FRU Removal and Replacement Guide
Part Number: P0450139 Rev: A
NEXSAN
| 910 E Hamilton Ave, Campbell, CA 95008| p. 1.760.690.1111 |
www.nexsan.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nexsan E60

  • Page 1 NEXSAN E-SERIES™ Nexsan E60™/E60V™/E60VT™/E60P™ and Nexsan E48™/E48V™/E48VT™/E48P™ RAID Storage Units FRU Removal and Replacement Guide Part Number: P0450139 Rev: A NEXSAN | 910 E Hamilton Ave, Campbell, CA 95008| p. 1.760.690.1111 | www.nexsan.com...
  • Page 2 Unauthorized use, duplication, or modification of this document in whole or in part without the written consent of Nexsan is strictly prohibited. Nexsan reserves the right to make changes to this manual, as well as the equipment and software described in this manual, at any time without notice.
  • Page 3: Table Of Contents

    LEDs Switches Turbo cards (VT units only) Host port options Drawer interior Field-replaceable modules Other modules LEDs Physical characteristics Dimensions, Nexsan E60™/E60V™/E60VT™/E60P™ Dimensions, Nexsan E48™/E48V™/E48VT™/E48P™ Power Cooling Materials Environment Chapter 2: Adding Modules Take proper ESD precautions Adding a second RAID Controller...
  • Page 4 Contents RAID Controllers Disk drives Front drive drawer fans Rear drive drawer fan assembly Glossary Nexsan Nexsan E60™/Nexsan E48™ www.nexsan.com FRU Removal and Replacement Guide...
  • Page 5: About This Manual

    About this manual About this manual This FRU removal and replacement guide provides detailed procedures for installing, removing, and replacing field-replaceable units (FRUs) in the Nexsan E60™ and Nexsan E48™ disk storage chassis and their V and VT variants . Audience...
  • Page 6: Contacting Nexsan

    Nexsan's Technical Services Group provides worldwide assistance with installation, configuration, software support, warranty and repair for all Nexsan products. A variety of service and support programs are available to provide you with the level of coverage and availability your operation requires.
  • Page 7: Related Documents

    The following Nexsan product manuals contain related information: Nexsan E60™/E60V™/E60VT™/E60P™/Nexsan E48™/E48V™/E48VT™/E48P™ RAID Storage Units Installation Guide Nexsan E60X™/E60XV™/Nexsan E48X™/E48XV™ RAID Storage Expansion Units Installation Guide Nexsan E60X™/E60XV™/Nexsan E48X™/E48XV™ RAID Storage Expansion Units FRU Removal and Replacement Guide Nexsan High-Density Storage User Guide Nexsan E-Series™ Snapshots and Replication User Guide Nexsan E-Series™...
  • Page 8: Safety Notices

    E48™/E48V™/E48VT™/E48P™ digital storage units only. Refer to the relevant product manuals for information on other Nexsan storage or expansion units and other Nexsan products mentioned in this guide. Always observe the following precautions to reduce the risk of injury and equipment damage: WARNING: There is a risk of ELECTRIC SHOCK if Nexsan E-Series™...
  • Page 9: Revision History

    Added patent information to page ii and back cover; updated Common Terms and Abbreviations on page 45. Version 3.0, May 2012: Updated illustrations on page 1 and page 3 to call out drawer, PSU, and controller numbers; changed Nexsan E48™ power specification on page 4, page 7, and page 12; added instructions for attaching two expansion units to a Nexsan E60™/Nexsan E48™...
  • Page 10 18 and page 19; expanded section Attach Communication Cables on page 21; expanded section Power Up the Nexsan E60 on page 22; added caution to page 23 and page 24; added photographs to Disk Drives on page 26 and page 27.
  • Page 11 7; removed example from Circuit Overloading on page 8; expanded and clarified rack mounting instructions under Installing the Nexsan B60 into a Rack on pages 8–15; Disk Drives section removed from page 16; Disk Drawer (internal) LEDs section added to page 18; expanded and clarified descriptions under Rear LEDs on pages 19–20;...
  • Page 12 Revision history Nexsan Nexsan E60™/Nexsan E48™ www.nexsan.com FRU Removal and Replacement Guide...
  • Page 13: Chapter 1: Overview

    Note Unless otherwise specified, “Nexsan E60™/Nexsan E48™” is assumed to refer to all variants (base model, V, and VT) of the Nexsan E60™ and Nexsan E48™ storage systems. Where information applies to only one variant, that variant is specified. This chapter contains the following sections:...
  • Page 14: Front Panel

    2. Active Drive Drawers (3): Each drawer can hold up to 16 (for Nexsan E48™ units) or 20 (for Nexsan E60™ units) 3.5" disk drives, for a total of up to 48 or 60 drives in the unit. Can only be replaced by a fully trained Service Engineer.
  • Page 15: Other Items

    The Environmental Information page (under System Information) in the graphical user interface (GUI) displays details (see the Nexsan High-Density Storage User Guide). 6. Status LED (STAT): Indicates overall status. Green indicates that the unit is operating within specification.
  • Page 16: Rear Panel

