HYPER-UNIFIED STORAGE
Nexsan Unity
Hardware Reference Guide
Firmware Version Unity v. 5.1
NEXSAN
| 325 E. Hillcrest Drive, Suite #150 | Thousand Oaks, CA 91360 USA
Printed Wednesday, November 28, 2018 |
www.nexsan.com
