DAWs With Proprietary Soundcards
Some DAWs can only receive audio via their own proprietary soundcard hardware. Many of these soundcards provide
digital (S/PDIF) connections, allowing you to take full advantage of the SSL quality pre-amps and converters. The two
2
Nucleus input channels are sent using the left and right channels of the S/PDIF Out, and the S/PDIF In feeds the monitor
inputs.
If your S/PDIF connections are coaxial (usually using phono sockets), simple coaxial to optical S/PDIF converters will
be required to connect the soundcard digitally to the Nucleus
2
Using Nucleus 's Digital IO
DAW
Computer
Ethernet
(DAW control
and Remote)
Page 6
Optical to
coax adaptor
USB S/PDIF
(DAW keyboard (digital
commands) audio)
2
PRe (pre-amp) outputs.
Monitoring
Headphones
Recording
Sources
MP3
Player
Mains
Power
2
