4 CPU card Resources

4. CPU card Resources

4.1. I/O MAP

Address (H)
0000 - 000F
0020 - 0021
002E - 002F
0040 - 0043
0048 - 004B
0060
0061
0064
0070 - 0071
0080 - 008F
00A0 - 00A1
00B2 - 00B3
00C0 - 00DE
00F0 - 00FF
01F0 - 01F7
0228 - 022F*
0278 - 027F*
02E8 - 02EF*
02F8 - 02FF*
0376 - 0377
0274 - 0277
0378 - 037F
03B0 - 03BB
03C0 - 03DF
SIS-8601-LVA
Size Description
16 bytes DMA Controller
2 bytes Interrupt Control (PIC)
Super I/O controller configuration
2 bytes
registers
4 bytes System timer 1
4 bytes System timer 2
1 byte Keyboard Controller
1 byte NMI, speaker control
1 byte Keyboard controller
2 bytes Real Time Clock Controller
16 bytes DMA page registers
2 bytes Interrupt controller 2
2 bytes APM control
31 bytes DMA controller 2
16 bytes Numeric processor
8 bytes Primary IDE controller
8 bytes LPT3
8 bytes LPT2
8 bytes COM4
8 bytes COM2
2 bytes Secondary IDE channel
I/O read data port for ISA PnP
4 bytes
enumerator
8 bytes LPT1
12 bytes Video (Monochrome)
32 bytes Video (VGA)
