User Manual
V 1.0
ProDrone Byrd
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Byrd and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ProDrone Byrd

  • Page 1 User Manual V 1.0 ProDrone Byrd...

  • Page 2: Tutorial Video

    Instructions Warnings Thank you for using the product of ProDrone. This is a special electronic product. Faulty operation might damage articles, injure human body and even cause deaths. The caused legal consequences should be shouldered on your own. Juveniles younger than 18 years old are not suggested to use this aircraft.

  • Page 3: App Download

    To enjoy perfect after-sale services, please complete your register by visiting www.prodrone-tech.com.Registering or not will not affect product’s normal use, but we still invite you to be our VIP. Unscheduled official activities and more privileges have been prepared for you, stay tuned! ※...
  • Page 4 Aircraft ※ Only Advanced and Premium versions have the capacity of ‘Visual and acoustic positioning’. ※ Only Premium version is equipped with the ‘Dropping Box’.

  • Page 5: Flight Mode

    RTH Mode ProDrone Byrd has the function of returning to home automatically. If the home point is recorded successfully before the flight and when the remote controller and the aircraft loss connection, the aircraft would return to the home point automatically and land on the ground. The following three conditions would cause the returning: returning to home instantly, returning to home in low battery and returning to base when the aircraft is out of touch.
  • Page 6 Home point refers to the point at which the aircraft has been unlocked for the first time successfully, when it is in Mode P and the GPS signal is good. Home point is only effective for the flight at this time. 2.
  • Page 7 And APP will alarm the warning tone to suggest you to return to home as soon as possible.  RTH in Severe Low Battery When the electric quantity is less than 20%, the battery is serious low and the aircraft will return to home mandatorily.

  • Page 8: Vision Positioning System

    Indicators of Aircraft Status The flight status of the ProDrone Byrd could be judged from the two groups of LED indicator lights at the head and the end of the aircraft. Their places are shown in the following picture. The two groups of LED indicator lights show the current status of the flight control system through different groups of colors and flickers.

  • Page 9: Stowage Dropping

    This system is only open to ProDrone Byrd Advanced/Premium version. Stowage Dropping ProDrone Byrd could be loaded with loads less than 500g (not including the gimbal and the camera) to eject objects from a long distance. Before the ejection, the buttons C1 and C2 should be customized to choose the ‘steering gear control’...
  • Page 10 ※ This system is only open to ProDrone Byrd Premium version.

  • Page 11: Remote Controller

    The highly integrated wireless high-definition video transmission system within the controller is connected to the ProDrone APP by WIFI. In this way, you can watch the real time video in your personal mobile equipment (mobile phone or table computer). All parameters of the aircraft would also be fully showed in the screen of your mobile equipment.

  • Page 12: Hd Video Downlink System

    50 frames of 1080P video (P mode). This image transmission of high definition module in ProDrone Byrd Standard adopts common WIFI system and the transmitting distance is 500 meters. This image transmission of high definition module in ProDrone Byrd Advanced/Premium adopts OFDM system and the transmitting distance is 2000 meters.

  • Page 13: Gimbal Control

    Gimbal Control The control dial wheels for the gimbal yaw and pitch could control the yaw and pitch. The Back-to-center button of the gimbal could let the gimbal return to the initialization place. ※ The type of the gimbal in the above picture is only for indication. Different types of gimbals are used for different aircrafts with different configurations.
  • Page 14 Gimbal There are a total of three types of gimbals for ProDrone Byrd series products, and completely new integrated control algorithm is applied to them, making the high definition three-axle stabilization gimbal. The jittering of the angel is ±0.05°. Therefore, when the big maneuvering flight is made, stabilized pictures and videos could also be shot.

  • Page 15: Byrd-001 Gimbal

    The standard configuration of ProDrone Byrd Advanced is Byrd-001 multi-function gimbal (without the camera). You can buy the gimbal according to your own needs. What’s more, Byrd-001 Gimbal can realize the controllable two-axle of pitch and yaw, providing you broader shooting angels.

