Page Contents - EHC SLIMJIM Installation & Technical Manual

This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge unless they have been given supervision
or instruction concerning the use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not operate or interfere with the appliance.
Please read and follow the installation operating instructions carefully, to ensure the long life and reliable
operation of this appliance.
The Electric Heating Company may make minor changes when necessary to the appliance that will not be
shown in this document, so long as the main features of the boiler remain the same.
All boilers come with a 24 month warranty that covers all defects originating from faulty materials and work-
manship in the manufacture of the boilers.
The warranty will not cover any damage to the boiler from poor or incorrect installation work. In addition the
Warranty will not cover any call out charges that have not been authorised by the Electric Heating Company Ltd.
The warranty will not cover any water leaks into the boiler that may cause damage to the electrical or elec-
tronic control system.
All plumbing connections must be checked and auto air vents positioned to the side of the boiler and not
directly above the unit.
A Magnetic Filter must be installed to the boilers return pipe work before the circulation pump. It is recom-
mended that the filter is cleaned; failure to clean the Magnetic Filter may result in boiler/system failure. War-
ranty calls will not be covered where the above requirements have not been met.
The "Slim Jim" boiler is a low temperature boiler intended for use in unvented or vented central
heating systems with forced circulation.
GB-063C_f.615
I NT RO D U C T ION
PR EPE R AT IO N
L O C AT IO N
G EN E R A L
BO I L E R IN TE R N A L L AY OU T
I NS TA LL AT IO N
SYS T EM PR O TE C T IO N - C O MM I S S I ON I N G
EL E CT R IC A L C ON N E C TI ON S
EL E CT R IC A L C ON N E C TI ON S
CO NT R O L W IR IN G
BO I L E R C ON T R O L PA N E L
T EC HN IC A L SP E C I F IC AT IO N
PA RT S L IST TA B L E
IN TRO DUCT I ON
