5550 & 5550G MECHANICAL VIBRATION SWITCHES
Hazardous Area Installation Manual
Before proceeding to wire and install the
Model 5550 switch, read and thoroughly
understand these instructions. They are
intended for experienced personnel who
require only basic installation guidance,
and assume that the 5550 has already
been selected and applied properly for
the machinery at hand. Please contact
Metrix or its local representative for
additional assistance. See also the "Sup-
plamental Information" section of this
manual for additional technical resources
available free-of-change on our website
at www.metrixvibration.com
OVERVIEW
The Model 5550 Mechanical Vibration
Switch offers basic protection against gross
changes in structural seismic acceleration.
Its operating mechanism is purely mechani-
cal and consists of a tension spring attached
to a pivoting plate on an over-center
fulcrum – magnets are not employed.
Normally, this plate is in an untripped posi-
tion. However, in the presence of sufficient
seismic acceleration (whether vibratory or
impact), the trip plate will pivot beyond this
over-center position, snapping to a stable
tripped position where it contacts an inter-
nal microswitch relay, changing the state
DOC# M8905 • REV R (May 2016)
MODEL 5550
1180
MODEL 5550G
1180

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5550 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Metrix 5550

Summary of Contents for Metrix 5550

  • Page 1 They are intended for experienced personnel who require only basic installation guidance, and assume that the 5550 has already been selected and applied properly for the machinery at hand. Please contact Metrix or its local representative for additional assistance.

  • Page 2: Supplementary Information

    Observe the switch nameplate to ensure that it has the correct hazardous approval and environmental ratings for the intended area. Refer to Metrix datasheet 1004461 for a list of all available hazardous area approvals, environmental ratings, and other ordering options.
  • Page 3 CONDUIT When attaching conduit, observe the following: • Avoid long runs of unsupported conduit that can transfer unwanted impacts or vibra- tion of the conduit, rather than of the machine. • Orient conduit such that accumulated moisture or condensation does not drain into the switch and consider the use of J-traps or other drain mechanisms.

  • Page 4: Setpoint Adjustment

    REMOTE RESET AND STARTUP LOCKOUT All Model 5550 Mechanical Switches can be reset locally using the manual reset plunger. Additionally, those fitted with the optional electrical reset circuit can be remotely actuated.

  • Page 5: Important Safety Information

    NOTE: If the machine is restarted immediately after a shutdown, the lockout period will be shortened because the thermistor will be hot. An increase in the ambient temperature will also shorten the lockout period. IMPORTANT SAFETY INFORMATION General Safety Summary Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it.

  • Page 6: Hazardous Area Approvals

    USES COUPER L’ALIMENTATION (North ELECTRIQUE UL 508 America) CIRCUIT AVANT UL 698 Models 5550-2XX-XXX or D’OUVRIR COF- CSA C22.2 No. 14 5550-7XX-XXX: FRET GARDER LE CSA C22.2 No. 25 Class I, Div 1, Groups B,C,D, Class COUVERCLE BIEN CSA C22.2 No. 30...
  • Page 7 MODEL 5550G IECEx Approval IEC Markings: IEC Standards: CAUTION: TO REDUCE RISK (World): Ex d IIC T6 Gb IEC60079-0:2011 OF IGNITION OF HAZARDOUS Ex tb IIIC T85°C Db Ta IEC600079-1:2007 ATMOSPHERES, DISCONNECT THE -40°C to +70°C IP66 IEC600079-31:2008 SUPPLY CIRCUIT BEFORE OPENING. IECEx BAS10.0095X KEEP ASSEMBLY TIGHTLY CLOSED WHEN IN OPERATION.

  • Page 8: Environmental Information

    WEEE) should never be disposed of in the public waste stream. The “Crossed-Out Waste Bin” label affixed to this product is a reminder to dispose of this product in accordance with local WEEE regulations. If you have questions about the disposal pro- cess, please contact Metrix Customer Services. info@metrixvibration.com www.metrixvibration.com 8824 Fallbrook Dr.
