Summary of Contents for Starline GLV
- Page 1 Operator Manual...
-
Page 2: Table Of Contents
• tel (03) 9518 3888 • Fax (03) 9518 3818 • Web www.moffat.com.au Service 0800 782 754 m2 High performance passthrough Dishwasher - Operator Manual Parts 09 829 0930 Manufactured in New Zealand by Washtech Ltd. 414 Rosebank Road, Avondale, Auckland 1026. PO BOX 90548, Auckland 2 GLV - Operator Manual 160819... -
Page 3: Safety Instructions
All service/repair work must be carried out by qualified personnel only Power Cord Replacement • If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similar qualified person in order to avoid a hazard 3 GLV - Operator Manual 160819... - Page 4 Run several cycles, ensure that operator has read and understands instructions Troubleshooting Installation • If machine doesn’t fill after switching on power, check & ensure that hot water supply tap is open, water supply pressure is not below specification. 4 GLV - Operator Manual 160819...
-
Page 5: Installation Diagram
GLV Installation Diagram GLV-S INST 23-06-16 3 5 GLV - Operator Manual 160819... - Page 6 GLV Machine Operation START UP Turn machine on at wall. Fit filter, upstand and shut door. Turn on power at the wall and press Power button on machine. Power button light glows red and machine fills automatically Wash and Rinse temperatures will begin to rise on the temperature gauges once the machine has filled.
-
Page 7: Operating Procedures
Cycle times are short and water consumption per cycle low – so there is no advantage in overloading racks. CYCLE TIMES The GLV has 60 and 150 second cycles. CHEMICAL Correct type and quantity of detergent is essential for good results. Use good quality chemicals and regularly check containers. -
Page 8: Troubleshooting
Pre-rinse, change wash water regularly Not drying Poor wash/rinse performance Refer above Low temperatures Check heating systems Drying agent not used Use quality drying agent/rinse fluid Foaming Wash Excessive Rinse Fluid Adjust Rinse Fluid Injector 8 GLV - Operator Manual 160819... -
Page 9: Glv - Operator Manual
GLV7 SCHEMATIC DIAGRAM GLV7 Schematic Diagram 030172 05/04/16 1 A 9 GLV - Operator Manual 160819... - Page 10 Accessories Code Description 600 70080 Cuprack 450mm 600 70081 Dishrack 450mm C660503 G Cutlery Container 10 GLV - Operator Manual 160819...
- Page 11 11 GLV - Operator Manual 160819...
-
Page 12: Information Supplied In This Manual Is Copyright. No Part Of This Work May Be Reproduced Or Copied In Any Form Or
Manufactured in New Zealand by Washtech Ltd. 414 Rosebank Road Avondale Auckland 1026 New Zealand PO Box 90548, Auckland 24HR Service 0800 Starline 09 829 0930 09 829 0935 E-mail info@washtech.co.nz www.starline.co.nz ISO9001 All Washtech products are designed and...
