Access Credentials

Profile Series v.S2
Below are 125 kHz proximity credentials offered by SARGENT. Other credentials (125 kHz proximity and 13.56 MHz iCLASS, 26-39 bit formats) can be
purchased from HID.
Credential Features
• 26 & 33 bit Wiegand format available (consult factory for additional formats)
• HID Prox 125 kHz-based proximity cards, fobs or tags
®
• Allows integration into existing facilities with HID Prox 125kHz-based technology
• SARGENT standard credentials are 26 Bit Wiegand format, Site Code and Proximity ID assigned by SARGENT
• Custom credentials available with customer assigned Prox ID#'s
Product #
PCH-L70
SARGENT HID ProxCard II™
for SARGENT
• Site Code and Proximity ID#'s determined and controlled by SARGENT
logo on card
• 26 Bit Format, HID Coded Wiegand Output 125kHz
• Dimensions: 2-1/8" x 3-3/8" (54mm x 86mm)
PCH-B70
• Thickness: .070" nom. (1.8mm)
for blank
• Cards ordered individually*** (Min. Order is 25 Cards)
white card
ISO Prox Card II™ (Printable Card)
PCH-L30
• Site Code and Proximity ID#'s determined and Controlled by
for SARGENT
• 26 Bit Format, HID Coded Wiegand Output 125kHz
logo on card
• Dimensions: 2-1/8" x 3-3/8" (54mm x 86mm)
• Thickness: .031" nom. (1.8mm)
PCH-B30
• Blank Cards can be printed on by others
for blank
• Cards ordered individually*** (Min. Order is 25 Cards)
white card
Contact
DuoProx™ Card
Factory for
• Multiple Technology Proximity Cards - DuoProx™– dual technology -
specifications
proximity & magnetic stripe
options and
• DuoProx™ cards with unique site codes for higher level of security (SARGENT 1000) are available
pricing
• Cards ordered individually*** (Min order is 100 Cards)
The MicroProx™ Tag is a coin-sized (disk-shaped) transponder that provides the ability to add HID proximity
technology to a device. The MicroProx™ Tag has an adhesive backing which allows it to be secured to any
non-metallic object.
• Easily Secured To: Employee badges, PDAs, Magnetic stripe cards, Cell phones
• 26 Bit Format, HID Coded Wiegand Output 125kHz
• Proximity ID# marked on each Tag
- Site Code and Proximity ID#'s determined and controlled by SARGENT
- MicroProx™ Tag ordered individually***
MPT
- Min. order is 25 MicroProx™ Tag
- Site Code and Proximity ID#'s requested by customer
- MicroProx™ Tag ordered individually***
MPT-C
- MicroProx Tag with custom Site Code, consult factory for minimum quantities
PF SARGENT ProxKey II™
• Site Code and Proximity ID#'s determined and controlled by SARGENT
• 26 Bit Format, HID Coded Wiegand Output 125kHz
PF
• Dimensions: 1-29/32" x 29/32" x 11/32" (48mm x 23mm x 9mm)
• Includes Keyring
• SARGENT ProxKey II™ ordered individually*** (Min order is 25 ProxKey II™)
PF-C Custom ProxKey II™
• Site Code - requested by customer PF-C
• Proximity ID#'s requested by customer
PF-C
• 26 Bit Format, HID Coded Wiegand Output 125kHz
• Dimensions: 1-29/32" x 29/32" x 11/32" (48mm x 23mm x 9mm)
• Includes Keyring
• PF-C Custom ProxKey II™ ordered individually*** (Min order is 100 Custom ProxKey II™)
*** Products are ordered individually, Ordered Quantity is the number of individual items to be shipped. If a Qty of 25 is ordered -
25 individual items will be shipped
(Note: Min Order Requirements)
10
1-800-727-5477 • www.sargentlock.com
Features
• Gray color with HID Logo
• Dimensions: 1.285" Dia. x 0.070" (32.6mm x 1.78mm)
1000
NOTE: The
MicroProx™ Tag
should be attached to
magnetic stripe cards
so that contact with
the magnetic card
reader is avoided.
