Bluetooth QuickStart Kit Version 1.0 - User's Guide
decisions must be made quickly. Trends can be discovered when analyzing the data, for
example that a bearing is about to break down but will hold for another two months.
Maintenance can in such cases be planned in advance to minimize the operation costs.
Figure 6 below illustrates a typical system with motor diagnostics.
Vibration too high.
Stopping motor!
Figure 6 – Remote Diagnostics Use-Case
The benefits of remote diagnostics are numerous:
•
Lower maintenance cost
•
Fewer unexpected system failures since maintenance can be planned in advance
•
The prerequisite for Service Level Agreements (SLAs)
•
The possibility for remote data logging

3.5 Local Service

Local service is a good example of how the web server functionality in the Bluetooth
QuickStart Board can be used. The system stores a number of relevant documents, such as:
•
Service Logs
•
Blueprints
•
Datasheets
•
User's Manuals
The system can of course also be configured via the web server user interface. Figure 7
below illustrates the local service use-case.
Figure 7 – Local Service Use-Case
Copyright 2004-2005 © Embedded Artists AB

Operator Stations

Bluetooth or direct access
Wireless
PDA
Blueprint
Service Log
[2003-12-24]
[2004-01-10] Service Log
[2004-02-25]
User's Manual
Page 12