    Rear panel Rear panel Figure 1-2: Nexsan E60™/Nexsan E60V™ and Nexsan E48™/Nexsan E48V™ rear panel (8Gb/s Fibre Channel connections shown) HOST HOST HOST HOST EXP 0 EXP 1 EXP 0 EXP 1 MGMT STAT SERIAL MGMT STAT SERIAL WARRANY VOID...
  • Page 17 Chapter 1: Overview Figure 1-3: Nexsan E60P™ and Nexsan E48P™ Figure 1-4: Nexsan E60VT™/Nexsan E48VT™ rear panel (8Gb/s Fibre Channel connections shown) HOST HOST HOST HOST EXP 0 EXP 1 EXP 0 EXP 1 MGMT STAT SERIAL MGMT STAT SERIAL...
  • Page 18: Field-Replaceable Modules

    3. Interconnect Service Modules (ISMs) (3). Can only be replaced by a fully-trained Service Engineer. Connectors 4. Power (2): 200–240VAC, 47–63Hz (for Nexsan E60™ units) or 110–240VAC, 47–63Hz (for Nexsan E48™ units). CAUTION: The cordset specification for the Nexsan E60™/Nexsan E48™ in North America is IEC C13 to IEC C14 rated 250V/10A.
  • Page 19: Switches

    Chapter 1: Overview 12. Expansion port LEDs For E60/E48/V/VT controllers: There are two LEDs (L0 and L1), each indicating the connection status for an expansion port. Green indicates that the SAS cable is properly connected. Flashing amber indicates that the cable is improperly connected.
  • Page 20: Turbo Cards (Vt Units Only)

    This is the same as performing a System Shutdown via the graphical user interface (GUI) (see the Nexsan RAID Storage User Guide). On dual- controller systems, both SW0 switches must be held simultaneously for 8 seconds.
  • Page 21 All three LEDs light up during the power-up sequence. Note For Nexsan E60™/E60V™ and Nexsan E48™/E48V™ units with two HBA cards, the right HBA card's LEDs are inverted. 8Gb/s Fibre Channel port LEDs (speed and activity): The upper LED is orange when there is a 2Gb/s connection and green when there is a 4Gb/s connection.
  • Page 22: Drawer Interior

    4. Drive Status LEDs Field-replaceable modules 1. Disk Drives: Up to 16 (for Nexsan E48™ units) or 20 (for Nexsan E60™ units) 3.5" disk drives in each drawer. Disk drives can be field-replaced in the event of failure (see Disk drives on page 25).
  • Page 23: Physical Characteristics

    Rack mount kit weight approx. 2.5 kg (5.5 lbs.) Power Two 1,600W load-sharing, hot-pluggable, redundant PSUs. Nexsan E60™/E60V™/E60VT™/E60P™ nominal input voltage is 200–240VAC, 47–63Hz. Cordset specification in North America is IEC C13 to IEC C14 rated 250V/10A. Nexsan E60™/Nexsan E48™ Nexsan FRU Removal and Replacement Guide www.nexsan.com...
  • Page 24: Cooling

    Nexsan E48™/E48V™/E48VT™/E48P™ nominal input voltage is 110–240VAC, 47–63Hz. Cordset specification in North America is IEC C13 to IEC C14 rated 250V/10A. Typical power consumption for the E60 units is 1,164W (5.18A) for 600GB SAS drives and 806W (3.6A) for 3TB SATA drives. Peak current is up to 15A.
  • Page 25: Chapter 2: Adding Modules

    Chapter 2: Adding Modules The Nexsan E60™/Nexsan E48™ RAID storage unit is designed so that adding data disks can be performed while the unit is powered on and operating normally. Also, a second RAID Controller can be added to single- Controller systems, but this requires the unit to be powered down.
  • Page 26: Take Proper Esd Precautions

    Always ground any electrostatic charge from your person before touching components with your hands or with any tools. Always use an anti-static wrist strap (one ships with each unit) while installing or performing maintenance on any Nexsan RAID storage unit. ►...
  • Page 27: Adding A Second Raid Controller

    Controller module. This is necessary if you want to attach a Nexsan expansion unit to the Nexsan E60™/Nexsan E48™ storage unit or if you want to use any of the system modes that enable failover (see System Mode in the Nexsan RAID Storage User Guide for more information).
  • Page 28 9. In the graphical user interface (GUI), go to the Home page and verify that the status bar for the new RAID Controller is green. See Home Page in Chapter 3 of the Nexsan RAID Storage User Guide for more information.
  • Page 29: Adding Disk Drives

    The Spare Mode that the unit is set to determines whether or not newly-inserted disks are automatically assigned as pool spares. To check or set the spare mode, go to Configure RAID > Spare Mode in the graphical user interface (GUI). See the Nexsan RAID Storage User Guide for more information. ►...
  • Page 30 The STAT LED on the front of the drawer turns from amber to green to let you know that the drive drawer is properly latched. The DSK LED lights up green to let you know that all drives are functioning properly. Part Number: P0450139 Nexsan E60™/Nexsan E48™ Rev: A FRU Removal and Replacement Guide...
  • Page 31 See Home Page in Chapter 3 of the Nexsan RAID Storage User Guide for more information. Nexsan E60™/Nexsan E48™...
  • Page 32: Chapter 3: Replacing Modules

