Bluetooth QuickStart Kit Version 1.0 - User's Guide
•
Software platform code base is easily ported and extended to other hardware,
including other processor families.
•
Many sample applications included in order to lower the threshold to get you started.
•
Complete development environment is included (compiler, linker, make, editor, etc.)
−
−
•
The user can easily add own applications and experiment with the technology.
−
The hardware features of Embedded Artists' Bluetooth QuickStart Kit are:
•
Built around the new LPC2106 from Philips (ARM7TDMI).
−
−
•
cB-OEMSPA13i Bluetooth module from connectBlue included in kit.
−
−
•
Connector for MMC/SD memory card
•
ESD/EMI protected RS232 channel available for connection with other systems or
debug printouts.
−
•
32 kByte non-volatile parameter memory (256 Kbit I
•
Standard 20 pos. ARM JTAG connector available for debug.
•
Size: 108 x 58 mm
−
•
Power: 5VDC, <150mA

2.3 Typical Usage

The Bluetooth QuickStart Kit can be used to easily create advanced MMI (Man-Machine-
Interfaces) based on Internet technologies:
•
Use the web server to expose information and parameters that can be controlled.
•
Use the file system to store HTML files and picture files.
•
Use the serial channel to communicate (expose information or control parameters)
with ANY System.
•
Access the system directly via a PDA, a laptop, or a Bluetooth LAN access point.
Figure 2 below illustrates how the Bluetooth QuickStart Board can be connected to any
embedded system and expose internal variables in this system, or alternatively controls
Copyright 2004-2005 © Embedded Artists AB
Based on GCC.
Other compilers also supported, like Keil and IAR.
About 30 kbytes of FLASH available and about 10 kbyte of SRAM
128 Kbyte program Flash and 64 Kbyte SRAM
Processor pins available on an expansion connector for user hardware
expansion.
Also works with cB-OEMSPA13x (external antenna) and cB-OEMSPA33i/x
(100 meter version).
Works with connectBlue's Serial Port Adapter Wizard program
Support for automatic program download over the serial channel.
Four mounting holes are 100 x 50 mm apart
2 2
C E PROM)
