Dorel DASE3618DP Owner's Manual

Storage drawers

Advertisement

Quick Links

STORAGE
OWNER'S
DRAWERS
MANUAL
Model No.:
DASE3618DP-
PINE
DASE3618DW- WALNUT
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION PLEASE READ AND
KEEP FOR FUTURE REFERENCE
RECEIPT OF PURCHASE:
DATE OF PURCHASE:
ATTACH HERE
UPC CODE:
(PINE) 0-65857-15561-7
(WALNUT) 0-65857-15560-0
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our
customer service department. We will replace
the part FREE of charge.
Tel #: 1-800-295-1980
E-Mail: das@dorel.com
Fax #: 514-353-7819

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DASE3618DP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dorel DASE3618DP

  • Page 1 STORAGE OWNER'S DRAWERS MANUAL Model No.: DASE3618DP- PINE DASE3618DW- WALNUT NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION PLEASE READ AND KEEP FOR FUTURE REFERENCE RECEIPT OF PURCHASE: DATE OF PURCHASE: ATTACH HERE UPC CODE: (PINE) 0-65857-15561-7 (WALNUT) 0-65857-15560-0 DO NOT RETURN PRODUCT TO THE STORE.
  • Page 2: Care And Cleaning

    Check bolts/screws periodically and tighten them if necessary. DOREL ASIA LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase.
  • Page 3: Hardware List

    STORAGE DRAWERS DASE3618DP PINE / DASE3618DW WALNUT HARDWARE LIST WHEEL HANDLE CASTER WHEEL - 8 PCS KNOB - 4 PCS 8 PCS 4 PCS 8mm x 30mm WOOD DOWEL ROUND HEAD SCREW 12 PCS 4 PCS 4mm x 25mm 3mm x 12mm...
  • Page 4: Parts List

    STORAGE DRAWERS DASE3618DP PINE / DASE3618DW WALNUT PARTS LIST DRAWER FRONT PANEL DRAWER LEFT SIDE PANEL FRONT PANEL - 2 PCS LEFT SIDE PANEL - 2 PCS 2 PCS 2 PCS DRAWER RIGHT SIDE PANEL DRAWER BACK PANEL RIGHT SIDE PANEL - 2 PCS...
  • Page 5 STORAGE DRAWERS DASE3618DP PINE / DASE3618DW WALNUT STEP 1 Insert wood dowels (3) into the ends of left side panel (B) and right side panel (C). Attach left side panel (B) and right side panel (C) to front panel (A) with flat head wood screws (5) as shown.
  • Page 6 STORAGE DRAWERS DASE3618DP PINE / DASE3618DW WALNUT STEP 2 Slide bottom panel (E) into the grooves of left side panel (B), right side panel (C) and front panel (A). Push the drawer bottom panel (E) to secure it into place.
  • Page 7 STORAGE DRAWERS DASE3618DP PINE / DASE3618DW WALNUT STEP 3 Attach bottom support slat (F) to front panel (A) and back panel (D) with flat head wood screws (5) as shown. Attach caster wheels (1) to bottom panel (E) with flat head wood screws (6) as shown.
  • Page 8 STORAGE DRAWERS DASE3618DP PINE / DASE3618DW WALNUT STEP 4 Attach knobs (2) to drawer front panel (A) with round head screws (4). Use a Phillips head screwdriver (not included) to tighten round head screws (4) Repeat the previous steps to assemble the remaining another drawer.
  • Page 9 STORAGE DRAWERS DASE3618DP PINE / DASE3618DW WALNUT CAUTION "This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury ."...
  • Page 10: Customer Service

    MODEL #: DASE3618DP PINE / DASE3618DW WALNUT Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com...