  • Page 16: Byrd-003 Gimbal

    1080P high definition videos and 16 mega-pixel photos. Besides, the camera and the gimbal are connected together and could not be dismounted. What’s more, Byrd-002 Gimbal can realize the controllable two-axle of pitch and yaw, providing you broader shooting angels.
  • Page 17 WiFi Connection and Camera Use Afterpoweringon,thegimbalandthecamerawillworkautomatically.Thereal-timeimage willbesenttotheremotecontroller. Start up the WLAN of the mobile device. And search and connect the WiFi pot of the remote controller. See the information on the label at the back of the remote controller for the pot name and its passwords.
  • Page 18 ProFlight App FCS Firmware Version Update The ProDrone authority will continuously promote the update of the firmware in the flight control system. You need to download and install the ‘Update tool of the firmware in the flight control system’ on your own to update the firmware. The steps of using the software are as follows: 1.
  • Page 19 ProFlight App ProFlight APP is the interactive software which is specially designed for ProDrone Byrd series products. With this software, you could control the aircraft, the gimbal, the camera and the steering engine to take pictures, record videos, eject objects, and set parameters of the aircraft. To coordinate with the image transmission of high definition, it is suggested to be used on tablet devices or mobile phones with large screens to gain the best visual experience.
  • Page 20  Flight Status Bar ：Show quantities of searched satellites; ：Show strength of WIFI signal of the remote controller; ：Show the status of the connection between APP and the remote controller; ：Show the remained electricity quantity of the aircraft; ：Show the remained electricity quantity of the remote controller; ：Show the current flight height;...
  • Page 21 Click the icon and it will delete all the flight points. [3] Flight Planning After clicking the icon, its background will turn to red , which means the function of planning the flight track has been activated. At this time, you can click anywhere on the map to form the flight dot.
  • Page 22  System Setting Click the icon and it will enter the interface of the system setting, which includes three pages of the control setting, the camera setting and the general setting. In ‘Control setting ’ page, three operation modes could be chosen: Japanese customization, American customization, and Chinese customization.
  • Page 23 ※ The language in the APP interface is the same with that in the system of the mobile device. If you want to change the language, please first change that in the system.

  • Page 24: Aircraft Preparation

    1. Propellers Installation and Dismounting Foldable propeller is used in ProDrone Byrd. The two types of Propeller A and Propeller B are corresponding to the different rotation directions of the motor. Letters A and B are signed respectively on the root of the propeller, in the internal surface of the propeller cap, and the motor rotor.
  • Page 25 of the propeller cap. Even if the cap falls off in flight, this mechanism could effectively prevent the paddle from being ejected out. The card slot in the performing coordinates with that in the motor spindle. Only when the performing is rotated to certain angel, it could be taken down from the spindle.
  • Page 26 4. Dropping Box Installation and Dismounting There is a plug at the top of the container. Insert it to the steering gear hole at the bottom of the end of the aircraft and the installation is finished. In dismounting, the powers of the aircraft and the remote controller should be turned on. And then the ejection would be carried out (See Pxx for more details) and the container would break away from the aircraft.

  • Page 27: Remote Controller Preparation

    Please disconnect the charger timely. ※ Make sure to use the original charger to charge the battery and the remote controller. ProDrone will shoulder no responsibilities if faults and damages are caused by not using the original accessories.
  • Page 28 ※ Make sure to use the original charger to charge the battery and the remote controller. ProDrone will shoulder no responsibilities if faults and damages are caused by not using the original accessories.
  • Page 29 Unfold the joint lever of the support of the mobile device to the limited position and insert it downward to the installation hole. And adjust the seat to put the device in a secure and fixed place. Start up the WLAN of the mobile device. And search and connect the WiFi pot of the remote controller.
  • Page 30 Flight Safety Alarms 1. Environment  Do not fly in sever whether such as rain, thunder, high wind, snow, heavy fog, deep cold, the sand and dust weather.  Do not fly between the high buildings. In this condition, the signal would be shielded, so the GPS is unable to locate the aircraft.

