- Page 1 A Wilson Electronics Brand WILSON PRO 1000R In-Building Signal Booster With Extended Dynamic Range User Manual wilsonpro.com 866.294.1660 NEED HELP?
-
Page 2: Table Of Contents
_____ Index Package Content About The WilsonPro 1000R Key Features Competitive Advantages Post Install Setup Status Screen Band Status Screens Safety Guidelines Warranty... -
Page 3: Package Content
Content Kit 460231 WilsonPro Wide Band Directional 4 Qty. Dome 1000R Antenna + 75’ Antenna + 4 Qty. 100’ Wilson 400 Cable Wilson 400 Cable Pair of 2-Way 2’ Wilson Lightning Surge Radios Protector WILSON PRO 1000R IN-BUILDING SIGNAL BOOSTER... - Page 4 Color LCD For Easier Access Unlike other boosters, the WilsonPro 1000R has a color LCD screen with four-way navigation, allowing integrators to have easy and effective control of the product. WILSON PRO 1000R...
- Page 5 Unlike other boosters, the WilsonPro 1000R has a color LCD screen with four-way navigation, allowing integrators to have easy and effective control of the product. The 1000R is intended to fit into an existing server rack. This design allows for a neat and clean installation while leaving the unit easily accessible.
-
Page 6: Key Features
Extended Dynamic Range (XDR) for continuous connectivity: Gives the 1000R much greater tolerance than any competing booster for a strong incoming signal from the tower. XDR lets the 1000R system work with an incoming signal stronger than any competing booster and never shuts down. -
Page 7: Competitive Advantages
Lower Overload and Shutdown Threshold: No matter how strong the outside signal, the WilsonPro 1000R never shuts down. This is a huge benefit in strong signal environments like cities and locations close to a carrier tower. - Page 8 Outside Antenna and the Signal Booster. Outside Directional Antenna Inside Dome Antenna(s) 1000R The direction of the 2-way radios are included outside antenna should to help with the installation be adjusted until the process. “DL” bar is maximized. WILSON PRO 1000R IN-BUILDING SIGNAL BOOSTER...
-
Page 9: Post Install Setup
Post Install Setup The WilsonPRO 1000R is designed with advanced internal programming, which allows it to automatically adjust for a variety of conditions, while still boosting weak signals. Once the AC power cable and antenna cables are connected, turn the unit on by toggling the power switch located near the AC power receptacle, located at the rear of the unit. -
Page 10: Status Screen
____________ Status Screen The 1000R takes about 20 seconds to boot up. Once boot up is complete, the status screen will appear, showing the amplification and status of each port and band. System Status Screen Splash Screen Lights Description A solid green light indicates that a band is operating correctly with maximum allowable gain. - Page 11 Reposition antennas (more separation between indoor and outdoor antennas, and pointed in opposite directions) and then reboot (power cycle) the 1000R to reactivate the band and maximize performance. When adequate separation is achieved, the red light(s) will return to green upon reboot.
-
Page 12: Band Status Screens
D-Pad with Enter button Status Screen Close-up This screen provides specific band and port information. Including the strength of the received uplink and downlink signal, status details, and the amplifier gain. Band Details Screen WILSON PRO 1000R IN-BUILDING SIGNAL BOOSTER... - Page 13 ___________ (BAND STATUS SCREENS - GREEN LIGHT cont.) In the presence of a strong outdoor cell tower signal, the 1000R will reduce it’s “boost” (Gain) using internal Automatic Gain Control (AGC). This gain reduction is necessary to stay within FCC requirements. When this occurs, the 1000R has reached the ‘speed limit’...
-
Page 14: Safety Guidelines
Changes or modifications not expressly approved by weBoost could void the authority to operate this equipment. FOR MORE INFORMATION ON REGISTERING YOUR SIGNAL BOOSTER WITH YOUR WIRELESS PROVIDER, PLEASE SEE BELOW: Sprint: http://www.sprint.com/legal/fcc_boosters.html T-Mobile/MetroPCS: https://support.t-mobile.com/docs/DOC-9827 Verizon Wireless: http://www.verizonwireless.com/wcms/consumer/register-signal-booster.html AT&T: https://securec45.securewebsession.com/attsignalbooster.com/ U.S. Cellular: http://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp WILSON PRO 1000R IN-BUILDING SIGNAL BOOSTER... - Page 15 _________________ Antenna Kit Options The following accessories are certified by the FCC to be used with the Wilson PRO 1000R. Inside Antenna Expansion Kit Kit 311141-0620 50 Ohm Outside Antenna Kits 75 Ohm Grey Brick Antenna Kit 309900-50N40090 20’ RG6 Cable...
-
Page 16: Specifications
This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device. WILSON PRO 1000R IN-BUILDING SIGNAL BOOSTER... - Page 17 ____________ Notes WILSON PRO 1000R IN-BUILDING SIGNAL BOOSTER...
- Page 18 ____________ Notes WILSON PRO 1000R IN-BUILDING SIGNAL BOOSTER...
-
Page 19: Warranty
However, no responsibility is assumed by WilsonPro for any business or personal losses arising from its use, or for any infringements of patents or other rights of third parties that may result from its use. support.wilsonpro.com 866.294.1660 NEED HELP? WILSON PRO 1000R IN-BUILDING SIGNAL BOOSTER... - Page 20 A Wilson Electronics Brand 3301 East Deseret Drive, St. George, UT www.wilsonpro.com | support.wilsonpro.com Copyright © 2016 Wilson Electronics. All rights reserved. Wilson Electronics products covered by U.S. patent(s) and pending application(s) For patents go to: weboost.com/us/patents NOT AFFILIATED WITH WILSON ANTENNA GDE000006_Rev01_01.19.17...
