Creating Profiles – Method 2
An alternative way to create new Profiles is to use the Save As button in the Soft key Setup area which makes up the
bottom half of the DAW tab.
1. First select the Profile you want to use as a starting point and assign it to a layer, as described on the previous pages.
2. Click the Save As button in the Soft key Setup area at the bottom of the window to bring up the Save Profile As pop-
up.
3. Type a name for the new Profile into the pop-up and click on Ok.
After a moment, the new Profile will be created and become active in that layer.
Selecting a Profile
Profiles are selected and managed using the Profile Setup area in the top left corner of the DAW tab. The four default
Profiles are listed in the drop-down Selected Profile menu, along with any derivatives of them which you have created.
If the Profile you select uses a different protocol than that currently assigned to the layer selected in the Remote, or if the
layer previously contained no Profile, a pop-up will appear asking you to restart Nucleus
Press Ok to close the pop-up. A number of functions within the DAW tab will now be locked out until the restart. However,
further Profile selections can be made before restarting. To perform a restart simply re-power Nucleus
switch on the rear of the unit.
Note that, depending on the complexity of your setup, you may also need to re-find Nucleus
restart, as described on Page 21.
MCU User Display Configuration
In order to cater for variations in the ways in which MCU protocol DAWs return channel data to the scribble strip displays,
there is a Flip Scribble Strips box in the Profile Setup area. Actioning this function switches the two rows of the Nucleus
scribble strip display, allowing Nuendo labelling to emulate the Logic format for example. By default, Flip Scribble Strips
is therefore enabled for the default Nuendo Profile and disabled for the default Logic Profile. For other MCU protocol DAWs,
the labelling format described in the DAW's Control Surface documentation will enable you to ascertain whether or not to
activate this function.
MCU User Handshake Disabling
The Disable Handshake box located below the edit Profiles button is also only required for MCU protocol DAWs. This
function will only be of use in systems where there are multiple MCU layers in use, and where these layers include both
Logic and other MCU protocol DAWs. Checking this box will stop MCU programs from handshaking with each other via
2
Nucleus , thus preventing Logic from scanning for external controllers and subsequently creating ghost controllers of any
other MCU programs.
2
Nucleus must be power cycled before a Disable Handshake status change will take effect.
Page 28
2
– with a 'Now' or 'Later' option.
2
using the power
2
in the Remote after the
2
