  • Page 1 All manuals and user guides at all-guides.com G3-MS80 (MS80) 8-STACK MULTI STATION STRENGTH SERVICE MANUAL...

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com TABLE OF CONTENTS CHAPTER 1: SERIAL NUMBER LOCATION ………………………..…….3 CHAPTER 2: ASSEMBLY INSTRUCTIONS 2.1 G3-MS80 8-Stack Multi Station (MS80) Assembly Instructions......4 CHAPTER 3: TROUBLESHOOTING 3.1Troubleshooting - Cable issues……………………………….………………………12 CHAPTER 4: PART REPLACEMENT INSTRUCTIONS 4.1 Hand Grip Foam Replacement................13...

  • Page 3: Chapter 1: Serial Number Location

    All manuals and user guides at all-guides.com CHAPTER 1: SERIAL NUMBER LOCATION 1.1 SERIAL NUMBER LOCATION The serial number is located at the bottom of the weight stack frame.

  • Page 4: Chapter 2: Assembly Instructions

    CAUTION The weight of the G3-MS80 8-Stack Multi Station is 1980 lbs. (898.1 kg) not including the weight stack. To avoid injury to yourself and prevent damage to the frame components, be sure to have proper assistance removing the frame pieces from this box.
  • Page 5 All manuals and user guides at all-guides.com The standard of the screw torque Nom Diameter Torque (lbs/in) 1197 1901 2968 4079 2.1 G3-MS80 8-STACK MULTI STATION ASSEMBLY INSTRUCTIONS - CONTINUED...
  • Page 6 All manuals and user guides at all-guides.com 2.1 G3-MS80 8-STACK MULTI STATION ASSEMBLY INSTRUCTIONS - CONTINUED...
  • Page 7 All manuals and user guides at all-guides.com 2.1 G3-MS80 8-STACK MULTI STATION ASSEMBLY INSTRUCTIONS - CONTINUED...
  • Page 8 All manuals and user guides at all-guides.com 2.1 G3-MS80 8-STACK MULTI STATION ASSEMBLY INSTRUCTIONS - CONTINUED...
  • Page 9 All manuals and user guides at all-guides.com 2.1 G3-MS80 8-STACK MULTI STATION ASSEMBLY INSTRUCTIONS - CONTINUED...
  • Page 10 All manuals and user guides at all-guides.com 2.1 G3-MS80 8-STACK MULTI STATION ASSEMBLY INSTRUCTIONS - CONTINUED...
  • Page 11 All manuals and user guides at all-guides.com 2.1 G3-MS80 8-STACK MULTI STATION ASSEMBLY INSTRUCTIONS - CONTINUED...

  • Page 12: Chapter 3: Troubleshooting

    All manuals and user guides at all-guides.com CHAPTER 3: TROUBLESHOOTING 3.1 TROUBLESHOOTING – CABLE ISSUES CABLE IS LOOSE POSSIBLE CAUSES 1. The fix bolts are loosed. SOLUTION 1. Undo the top weight plate fixing nut, then the cable screw should be adjust fronted.(Figure A & 2.

  • Page 13: Chapter 4: Part Replacement Instructions

    All manuals and user guides at all-guides.com CHAPTER 4: PART REPLACEMENT INSTRUCTIONS 4.1 HAND GRIP FOAM REPLACEMENT 1) To loose the screws of end cap of handlebar (Figure A). 2) To take off the end cap and cut off the original foam (Figure B). 3) Using tape to seal up the handlebar tube to avoid the oil or suds into the tube (Figure C).

  • Page 14: Pulley Set Adjustment Handle Replacement

    All manuals and user guides at all-guides.com 4.2 THE STOPPER SLEEVE OF POSITION TUBE REPLACEMENT 1) Take off the lower fix bolt of stopper and loose higher one (Figure A). 2) Take off the stopper from position tube (Figure B) 3) Take off the sleeve from the stopper 4) Push the sleeve into the stopper.
  • Page 15 All manuals and user guides at all-guides.com 4.3 THE SLEEVE OF PULLEY SET REPLACEMENT 1) Remove the cable fixing screw (Figures A) 2) Refer section 4.2 to remove the stopper then remove the pulley set from position tube (Fig. B) 3) Disconnect the two old tube bushings from the pulley set (Figures C &...

  • Page 16: Pulley Set Sleeve Replacement

    All manuals and user guides at all-guides.com 4) Push the pulley set and sleeve into the adjustable tube (Figures G & H). 5) The cable fixing screw and the sleeve fixing screw should be locked (Figures I & J). Figure G Figure H Figure I Figure J...

  • Page 17: Round Pad Replacement

    All manuals and user guides at all-guides.com 4.4 ROUND PAD REPLACEMENT 1) Pull the old round pad from the tube (Figure A). 2) Push the new round pad into the tube (Figure B). Figure A Figure B 4.5 SEAT PAD REPLACEMENT 1) Using 6MM L-Shaped Allen Wrench to take off 3 bolts of the old seat pad (Figure A) 2) Replace new pad and fix the 3 bolts (Figure B).

  • Page 18: Back Pad Replacement

    All manuals and user guides at all-guides.com 4.6 BACK PAD REPLACEMENT 1) Using 8MM L-Shaped Allen Wrench to take off 4 bolts of the old back pad (Figure A) 2) Replace new pad and fix the 4 bolts (Figure B). Figure A Figure B 4.7 ROUND PAD ADJUSTMENT PIN REPLACEMENT...
