Cardio Zone Fast Track Owner's Manual page 11

5. MAINTENCE
1. If the Walking Belt tracks off center to the right
or left of the deck, first turn the power off. Then
use a 6mm wrench to tighten the rear roller bolt on
the side of the treadmill toward which the belt is
moving. For example, if the belt moves to the
left and the deck becomes exposed on the right,
tighten the bolt on the left side of the frame.
Tighten about 1/4 of turn (clockwise). If the belt
does not move back to the center of the treadmill,
make another adjustment to the same bolt. Once
the Walking Belt has been adjusted closer to the
center, the treadmill can be started again..
(Ps.1.This action is very important, please follow
the above steps.)
(Ps.2.The potion of running belt might not stay
precisely in the center with slightly moving
the left or right side, and the situation varies
with how end-users use and weight of
end-users. When end-user use properly, the
belt won't scotch side rails. )
2. It is recommended that the deck be lubricated
every 6~12 months according to the frequency of
usage. First, use wrench to loosen the bolts in the
end caps. Pull up the Walking Belt, dispense the
lubricant on the deck, and spread evenly. After
lubricating the deck, center the belt, and check the
belt tension. Adjust the belt as mentioned in
step3.
(Ps. If the belt happens to slip, follow the above
steps and lubricate the running deck.)
SUGGESTED PREVENTIVE MAINTENANCE SCHEDULE IN
ACCORDANCE WITH THE AVERAGE RUNNING SPEED
Measurement Speed
6KM/hr below
Metric
6~12KM/hr
12KM/hr above
4mile/hr below
English 4~8mile/hr
8mile/hr above
Note: This preventive maintenance schedule is
only meant for home use. It is suggested to
maintain the unit every month for
commercial use.
Interval
1 year
6 months
3 moths
1 year
6 months
3 moths
10
