T600HCN-1 Non-Programmable Thermostat
Applications
The T600HCN-1 is a single-stage non-programmable
thermostat that provides exceptional accuracy through
the use of a unique Proportional-Integral (PI) time
proportioning algorithm. The thermostat's proprietary
adaptive logic algorithm provides a constant space
temperature by controlling the Heating, Ventilating,
and Air Conditioning (HVAC) equipment to minimize
overshoot and maximize comfort. The algorithm
virtually eliminates temperature offset associated with
traditional, differential-based on/off thermostats.
Additionally, the menu-driven backlit display, plain text
menus, and five keys on the T600HCN-1 make
operating the thermostat easy and intuitive.
Installation
Location Considerations
Locate the T600HCN-1 thermostat as follows:
on a partitioning interior wall, and approximately
5 ft (1.5 m) above the floor in a location of average
temperature
away from direct sunlight, radiant heat, outside
walls, behind doors, air discharge grills, stairwells,
or outside doors
away from steam or water pipes, warm air stacks,
unheated/uncooled areas, or sources of electrical
interference
© 2003 Johnson Controls, Inc.
Part No. 24-9889-10, Rev. A
Installation Instructions
To install the thermostat:
1. Remove the security screw on the bottom of the
thermostat cover using a Phillips-head
screwdriver. Open the thermostat by pulling on the
bottom side of the thermostat cover (see Figure 1).
2. Unlock the Printed Circuit Board (PCB) by
carefully pressing the locking tabs to the right
(see Figure 2). Open the thermostat's PCB to the
left.
3. Pull out approximately 6 in. (152 mm) of wires
from the wall and insert the cable through the hole
in the base.
4. Align the base on the wall, and using the base as
a template, mark the location of the two mounting
holes on the wall. Confirm the thermostat base is
installed with the proper side up.
5. Use the supplied anchors and screws for mounting
on drywall or plaster. Drill two 3/16 in. (4.7 mm)
holes at the marked locations and tap nylon
anchors flush to wall surface (see Figure 3).
6. Position base on the wall, insert screws through
mounting base, and fasten into wall anchors. Do
not overtighten screws.
7. Swing the thermostat PCB back to the right to
close. Gently press on the PCB to secure each of
the locking tabs.
8. Pull out the screw terminal blocks using the pull
tabs on each connector (see Figure 4).
Note: The number of terminals on the terminal
blocks varies depending on the T600 model.
IMPORTANT:
Use this T600HCN-1
non-programmable thermostat only as an operating
control. Where failure or malfunction of the
T600HCN-1 could lead to personal injury or property
damage to the controlled equipment or other
property, additional precautions must be designed
into the system. Incorporate and maintain other
devices such as supervisory or alarm systems or
safety or limit controls intended to warn of, or protect
against, failure or malfunction of the T600HCN-1.
Issue Date December 9, 2003
www.johnsoncontrols.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the T600HCN-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Johnson Controls T600HCN-1

  • Page 1 Additionally, the menu-driven backlit display, plain text 3. Pull out approximately 6 in. (152 mm) of wires menus, and five keys on the T600HCN-1 make from the wall and insert the cable through the hole operating the thermostat easy and intuitive.
  • Page 2 Locking Tabs Note: When replacing an existing thermostat, remove and label wires to identify terminal designations. When replacing a T600HCN-1 thermostat, simply remove the terminal blocks and reinsert onto the new thermostat. To wire the thermostat: Figure 2: Opening the Thermostat PCB 1.
  • Page 3: Setup And Adjustments

    If using the same power source 24 VAC Sensor for the thermostat and heating Thermostat Power loads, install a jumper across RC and RH. Figure 5: T600HCN-1 Wiring Schematic Setup and Adjustments Thermostat Operation Overview Room Temp Backlit, plain text, Liquid 75.0ºF Crystal Display (LCD)
  • Page 4 Thermostat Interface Keys Programming Overview The T600HCN-1 interface consists of five keys on There are three menus used to view, program, and the front cover and one configuration key configure the T600HCN-1 thermostat. (see Figure 7) that is accessed by removing the The Status Display Menu is the menu that displays front cover.
  • Page 5 See Setting the Anti-Short Cycle Timer See Setting the Cooling Lockout (Anticycl). (C lock). Sets the Maximum Heating Cycles per Hour Heat cph Default: Four (4.0) set? Y/N See Setting the Maximum Heating Cycles per Hour (Heat cph). T600HCN-1 Non-Programmable Thermostat Installation Instructions...
  • Page 6 Menu. Setting the Power-up Delay (Pwr del) To configure the digital inputs while in the Installer On initial power up of the T600HCN-1 (or each time Configuration Menu: power is removed and reapplied), there is a delay 1. The first prompt is to configure the digital inputs.
  • Page 7 Setting the Maximum Heating Setpoint (Heat max) CAUTION: Risk of Property Damage. The maximum heating setpoint establishes the Do not set the T600HCN-1 anti-short cycling timer to maximum temperature in the heating setpoint range 0 minutes if the controlled equipment is not that can be adjusted from the Main User Menu.
  • Page 8 Press YES to store the selection. setpoints. The range is adjustable from 2 to 4 F° The display now shows the occupancy override (1 to 2 C°). prompt. See the Establishing the Temporary Occupancy Time (ToccTime) section for instructions. T600HCN-1 Non-Programmable Thermostat Installation Instructions...
  • Page 9 (digital input YES to enter the outdoor sensor calibration menu. configuration). 2. Use the UP/DOWN arrow keys to adjust the correction that should be applied to the sensor reading. Press YES to store the offset. T600HCN-1 Non-Programmable Thermostat Installation Instructions...
  • Page 10: Operation

    Sets the Temperature Setpoints set? Y/N See Entering Temperature Setpoints. Note: (If the T600HCN-1 is not in one of these modes, this prompt does not appear). Answering yes to this prompt enables the T600HCN-1 to resume the regular scheduled program and setpoints.
  • Page 11 Entering Temperature Setpoints Setpoint Type When the T600HCN-1 is in the occupied state, the first Permanent Setpoints are permanently stored in the prompt appearing in the Main User Menu is to set the schedule. This is the default setpoint type.
  • Page 12 Permanent Occupied Hold (occ hold) • Off Mode (off) This selection puts the thermostat into a The T600HCN-1 is off. However, when frost permanent occupied mode using the occupied protection is on (see the Enabling Frost Protection setpoints. Occupied hold appears in the Status [Frost pr] section) the thermostat still calls for heat, Display Menu when this selection is active.
  • Page 13: Technical Specifications

    The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
