Summary of Contents for National Flooring Equipment DL1000
- Page 1 DL1000 DUST COLLECTOR SERVICE MANUAL Read this manual carefully before servicing machine 403081 Rev C...
- Page 2 This manual should be considered an integral part of the dust collector and must be kept together with the unit until this is scrapped. In case of loss of or damage to the manual, ask National Flooring Equipment (NFE) for a new copy.
-
Page 3: Table Of Contents
Contents Information section Identification of main parts Accessories provided Technical details Warranty Safety section Safety details Safety warnings Safety plates and symbols Outstanding risks Maintenance section Informative notes General safety warnings Maintenance operations Replacing the filters Cleaning the filters Troubleshooting Recommended spare parts... -
Page 4: Identification Of Main Parts
Information Identification of main parts ON/OFF switch Push handle Release fastener Collected material container Fixed wheels Casters Inlet Filter chamber - 1 -... -
Page 5: Accessories Provided
Information Accessories provided 402492 – Filter, Primary (ONLY SPARE PART) - 2 -... -
Page 6: Technical Details
Information 1.10 Technical details Power 1.3 (1 Kw) Volts Voltage Frequency Filter efficiency .0000394 (1 µm) cat M Weight 63.9 (29 kg) in H Max. lift capacity 88.6” (2,250 mm H Max. air flow rate 103 (175 m dB (A) Noise level Filter type Polyester... -
Page 7: Warranty
1.11 Warranty National Flooring Equipment Inc. (referred to as “the Company”) warrants that each new unit manufactured by The Company, to be free from defects in material and workmanship in normal use and service for a period of twelve (12) months from date of shipment from the Company. For administrative ease, will honor warranty for a period of fifteen (15) months from date of shipment from the company. -
Page 8: Safety Details
Safety Safety details The person in charge of safety shall be responsible for informing workers about the risks associated with dust collector operation. The obligation also exists of training workers so they are able to protect themselves and others. Failure to observe basic safety regulations and warnings could cause accidents during dust collector operation, maintenance and repair. -
Page 9: Safety Warnings
Safety Safety warnings Attention! The following indications are, by themselves, not enough to fully protect against all the hazards that could arise during dust collector operation. These will have to be integrated with common sense and the experience of the operator, both of which are crucial factors for preventing accidents. Each section of this manual lists further specific safety warnings for the various operations. - Page 10 Safety Only skilled persons should carry out repairs. During use, mind the power supply cables and avoid crushing or pulling these. Periodically check the mains power cable to ensure this is not damaged. In the event of the cable being damaged, the machine must not be used. In the event of the cable, plugs, or couplings being replaced, make sure these are protected against water spray and check mechanical strength.
- Page 11 Safety Do not open the dust collector container with the machine running. The manual should always be kept handy for reference so the operating cycle can be checked any time there are doubts. In the event of this manual being lost or damaged, ask NFE for a new copy. Structural damage and improper alterations or repairs could change the protection capacity of the dust collector and therefore void the warranty.
-
Page 12: Safety Plates And Symbols
Safety Safety plates and symbols Plates are affixed to the dust collector showing safety symbols and/or messages. Attention! Make sure all the safety messages are legible. Clean these with a cloth, soap and water. Do not use solvents, diesel fuel or petrol. Replace the damaged plates with new ones supplied by NFE. -
Page 13: Outstanding Risks
Safety Outstanding risks Careful analysis of risks performed by the manufacturer and stored in the technical file has made it possible to eliminate most of the risks associated with dust collector operation. The manufacturer advises carefully following the instructions, procedures and advice contained in this manual as well as applicable safety regulations, including the use of the envisaged protection devices, both those integrated in the dust collector and individual. -
Page 14: Informative Notes
Maintenance Informative notes This section describes the control and special maintenance operations crucial for keeping the dust collector in perfect working condition. All other maintenance and major repairs must be expressly authorized by the manufacturer. In such cases, always contact NFE or an authorized dealer. General safety warnings Maintenance jobs must always be performed by skilled technicians, trained to carry out their specific jobs. -
Page 15: Maintenance Operations
Maintenance Maintenance operations Attention! All the described operations must be done with the plug disconnected from the power socket. Before starting any maintenance or cleaning job, always wear adequate protective clothing, eyewear and/or gloves according to the type of job to be done. For smooth dust collector operation, the following periodic maintenance is necessary: Check to see whether the filter is worn or has become too permeable. -
Page 16: Replacing The Filters
Maintenance Replacing the filters To replace the filters, proceed as follows: Turn off the dust collector by pressing the motor STOP buttons. Disconnect the dust collector plug from the power socket. Important! Wear individual protection devices. Release the retainers that hold the motor head. Lift the motor head and rest this on a flat surface ... -
Page 17: Cleaning The Filters
Maintenance Fit the new filter and put everything back in place, locking the cap. Warning! All the material trapped by the filter and the filter itself must be disposed of through authorized channels where the dust collector is used. Cleaning the filters ... -
Page 18: Troubleshooting
Maintenance Troubleshooting Recommended remedy Fault found Possible cause No power Check the power mains supply Check the integrity of the plug and power cable The dust collector fails to start Thermal magnetic switch Reset the thermal magnetic tripped switch Perforated collecting pipe Replace the pipe Perforated filter Replace the filter... -
Page 19: Recommended Spare Parts
Maintenance Recommended spare parts Code Description 402492 Filter, Primary 402493 Gasket, Container, 1.2m 402488 Gasket, Filter Chamber, 1.2m 402471 Filter, HEPA 402484 Switch, On/Off 402495 Filter, Pleated Teflon 402496 Motor Head, 120V 402504 Cord, Adaptor, 120V, 15 amp, 33’ 402520 Reducer, Hose, 50mm to 38mm 402521 Hose, Antistatic, 38mm, 7.5m... - Page 20 Safety 9250 Xylon Avenue N • Minneapolis, MN 55445 • U.S.A. Toll-free 800-245-0267 • Phone 763-315-5300 • Fax 800-648-7124 • Fax 763-535-8255 Web Site: www.nationalequipment.com • E-Mail: info@nationalequipment.com...
