Bluetooth QuickStart Kit Version 1.0 - User's Guide
OEMSPA-13i datasheet for details
about functionality.
This push-button should normally
never be used, and it is only active
during power-up of the Bluetooth
module.
RGB LED #1
This RGB LED is controlled from
the Bluetooth module and indicates
current status.
RGB LED #2
This RGB LED is controlled by the
application program and can be used
for program debugging or showing
application status.
Table 1 – Board Interfaces

5.3 Bluetooth Modules

The Bluetooth connector (J9 in the schematic) supports four different versions in the OEM
Serial Port Adapter family from connectBlue, as listed in Table 2 below.
Name
OEMSPA13i
OEMSPA13x
OEMSPA33i
OEMSPA33x
Table 2 – OEM Serial Port Adapters
Copyright 2004-2005 © Embedded Artists AB
Green =
Orange =
Blue =
Flashing Blue = Data is transferred over the active
Red =
Size Bluetooth Data
23 x 36 mm Class 2 / 0 dBm with internal antenna
It is this Bluetooth module that the Bluetooth
QuickStart Kit is shipped with.
23 x 36 mm Class 2 / 0 dBm with external antenna
40 x 42 mm Class 1 / 20 dBm with internal antenna
40 x 42 mm Class 1 / 20 dBm with external antenna
Module is OK
Module is in AT-command mode
A connection is active
connection
Reset or illegal AT-commands
received
Page 24