  • Page 31: Accelerator Calibration

     Visit www.prodrone-tech.com to download and install the ‘Byrd Parameter adjustment software of the aircraft’ on the PC end.  Connect the parameter adjustment port of the aircraft with the PC, the parameter adjustment software would identify the hardware of aircraft automatically.
  • Page 32  Hold the aircraft upside down and rotate it clock-wisely and HORIZONTALLY. Observe the color of the LED indicator light in the aircraft and go to the next step when the yellow LED indicator light at the head of the aircraft keep on and the green light at the tail flashes. Otherwise, please return to the step 2.
  • Page 33 Take Off You could choose to press the ‘Take off’ button (See Take off button for more details) or to start up the flight by hand. After calibrating the compass, move the control stick in the toe-in directions. After the motor is started, loosen two sticks at the same time to unlock the motor. At this time, push the throttle rod upward slowly and the aircraft will take off.
  • Page 34 Questions 1. What is the control distance of the remote controller? How the aircraft, the mobile phone and the remote controller are connected? The control distance of the remote controller is 2000 meters (this distance would also be influenced by the environment). The mobile phone and the remote controller are connected by WIFI and the aircraft and the remote controller communicate with each other by radio waves.
  • Page 35 8. How to download ProFlight APP? You can visit www.prodrone-tech.com or scan the two-dimension code in the instruction profile to download ProFlight APP. 9. Whether it could take off in windows of high buildings or in comparatively narrow spaces? (Whether it only could take off in flat ground?) Yes, it could.
  • Page 36 20. What is the material of the gimbal? And what is the control range of the pitch? This aircraft is equipped with a three-axle high definition gimbal developed by ProDrone. It is made of light aluminum alloy. The three types of gimbals are two-axle controllable. Their controllable pitch range is -125°- 30°...
  • Page 37 23. What are the meanings of the red full lines and blue dotted lines in the map in the APP of the mobile phone? The red full lines show the flight track while the blue dotted line show the flight lines made by the planning function of flight track.

  • Page 38: Specifications

    Specifications ProDrone Byrd Standard  Aircraft Weight 1890 g Rated Load 200 g Max. Load 500 g Wind Resistance 3 Grade Max. Ascent Speed 6 m/s Max. Speed 15m/s Hover Precision（P Mode） ±0.8 m（Vertical） ±1.0 m（Horizontal） Max. Flight Altitude 4000 m...
  • Page 39 Frame Rate 1080P：25/30/50/60fps 960P: 25/30/48/50/60fps 720P: 25/30/50/60/100/120fps Field Angle (Opposite Angles) 1080P：120° 960P: 140° 720P: 120° Focal Length 3.64 mm Photo Mode 16/14/12M（4：3）Pixel Supported SD Card Types Support 32GB Micro-SD Operation Temperature -10℃ to 50℃  Remote Controller Image trasmission frequency 2412MHz-2462MHz Digital transmission frequency 5745MHz~5810MHz...
  • Page 40 Voltage 14.8V Energy 99.16 Wh Weight 560 g Operating Temperature 0℃ to 40℃...
  • Page 41 ProDrone Byrd Advanced  Aircraft Weight 1866 g Rated Load 200 g Max. Load 500 g Wind Resistance 3 Grade Max. Ascent Speed 6 m/s Max. Speed 15m/s Hover Precision（P Mode） ±0.2 m（Vertical） ±0.2 m（Horizontal） Max. Flight Altitude 4000 m...
  • Page 42 Capacity 6700 mAh Voltage 14.8 V Energy 99.16 Wh Weight 560 g Operating Temperature 0℃ to 40℃ ProDrone Byrd Premium  Aircraft Weight 1930 g Rated Load 200 g Max. Load 500 g Wind Resistance 3 Grade Max. Ascent Speed 6 m/s Max.
  • Page 43 ±0.2 m（Horizontal） Max. Flight Altitude 4000 m Endurance 29 min Operating Temperature -10℃ to 50℃  Gimbal Controllable Angle Range Pitching：-90° to 0° Yawing：-45° to 45°  Vision Positioning System Velocity Range < 8 m/s Altitude Range 20 cm – 600 cm Positioning Accuracy ±3.0 cm（Horizontal）...
  • Page 44 1440P：25/50 fps 1080P：25/30/50/60/120 fps Field Angle 104°（Opposite） 82°（Horizontal） Distortion <27% Output Mode 2GB flash + 8GB DDR Supported SD Card Types Support Maximum 64GB Operation Temperature -10℃ to 50℃  Remote Controller Image trasmission frequency 2412MHz-2462MHz Digital transmission frequency 5745MHz~5810MHz Max.
  • Page 45 Energy 99.16 Wh Weight 560 g Operating Temperature 0℃ to 40℃...

  • Page 46: Fcc Compliance

    FCC Compliance FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.
  • Page 47 ---Increase the separation between the equipment and receiver. ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experience radio/TV technician for help.
