Intelligent WiFi Access Control
Profile Series v.S2

Table of Contents

Overview and Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
S2 8200 Series Mortise Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
S2 10 Line Bored Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
S2 80 Series Exit Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Standard and Coastal Series Levers, Finishes & Handing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Studio Collection Levers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Ordering Gramercy Series Levers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Lock Management Tool. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Access Credentials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Accessories and Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Mechanical Options & Shipping Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cylinder Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15
Windstorm Certifications: UL Listed & Florida Building Codes . . . . . . . . . . . . . . . . . . . . . . . 16
Architectural Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Profile Series v.S2
Wireless Ethernet
Typical Application
On the Cover
v.S2 8200 Series Mortise Lock
with a MJ Studio Collection Lever
1-800-727-5477 • www.sargentlock.com
As part of their promise to provide innovative, fast and effective
high security solutions to their customers, certain ASSA ABLOY
Group brands offer ElectroLynx , a universal quick-connect
®
system that simplifies the electrification of the door opening.
ElectroLynx is a registered trademark of ASSA ABLOY Inc.
®
MicroShield
®
As part of their promise to provide innovative solutions to
their customers, certain ASSA ABLOY Group brands offer the
MicroShield technology, a silver-based antimicrobial coating
®
designed to inhibit the growth of bacteria.
MicroShield is a registered trademark of Yale Security Inc.,
®
an ASSA ABLOY Group company.
MicroShield Coating
®
• Revolutionary finish coating available on all SARGENT
product lines, utilizes a silver-based antimicrobial
compound from Agion Technologies
• As an integral part of the finish coating, MicroShield
the life of the hardware
• MicroShield coating permanently suppresses the growth
®
of bacteria, algae, fungus, mold and mildew. It is effective
against a broad spectrum of bacteria.
• Non-toxic and completely safe. The Agion antimicrobial
compound is EPA and NSF approved and FDA listed for use in
medical and food preparation equipment.
• Applications: Anywhere there is need for a clean
environment (hospitals, laboratories, schools, medical
centers, daycare, food processing etc.)
lasts for
®