    Chapter 3: Replacing Modules The Nexsan E60™ and Nexsan E48™ are designed so that some of their components can be replaced without turning off the unit or interrupting its functioning. This chapter describes how to replace each of these modules in the field while the unit is running.
  • Page 33: Power Supply Units (Psus)

    The Home page of the graphical user interface (GUI) also tells you which unit has failed (see the Nexsan High-Density Storage User Guide). 2. Remove the power cable from the power cable socket on the PSU where the failure has occurred.
  • Page 34 7. In the graphical user interface (GUI), go to the Home page and verify that the status bar for the new Power Supply Unit is green. See the Nexsan High-Density Storage User Guide for more information. Nexsan E60™/Nexsan E48™...
  • Page 35: Raid Controllers

    1). A flashing red LED indicates the failed unit. The Home page of the graphical user interface (GUI) also tells you which unit has failed (see the Nexsan High-Density Storage User Guide). Note In some cases, a RAID Controller needs to be replaced even if it has not failed outright. In this case, you must determine which RAID Controller to replace by following the troubleshooting procedures in Chapter 4 of the Nexsan High-Density Storage User Guide.
  • Page 36 6. Make sure that the replacement RAID Controller is right side up. The host ports should be at the top. Note If you have a Nexsan expansion unit attached to your Nexsan storage unit, plug the SAS cables from the expansion unit into the expansion ports on the replacement RAID Controller BEFORE you insert the RAID Controller into its slot.
  • Page 37: Disk Drives

    To check or set the spare mode, go to Configure RAID > Spare Mode in the graphical user interface (GUI). See the Nexsan RAID Storage User Guide for more information. CAUTION: Computer components and disk drives are sensitive to electrostatic discharge (ESD).
  • Page 38 6. Carefully lift the drive’s ejection handle to disengage the drive, then remove the drive from the drive slot. Support the weight of the drive with your free hand while removing it. Figure 3-7: Removing a disk drive Nexsan E60™/Nexsan E48™ Nexsan FRU Removal and Replacement Guide...
  • Page 39 See Home Page in Chapter 3 of the Nexsan RAID Storage User Guide for more information. Part Number: P0450139 Nexsan E60™/Nexsan E48™...
  • Page 40: Front Drive Drawer Fans

    A red LED indicates which drawer has the failed fan. The Home page of the graphical user interface (GUI) also tells you which fan has failed (see Home Page in Chapter 3 of the Nexsan RAID Storage User Manual). 2. Unlock the drive drawer (see Figure 3-5).
  • Page 41 12. In the graphical user interface (GUI), go to the Home page and verify that the status bar for the new fan assembly is green. See Home Page in Chapter 3 of the Nexsan RAID Storage User Manual for more information.
  • Page 42: Rear Drive Drawer Fan Assembly

    Front panel on page 2). A red LED indicates which drawer has the failed fan. The Home page of the graphical user interface (GUI) also tells you which fan has failed (see the Nexsan RAID Storage User Manual). 2. Unlock the drive drawer (see Figure 2-4).
  • Page 43 8. In the graphical user interface (GUI), go to the Home page and verify that the status bar for the new fan assembly is green. See Home Page in Chapter 3 of the Nexsan RAID Storage User Manual for more information.
  • Page 44: Glossary

    Also called an ESD strap or a In Nexsan E60 and E48 storage units (and their grounding bracelet. V, VT and P variants), the assembly that houses Nexsan E60™/Nexsan E48™...
  • Page 45 E-Series The series of Nexsan units that includes the Fiber Channel Nexsan E18, E48, and E60 storage units (and A gigabit (Gb) speed network technology their V, VT and P variants), the Nexsan E32V, primarily used for storage networking and the...
  • Page 46 To insert a new piece of hardware into a computerized system while the system is Light Emitting Diode. LEDs are used for indicator running. See also hot-swap. lights on the front and back of Nexsan storage hot-swap units. To replace a failed or faulty component of a...
  • Page 47 Mb/s them as a single logical unit to attached devices. Megabits (Mb) per second. Used to describe the The RAID Controllers in Nexsan storage units speed of network data transmission. are hardware modules. Nexsan RAID Controllers also provide connections for system administration and configuration.
  • Page 48 The Fiber Channel ports or 10Gb iSCSI A telecommunication network that covers a ports on Nexsan storage devices are SFPs. broad area or that links across metropolitan, regional, or national boundaries. Wide area networks are used to connect local area Solid State Disk.
  • Page 49: Nexsan

    This product is protected by one or more of the following patents, and other pending patent applications worldwide: United States patents US8,191,841, ® Nexsan and the Nexsan logo are trademarks or registered trademarks of US8,120,922; United Kingdom patents GB2466535B, GB2467622B, Nexsan. GB2467404B, GB2296798B, GB2297636B...
