.3 Warranty ..............3 0.4 Installation Recommendations ....... 4 Section 1 - Getting Started 1.1 Rear Panel Connections ........... 6 1.2 Front Panel Connections ......... 6 Section 2 - Setups and Applications 2.1 Basic Connection ............
  • Page 5 1074 INTRODUCTION INtro Customer servICe INfo 1074 DefINeD WArrANtY INfo...

  • Page 6: Introduction

    1074, the standard for Noise Gate Processors has been raised by the industry leader once again. The 1074 Quad Noise gate offers is the perfect tool for any gating need that may come about. From whether you need to remove unwanted noise or other background noise. The 1074 is also ideal for gating high transient material through four independent channels.

  • Page 7: Service Contact Info

    Proof-of-purchase is considered to be the burden of the consumer. 2). dbx warrants this product, when bought and used solely within the U.S., to be free from defects in materials and workmanship under normal use and service.

  • Page 8: Installation Recommendations

    0.4 Installation Recommendations FOR RACK MOUNT USE ONLY - Install the 1074 in your rack with the provided rack screws. When installed in a rack, the unit should be positioned with enough room (at least one 1U above the and 1U below the unit) to allow proper ventilation.

  • Page 9: Section 1 - Getting Started

    1074 Section 1 Getting Started GettING stArteD...

  • Page 10: Rear Panel Connections

    Section 1 Getting Started 1.1 Rear Panel Connections FUSE: T 300mA L 250V IEC Power Cord Receptacle This is the power cord receptacle of the 1074. An IEC cord is included with the shipped product. DESCRIPTION: ECN: NOTE: dbx 1074...
  • Page 11 Monitor switch back out for normal operation. Stereo Couple Switch The Stereo Couple switch is used to select either Stereo or Dual Mono modes on the 1074. To couple channels as stereo pairs, press the Stereo Couple switch between each pair. When this procedure is performed, the odd-numbered channel becomes the master, and the even-numbered channel, becomes the slave.

  • Page 12: Section 2 - Setups And Applications

    • Turn off all equipment before making any connections. • Install the 1074 in your rack with the provided rack screws. It is essential that when the 1074 is being mounted in a rack mounting enclosure, the unit should be positioned with enough room (at least 1U of space above the unit and 1U of space at the below the unit) to allow proper ventilation.

  • Page 13: Appendix

    1074 Appendix AppeNDIx AppeNDIx BloCk DIAGrAm speCIfICAtIoNs...

  • Page 14: Block Diagram

    1074 Appendix Appendix Block diagram 1074 Block Diagram Input Monitor Outputs Key Input BYPASS Filter CV 1/3 Control Detector Threshold Depth Release Ch. 1 and/or 3 Filter Input Monitor Outputs BYPASS Key Input Stereo CV 1/3 Couple Filter Control Detector...

  • Page 15: Specifications

    200-240 VAC: T 160 mA L 250V Mains Connection: IEC receptacle Physical Dimensions: 1.75”Hx19”Wx9”D (4.4cmx48.3cmx20.1cm) Weight: 6.9 lbs. Shipping Weight: 9.3 lbs. Options Output Transformer Per Channel: Jensen® JT-123-dbx or BCI™ RE-123-dbx Note: Specifications subject to change. 1074 User Manual...
  • Page 16 8760 South Sandy Pkwy. Sandy, Utah 84070 Phone: (801) 568-7660 Fax: (801) 568-7662 Questions or comments? Email: customer@dbxpro.com Website: www.dbxpro.com 18-0431V-B Printed in China...
