Remote LED Screen Indicators

Transmission Indicator
Lights up when remote sends a
signal to the unit
MODE display
Displays the current
mode, including:
• AUTO
• COO
• DRY
• heat
• FAN
FAN SPEED display
Displays selected FAN SPEED:
»»»»»»» HIGH,»»»»»»» MED,
or »»» LOW
This display is blank when set
to AUTO speed.
NOTE: MED is optional.
ON/OFF display
Appears when the unit is turned
on, and disappears when it is
turned off
TIMER ON display
Displays when TIMER
ON is set
SILENT display
Not available for this unit
Temperature/Timer display
Displays the set temperature by default, or timer setting
when using TIMER ON/OFF functions
• Temperature range: 17-30oC(62°F-86°F)
• Timer setting range: 0-24 hours
This display is blank when operating in FAN mode.
TIMER OFF display
Displays when TIMER
OFF is set
6
ECO display
Not available for
this unit
Battery display
Low battery
detection
SLEEP display
Displays when
SLEEP function is
activated
FOLLOW ME
display
Indicates that the
FOLLOW ME
function is on
Not available for
this unit
