5.5 Board Measurements
The board is 108 x 58 mm and Figure 19 below illustrates the mounting hole positions. The
four mounting holes are 3.5 mm wide and 50 x 100 mm apart.
50 mm
100 mm
Figure 19 – Mounting Hole Positions
Copyright 2004-2005 © Embedded Artists AB
